使用ArkTS、Uni-app、Taro开发鸿蒙 todolist对比

sRect
1,018 阅读7分钟

本文将通过使用ArkTS、Uni-app、Taro三种方式，分别完成todolist小demo。

1. 本文操作系统及主要package version

nameversion
操作系统macOS
Nodejsv20.9.0
DevEco-Studio5.0.0 Release
HbuilderX4.36
@tarojs/cliv4.0.8

2. 本文github仓库地址

nameurl
Harmony-Arkts-todolistgithub.com/sRect/Harmo…
Harmony-uniapp-todolistgithub.com/sRect/Harmo…
Harmony-taro-todolistgithub.com/sRect/Harmo…

1. 前置条件

  1. 需要进行华为开发者实名认证
  2. ArkTS
  3. uniapp + Vue3
  4. Taro + React

2. 使用ArkTS

下载好DevEco Studio，跟着鸿蒙文档快速上手hello world

2.1 添加Todolist页面

新建文件 entry > src > main > ets > pages > Todolist.ets

2.2 添加todolist路由

entry > src > main > resources > base > profile > main_pages.json

{
  "src": [
    "pages/Index",
    "pages/Todolist"
  ]
}

2.3 首页增加跳转按钮

entry > src > main > ets > pages > Index.ets

import { router } from "@kit.ArkUI";
import { BusinessError } from '@kit.BasicServicesKit';

Button() {
 Text('goto todolist')
  .fontSize(30)
  .fontWeight(FontWeight.Normal)
  .fontColor('white')
}
  .type(ButtonType.Capsule)
  .backgroundColor("#0D9FFB")
  .width('auto')
  .height('auto')
  .padding('10 5')
  .onClick(() => {
    try {
      router.pushUrl({
        url: "pages/Todolist"
      });
    }catch(e) {
      const errMsg = (e as BusinessError).message;
      console.error(errMsg);
    }
  })

2.4 完成Todolist页面

布局文档，有web开发人员熟悉的Flex、Row、Column等布局方式，直接干

  1. 首先完成顶部输入框+提交按钮
export interface ICurEditObj {
    val: string;
    index: number;
}

@Entry
@Component
struct Todolist {
  @State inputVal: string = ''; // 输入框内容
  @State private list: string[] = []; // 列表
  @State curEditObj: ICurEditObj = { val: "", index: 0 }; // 当前修改项
  scroller:Scroller = new Scroller();

  build() {
    Flex({direction: FlexDirection.Column}) {
      // 顶部输入
      Row({space: 10}) {
        TextInput({text: this.inputVal, placeholder: '请输入...'})
          .placeholderFont({ size: 14, weight: 400 })
          .placeholderColor(Color.Gray)
          .width('76%')
          .height('100%')
          .fontSize(14)
          .fontColor('#333333')
          .type(InputType.Normal)
          .onChange((val: string) => {
            this.inputVal = val;
          })

        Button() {
          Text('提交')
            .fontSize(18)
            .fontWeight(FontWeight.Normal)
            .fontColor('white')
        }
          .type(ButtonType.Capsule)
          .width('24%')
          .height('100%')
          .flexShrink(1)
          .backgroundColor('#06BA8C')
          .onClick(():void => {
            console.log('click:', this.inputVal);

            if(this.inputVal === "" || this.inputVal.trim() === "") {
              // 这里暂时没找到Toast的方法，先用AlertDialog代替
              AlertDialog.show({
                title: "",
                message: "内容不可为空",
                isModal: true,
                autoCancel: true,
                alignment: DialogAlignment.Center,
                borderWidth: 0,
                cornerRadius: 10,
                width: '50%',
                gridCount: 1
              });
              return;
            }

            this.list.unshift(this.inputVal);
            this.inputVal = "";
          });
      }.width('100%').height(40);

      // 中间列表滚动区域
      Scroll(this.scroller) {
        // list item
      }
        .backgroundColor('white')
        .scrollable(ScrollDirection.Vertical) // 滚动方向为垂直方向
          // .scrollBar(BarState.On) // 滚动条常驻显示
        .scrollBarColor(Color.Gray) // 滚动条颜色
        .scrollBarWidth(5) // 滚动条宽度
        .edgeEffect(EdgeEffect.Spring) // 滚动到边沿后回弹
        .height('auto')
        .margin({top: 20})
        .padding(10)
        .borderRadius(4)
    }
      .height('100%')
      .width('100%')
      .backgroundColor('#f6f6f6')
      .padding(10)
  }
}

  1. 接着完成中间列表滚动部分

Scroll(this.scroller) {
  Column({space:10}) {
    if(this.list.length > 0) {
      ForEach(this.list, (item?:string, index?:number) => {
        if(item && typeof index === 'number') {
          Row({space: 10}) {
            Text(`${index+1}. ${item}`)
              .fontSize(14)
              .fontColor('#333333')
              .width('58%')
              .wordBreak(WordBreak.BREAK_ALL)
              .maxLines(2)
              .textOverflow({ overflow: TextOverflow.MARQUEE })

            Row({space: 5}) {
              Button() {
                Text('编辑').fontSize(14).fontColor(Color.White)
              }
              .width('50%')
                .height('100%')
                .flexShrink(0)
                .flexGrow(0)
                .flexBasis('50%')
                .backgroundColor(Color.Blue)
                .onClick(() => {
                  // 打开自定义模态框
                  console.log("当前数据：", item);
                })

