WebGL cubeMap 贴图 texture

纳铭
861 阅读3分钟

learnopengl-cn.github.io/04%20Advanc…

cubeMap示意图

image.png image.png

cubeMap API调用

  • 我们还要改变一下深度函数，将它从默认的GL_LESS改为GL_LEQUAL。深度缓冲将会填充上天空盒的1.0值，所以我们需要保证天空盒在值小于或等于深度缓冲而不是小于时通过深度测试。
int width, height, nrChannels;
unsigned char *data;
for(unsigned int i = 0; i < textures_faces.size(); i++)
{
    data = stbi_load(textures_faces[i].c_str(), &width, &height, &nrChannels, 0);
    glTexImage2D(
        GL_TEXTURE_CUBE_MAP_POSITIVE_X + i,
        0, GL_RGB, width, height, 0, GL_RGB, GL_UNSIGNED_BYTE, data
    );
}

glTexParameteri(GL_TEXTURE_CUBE_MAP, GL_TEXTURE_MAG_FILTER, GL_LINEAR);
glTexParameteri(GL_TEXTURE_CUBE_MAP, GL_TEXTURE_MIN_FILTER, GL_LINEAR);
glTexParameteri(GL_TEXTURE_CUBE_MAP, GL_TEXTURE_WRAP_S, GL_CLAMP_TO_EDGE);
glTexParameteri(GL_TEXTURE_CUBE_MAP, GL_TEXTURE_WRAP_T, GL_CLAMP_TO_EDGE);
glTexParameteri(GL_TEXTURE_CUBE_MAP, GL_TEXTURE_WRAP_R, GL_CLAMP_TO_EDGE);
  • webgl版
  faceInfos.forEach((faceInfo) => {
    const {target, faceColor, textColor, text} = faceInfo;
    generateFace(ctx, faceColor, textColor, text);

    // Upload the canvas to the cubemap face.
    const level = 0;
    const internalFormat = gl.RGBA;
    const format = gl.RGBA;
    const type = gl.UNSIGNED_BYTE;
    gl.texImage2D(target, level, internalFormat, format, type, ctx.canvas);
  });
  gl.generateMipmap(gl.TEXTURE_CUBE_MAP);
  gl.texParameteri(gl.TEXTURE_CUBE_MAP, gl.TEXTURE_MIN_FILTER, gl.LINEAR_MIPMAP_LINEAR);

cubeMap的shader

  • 最终的标准化设备坐标将永远会有一个等于1.0的z值：最大的深度值。
void main()
{
    TexCoords = aPos;
    vec4 pos = projection * view * vec4(aPos, 1.0);
    gl_Position = pos.xyww;
}

#version 330 core
out vec4 FragColor;

in vec3 TexCoords;

uniform samplerCube skybox;

void main()
{
    FragColor = texture(skybox, TexCoords);
}

cubeMap与反射


#version 330 core
layout (location = 0) in vec3 aPos;
layout (location = 1) in vec3 aNormal;

out vec3 Normal;
out vec3 Position;

uniform mat4 model;
uniform mat4 view;
uniform mat4 projection;

void main()
{
    Normal = mat3(transpose(inverse(model))) * aNormal;
    Position = vec3(model * vec4(aPos, 1.0)); //世界空间
    gl_Position = projection * view * model * vec4(aPos, 1.0);
}

#version 330 core
out vec4 FragColor;

in vec3 Normal;
in vec3 Position;

uniform vec3 cameraPos;
uniform samplerCube skybox;

void main()
{
    vec3 I = normalize(Position - cameraPos); //世界空间
    vec3 R = reflect(I, normalize(Normal));
    FragColor = vec4(texture(skybox, R).rgb, 1.0); //计算反射即可
}

cubeMap与折射


材质折射率
空气1.00
水1.33
冰1.309
玻璃1.52
钻石2.42
#version 330 core
layout (location = 0) in vec3 aPos;
layout (location = 1) in vec3 aNormal;

out vec3 Normal;
out vec3 Position;

uniform mat4 model;
uniform mat4 view;
uniform mat4 projection;

void main()
{
    Normal = mat3(transpose(inverse(model))) * aNormal;
    Position = vec3(model * vec4(aPos, 1.0)); //世界空间
    gl_Position = projection * view * model * vec4(aPos, 1.0);
}

void main()
{
    float ratio = 1.00 / 1.52;
    vec3 I = normalize(Position - cameraPos);
    vec3 R = refract(I, normalize(Normal), ratio);
    FragColor = vec4(texture(skybox, R).rgb, 1.0);
}

