一、Sqlserver的安装及开启事务日志

如果没有Sqlserver环境，但你又想学习这块的内容，那你只能自己动手通过docker安装一个 myself sqlserver来用作学习，当然，如果你有现成环境，那就检查一下Sqlserver是否开启了代理(sqlagent.enabled)服务和CDC功能。

1.1 docker拉取镜像

看Github上写Flink-CDC 目前支持的Sqlserver版本为2012, 2014, 2016, 2017, 2019，但我想全部拉到最新（事实证明，2022-latest 和latest是一样的，因为imagId都是一致的，且在后续测试也是没有问题的），所以我在docker上拉取镜像时，直接采用如下命令：

docker pull mcr.microsoft.com/mssql/server:latest
1.2 运行Sqlserver并设置代理

标准启动模式，没什么好说的，主要设置一下密码(密码要求比较严格，建议直接在网上搜个随机密码生成器来搞一下)。

docker run -e 'ACCEPT\_EULA=Y' -e 'SA\_PASSWORD=${your\_password}' \
   -p 1433:1433 --name sqlserver \
   -d mcr.microsoft.com/mssql/server:latest

设置代理sqlagent.enabled,代理设置完成后，需要重启Sqlserver，因为我们是docker安装的，直接用docker restart sqlserver就行了。

[root@hdp-01 ~]# docker exec -it --user root sqlserver bash
root@0274812d0c10:/# /opt/mssql/bin/mssql-conf set sqlagent.enabled true
SQL Server needs to be restarted in order to apply this setting. Please run
'systemctl restart mssql-server.service'.
root@0274812d0c10:/# exit
exit
[root@hdp-01 ~]# docker restart sqlserver
sqlserver
1.3 启用CDC功能

按照如下步骤执行命令，如果看到is_cdc_enabled = 1，则说明当前数据库

root@0274812d0c10:/# /opt/mssql-tools/bin/sqlcmd -S localhost -U SA -P "${your\_password}"
1> create databases test;
2> go
1> use test;
2> go
Changed database context to 'test'.
1> EXEC sys.sp_cdc_enable_db;
2> go
1> SELECT is_cdc_enabled FROM sys.databases WHERE name = 'test';
2> go
is_cdc_enabled
--------------
             1

(1 rows affected)
1> CREATE TABLE t_info (id int,order_date date,purchaser int,quantity int,product_id int,PRIMARY KEY ([id]))
2> go
1>
2>
3> EXEC sys.sp_cdc_enable_table
4> @source_schema = 'dbo',
5> @source_name   = 't\_info',
6> @role_name     = 'cdc\_role';
7> go
Update mask evaluation will be disabled in net_changes_function because the CLR configuration option is disabled.
Job 'cdc.zeus\_capture' started successfully.
Job 'cdc.zeus\_cleanup' started successfully.
1> select * from t_info;
2> go
id          order_date       purchaser   quantity    product_id
----------- ---------------- ----------- ----------- -----------

(0 rows affected)
1.4 检查CDC是否正常开启

用客户端连接Sqlserver，查看test库下的INFORMATION_SCHEMA.TABLES中是否出现TABLE_SCHEMA = cdc的表，如果出现，说明已经成功安装Sqlserver并启用了CDC。

1> use test;

2> go
Changed database context to 'test'.

1> select * from INFORMATION_SCHEMA.TABLES;

2> go


TABLE_CATALOG	TABLE_SCHEMA	TABLE_NAME	       TABLE_TYPE
test	            dbo	      user_info	         BASE TABLE
test	            dbo	      systranschemas	   BASE TABLE
test	            cdc	      change_tables	     BASE TABLE
test	            cdc	      ddl_history	       BASE TABLE
test	            cdc	      lsn_time_mapping	 BASE TABLE
test	            cdc	      captured_columns	 BASE TABLE
test	            cdc	      index_columns	     BASE TABLE
test	            dbo	      orders	           BASE TABLE
test	            cdc	      dbo_orders_CT	     BASE TABLE

二、具体实现

2.1 Flik-CDC采集SqlServer主程序

添加依赖包：

        <dependency>
            <groupId>com.ververica</groupId>
            <artifactId>flink-connector-sqlserver-cdc</artifactId>
            <version>3.0.0</version>
        </dependency>

