OpenGL_JS-lighting_maps_specular

纳铭
135 阅读2分钟


image.png image.png

  • lamp顶点着色器
export let vs_lamp = `#version 300 es
layout (location = 0) in vec3 aPos;
uniform mat4 model;
uniform mat4 view;
uniform mat4 projection;
void main()
{
    gl_Position = projection * view * model * vec4(aPos, 1.0);
}`
  • lamp片元着色器
export let fs_lamp = `#version 300 es
precision mediump float;
out vec4 FragColor;
void main()
{
    FragColor = vec4(1.0); // set alle 4 vector values to 1.0
}`
  • material顶点着色器 (lighting 模型)
export let vs_lighting_maps = `#version 300 es
layout (location = 0) in vec3 aPos;
layout (location = 1) in vec3 aNormal;
layout (location = 2) in vec2 aTexCoords;

out vec3 FragPos;
out vec3 Normal;
out vec2 TexCoords;

uniform mat4 model;
uniform mat4 view;
uniform mat4 projection;

void main()
{
    FragPos = vec3(model * vec4(aPos, 1.0));
    Normal = mat3(transpose(inverse(model))) * aNormal;
    TexCoords = aTexCoords;

    gl_Position = projection * view * vec4(FragPos, 1.0);
}`
  • material片元着色器 (lighting 模型)
export let fs_lighting_maps = `#version 300 es
precision mediump float;
out vec4 FragColor;

struct Material {
    sampler2D diffuse;
    sampler2D specular;
    float shininess;
};

struct Light {
    vec3 position;

    vec3 ambient;
    vec3 diffuse;
    vec3 specular;
};

in vec3 FragPos;
in vec3 Normal;
in vec2 TexCoords;

uniform vec3 viewPos;
uniform Material material;
uniform Light light;

void main()
{
    // ambient
    vec3 ambient = light.ambient * texture(material.diffuse, TexCoords).rgb;

    // diffuse
    vec3 norm = normalize(Normal);
    vec3 lightDir = normalize(light.position - FragPos);
    float diff = max(dot(norm, lightDir), 0.0);
    vec3 diffuse = light.diffuse * diff * texture(material.diffuse, TexCoords).rgb;

    // specular
    vec3 viewDir = normalize(viewPos - FragPos);
    vec3 reflectDir = reflect(-lightDir, norm);
    float spec = pow(max(dot(viewDir, reflectDir), 0.0), material.shininess);
    vec3 specular = light.specular * spec * texture(material.specular, TexCoords).rgb;