              Button() {
                Text('删除').fontSize(14).fontColor(Color.White)
              }
              .type(ButtonType.Capsule)
                .width('50%')
                .height('100%')
                .flexShrink(0)
                .flexGrow(0)
                .flexBasis('50%')
                .backgroundColor(Color.Orange)
                .onClick(() => {
                  this.list.splice(index, 1);
                })
            }.width('40%').height('100%').flexShrink(0);
          }
          .justifyContent(FlexAlign.SpaceBetween)
            .alignItems(VerticalAlign.Center)
            .width('100%')
            .flexGrow(0)
            .height('50')
            .backgroundColor('#f0f0f0')
            .padding('10')
            .borderRadius(4);
        }
      })
    } else {
      Text('暂无数据').fontColor(Color.Gray).margin({top: '30%', bottom: '30%'});
    }
  }
    .width('100%')
    .height('auto')
    .justifyContent(FlexAlign.Start)
    .alignItems(HorizontalAlign.Center)
}

  1. 接着完成列表item弹框修改

@Component
@CustomDialog
struct CustomDialogExample {
  @State curEditVal: string = "";
  cancel?: () => void
  confirm?: (val?: string) => void
  controller: CustomDialogController

  build() {
    Column() {
      Text("请修改").fontSize(20).fontWeight(FontWeight.Bold)
      TextInput({text: this.curEditVal, placeholder: "请输入"})
        .fontSize(14)
        .fontColor('#333333')
        .onChange((val: string) => {
          this.curEditVal = val;
        });

      Row() {
        Button('取消')
          .onClick(() => {
            this.controller.close();
            this.curEditVal = "";

            if (this.cancel) {
              this.cancel()
            }
          })
          .backgroundColor("#cccccc")
          .fontColor(Color.Black)
          .type(ButtonType.Capsule)

        Button('确定')
          .onClick(() => {
            this.controller.close()
            if (this.confirm) {
              // 点击确定修改，将当前的值传回去
              this.confirm(this.curEditVal)
            }
          })
          .backgroundColor('#06BA8C')
          .fontColor(Color.White)
          .type(ButtonType.Capsule)
      }.width('100%').alignItems(VerticalAlign.Center).justifyContent(FlexAlign.SpaceAround);
    }
      .padding('20 12')
      .height('30%')
      .justifyContent(FlexAlign.SpaceBetween)
  }
}

@Entry
@Component
struct Todolist {
  // ...
  // 创建构造器，与上面装饰器呼应相连
  dialogController: CustomDialogController = new CustomDialogController({
    builder: CustomDialogExample({
      confirm: (val?:string)=> {
        console.info("获取到模态框输入值：", val)
        if(val) {
          // 获取到dialog确定返回的新值，修改原数据
          this.list[this.curEditObj.index] = val;
        }
      }
    }),
    alignment: DialogAlignment.Center,
    cornerRadius: 10,
  })
}
  1. 点击按钮，打开自定义弹框
Button() {
  Text('编辑').fontSize(14).fontColor(Color.White)
}
    .width('50%')
    .height('100%')
    .flexShrink(0)
    .flexGrow(0)
    .flexBasis('50%')
    .backgroundColor(Color.Blue)
    .onClick(() => {
      console.log("当前数据：", item);
      this.curEditObj = {
        val: item,
        index: index
      }

      // 打开自定义模态框
      this.dialogController.open();
    })

美中不足的是，打开弹框的时候，没有把当前的值显示在弹框上，这样方便在原先值的基础上进行修改。

2.5 调用系统相机api进行拍照

通过系统相机拍照和录像(ArkTS)

注意：

  • 调用CameraPicker拍摄照片或录制视频，无需申请相机权限
  • 应用调试时，开发者需在release模式下调用系统相机（CameraPicker）
import { camera, cameraPicker as picker } from '@kit.CameraKit'
import { fileIo, fileUri } from '@kit.CoreFileKit'

let pathDir = getContext().filesDir;
let fileName = `${new Date().getTime()}`
let filePath = pathDir + `/${fileName}.tmp`
fileIo.createRandomAccessFileSync(filePath, fileIo.OpenMode.CREATE);

let uri = fileUri.getUriFromPath(filePath);
let pickerProfile: picker.PickerProfile = {
   cameraPosition: camera.CameraPosition.CAMERA_POSITION_BACK,
   saveUri: uri
};
let result: picker.PickerResult =
   await picker.pick(getContext(), [picker.PickerMediaType.PHOTO, picker.PickerMediaType.VIDEO],
      pickerProfile);
console.info(`picker resultCode: ${result.resultCode},resultUri: ${result.resultUri},mediaType: ${result.mediaType}`);
if (result.resultCode == 0) {
   if (result.mediaType === picker.PickerMediaType.PHOTO) {
      this.imgSrc = result.resultUri;
   } else {
      this.videoSrc = result.resultUri;
   }
}

2.5 云真机调试

2.5.1 准备数字签名证书

由于本地没有华为鸿蒙真机，登录AppGallery Connect，把打包好的release包上传，选择对应的机型，进行测试。如果本地有华为鸿蒙机型，直接本地调试

  1. Stage模型下两个重要文件
  • app.json5配置文件：应用的全局配置信息，包含应用的Bundle名称、开发厂商、版本号等基本信息
  • module.json5配置文件：包含Module名称、类型、描述、支持的设备类型等基本信息、权限信息等

