效果实现
Echarts线图线条渐变色及区域渐变
- 效果图
-
关注点
- 线条颜色渐变
- 线条含有阴影
- 区域填充色渐变
-
配置项
series:[{
data: [820, 932, 901, 934, 1290, 1330, 1320],
type: 'line',
smooth: false,
lineStyle: {
normal: {
// 1. 设置线条渐变色
color: new echarts.graphic.LinearGradient(0, 0, 1, 0, [
{
offset: 0,
color: '#FDFDFF',
},
{
offset: 0.3,
color: '#6EA4F8',
},
{
offset: 0.6,
color: '#7DA0E0',
}, {
offset: 1,
color: '#679BF0',
},
]),
width: 3,
// 2. 设置线条阴影
shadowColor: '#2E4F84',
shadowOffsetY: 15,
shadowOffsetX: 5,
shadowBlur: 3,
},
},
// 3. 设置区域填充渐变：渐变色设置文档 https://echarts.apache.org/zh/option.html#color
areaStyle: {
color: {
type: 'linear',
x: 0,
y: 0,
x2: 0,
y2: 1,
colorStops: [
{
offset: 0,
color: 'rgba(36,173,254, 0.5)',
}, {
offset: 1,
color: 'rgba(52,112,252, 0.1)',
},
],
},
},
}]
Echarts外环饼图
- 效果图
-
关注点
- 内圈含有间隔数据
- 外圈效果
-
配置项
// 数据处理
// 间隔空白数据
const gapData = {
name: '',
value: 20,
itemStyle: {
color: 'transparent', // 颜色设置为透明数据
},
};
// 计算饼图渲染数据
const seriesData = [];
[
{ value: 1048, name: 'Search Engine' },
{ value: 735, name: 'Direct' },
{ value: 580, name: 'Email' },
{ value: 484, name: 'Union Ads' },
{ value: 300, name: 'Video Ads' }
].forEach((item) => {
seriesData.push(item);
seriesData.push(gapData);
});
// 图表配置项
series: [
// 内圆环配置项
{
data: seriesData,
roundCap: true,
center: ['50%', '50%'],
radius: ['50%', '60%'],
label: {
show: false,
position: 'center',
},
}，
// 外圆环配置项
{
type: 'pie',
name: '旋转圆',
silent: true,
center: ['50%', '50%'],
radius: ['70%', '69%'],
hoverAnimation: false,
startAngle: 50,
// Notes：这里的数据根据要展示的外环段数及长短自定义设置
data:[120, 40, 120, 40, 120, 40].map((item, index) => ({
value: item,
name: '',
itemStyle: {
color: index % 2 === 0 ? '#5999E1' : 'transparent',
shadowBlur: 20,
shadowColor: '#86C6FD',
},
})),
label: {
normal: {
show: false,
},
},
labelLine: {
normal: {
show: false,
},
},
}
],
Echarts 渐变色柱状图
- 效果图
-
关注点
- 柱体颜色渐变
-
配置项
series: [
{
data: [120, 200, 150, 80, 70, 110, 130],
type: 'bar',
// 设置柱体颜色渐变
itemStyle: {
normal: {
color: new echarts.graphic.LinearGradient(0, 0, 0, 1, [
{
offset: 1,
color: '#20517E',
opacity: 0.85,
},
{
offset: 0,
color: '#3FC0F7',
opacity: 0.79,
},
]),
},
},
label: {
show: true,
color:'#3FC0F7',
fontSize: 12,
position: 'outside',
},
}
]
Echarts含图片标签渐变色柱状图
- 效果图
-
关注项
- 渐变色柱体
- 高亮结尾
- 数据标签含背景图
-
配置项
option = {
backgroundColor:'#17243A',
tooltip: {
trigger: 'axis',
axisPointer: {
type: 'shadow'
}
},
grid: {
left: '3%',
right: '4%',
bottom: '3%',
containLabel: true
},
xAxis: {
type: 'value',
boundaryGap: [0, 0.01]
},
yAxis: [
{
inverse: true,
axisLabel: {
color: '#ADCBE9',
fontSize: 20,
formatter: (value) => {
if (value.length < 8) {
return value;
}
return `${value.substring(0, 8)}...`;
},
},
axisLine: {
lineStyle: {
color: 'transparent',
},
},
data: ['Mon', 'Tue', 'Wed', 'Thu', 'Fri', 'Sat', 'Sun']
}, {
inverse: true,
axisTick: 'none',
axisLine: 'none',
axisLabel: {
show: true,
fontSize: 20,
fontWeight: 'bold',
color: '#BFD1E3',
padding: [5, 12, 5, 12],
backgroundColor: {
},
},
data: [120, 200, 150, 80, 70, 110, 130],
},
],
series: [
{
type: 'pictorialBar',
symbolOffset: [20, -5],
symbolSize: [40, 40],
symbolPosition: 'end',
z: 12,
data: [120, 200, 150, 80, 70, 110, 130],
}, {
name: '',
type: 'bar',