动态环境贴图

  • 通过使用帧缓冲，我们能够为物体的6个不同角度创建出场景的纹理，并在每个渲染迭代中将它们储存到一个立方体贴图中。之后我们就可以使用这个（动态生成的）立方体贴图来创建出更真实的，包含其它物体的，反射和折射表面了。这就叫做动态环境映射(Dynamic Environment Mapping)，因为我们动态创建了物体周围的立方体贴图，并将其用作环境贴图。 WebGL Dynamic Cubemap (webglsamples.org)

分析CubeMap

  • bufferData
// Fill the buffer with the values that define a cube.
function setGeometry(gl) {
  var positions = new Float32Array(
    [
    -0.5, -0.5,  -0.5,
    -0.5,  0.5,  -0.5,
     0.5, -0.5,  -0.5,
    -0.5,  0.5,  -0.5,
     0.5,  0.5,  -0.5,
     0.5, -0.5,  -0.5,

    -0.5, -0.5,   0.5,
     0.5, -0.5,   0.5,
    -0.5,  0.5,   0.5,
    -0.5,  0.5,   0.5,
     0.5, -0.5,   0.5,
     0.5,  0.5,   0.5,

    -0.5,   0.5, -0.5,
    -0.5,   0.5,  0.5,
     0.5,   0.5, -0.5,
    -0.5,   0.5,  0.5,
     0.5,   0.5,  0.5,
     0.5,   0.5, -0.5,

    -0.5,  -0.5, -0.5,
     0.5,  -0.5, -0.5,
    -0.5,  -0.5,  0.5,
    -0.5,  -0.5,  0.5,
     0.5,  -0.5, -0.5,
     0.5,  -0.5,  0.5,

    -0.5,  -0.5, -0.5,
    -0.5,  -0.5,  0.5,
    -0.5,   0.5, -0.5,
    -0.5,  -0.5,  0.5,
    -0.5,   0.5,  0.5,
    -0.5,   0.5, -0.5,

     0.5,  -0.5, -0.5,
     0.5,   0.5, -0.5,
     0.5,  -0.5,  0.5,
     0.5,  -0.5,  0.5,
     0.5,   0.5, -0.5,
     0.5,   0.5,  0.5,

    ]);
  gl.bufferData(gl.ARRAY_BUFFER, positions, gl.STATIC_DRAW);
}

"use strict";

function main() {
  // Get A WebGL context
  /** @type {HTMLCanvasElement} */
  var canvas = document.querySelector("#canvas");
  var gl = canvas.getContext("webgl");
  if (!gl) {
    return;
  }

  //program location
  var program = webglUtils.createProgramFromScripts(gl, ["vertex-shader-3d", "fragment-shader-3d"]);
  var positionLocation = gl.getAttribLocation(program, "a_position");
  var matrixLocation = gl.getUniformLocation(program, "u_matrix");
  var textureLocation = gl.getUniformLocation(program, "u_texture");

  //createbuffer bindbuffer bufferdata
  var positionBuffer = gl.createBuffer();
  gl.bindBuffer(gl.ARRAY_BUFFER, positionBuffer);
  setGeometry(gl);