  1. AppGallery Connect管理中心-创建项目，进入到证书、APP ID和Profile模块，新增证书，选择发布证书，证书需要的CSR文件，在DevEco Studio里生成

  2. HarmonyOS应用/元服务发布，跟着文档，这一步生成两个文件，xxx_release.csr和xxx_release.p12

  3. 上面第2步需要的csr文件选择上传，生成release证书，点击xxx_release.cer文件下载到本地

  4. AppGallery Connect管理中心- 证书、APP ID和Profile-Profile，新增Profile，xxx.p7b下载到本地

  5. DevEco Studio配置工程的签名信息, 跟着文档，选择对应的文件，点击Apply+OK

上面6步，一共产生了4个文件。

  • xxx.csr
  • xxx.p12
  • xxx.cer
  • xxx.p7b

此时，根目录下的build-profile.json5文件如下：

signingConfigs下的default为本地开发debug模式使用，release为生产打包使用

{
  "app": {
    "signingConfigs": [
      {
        "name": "default",
        "type": "HarmonyOS",
        "material": {
          "certpath": "/Users/xxx/.ohos/config/default_harmonyTodolist_1E20EuW6JSNNRofCNXMMXzxBWhxfMG9yA9x0FxAlCXE=.cer",
          "storePassword": "xxx",
          "keyAlias": "debugKey",
          "keyPassword": "xxx",
          "profile": "/Users/xxx/.ohos/config/default_harmonyTodolist_1E20EuW6JSNNRofCNXMMXzxBWhxfMG9yA9x0FxAlCXE=.p7b",
          "signAlg": "SHA256withECDSA",
          "storeFile": "/Users/xxx/.ohos/config/default_harmonyTodolist_1E20EuW6JSNNRofCNXMMXzxBWhxfMG9yA9x0FxAlCXE=.p12"
        }
      },
      {
        "name": "release",
        "type": "HarmonyOS",
        "material": {
          "storePassword": "xxx",
          "certpath": "/Users/xxx/code/harmonyTodolist/arkts-todolist.cer",
          "keyAlias": "arktsTodolist_release",
          "keyPassword": "xxx",
          "profile": "/Users/xxx/code/harmonyTodolist/arktsTodolistProfileRelease.p7b",
          "signAlg": "SHA256withECDSA",
          "storeFile": "/Users/xxx/code/harmonyTodolist/arktsTodolist_release.p12"
        }
      }
    ],
    "products": [
      {
        "name": "default",
        "signingConfig": "release",
        "compatibleSdkVersion": "5.0.0(12)",
        "runtimeOS": "HarmonyOS",
        "buildOption": {
          "strictMode": {
            "caseSensitiveCheck": true,
            "useNormalizedOHMUrl": true
          }
        }
      }
    ],
    "buildModeSet": [
      {
        "name": "debug",
      },
      {
        "name": "release"
      }
    ]
  },
  "modules": [
    {
      "name": "entry",
      "srcPath": "./entry",
      "targets": [
        {
          "name": "default",
          "applyToProducts": [
            "default"
          ]
        }
      ]
    }
  ]
}

2.5.2 进行打包

  1. DevEco StudioBuild > Build Hap(s)/APP(s) > Build APP(s)
> hvigor Finished ::PreBuildApp... after 1 ms
> hvigor UP-TO-DATE :entry:default@PreBuild...
> hvigor Finished ::DuplicateDependencyCheck... after 1 ms
> hvigor UP-TO-DATE :entry:default@GenerateMetadata...
> hvigor Finished :entry:default@ConfigureCmake... after 1 ms
> hvigor UP-TO-DATE :entry:default@MergeProfile...
> hvigor UP-TO-DATE :entry:default@CreateBuildProfile...
> hvigor Finished :entry:default@PreCheckSyscap... after 1 ms
> hvigor UP-TO-DATE :entry:default@GeneratePkgContextInfo...
> hvigor Finished :entry:default@ProcessIntegratedHsp... after 1 ms
> hvigor Finished :entry:default@BuildNativeWithCmake... after 1 ms
> hvigor UP-TO-DATE :entry:default@MakePackInfo...
> hvigor UP-TO-DATE :entry:default@ProcessProfile...
> hvigor Finished :entry:default@SyscapTransform... after 1 ms
> hvigor UP-TO-DATE :entry:default@ProcessRouterMap...
> hvigor Finished :entry:default@BuildNativeWithNinja... after 1 ms
> hvigor UP-TO-DATE :entry:default@ProcessResource...
> hvigor UP-TO-DATE :entry:default@GenerateLoaderJson...
> hvigor UP-TO-DATE :entry:default@ProcessLibs...
> hvigor UP-TO-DATE :entry:default@CompileResource...
> hvigor UP-TO-DATE :entry:default@DoNativeStrip...
> hvigor UP-TO-DATE :entry:default@CompileArkTS...
> hvigor Finished :entry:default@BuildJS... after 1 ms
> hvigor UP-TO-DATE :entry:default@CacheNativeLibs...
> hvigor Finished :entry:default@GeneratePkgModuleJson... after 1 ms
> hvigor WARN: If obfuscation is needed, enable obfuscation settings in this build process; failing to do so may prevent future obfuscation.
               Properly configure obfuscation rules to avoid runtime issues.
> hvigor UP-TO-DATE :entry:default@PackageHap...
> hvigor UP-TO-DATE :entry:default@SignHap...
> hvigor Finished :entry:assembleHap... after 1 ms
> hvigor UP-TO-DATE ::MakeProjectPackInfo...
> hvigor UP-TO-DATE ::GeneratePackRes...
> hvigor UP-TO-DATE ::PackageApp...
> hvigor UP-TO-DATE ::SignApp...
> hvigor Finished ::assembleApp... after 1 ms
> hvigor BUILD SUCCESSFUL in 156 ms

