Vue3+echarts + echarts-wordcloud 实现各种形状的词云图在数据可视化场景中，词云图是一种非

在数据可视化场景中，词云图是一种非常直观且吸引人的表现形式，尤其在需要统计词语出现频率或展示关键词权重时，词云图能够以形象化的方式呈现信息。本文将详细介绍如何使用 Vue3、ECharts 以及 ECharts-WordCloud 插件开发各种类型的词云图，从基础到高级功能，让你掌握词云图的开发技巧。

开发一个基础的词云图：

步骤一：创建一个Vue3项目

首先，我们需要创建一个 Vue3 项目，推荐使用 Vite 来快速搭建项目环境。可以通过以下命令创建项目：

pnpm create vite vue-echarts --template vue

cd vue-echarts

步骤二：安装echarts 和echarts-wordcloud

在项目目录下安装 ECharts 和 ECharts-WordCloud 插件：

pnpm i echarts echarts-wordcloud

步骤三: 运行项目

运行以下命令启动开发服务器：

pnpm run dev

步骤四：编写词云图组件WordCloudMap

<template>
  <div>
    <div class="echarts-wrap" ref="echartWord"></div>
  </div>
</template>

<script setup>
import { ref, onMounted, onBeforeUnmount } from 'vue';
import * as echarts from 'echarts';
import 'echarts-wordcloud';

const props = defineProps({
  // 词云数据
  data: {
    type: Array,
    required: true,
    // 示例：
    // [
    //   { name: 'Vue', value: 1000 },
    //   { name: 'ECharts', value: 618 },
    //   // ...
    // ]
  },
  // 词云形状，可以是 'circle', 'cardioid', 'diamond', 'triangle-forward', 'triangle', 'pentagon' 等
  shape: {
    type: String,
    default: 'circle',
  },
});

const echartWord = ref(null);
let myChart = null;

const initChart = () => {
  if (echartWord.value) {
    myChart = echarts.init(echartWord.value);
    const option = {
      series: [{
        type: 'wordCloud',
        shape: props.shape,
        // 其他形状你可以使用形状路径
        // shape: 'circle', // 示例
        // 或者自定义路径
        gridSize: 2,
        sizeRange: [12, 60],
        rotationRange: [-90, 90],
        rotationStep: 45,
        // 字体
        textStyle: {
          normal: {
            color: function () {
              return 'rgb(' + [
                Math.round(Math.random() * 160),
                Math.round(Math.random() * 160),
                Math.round(Math.random() * 160)
              ].join(',') + ')';
            }
          },
          emphasis: {
            shadowBlur: 10,
            shadowColor: '#333'
          }
        },
        // 设置词云数据
        data: props.data
      }]
    };
    myChart.setOption(option);
    window.addEventListener('resize', myChart.resize);
  }
};

onMounted(() => {
  initChart();
});

onBeforeUnmount(() => {
  if (myChart) {
    window.removeEventListener('resize', myChart.resize);
    myChart.dispose();
  }
});
</script>

<style lang="scss" scoped>
.echarts-wrap{
  width: 1000px;
  height: 1000px;
}
</style>

步骤四：使用词云图组件

在项目中引入并使用 WordCloudMap 组件，传入词云数据和图形类型。

<template>
  <div>
    <WordCloudMap :data="data" :shape="circle" />
  </div>
</template>

<script setup>
import WordCloudMap from '@/components/WordCloudMap/index.vue'