    vec3 result = ambient + diffuse + specular;
    FragColor = vec4(result, 1.0);
} `
  • 两个模型 lamp 与 lighting
    lightingShader = new Shader(gl, vs_materials, fs_materials);
    lampShader = new Shader(gl, vs_lamp, fs_lamp);
  • createVertexArray bindVertexArray
  • createBuffer bindBuffer bufferData vertexAttribPointer enableVertexAttribArray
    gl.enable(gl.DEPTH_TEST);
    let vertices = new Float32Array([
        -0.5, -0.5, -0.5, 0.0, 0.0, -1.0,
        0.5, -0.5, -0.5, 0.0, 0.0, -1.0,
        0.5, 0.5, -0.5, 0.0, 0.0, -1.0,
        0.5, 0.5, -0.5, 0.0, 0.0, -1.0,
        -0.5, 0.5, -0.5, 0.0, 0.0, -1.0,
        -0.5, -0.5, -0.5, 0.0, 0.0, -1.0,
        -0.5, -0.5, 0.5, 0.0, 0.0, 1.0,
        0.5, -0.5, 0.5, 0.0, 0.0, 1.0,
        0.5, 0.5, 0.5, 0.0, 0.0, 1.0,
        0.5, 0.5, 0.5, 0.0, 0.0, 1.0,
        -0.5, 0.5, 0.5, 0.0, 0.0, 1.0,
        -0.5, -0.5, 0.5, 0.0, 0.0, 1.0,
        -0.5, 0.5, 0.5, -1.0, 0.0, 0.0,
        -0.5, 0.5, -0.5, -1.0, 0.0, 0.0,
        -0.5, -0.5, -0.5, -1.0, 0.0, 0.0,
        -0.5, -0.5, -0.5, -1.0, 0.0, 0.0,
        -0.5, -0.5, 0.5, -1.0, 0.0, 0.0,
        -0.5, 0.5, 0.5, -1.0, 0.0, 0.0,
        0.5, 0.5, 0.5, 1.0, 0.0, 0.0,
        0.5, 0.5, -0.5, 1.0, 0.0, 0.0,
        0.5, -0.5, -0.5, 1.0, 0.0, 0.0,
        0.5, -0.5, -0.5, 1.0, 0.0, 0.0,
        0.5, -0.5, 0.5, 1.0, 0.0, 0.0,
        0.5, 0.5, 0.5, 1.0, 0.0, 0.0,
        -0.5, -0.5, -0.5, 0.0, -1.0, 0.0,
        0.5, -0.5, -0.5, 0.0, -1.0, 0.0,
        0.5, -0.5, 0.5, 0.0, -1.0, 0.0,
        0.5, -0.5, 0.5, 0.0, -1.0, 0.0,
        -0.5, -0.5, 0.5, 0.0, -1.0, 0.0,
        -0.5, -0.5, -0.5, 0.0, -1.0, 0.0,
        -0.5, 0.5, -0.5, 0.0, 1.0, 0.0,
        0.5, 0.5, -0.5, 0.0, 1.0, 0.0,
        0.5, 0.5, 0.5, 0.0, 1.0, 0.0,
        0.5, 0.5, 0.5, 0.0, 1.0, 0.0,
        -0.5, 0.5, 0.5, 0.0, 1.0, 0.0,
        -0.5, 0.5, -0.5, 0.0, 1.0, 0.0
    ]);
    cubeVAO = gl.createVertexArray();
    let VBO = gl.createBuffer();
    gl.bindBuffer(gl.ARRAY_BUFFER, VBO);
    gl.bufferData(gl.ARRAY_BUFFER, vertices, gl.STATIC_DRAW);
    gl.bindVertexArray(cubeVAO);
    gl.vertexAttribPointer(0, 3, gl.FLOAT, false, 8 * sizeFloat, 0);
    gl.enableVertexAttribArray(0);
    gl.vertexAttribPointer(1, 3, gl.FLOAT, false, 8 * sizeFloat, (3 * sizeFloat));
    gl.enableVertexAttribArray(1);
    gl.vertexAttribPointer(2, 2, gl.FLOAT, false, 8 * sizeFloat, (6 * sizeFloat));
    gl.enableVertexAttribArray(2);
    lightVAO = gl.createVertexArray();
    gl.bindVertexArray(lightVAO);
    gl.bindBuffer(gl.ARRAY_BUFFER, VBO);
    gl.vertexAttribPointer(0, 3, gl.FLOAT, false, 8 * sizeFloat, 0);
    gl.enableVertexAttribArray(0);
    diffuseMap = gl.createTexture();
    loadTexture("../../textures/container2.png", diffuseMap);
    specularMap = gl.createTexture();
    loadTexture("../../textures/container2_specular.png", specularMap);
    lightingShader.use(gl);
    lightingShader.setInt(gl, "material.diffuse", 0);
    lightingShader.setInt(gl, "material.specular", 1);
    requestAnimationFrame(render);
    function loadTexture(url, texture) {
        initTexture(gl, texture);
        const image1 = new Image();
        image1.onload = function () {