Process finished with exit code 0

Build Analyzer results available

有一个关于obfuscation的警告，是代码加固混淆的，先不管，真正需要上线的再改。

  1. 不出意外，build/outputs/default下多出了3个文件
build/outputs/default
├── harmonyTodolist-default-signed.app
├── harmonyTodolist-default-unsigned.app
└── pack.info

2.5.2 云上真机测试

AppGallery Connect管理中心-云调试


选择一个机型，将刚才打包好的xxx-signed.app拖拽上传，进行测试


可以看到，成功使用系统相机，拍了一张黑漆漆的照片

3. 使用uniapp+vue3

注意:

  1. uniapp目前仅支持vue3编译成鸿蒙
  2. HBuilderX需要更新到最新版，不然顶部菜单点击运行的时候，没有运行到鸿蒙选项
  3. DevEco-Studio还是要下载，模拟器要先在DevEco-Studio中启动

3.1 创建一个vue3项目

这里就使用HBuilderX的方式创建项目，暂时不使用cli命令的方式

右击新建项目，选择默认模板，Vue版本选择3

此时项目目录结构大致如下:

├── App.vue
├── README.md
├── index.html
├── main.js
├── manifest.json
├── node_modules
├── package.json
├── pages
|  ├── index
|  └── todolist
├── pages.json
├── pnpm-lock.yaml
├── static
|  ├── css
|  └── logo.png
├── tailwind.config.js
├── uni.promisify.adaptor.js
├── uni.scss
├── uni_modules
└── unpackage
   ├── debug
   ├── dist
   └── release

另外，这里我添加了tailwindcss和uv-ui，不添加也没关系

3.2 新建tolist页面，添加路由

  1. pages文件下新建页面todolist
  2. pages.json中新增路由
{
	"pages": [
		{
			"path" : "pages/todolist/todolist",
			"style" :
			{
				"navigationBarTitleText" : "todolist"
			}
		}
	]
}

3.3 完成todolist页面

  1. template部分
<template>
	<view class="w-full h-[95%] flex flex-col gap-[4px] overflow-hidden bg-white px-[16px] pt-[5px] box-border">
		<view class="w-full flex items-center justify-between gap-[10px]">
      <uv-input placeholder="请输入..." border="surround" v-model="inputVal"></uv-input>

      <uv-button text="添加" type="primary" @click="handleAdd"></uv-button>
    </view>

    <view class="w-full flex-1 overflow-hidden">
      <scroll-view :scroll-y="true" class="w-full h-[100%]">
        <uv-empty v-if="list.length === 0" mode="data" text="暂无数据" marginTop="40"></uv-empty>
        <template v-else>
          <view
            class="w-full flex items-center justify-between gap-[8px] px-[10px] py-[20px] box-border bg-slate-100 mb-[8px] rounded-[4px] overflow-hidden"
            v-for="(item, key) in list"
            :key="key"
          >
            <text class="flex-[1_1_auto] text-[#333333] font-[500] text-[14px] break-all">{{key+1}}. {{item}}</text>

            <view class="flex-none flex items-center gap-[4px]">
              <uv-button text="编辑" plain :hairline="false" size="normal" type="info" @click="handleEdit(key)"></uv-button>
              <uv-button text="删除" plain :hairline="false" size="normal" type="error" @click="handleDelete(key)"></uv-button>
            </view>
          </view>
        </template>
      </scroll-view>
    </view>
	</view>
  <uv-modal
    ref="modalRef"
    title="修改"
    :closeOnClickOverlay="false"
    :showCancelButton="true"
    :asyncClose="true"
    @confirm="handleConfirmEdit"
    @cancel="handleCloseModal"
  >
    <view class="slot-content w-full">
      <uv-input placeholder="请输入..." border="surround" v-model="currentEditObj.val"></uv-input>
    </view>
  </uv-modal>

  <uv-safe-bottom></uv-safe-bottom>
</template>
<script setup>
   // 下面js部分
</script>
  1. js部分
import {ref, reactive} from "vue";

const modalRef = ref();
const inputVal = ref("");
const list = ref([]);
const currentEditObj = reactive({
   index: "",
   val: ""
});

const handleCloseModal = () => {
   modalRef.value.close();

   currentEditObj.val = "";
}

const handleAdd = () => {
   const newVal = inputVal.value.trim();
   if(newVal === "") {
      uni.showToast({
         title: "添加内容不可为空",
         icon: "none"
      })
      return;
   }

   list.value.push(newVal);
   inputVal.value = "";
   console.log("list:", JSON.stringify(list.value));
}

const handleEdit = (index) => {
   //  这里uni.showModal的editable属性暂时不支持，所以modal选择了uv-ui框架的modal
   currentEditObj.index = index;
   currentEditObj.val = list.value[index];

   modalRef.value.open();
};

const handleConfirmEdit = () => {
   const newVal = currentEditObj.val.trim();
   if(newVal === "") {
      uni.showToast({
         title: "修改内容不可为空",
         icon: "none"
      });
      modalRef.value.closeLoading();
      return;
   }

   list.value.splice(currentEditObj.index, 1, newVal);
   handleCloseModal();
}

const handleDelete = (index) => {
   uni.showModal({
      title: "提示",
      content: "确定删除吗？",
      success(res) {
         if(res.confirm) {
            list.value.splice(index, 1);
         }
      }
   })
}