const data = [
  { name: 'Vue', value: 1000 },
  { name: 'ECharts', value: 618 },
  { name: 'JavaScript', value: 438 },
  { name: 'HTML', value: 405 },
  { name: 'CSS', value: 248 },
  { name: 'TypeScript', value: 147 },
  { name: 'Webpack', value: 102 },
  { name: 'Babel', value: 86 },
  { name: 'Node.js', value: 62 },
  { name: 'NPM', value: 38 },
  { name: 'React', value: 300 },
  { name: 'Angular', value: 250 },
  { name: 'Svelte', value: 180 },
  { name: 'Backbone', value: 120 },
  { name: 'Ember', value: 95 },
  { name: 'jQuery', value: 400 },
  { name: 'Bootstrap', value: 350 },
  { name: 'Tailwind', value: 220 },
  { name: 'LESS', value: 110 },
  { name: 'SASS', value: 130 },
  { name: 'Git', value: 500 },
  { name: 'GitHub', value: 450 },
  { name: 'GitLab', value: 200 },
  { name: 'Bitbucket', value: 150 },
  { name: 'Docker', value: 320 },
  { name: 'Kubernetes', value: 280 },
  { name: 'AWS', value: 360 },
  { name: 'Azure', value: 340 },
  { name: 'GCP', value: 290 },
  { name: 'Firebase', value: 210 },
  { name: 'GraphQL', value: 190 },
  { name: 'REST', value: 410 },
  { name: 'API', value: 430 },
  { name: 'SQL', value: 370 },
  { name: 'NoSQL', value: 230 },
  { name: 'MongoDB', value: 260 },
  { name: 'PostgreSQL', value: 240 },
  { name: 'MySQL', value: 310 },
  { name: 'SQLite', value: 170 },
  { name: 'Redis', value: 160 },
  { name: 'Memcached', value: 140 },
  { name: 'Python', value: 520 },
  { name: 'Django', value: 340 },
  { name: 'Flask', value: 280 },
  { name: 'Ruby', value: 200 },
  { name: 'Rails', value: 220 },
  { name: 'Laravel', value: 180 },
  { name: 'PHP', value: 300 },
  { name: 'C#', value: 260 },
  { name: '.NET', value: 250 },
  { name: 'Java', value: 480 },
  { name: 'Spring', value: 220 },
  { name: 'Kotlin', value: 190 },
  { name: 'Swift', value: 210 },
  { name: 'Objective-C', value: 150 },
  { name: 'Go', value: 330 },
  { name: 'Rust', value: 170 },
  { name: 'C++', value: 360 },
  { name: 'C', value: 400 },
  { name: 'Perl', value: 90 },
  { name: 'Scala', value: 130 },
  { name: 'Haskell', value: 80 },
  { name: 'Elixir', value: 70 },
  { name: 'Erlang', value: 60 },
  { name: 'Lua', value: 100 },
  { name: 'Shell', value: 140 },
  { name: 'PowerShell', value: 120 },
  { name: 'Vim', value: 200 },
  { name: 'Emacs', value: 180 },
  { name: 'IntelliJ', value: 250 },
  { name: 'VSCode', value: 500 },
  { name: 'Sublime', value: 160 },
  { name: 'Atom', value: 130 },
  { name: 'WebStorm', value: 140 },
  { name: 'PyCharm', value: 210 },
  { name: 'NetBeans', value: 90 },
  { name: 'Eclipse', value: 100 },
  { name: 'Visual Studio', value: 300 },
  { name: 'Xcode', value: 220 },
  { name: 'Android Studio', value: 180 },
  { name: 'Bootstrap', value: 350 },
  { name: 'Tailwind CSS', value: 200 },
  { name: 'Material UI', value: 190 },
  { name: 'Ant Design', value: 170 },
  { name: 'Bulma', value: 150 },
  { name: 'Foundation', value: 140 },
  { name: 'Semantic UI', value: 130 },
  { name: 'Chakra UI', value: 120 },
  { name: 'Styled Components', value: 110 },
  { name: 'Emotion', value: 100 },
  { name: 'Redux', value: 280 },
  { name: 'MobX', value: 160 },
  { name: 'Vuex', value: 180 },
  { name: 'Pinia', value: 140 },
  { name: 'Nuxt.js', value: 200 },
  { name: 'Next.js', value: 220 },
  { name: 'Gatsby', value: 190 },
  { name: 'Gridsome', value: 80 },
  { name: 'Sapper', value: 60 },
  { name: 'Quasar', value: 50 },
  { name: 'TailwindUI', value: 40 },
  { name: 'Storybook', value: 170 },
  { name: 'Jest', value: 250 },
  { name: 'Mocha', value: 200 },
  { name: 'Chai', value: 150 },
  { name: 'Jasmine', value: 120 },
  { name: 'Cypress', value: 180 },
  { name: 'Puppeteer', value: 160 },
  { name: 'Playwright', value: 140 },
];
</script>

<style scoped>
</style>

通过以上步骤，一个基础的词云图就完成了。

查看项目运行结果

可以看到一个词云图就开发完成了。有几个重要的参数配置

词云图参数解释

1. shape

配置词云图的形状，支持值包括 circle, cardioid, diamond, triangle-forward, triangle,等。以triangle 为例，看下效果：