  //createtexture bindtexture texImage2D texParameteri generateMipmap
  var texture = gl.createTexture();
  gl.bindTexture(gl.TEXTURE_CUBE_MAP, texture);
  const ctx = document.createElement("canvas").getContext("2d");
  ctx.canvas.width = 128;
  ctx.canvas.height = 128;
  const faceInfos = [
    { target: gl.TEXTURE_CUBE_MAP_POSITIVE_X, faceColor: '#F00', textColor: '#0FF', text: '+X' },
    { target: gl.TEXTURE_CUBE_MAP_NEGATIVE_X, faceColor: '#FF0', textColor: '#00F', text: '-X' },
    { target: gl.TEXTURE_CUBE_MAP_POSITIVE_Y, faceColor: '#0F0', textColor: '#F0F', text: '+Y' },
    { target: gl.TEXTURE_CUBE_MAP_NEGATIVE_Y, faceColor: '#0FF', textColor: '#F00', text: '-Y' },
    { target: gl.TEXTURE_CUBE_MAP_POSITIVE_Z, faceColor: '#00F', textColor: '#FF0', text: '+Z' },
    { target: gl.TEXTURE_CUBE_MAP_NEGATIVE_Z, faceColor: '#F0F', textColor: '#0F0', text: '-Z' },
  ];
  faceInfos.forEach((faceInfo) => {
    const {target, faceColor, textColor, text} = faceInfo;
    generateFace(ctx, faceColor, textColor, text);
    const level = 0;
    const internalFormat = gl.RGBA;
    const format = gl.RGBA;
    const type = gl.UNSIGNED_BYTE;
    gl.texImage2D(target, level, internalFormat, format, type, ctx.canvas); //target
  });
  gl.generateMipmap(gl.TEXTURE_CUBE_MAP);
  gl.texParameteri(gl.TEXTURE_CUBE_MAP, gl.TEXTURE_MIN_FILTER, gl.LINEAR_MIPMAP_LINEAR);


  function radToDeg(r) {
    return r * 180 / Math.PI;
  }
  function degToRad(d) {
    return d * Math.PI / 180;
  }
  var fieldOfViewRadians = degToRad(60);
  var modelXRotationRadians = degToRad(0);
  var modelYRotationRadians = degToRad(0);
  var then = 0;

  requestAnimationFrame(drawScene);

  function drawScene(time) {
    time *= 0.001;
    var deltaTime = time - then;
    then = time;

    webglUtils.resizeCanvasToDisplaySize(gl.canvas);

    gl.viewport(0, 0, gl.canvas.width, gl.canvas.height);
    gl.enable(gl.CULL_FACE);
    gl.enable(gl.DEPTH_TEST);

    modelYRotationRadians += -0.7 * deltaTime;
    modelXRotationRadians += -0.4 * deltaTime;

    gl.clear(gl.COLOR_BUFFER_BIT | gl.DEPTH_BUFFER_BIT);

    gl.useProgram(program);

    gl.enableVertexAttribArray(positionLocation);
    gl.bindBuffer(gl.ARRAY_BUFFER, positionBuffer);

    var size = 3;          // 3 components per iteration
    var type = gl.FLOAT;   // the data is 32bit floats
    var normalize = false; // don't normalize the data
    var stride = 0;        // 0 = move forward size * sizeof(type) each iteration to get the next position
    var offset = 0;        // start at the beginning of the buffer
    gl.vertexAttribPointer(
        positionLocation, size, type, normalize, stride, offset);

    var aspect = gl.canvas.clientWidth / gl.canvas.clientHeight;
    var projectionMatrix =
        m4.perspective(fieldOfViewRadians, aspect, 1, 2000);

    var cameraPosition = [0, 0, 2];
    var up = [0, 1, 0];
    var target = [0, 0, 0];

    var cameraMatrix = m4.lookAt(cameraPosition, target, up);
    var viewMatrix = m4.inverse(cameraMatrix);
    var viewProjectionMatrix = m4.multiply(projectionMatrix, viewMatrix);

    var matrix = m4.xRotate(viewProjectionMatrix, modelXRotationRadians);
    matrix = m4.yRotate(matrix, modelYRotationRadians);

    gl.uniformMatrix4fv(matrixLocation, false, matrix);
    gl.uniform1i(textureLocation, 0);
    gl.drawArrays(gl.TRIANGLES, 0, 6 * 6);
    requestAnimationFrame(drawScene);
  }
}

function generateFace(ctx, faceColor, textColor, text) {
  const {width, height} = ctx.canvas;
  ctx.fillStyle = faceColor;
  ctx.fillRect(0, 0, width, height);
  ctx.font = `${width * 0.7}px sans-serif`;
  ctx.textAlign = 'center';
  ctx.textBaseline = 'middle';
  ctx.fillStyle = textColor;
  ctx.fillText(text, width / 2, height / 2);
}


main();