3.4 本地运行

  1. 先到DevEco-Studio中打开模拟器

  2. HbuilderX顶部菜单运行-运行到手机或模拟器-运行到鸿蒙,选择启动的模拟器，点击运行

  3. 模拟器中即可看到已经安装了我们的应用


3.5 调用鸿蒙原生API

跟着文档，这里我们写打开手机系统相机，拍照返回给页面。

  1. uni_modules文件夹右击，新建uni_modules插件，选择UTS插件-API插件，插件ID命名成ikun-openCamera

  2. /uni_modules/ikun-openCamera/package.json中找到uni_modules字段，新增

    {
   "uni_modules": {
      "uni-ext-api": {
         "uni": {
            "openCamera": {
               "name": "openCamera",
               "app": {
                  "js": false,
                  "kotlin": false,
                  "swift": false,
                  "arkts": true
               }
            }
         }
      }
   }
}

  3. uni_modules/ikun-openCamera/utssdk/interface.uts中声明类型

    export interface Uni {
    /**
        * OpenCamera()
        * @description
        * 打开相机
        * @param {OpenCameraOptions}  options
        * @return {void}
        * @example
         ```typescript
            uni.OpenCamera({});
         ```
        */
    openCamera(options : OpenCameraOptions) : void;
}

export type OpenCamera = (options : OpenCameraOptions) => void;
export type OpenCameraSuccess = {
  [key:string]: string
};
export type OpenCameraSuccessCallback = (result : OpenCameraSuccess) => void;
export type OpenCameraFail = {
    /**
     * 错误信息
     */
    errMsg : string
};
export type OpenCameraFailCallback = (result : OpenCameraFail) => void;
export type OpenCameraComplete = {
    /**
     * 错误信息
     */
    errMsg : string
};
export type OpenCameraCompleteCallback = (result : OpenCameraComplete) => void;

export type OpenCameraOptions = {
    /**
     * 接口调用成功的回调函数
     * @defaultValue null
     */
    success ?: OpenCameraSuccessCallback | null,
    /**
     * 接口调用失败的回调函数
     * @defaultValue null
     */
    fail ?: OpenCameraFailCallback | null,
    /**
     * 接口调用结束的回调函数（调用成功、失败都会执行）
     * @defaultValue null
     */
    complete ?: OpenCameraCompleteCallback | null
};

  4. uni_modules/ikun-openCamera/utssdk/app-harmony/index.uts中暴露调用相机方法

    ├── uni_modules
|  └── ikun-openCamera
       ├── confis.json
       └── index.uts
    • 没有app-harmony文件夹，就新建
    • 通过系统相机拍照和录像(ArkTS)
    • 应用可调用CameraPicker拍摄照片或录制视频，无需申请相机权限
    • 应用调试时，开发者需在release模式下调用系统相机（CameraPicker）
    import { camera, cameraPicker as picker } from '@kit.CameraKit';
import { fileIo, fileUri } from '@kit.CoreFileKit';
// import { BusinessError } from '@kit.BasicServicesKit';
import {OpenCameraOptions, OpenCameraSuccess, OpenCameraFail} from "../interface.uts";

export async function openCamera(options : OpenCameraOptions) {
   try {
      let imgSrc: string = '';
      let videoSrc: string = '';

      let pathDir = getContext().filesDir;
      let fileName = `${new Date().getTime()}`
      let filePath = pathDir + `/${fileName}.tmp`
      fileIo.createRandomAccessFileSync(filePath, fileIo.OpenMode.CREATE);

      let uri = fileUri.getUriFromPath(filePath);
      let pickerProfile: picker.PickerProfile = {
         cameraPosition: camera.CameraPosition.CAMERA_POSITION_BACK,
         saveUri: uri
      };
      let result: picker.PickerResult =
         await picker.pick(getContext(), [picker.PickerMediaType.PHOTO, picker.PickerMediaType.VIDEO],
            pickerProfile);

      console.log("result:", result);
      console.info(`picker resultCode: ${result.resultCode},resultUri: ${result.resultUri},mediaType: ${result.mediaType}`);
      if (result.resultCode == 0) {
         if (result.mediaType === picker.PickerMediaType.PHOTO) {
            imgSrc = result.resultUri;
         } else {
            videoSrc = result.resultUri;
         }
      }

      let obj: OpenCameraSuccess = {
         imgSrc,
         videoSrc,
      }

      options?.success?.(obj);
   } catch (error) {
      let result : OpenCameraFail = {
         errMsg: error.message ?? ""
      };

      options?.fail?.(result);
   }
}

  5. vue3页面中调用上面暴露的方法

    <template>
   <button type="primary" @click="handleOpenCamera">打开系统相机拍照</button>
   <image :src="obj.imgSrc" class="w-[200px] h-[200px]" @error="handleImgLoadErr"></image>

    <text>imgSrc: </text>
    <text :selectable="true" class="my-text-wrap">{{obj.imgSrc}}</text>
    <text class="my-text-wrap">{{imgLoadErrRef || '暂无图片加载失败信息'}}</text>
 </template>

    import { reactive, ref } from 'vue';
import { openCamera } from '@/uni_modules/ikun-openCamera';

export type TCameraReturnObj = {
   imgSrc?: string;
   videoSrc?: string;
}

export type TImgLoadErr = {
  detail?: object
}

const obj = reactive({
   imgSrc: "",
   videoSrc: "",
});
const imgLoadErrRef = ref();

const handleOpenCamera = async () => {
  try {
    await openCamera({
      success(r: TCameraReturnObj) {
        console.log("r", JSON.stringify(r));
         // 这里通过打印看出，r.imgSrc是file://协议，uniapp的image标签无法显示
         obj.imgSrc = r.imgSrc;
         obj.videoSrc = r.videoSrc;
      },
      fail(e) {
        console.error("openCamera error:", JSON.stringify(e));
      }
    });
  } catch (error) {
    console.error(error);
  }
}

const handleImgLoadErr = (event:TImgLoadErr) => {
 imgLoadErrRef.value = JSON.stringify(event.detail);
}