可以看到词云图就变成了一个三角形。其他形状可以自行去尝试。

2. gridSize

控制词语在图中的紧密程度。值越大，词语之间的距离越大。比如现在我们将2改成20，查看效果

可以看到词语之间的举例变稀松了许多。

3. sizeRange

设置字体大小的范围，格式为 [最小值, 最大值]。

现在我们将sizeRange改成[0, 100]查看效果：

可以看到词语大小的差距变得更加明显了，大的更大，小的更小

4. rotationRange 控制词语的旋转角度范围，格式为 [最小角度, 最大角度]。

示例：设置为 [0, 0]，所有词语将保持水平。

可以看到词语都不旋转了。

词云图高级功能，自定义形状。

在实际使用中，我们可能需要让词云图的形状更加个性化，比如根据特定的图片轮廓生成词云图。

1. 准备图片

选择一个合适的图片作为词云图的形状模板。可以从 iconfonticonfont(www.iconfont.cn/) 或其他素材网站下载图标。

搜索想要的图形

这里我选择一个空心问号图形：

2.将图片转换为base64

将图片转换为 Base64 格式，可以使用在线工具如图片转Base64图片转Base64(tool.chinaz.com/tools/imgto…)。

上传刚才下载的图片，在右侧就能看到转换的base64 图片了

3. 修改 WordCloudMap 组件

<template>
  <div>
    <div class="echarts-wrap" ref="echartWord"></div>
  </div>
</template>

<script setup>
import { ref, onMounted, onBeforeUnmount } from 'vue';
import * as echarts from 'echarts';
import 'echarts-wordcloud';

const maskImage = new Image()

const props = defineProps({
  // 词云数据
  data: {
    type: Array,
    required: true,
    // 示例：
    // [
    //   { name: 'Vue', value: 1000 },
    //   { name: 'ECharts', value: 618 },
    //   // ...
    // ]
  },
  // 词云形状，可以是 'circle', 'cardioid', 'diamond', 'triangle-forward', 'triangle', 'pentagon' 等
  shape: {
    type: String,
    default: 'triangle-forward',
  },
});

const echartWord = ref(null);
let myChart = null;

const initChart = () => {
  if (echartWord.value) {
    myChart = echarts.init(echartWord.value);
    const option = {
      renderer: 'canvas', // 强制使用 Canvas 渲染器
      series: [{
        type: 'wordCloud',
        shape: props.shape,
        // 其他形状你可以使用形状路径
        // shape: 'circle', // 示例
        // 或者自定义路径
        gridSize: 2,
        sizeRange: [12, 60],
        rotationRange: [-90, 90],
        rotationStep: 45,
        maskImage: maskImage,
        // 字体
        textStyle: {
          normal: {
            color: function () {
              return 'rgb(' + [
                Math.round(Math.random() * 160),
                Math.round(Math.random() * 160),
                Math.round(Math.random() * 160)
              ].join(',') + ')';
            }
          },
          emphasis: {
            shadowBlur: 10,
            shadowColor: '#333'
          }
        },
        // 设置词云数据
        data: props.data
      }]
    };
    maskImage.onload = function () {
      myChart.setOption(option, true);
    }

    window.addEventListener('resize', myChart.resize);
  }
};

onMounted(() => {
  initChart();
});

onBeforeUnmount(() => {
  if (myChart) {
    window.removeEventListener('resize', myChart.resize);
    myChart.dispose();
  }
});
</script>

<style lang="scss" scoped>
.echarts-wrap{
  width: 800px;
  height: 800px;
}
</style>

主要增加了3行代码：

const maskImage = new Image()

maskImage: maskImage,

查看运行效果：

这样一个空心问号词云图就被绘制出来了。

四、总结与扩展

通过本文的讲解，我们已经掌握了如何使用 Vue3、ECharts 和 ECharts-WordCloud 开发各种类型的词云图，包括基础词云图和自定义形状的高级词云图。以下是一些扩展思路：

动态数据更新

可以通过 Vue 的响应式数据机制，实现词云图的动态更新。
交互功能

利用 ECharts 提供的事件监听功能，为词云图添加点击、鼠标悬浮等交互效果。
多种样式组合

结合不同的字体、颜色和动画效果，打造更加炫酷的词云图。

通过不断探索和实践，相信你可以开发出更加丰富多彩的词云图，为数据可视化增添更多亮点！
