uni-app微信小程序 手写签名【开箱即用】

文章主要介绍了uni-app + vue3 手写签名的完整代码

vue代码：

<template>
    <canvas canvas-id="myCanvas" class="canvas" disable-scroll="true" @touchstart="touchStart" @touchmove="touchMove" @touchend="touchEnd" />
    <cover-view class="row button-container">
        <cover-view class="flex1 button" @click="clear">重写</cover-view>
        <cover-view class="flex1 button margin-left-12" @click="save">提交</cover-view>
    </cover-view>
</template>
<script setup>
import { useDrawSignature } from '@/hooks/index';
import { ref, unref } from 'vue';
import { onLoad } from '@dcloudio/uni-app';
onLoad(() => {});
const { isSigned, touchStart, touchMove, touchEnd, clear } = useDrawSignature('myCanvas');

const save = () => {
    if (!unref(isSigned)) {
        uni.showToast({
            title: '请签名',
            icon: 'none',
        });
        return;
    } else {
        uni.canvasToTempFilePath({
            canvasId: 'myCanvas',
            success: function (res) {
                console.log(res);
                console.log(res.tempFilePath);
            },
        });
    }
};
</script>
<style scoped>
.canvas {
    height: 100vh;
    width: 100vw;
}
.button-container {
    width: 150rpx;
    height: 60rpx;
    position: absolute;
    bottom: 26rpx;
    right: 16rpx;
}

.button {
    font-size: 18rpx;
    height: 26rpx;
    line-height: 26rpx;
    background: white;
    color: #616161ff;
    box-sizing: border-box;
    border-radius: 20rpx;
    margin-top: 2rpx;
    text-align: center;
    border: 1px solid #c9c9c9;
}
</style>

js代码

// 在hooks目录下，新建index.js
import { ref, unref } from 'vue';
import { onLoad } from '@dcloudio/uni-app';

export function useDrawSignature(canvasId) {
    let ctx = null;
    let isButtonDown = false;
    let points = [];
    let isSigned = ref(false);

    onLoad(() => {
        ctx = uni.createCanvasContext(canvasId);
        // 设置画笔样式
        ctx.lineWidth = 4;
        ctx.lineCap = 'round';
        ctx.lineJoin = 'round';
    });

    // 触摸开始，获取到起点
    function touchStart(e) {
        let startPoint = { X: e.changedTouches[0].x, Y: e.changedTouches[0].y };
        points.push(startPoint); // 把起点存起来
        ctx.beginPath(); // 每次触摸开始，开启新的路径
        isButtonDown = true;
    }

    // 触摸移动，获取到路径点
    function touchMove(e) {
        if (isButtonDown) {
            let movePoint = { X: e.changedTouches[0].x, Y: e.changedTouches[0].y };
            points.push(movePoint); // 存点
            let len = points.length;
            if (len >= 2) {
                draw(); // 绘制路径
            }
        }
    }

    // 触摸结束，将未绘制的点清空防止对后续路径产生干扰
    function touchEnd() {
        points = [];
        isButtonDown = false;
    }

    // 绘画
    function draw() {
        let point1 = points[0];
        let point2 = points[1];
        points.shift();
        ctx.moveTo(point1.X, point1.Y);
        ctx.lineTo(point2.X, point2.Y);
        ctx.stroke();
        ctx.draw(true);
        isSigned.value = true;
    }

    function clear() {
        ctx.clearRect(0, 0, 1000, 1000);
        ctx.draw(true);
        isSigned.value = false;
    }

    return {
        isSigned,
        touchStart,
        touchMove,
        touchEnd,
        clear,
    };
}