3.6 打包测试

  1. HbuilderX点击发行->App-Harmony-本地打包，此时因为没有配置签名，打的包是无法提交云上测试的
  2. 可以将打完包路径unpackage/release/xxx直接用DevEco-Studio打开，找到根目录的build-profile.json5，配置signingConfigs字段，按照上面那些步骤，将需要生成的文件都准备好，最后进行打包
  3. 将打包完的xxx-default-signed.app拖拽到AppGallery Connect 云测试里安装测试，发现uniapp的image标签无法显示file协议图片


3.7 尝试解决uniapp中image标签无法显示file://协议问题，未解决

【HarmonyOS】ArrayBuffer转Base64，Base64转ArrayBuffer，Uri转ArrayBuff，PixelMap转ArrayBuffer，图片Uri转为PixelMap

import { fileIo } from '@kit.CoreFileKit';
import util from '@ohos.util';

// 1. 先将图片uri转为arraybuffer
function imageUri2Buffer(uri: string){
 let file = fs.openSync(uri, fileIo.OpenMode.READ_ONLY);
 let buffer = new ArrayBuffer(4096);
 fs.readSync(file.fd, buffer);
 return buffer ;
}

// 2. 然后将arraybuffer转为base64
function arrayBuffer2Base64(buffer: ArrayBuffer){
   let temp = new Uint8Array(buffer);
   // 官方提供的base64编码转换工具
   let helper = new util.Base64Helper();
   let res = helper.encodeToStringSync(temp);
   return res;
}

通过上面这样的转换，成功返回base64字符串

const handleOpenCamera = async () => {
   try {
      await openCamera({
         success: async (r: TCameraReturnObj) => {
            if(r.imgSrc) {
            } else {
               obj.imgSrc = r.imgSrc;
            }

            obj.videoSrc = r.videoSrc;
         },
         fail(e) {
            errorRef.value = JSON.stringify(e);
            console.error("openCamera error:", JSON.stringify(e));
         }
      });
   } catch (error) {
      console.error(error);
   }
}

但是最终失败了，image标签的error事件显示base64路径错误`404 Not Found`` 有大佬知道这里怎么解决的，麻烦留言告知一声。

4. 使用taro+react

Taro开发鸿蒙ArkUI文档

4.1 首先初始化taro项目

  1. 安装taro-cli，选择vite模板
npm i -g @tarojs/cli@beta`
  1. 初始化项目
taro init xxx
  1. 安装 Taro 适配鸿蒙插件并修改 Taro 编译配置
  • 安装插件
npm i @tarojs/plugin-platform-harmony-ets@beta
  • config/index.ts
import path from 'node:path';

config = {
  // 配置使用插件
  plugins: ['@tarojs/plugin-platform-harmony-ets'],
  // harmony 相关配置
  harmony: {
    // 将编译方式设置为使用 Vite 编译
    compiler: 'vite',
    // 【必填】鸿蒙主应用的绝对路径
    // 这里等下在DevEco-studio里创建项目的时候，就选择这个文件夹地址
    projectPath: path.resolve(process.cwd(), '../MyApplication'),
    hapName: 'entry',
    name: 'default',
  },
}
  1. package.json文件中新增scripts命令
{
  "scripts": {
    "build:harmony": "taro build --type harmony",
    "dev:harmony": "npm run build:harmony -- --watch"
  }
}

4.2 DevEco-Studio中创建主项目


注意： 文件夹关系一定要对应好，即现在有两个项目，taro中编译的输出到DevEco-Studio里

4.3 启动运行

下面报错信息弄得头疼

  1. 启动taro项目
npm run dev:harmony

启动后直接报错：

node:internal/modules/cjs/loader:1327
  return process.dlopen(module, path.toNamespacedPath(filename));
                ^

Error: dlopen(/Users/xxx/code/harmonyTodolistTaro/node_modules/.pnpm/@tarojs+parse-css-to-stylesheet-darwin-arm64@0.0.69/node_modules/@tarojs/parse-css-to-stylesheet-darwin-arm64/parse-css-to-stylesheet.darwin-arm64.node, 0x0001): Library not loaded: /opt/homebrew/opt/pcre2/lib/libpcre2-8.0.dylib
  Referenced from: <005B3B76-8884-3214-A052-75F904AFBABF> /Users/xxx/code/harmonyTodolistTaro/node_modules/.pnpm/@tarojs+parse-css-to-stylesheet-darwin-arm64@0.0.69/node_modules/@tarojs/parse-css-to-stylesheet-darwin-arm64/parse-css-to-stylesheet.darwin-arm64.node
  Reason: tried: '/opt/homebrew/opt/pcre2/lib/libpcre2-8.0.dylib' (no such file), '/System/Volumes/Preboot/Cryptexes/OS/opt/homebrew/opt/pcre2/lib/libpcre2-8.0.dylib' (no such file), '/opt/homebrew/opt/pcre2/lib/libpcre2-8.0.dylib' (no such file)
    at Object.Module._extensions..node (node:internal/modules/cjs/loader:1327:18)
    at Module.load (node:internal/modules/cjs/loader:1091:32)
    at Function.Module._load (node:internal/modules/cjs/loader:938:12)
    at Module.require (node:internal/modules/cjs/loader:1115:19)
    at require (node:internal/modules/helpers:130:18)
    at Object.<anonymous> (/Users/xxx/code/harmonyTodolistTaro/node_modules/.pnpm/@tarojs+parse-css-to-stylesheet@0.0.69/node_modules/@tarojs/parse-css-to-stylesheet/index.js:141:29)
    at Module._compile (node:internal/modules/cjs/loader:1241:14)
    at Module._extensions..js (node:internal/modules/cjs/loader:1295:10)
    at Object.newLoader [as .js] (/Users/xxx/code/harmonyTodolistTaro/node_modules/.pnpm/pirates@4.0.6/node_modules/pirates/lib/index.js:121:7)
    at Module.load (node:internal/modules/cjs/loader:1091:32) {
  code: 'ERR_DLOPEN_FAILED'
}