showBackground: true,
yAxisIndex: 0,
barWidth: 7,
barBorderRadius: 10,
data: [120, 200, 150, 80, 70, 110, 130].map((value, index) => ({
value,
itemStyle: {
normal: {
color: {
type: 'linear',
x: 0,
y: 0,
x2: 1,
y2: 0,
colorStops: [
{
offset: 0,
color: '#2F3E56',
},
{
offset: 1,
color:'#7BB1EE',
},
],
},
},
},
})),
},
]
};
Echarts立体柱状图
- 效果图
-
关注点
- 三面立体
- 柱体渐变
-
配置项
// 自定义图形 // 绘制左侧面 export const CubeLeft = echarts.graphic.extendShape({ shape: { x: 0, y: 0, }, buildPath (ctx, shape) { const xAxisPoint = shape.xAxisPoint; const c0 = [shape.x, shape.y]; const c1 = [shape.x - offsetX, shape.y - offsetY]; const c2 = [xAxisPoint[0] - offsetX, xAxisPoint[1] - offsetY]; const c3 = [xAxisPoint[0], xAxisPoint[1]]; ctx.moveTo(c0[0], c0[1]).lineTo(c1[0], c1[1]).lineTo(c2[0], c2[1]).lineTo(c3[0], c3[1]) .closePath(); }, }); // 绘制右侧面 export const CubeRight = echarts.graphic.extendShape({ shape: { x: 0, y: 0, }, buildPath (ctx, shape) { const xAxisPoint = shape.xAxisPoint; const c1 = [shape.x, shape.y]; const c2 = [xAxisPoint[0], xAxisPoint[1]]; const c3 = [xAxisPoint[0] + offsetX, xAxisPoint[1] - offsetY]; const c4 = [shape.x + offsetX, shape.y - offsetY]; ctx.moveTo(c1[0], c1[1]).lineTo(c2[0], c2[1]).lineTo(c3[0], c3[1]).lineTo(c4[0], c4[1]) .closePath(); }, }); // 绘制顶面 export const CubeTop = echarts.graphic.extendShape({ shape: { x: 0, y: 0, }, buildPath (ctx, shape) { const c1 = [shape.x, shape.y]; const c2 = [shape.x + offsetX, shape.y - offsetY]; // 右点 const c3 = [shape.x, shape.y - offsetX]; const c4 = [shape.x - offsetX, shape.y - offsetY]; ctx.moveTo(c1[0], c1[1]).lineTo(c2[0], c2[1]).lineTo(c3[0], c3[1]).lineTo(c4[0], c4[1]) .closePath(); }, });function getRenderItem(param, type) { const colorList = ['#66C9F2', '#80D1CD', '#9BD977']; const color = colorList[param.dataIndex % 3]; const rgba = color16ToRGBA(color, type === 'top' ? 0.6 : 0.01); return { fill: new echarts.graphic.LinearGradient(0, 0, 0, 1, [ { offset: 1, color: rgba, }, { offset: 0, color, }, ]), }; }// 图表配置项 config = { xAxis: { axisLine: { lineStyle: { color: 'transparent', }, }, axisLabel: { color: '#B1CBD8', fontSize: 20, }, }, yAxis: { show: false, splitLine: { show: false, }, }, series:[ { type: 'custom', // 使用自定义的图形进行绘制 renderItem: (params, api) => { const location = api.coord([api.value(0), api.value(1)]); return { type: 'group', children: [ { type: 'CubeLeft', // 绘制左侧面 shape: { api, xValue: api.value(0), yValue: api.value(1), x: location[0], y: location[1], xAxisPoint: api.coord([api.value(0), 0]), }, style: { ...getRenderItem(params), }, }, { type: 'CubeRight', // 绘制右侧面 shape: { api, xValue: api.value(0), yValue: api.value(1), x: location[0], y: location[1], xAxisPoint: api.coord([api.value(0), 0]), }, style: { ...getRenderItem(params), }, }, { type: 'CubeTop', // 绘制顶层 shape: { api, xValue: api.value(0), yValue: api.value(1), x: location[0], y: location[1], xAxisPoint: api.coord([api.value(0), 0]), }, style: { ...getRenderItem(params, 'top'), }, }, ], }; }, data: [120, 200, 150, 80, 70, 110, 130], }, { type: 'bar', label: { normal: { show: true, position: 'top', formatter: e => `${e.value}%`, fontSize: 15, color: '#fff', offset: [0, -15], }, }, itemStyle: { color: 'transparent', }, tooltip: {}, data: [120, 200, 150, 80, 70, 110, 130], }, ] }