            gl.bindTexture(gl.TEXTURE_2D, texture);
            gl.texImage2D(gl.TEXTURE_2D, 0, gl.RGB, gl.RGB, gl.UNSIGNED_BYTE, image1);
            gl.texParameteri(gl.TEXTURE_2D, gl.TEXTURE_WRAP_S, gl.REPEAT);
            gl.texParameteri(gl.TEXTURE_2D, gl.TEXTURE_WRAP_T, gl.REPEAT);
            gl.texParameteri(gl.TEXTURE_2D, gl.TEXTURE_MIN_FILTER, gl.LINEAR);
            gl.texParameteri(gl.TEXTURE_2D, gl.TEXTURE_MAG_FILTER, gl.LINEAR);
            gl.generateMipmap(gl.TEXTURE_2D);
        };
        image1.src = url;
    }
    function initTexture(gl, texture) {
        gl.bindTexture(gl.TEXTURE_2D, texture);
        const width = 1;
        const height = 1;
        const pixel = new Uint8Array([0, 0, 255]);
        gl.texImage2D(gl.TEXTURE_2D, 0, gl.RGB, width, height, 0, gl.RGB, gl.UNSIGNED_BYTE, pixel);
    }
  • drawCall lighting
    let currentFrame = performance.now() / 1000;
    deltaTime = (currentFrame - lastFrame) * 1000;
    lastFrame = currentFrame;
    processInput();
    gl.clearColor(0.1, 0.1, 0.1, 1.0);
    gl.clear(gl.COLOR_BUFFER_BIT | gl.DEPTH_BUFFER_BIT);
    //--------------------------------------
    let lightPos = vec3.fromValues(0.5, 0.7, 2.0);
    camera = new Camera(vec3.fromValues(0.0, 0.0, 3.0), vec3.fromValues(0.0, 1.0, 0.0));
    lightingShader.use(gl);
    setVec3vShader(lightingShader, "light.position", lightPos);
    setVec3vShader(lightingShader, "viewPos", camera.Position);
    lightingShader.setFloat3(gl, "light.ambient", 0.2, 0.2, 0.2);
    lightingShader.setFloat3(gl, "light.diffuse", 0.5, 0.5, 0.5);
    lightingShader.setFloat3(gl, "light.specular", 1.0, 1.0, 1.0);
    lightingShader.setFloat(gl, "material.shininess", 64.0);
    let projection = mat4.create();
    mat4.perspective(projection, (camera.Zoom) * Math.PI / 180, canvas.width / canvas.height, 0.1, 100.0);
    let view = camera.GetViewMatrix();
    setMat4vShader(lightingShader, "projection", projection);
    setMat4vShader(lightingShader, "view", view);
    let model = mat4.create();
    setMat4vShader(lightingShader, "model", model);
    gl.activeTexture(gl.TEXTURE0);
    gl.bindTexture(gl.TEXTURE_2D, diffuseMap);
    gl.activeTexture(gl.TEXTURE1);
    gl.bindTexture(gl.TEXTURE_2D, specularMap);
    gl.bindVertexArray(cubeVAO);
    gl.drawArrays(gl.TRIANGLES, 0, 36);
  • drawCall lampShader
    lampShader.use(gl);
    setMat4vShader(lampShader, "projection", projection);
    setMat4vShader(lampShader, "view", view);
    mat4.identity(model);
    mat4.translate(model, model, lightPos);
    mat4.scale(model, model, vec3.fromValues(0.2, 0.2, 0.2));
    setMat4vShader(lampShader, "model", model);
    gl.bindVertexArray(lightVAO);
    gl.drawArrays(gl.TRIANGLES, 0, 36);

function setVec3vShader(shader, uniformName, value) {
    gl.uniform3fv(gl.getUniformLocation(shader.programId, uniformName), value);
}
function setMat4vShader(shader, uniformName, value) {
    gl.uniformMatrix4fv(gl.getUniformLocation(shader.programId, uniformName), false, value);
}
function componentProduct3(a, b) {
    return vec3.fromValues(a[0] * b[0], a[1] * b[1], a[2] * b[2]);
}
//# sourceMappingURL=materials.js.map