Node.js v20.9.0
  1. 解决启动报错

  • 删除node_modules后，重新pnpm install安装依赖，还是不行

  • 以为是全局安装的taro cli版本是beta版本导致的，换了稳定v4.0.8版本，再次启动还是不行

  • 以为是初始化项目选择了pnpm导致安装，重新来选择npm，结果还是不行

  • 解决：

    最终丢给ai，提示要安装pcre2,执行brew list | grep pcre2后，果然没有打印，执行brew install pcre2安装，重新启动项目，解决了。

  1. 正常启动日志：
> harmonyTodolistTaro@1.0.0 build:harmony
> taro build --type harmony --watch

👽 Taro v4.0.8
vite v4.5.5 building for production...

watching for file changes...

build started...
transforming (1) taro:compiler(node:25315) [stylelint:002] DeprecationWarning: The CommonJS Node.js API is deprecated.
See https://stylelint.io/migration-guide/to-16
(Use `node --trace-deprecation ...` to show where the warning was created)
(node:25315) [stylelint:002] DeprecationWarning: The CommonJS Node.js API is deprecated.
See https://stylelint.io/migration-guide/to-16
✓ 7 modules transformed.
rendering chunks (6)...

开始 ohpm install 脚本执行...

/bin/sh: /Users/xxx/Library/Huawei/ohpm/bin/ohpm: No such file or directory
自动安装依赖失败，请手动执行 ohpm install 或在 DevEco Studio 中打开 oh-package.json5 并点击 Sync Now 按钮
MyApplication/entry/src/main/ets/app.css.xss.js                  0.09 kB │ gzip: 0.10 kB │ map: 0.10 kB
MyApplication/entry/src/main/ets/index.css.xss.js                0.10 kB │ gzip: 0.10 kB │ map: 0.10 kB
MyApplication/entry/src/main/ets/app_comp.js                     0.27 kB │ gzip: 0.21 kB │ map: 0.69 kB
MyApplication/entry/src/main/ets/pages/index/index_taro_comp.js  0.40 kB │ gzip: 0.27 kB │ map: 0.11 kB
MyApplication/entry/src/main/ets/app_taro_comp.js                0.83 kB │ gzip: 0.46 kB │ map: 0.13 kB
MyApplication/entry/src/main/ets/pages/index/index_comp.js       0.89 kB │ gzip: 0.42 kB │ map: 0.98 kB
MyApplication/entry/src/main/ets/app.ets                         2.21 kB │ gzip: 0.86 kB
MyApplication/entry/src/main/ets/render.ets                      5.76 kB │ gzip: 1.23 kB
MyApplication/entry/src/main/ets/pages/index/index.ets           9.04 kB │ gzip: 2.44 kB
built in 312ms.

  1. DevEco-Studio中打开模拟器，不出意外，hello world正常显示

  2. 关于上面启动后警告信息ohpm install自动安装依赖失败

其实就是本地全局的OHPM_HOME环境变量配置问题

打开本地zsh，测试下，能打印出版本号，说明就没问题

ohpm -v

但我这本地，通过zsh打开的命令行，没打印出ohpm的版本号，而通过DevEco-Studio内置的命令行，可以打印出ohpm版本号5.0.8

还有本地就没有/Users/xxx/Library/Huawei/ohpm这个目录，哪里出问题了？

解决：

    1. 首先下载ohpm工具包,找到Command Line Tools for HarmonyOS,选择对应的平台下载即可
    1. 解压目录 将解压后的ohpm文件夹复制到本地/Users/xxx/Library/Huawei文件夹
    # 首先切到该文件夹
cd /Users/xxx/Library/Huawei/ohpm/bin
# 然后执行下面命令
./init
    1. 配置ohpm环境变量
    echo $SHELL

    我这里输出/bin/zsh,所以修改~/.zshrc配置文件，bash的修改~/.bashrc即可

    sudo vim ~/.zshrc

    进入编辑模式，然后添加

    # ohpm
export OHPM_HOME=/Users/xxx/Library/Huawei/ohpm
export PATH=$PATH:$OHPM_HOME/bin
# ohpm end

    保存退出后，执行

    source ~/.bashrc

    此时再执行,不出意外，正确打印出版本号。但这里打印出来的是1.2.0，但是DevEco-Studio的内置命令行打印出来的是5.0.8。

    ohpm -v
  1. 再次执行npm run dev:harmony,ohpm警告问题解决。
> harmonyTodolistTaro@1.0.0 build:harmony
> taro build --type harmony --watch

👽 Taro v4.0.8

vite v4.5.5 building for production...

watching for file changes...

build started...
transforming (1) taro:compiler(node:11988) [stylelint:002] DeprecationWarning: The CommonJS Node.js API is deprecated.
See https://stylelint.io/migration-guide/to-16
(Use `node --trace-deprecation ...` to show where the warning was created)
(node:11988) [stylelint:002] DeprecationWarning: The CommonJS Node.js API is deprecated.
See https://stylelint.io/migration-guide/to-16
✓ 7 modules transformed.
rendering chunks (6)...