编写主函数：

    public static void main(String[] args) throws Exception {

        StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();

        // 设置全局并行度
        env.setParallelism(1);
        // 设置时间语义为ProcessingTime
        env.getConfig().setAutoWatermarkInterval(0);
        // 每隔60s启动一个检查点
        env.enableCheckpointing(60000, CheckpointingMode.EXACTLY\_ONCE);
        // checkpoint最小间隔
        env.getCheckpointConfig().setMinPauseBetweenCheckpoints(1000);
        // checkpoint超时时间
        env.getCheckpointConfig().setCheckpointTimeout(60000);
        // 同一时间只允许一个checkpoint
        // env.getCheckpointConfig().setMaxConcurrentCheckpoints(1);
        // Flink处理程序被cancel后，会保留Checkpoint数据
        // env.getCheckpointConfig().setExternalizedCheckpointCleanup(CheckpointConfig.ExternalizedCheckpointCleanup.RETAIN\_ON\_CANCELLATION);


        SourceFunction<String> sqlServerSource = SqlServerSource.<String>builder()
                .hostname("localhost")
                .port(1433)
                .username("SA")
                .password("")
                .database("test")
                .tableList("dbo.t\_info")
                .startupOptions(StartupOptions.initial())
                .debeziumProperties(getDebeziumProperties())
                .deserializer(new CustomerDeserializationSchemaSqlserver())
                .build();

        DataStreamSource<String> dataStreamSource = env.addSource(sqlServerSource, "\_transaction\_log\_source");
        dataStreamSource.print().setParallelism(1);
        env.execute("sqlserver-cdc-test");

    }


        public static Properties getDebeziumProperties() {
        Properties properties = new Properties();
        properties.put("converters", "sqlserverDebeziumConverter");
        properties.put("sqlserverDebeziumConverter.type", "SqlserverDebeziumConverter");
        properties.put("sqlserverDebeziumConverter.database.type", "sqlserver");
        // 自定义格式，可选
        properties.put("sqlserverDebeziumConverter.format.datetime", "yyyy-MM-dd HH:mm:ss");
        properties.put("sqlserverDebeziumConverter.format.date", "yyyy-MM-dd");
        properties.put("sqlserverDebeziumConverter.format.time", "HH:mm:ss");
        return properties;
    }
2.2 自定义Sqlserver反序列化格式：

Flink-CDC底层技术为debezium，它捕获到Sqlserver数据变更(CRUD)的数据格式如下：

#初始化
Struct{after=Struct{id=1,order_date=2024-01-30,purchaser=1,quantity=100,product_id=1},source=Struct{version=1.9.7.Final,connector=sqlserver,name=sqlserver_transaction_log_source,ts_ms=1706574924473,snapshot=true,db=zeus,schema=dbo,table=orders,commit_lsn=0000002b:00002280:0003},op=r,ts_ms=1706603724432}

#新增
Struct{after=Struct{id=12,order_date=2024-01-11,purchaser=6,quantity=233,product_id=63},source=Struct{version=1.9.7.Final,connector=sqlserver,name=sqlserver_transaction_log_source,ts_ms=1706603786187,db=zeus,schema=dbo,table=orders,change_lsn=0000002b:00002480:0002,commit_lsn=0000002b:00002480:0003,event_serial_no=1},op=c,ts_ms=1706603788461}


#更新
Struct{before=Struct{id=12,order_date=2024-01-11,purchaser=6,quantity=233,product_id=63},after=Struct{id=12,order_date=2024-01-11,purchaser=8,quantity=233,product_id=63},source=Struct{version=1.9.7.Final,connector=sqlserver,name=sqlserver_transaction_log_source,ts_ms=1706603845603,db=zeus,schema=dbo,table=orders,change_lsn=0000002b:00002500:0002,commit_lsn=0000002b:00002500:0003,event_serial_no=2},op=u,ts_ms=1706603850134}


#删除
Struct{before=Struct{id=11,order_date=2024-01-11,purchaser=6,quantity=233,product_id=63},source=Struct{version=1.9.7.Final,connector=sqlserver,name=sqlserver_transaction_log_source,ts_ms=1706603973023,db=zeus,schema=dbo,table=orders,change_lsn=0000002b:000025e8:0002,commit_lsn=0000002b:000025e8:0005,event_serial_no=1},op=d,ts_ms=1706603973859}