CSS旋转圆动画效果
- 效果图
-
关注点
- 背景图渐变
- 旋转动画
-
实现
<div class="value">
<span>{{ item.value }}</span>
<span class="unit">%</span>
</div>
/** 定义旋转动画 **/
@keyframes rotate {
100% {
transform: rotate(360deg);
}
}
.value {
width: 9vh;
height: 9vh;
line-height: 9vh;
text-align: center;
position: relative;
margin: auto;
border-radius: 50%;
/** 设置元素背景径向渐变色 **/
background: radial-gradient(50% 50% at 50% 50%, rgba(12, 27, 48, 0.1) 0%, rgba(12, 27, 48, 0.1) 49%, rgba(116, 217, 229, 0.1) 98%);
text-align: center;
.unit {
font-size: 1.4vh;
position: absolute;
margin-top: 3px;
margin-left: 3px;
}
/** 添加外环元素 **/
&::before,
&::after {
content: "";
position: absolute;
top: -1.5vh;
left: -1.5vh;
bottom: -1.5vh;
right: -1.5vh;
border-radius: 50%;
border-top: 3px solid #58A7B4;
/** 为外环元素添加旋转动画 **/
animation: rotate 6s infinite linear;
}
/** 第二个半圆添加动画延迟3S，使两个动画可以交替执行 **/
&::after {
animation-delay: 3s;
}
}
CSS元素浮动漂浮效果
- 效果图
- 实现
/** 定义浮动动画 **/
@keyframes float {
0% {
transform: translateY(0);
}
50% {
transform: translateY(-20px);
}
100% {
transform: translateY(0);
}
}
/** 为元素整体添加动画 **/
.indicator{
...其他样式项
animation: float 3s infinite ease-in-out;
/** 往后每个元素的动画执行延迟2s，保证不同的漂浮幅度 **/
&.indicator2{
animation-delay: 2s;
}
&.indicator3{
animation-delay: 4s;
}
&.indicator4{
animation-delay: 6s;
}
}
字体渐变色
- 效果
-
关注点
- 背景绘制区域：background-clip
-
实现
span {
/** 设置字体的背景色为径向渐变色 **/
background: linear-gradient(180deg, #F5F5F5 0%, #7EB8E6 100%);
/** 将背景作用区域更新为文本，背景被裁剪为文字的形状 **/
background-clip: text;
-webkit-background-clip: text;
-webkit-text-fill-color: transparent;
/** 文字本身设置为透明色 **/
color: transparent;
}
其他
动态渲染大屏模块
-
背景
一般大屏页面会显示多个小模块，在不同的场景下分别配置显示哪几个。当前由接口提供一组要渲染的模块值，需要根据接口动态设置要渲染的内容
-
实现方式
由Vue component动态组件进行渲染
-
从接口获取一组模块名称：comList
-
对comList进行遍历，使用component :is 进行匹配渲染
-
注意组件的name名称，使用:is匹配时，需要字段值于之一致
<template v-for="name in comList"> <component :is="name" :key="name"/> </template> -
定时器更新图表数据
-
背景
所有图表数据量较多，不宜一次性展示全部，而是分组进行循环展示。即每次展示5条数据，间隔一定时间后切换至下5条数据，以此循环。
-
实现方式
在顶层App.vue组件中，开启一个定时器，并使用
moduleTimerCount字段记录当前的组别数，按时间间隔更新该字段。并在子组件中监听该字段，该字段变化时计算当前子组件需要显示的数据条数，并更细图表数据。- 声明
moduleTimerCount变量
data(){ return { moduleTimerCount:0 } }- 开启一个定时器
使用
setTimeout模拟setInterval定时器（相比于setInterval，setTimeout每次执行完当前次任务后才会执行下一次任务，不存在任务堆积问题，每次执行完后自行清理、独立调用，内存泄露的风险较低）。```JavaScript function openModuleRefresh(delay) { const execute = () => { this.moduleTimerCount += 1; if (moduleRefreshTime) { clearTimeout(moduleRefreshTime); } moduleRefreshTime = setTimeout(execute, delay * 1000); }; setTimeout(execute, delay * 1000); // 首次延迟执行 }, ```3. 子组件监听字段变化
```JavaScript watch: { moduleTimerCount(value) { if (dataList) { // 当前接口数据的数据长度 const dataLength = dataList.length; // 每5个分一组，计算组别数 const totalGroup = Math.ceil(dataLength / 5); // 计算当前组别数，使用 moduleTimerCount 值对组别数取余，保证获取的当前组别不会超过总组别数 this.chartGroupIndex = value % totalGroup; // 计算当前的数据，由组别数获取当前组的数据索引 const startIndex = this.chartGroupIndex * 5; let endIndex = (this.chartGroupIndex + 1) * 5; if (endIndex >= echartsData.data.length) { endIndex = echartsData.data.length; } // 根据索引截取数据 const renderChartData = echartsData.slice(startIndex, endIndex); } }, }, ``` - 声明