开始 ohpm install 脚本执行...

install completed in 0s 1ms
执行 ohpm install 脚本成功。

../harmonyTodolistTaroMain/entry/src/main/ets/app.less.xss.js                 0.10 kB │ gzip: 0.10 kB │ map: 0.10 kB
../harmonyTodolistTaroMain/entry/src/main/ets/index.less.xss.js               0.10 kB │ gzip: 0.10 kB │ map: 0.10 kB
../harmonyTodolistTaroMain/entry/src/main/ets/app_comp.js                     0.27 kB │ gzip: 0.21 kB │ map: 0.71 kB
../harmonyTodolistTaroMain/entry/src/main/ets/pages/index/index_taro_comp.js  0.40 kB │ gzip: 0.27 kB │ map: 0.11 kB
../harmonyTodolistTaroMain/entry/src/main/ets/app_taro_comp.js                0.83 kB │ gzip: 0.46 kB │ map: 0.13 kB
../harmonyTodolistTaroMain/entry/src/main/ets/pages/index/index_comp.js       0.89 kB │ gzip: 0.42 kB │ map: 1.00 kB
../harmonyTodolistTaroMain/entry/src/main/ets/app.ets                         2.21 kB │ gzip: 0.86 kB
../harmonyTodolistTaroMain/entry/src/main/ets/render.ets                      5.76 kB │ gzip: 1.23 kB
../harmonyTodolistTaroMain/entry/src/main/ets/pages/index/index.ets           9.04 kB │ gzip: 2.44 kB
built in 435ms.
  1. 关于taro项目启动后，DevEco-Studio打开模拟器报错
> hvigor ERROR: Failed :default:default@HotReloadArkTS...
> hvigor ERROR:  ERROR: srcEntry file '/Users/xxx/code/harmonyTodolistTaroMain/entry/src/main/ets/entrybackupability/EntryBackupAbility.ets' does not exist.
> hvigor ERROR: BUILD FAILED in 904 ms

本地确实没有这个文件，不知道什么原因造成的

解决：

卸载掉全局安装的taro/cli的beta版本，重新安装稳定版本，再次重新初始化项目，按着那些步骤重新运行，ok了

npm i -g @tarojs/cli

4.4 完成todolist页面

import {useState} from "react";
import { View, Text, Input, Button, ScrollView } from '@tarojs/components';
import Taro from "@tarojs/taro";
import './index.less'

export default function Index () {
  const [val, setVal] = useState<string>("");
  const [list, setList] = useState<Array<string>>([]);

  const handleAdd = () => {
    if(val.trim() === "") {
      Taro.showToast({
        title: "添加内容不可为空",
        icon: "none"
      });

      return;
    }

    setList([val, ...list]);
    setVal("");
  }

  const handleDelete = (index: number) => {
    console.log("index:", index);
    Taro.showModal({
      title: "提示",
      content: "确定要删除此项吗？",
      success: (res) => {
        if (res.confirm) {
          const newList = [...list];

          newList.splice(index, 1);
          setList(newList);
        }
      }
    });
  }

  return (
    <View className='wrap'>
      <View className='head'>
        <View className='inputWrap'>
          <Input className='input' type='text' placeholder='请输入...' value={val} onInput={e => setVal(e.detail.value)} />
        </View>

        <View className='btnWrap'>
          <Button size='mini' className='btn' type='primary' onClick={handleAdd}>
            <Text className='text-white text-[14px] font-[500]'>添加</Text>
          </Button>
        </View>
      </View>

      <View className='scrollWrap'>
        {
          list.length === 0
            ? <View className='empty'><Text className='text'>暂无数据</Text></View>
            : <ScrollView className='scroll'>
                {
                  list.map((item, index) => (<View key={index} className='item'>
                    <View className='left'>
                      <Text className='text'>{index+1}. {item}</Text>
                    </View>

                    <View className='right'>
                      <Button size='mini' className='btn' type='default'>
                        <Text className='text-[#333333] text-[14px] font-[500]'>编辑</Text>
                      </Button>
                      <Button size='mini' className='btn' type='warn' onClick={() => handleDelete(index)}>
                        <Text className='text-white text-[14px] font-[500]'>删除</Text>
                      </Button>
                    </View>
                  </View>))
                }
              </ScrollView>
        }
      </View>
    </View>
  )
}


实际感受就是，css样式有些不支持，咋感觉比uniapp中写起来要费劲。最要命的是，项目热更新没生效，虽然没报错，但是模拟器中的样式不是最新的，只能每次重新启动taro项目，重新启动模拟器，这样才是最新的样式。很心累，使用姿势哪里有问题，麻烦评论区说下。只能匆忙结束taro。

5.写在最后

如果文章对您有帮助，可以关注我的个人公众号半个柠檬2020，偶尔也会在公众号上面更新一些自己的学习笔记。

avatar
文章
阅读
粉丝