因此，可以根据自己需要自定义反序列化格式，将数据按照标准统一数据输出，下面是我自定义的格式，供大家参考：

import com.alibaba.fastjson2.JSON;
import com.alibaba.fastjson2.JSONObject;
import com.alibaba.fastjson2.JSONWriter;
import com.ververica.cdc.debezium.DebeziumDeserializationSchema;
import io.debezium.data.Envelope;
import org.apache.flink.api.common.typeinfo.BasicTypeInfo;
import org.apache.flink.api.common.typeinfo.TypeInformation;
import org.apache.flink.util.Collector;
import org.apache.kafka.connect.data.Field;
import org.apache.kafka.connect.data.Schema;
import org.apache.kafka.connect.data.Struct;
import org.apache.kafka.connect.source.SourceRecord;

import java.util.HashMap;
import java.util.Map;

public class CustomerDeserializationSchemaSqlserver implements DebeziumDeserializationSchema<String> {

    private static final long serialVersionUID = -1L;


    @Override
    public void deserialize(SourceRecord sourceRecord, Collector collector) {
        Map<String, Object> resultMap = new HashMap<>();
        String topic = sourceRecord.topic();
        String[] split = topic.split("[.]");
        String database = split[1];
        String table = split[2];
        resultMap.put("db", database);
        resultMap.put("tableName", table);
        //获取操作类型
        Envelope.Operation operation = Envelope.operationFor(sourceRecord);
        //获取数据本身
        Struct struct = (Struct) sourceRecord.value();
        Struct after = struct.getStruct("after");
        Struct before = struct.getStruct("before");
        String op = operation.name();
        resultMap.put("op", op);

        //新增,更新或者初始化
        if (op.equals(Envelope.Operation.CREATE.name()) || op.equals(Envelope.Operation.READ.name()) || op.equals(Envelope.Operation.UPDATE.name())) {
            JSONObject afterJson = new JSONObject();
            if (after != null) {
                Schema schema = after.schema();
                for (Field field : schema.fields()) {
                    afterJson.put(field.name(), after.get(field.name()));
                }
                resultMap.put("after", afterJson);
            }
        }

        if (op.equals(Envelope.Operation.DELETE.name())) {
            JSONObject beforeJson = new JSONObject();
            if (before != null) {
                Schema schema = before.schema();
                for (Field field : schema.fields()) {
                    beforeJson.put(field.name(), before.get(field.name()));
                }
                resultMap.put("before", beforeJson);
            }
        }

        collector.collect(JSON.toJSONString(resultMap, JSONWriter.Feature.FieldBased, JSONWriter.Feature.LargeObject));

    }

    @Override
    public TypeInformation<String> getProducedType() {
        return BasicTypeInfo.STRING\_TYPE\_INFO;
    }

}
2.3 自定义日期格式转换器

debezium会将日期转为5位数字，日期时间转为13位的数字，因此我们需要根据Sqlserver的日期类型转换成标准的时期或者时间格式。Sqlserver的日期类型主要包含以下几种：

字段类型快照类型(jdbc type)cdc类型(jdbc type)
DATEjava.sql.Date(91)java.sql.Date(91)
TIMEjava.sql.Timestamp(92)java.sql.Time(92)
DATETIMEjava.sql.Timestamp(93)java.sql.Timestamp(93)
DATETIME2java.sql.Timestamp(93)java.sql.Timestamp(93)
DATETIMEOFFSETmicrosoft.sql.DateTimeOffset(-155)microsoft.sql.DateTimeOffset(-155)
SMALLDATETIMEjava.sql.Timestamp(93)java.sql.Timestamp(93)
import io.debezium.spi.converter.CustomConverter;
import io.debezium.spi.converter.RelationalColumn;
import org.apache.kafka.connect.data.SchemaBuilder;
import java.time.ZoneOffset;
import java.time.format.DateTimeFormatter;
import java.util.Properties;

@Sl4j
public class SqlserverDebeziumConverter implements CustomConverter<SchemaBuilder, RelationalColumn> {



    private static final String DATE\_FORMAT = "yyyy-MM-dd";
