struct android_namespace_link_t
private: std::string name_; namespace名称 bool is_isolated_; 是否隔离（大部分是true) std::vectorstd::string ld_library_paths_; 链接路径 std::vectorstd::string default_library_paths_;默认可访问路径 std::vectorstd::string permitted_paths_;已允许访问路径 ....
我们来看一看，这个数据结构在哪里会被使用到，其实就是so库加载过程。当我们调用System.loadLibrary的时候，其实最终调用的是
private synchronized void loadLibrary0(ClassLoader loader, Class<?> callerClass, String libname) { 文件名校验 if (libname.indexOf((int)File.separatorChar) != -1) { throw new UnsatisfiedLinkError( "Directory separator should not appear in library name: " + libname); } String libraryName = libname; // Android-note: BootClassLoader doesn't implement findLibrary(). http://b/111850480 // Android's class.getClassLoader() can return BootClassLoader where the RI would // have returned null; therefore we treat BootClassLoader the same as null here. if (loader != null && !(loader instanceof BootClassLoader)) { String filename = loader.findLibrary(libraryName); if (filename == null && (loader.getClass() == PathClassLoader.class || loader.getClass() == DelegateLastClassLoader.class)) { // Don't give up even if we failed to find the library in the native lib paths. // The underlying dynamic linker might be able to find the lib in one of the linker // namespaces associated with the current linker namespace. In order to give the // dynamic linker a chance, proceed to load the library with its soname, which // is the fileName. // Note that we do this only for PathClassLoader and DelegateLastClassLoader to // minimize the scope of this behavioral change as much as possible, which might // cause problem like b/143649498. These two class loaders are the only // platform-provided class loaders that can load apps. See the classLoader attribute // of the application tag in app manifest. filename = System.mapLibraryName(libraryName); } if (filename == null) { // It's not necessarily true that the ClassLoader used // System.mapLibraryName, but the default setup does, and it's // misleading to say we didn't find "libMyLibrary.so" when we // actually searched for "liblibMyLibrary.so.so". throw new UnsatisfiedLinkError(loader + " couldn't find "" + System.mapLibraryName(libraryName) + """); } String error = nativeLoad(filename, loader); if (error != null) { throw new UnsatisfiedLinkError(error); } return; }
// We know some apps use mLibPaths directly, potentially assuming it's not null. // Initialize it here to make sure apps see a non-null value. getLibPaths(); String filename = System.mapLibraryName(libraryName); 最终调用nativeLoad String error = nativeLoad(filename, loader, callerClass); if (error != null) { throw new UnsatisfiedLinkError(error); } }
这里我们注意到，抛出UnsatisfiedLinkError的时机，要么so文件名加载不合法，要么就是nativeLoad方法返回了错误信息，这里是需要我们注意的，我们如果出现这个异常，可以从这里排查，nativeLoad方法最终通过LoadNativeLibrary，在native层真正进入so的加载过程
LoadNativeLibrary 非常长，我们截取部分 bool JavaVMExt::LoadNativeLibrary(JNIEnv* env, const std::string& path, jobject class_loader, jclass caller_class, std::string* error_msg) {
会判断是否已经加载过当前so，同时也要加锁，因为存在多线程加载的情况
SharedLibrary* library; Thread* self = Thread::Current(); { // TODO: move the locking (and more of this logic) into Libraries. MutexLock mu(self, *Locks::jni_libraries_lock_); library = libraries_->Get(path); }
调用OpenNativeLibrary加载 void* handle = android::OpenNativeLibrary( env, runtime_->GetTargetSdkVersion(), path_str, class_loader, (caller_location.empty() ? nullptr : caller_location.c_str()), library_path.get(), &needs_native_bridge, &nativeloader_error_msg);
这里又是漫长的native方法，OpenNativeLibrary，在这里我们终于见到namespace了
void* OpenNativeLibrary(JNIEnv* env, int32_t target_sdk_version, const char* path, jobject class_loader, const char* caller_location, jstring library_path, bool* needs_native_bridge, char** error_msg) { #if defined(ART_TARGET_ANDROID) UNUSED(target_sdk_version);
if (class_loader == nullptr) { needs_native_bridge = false; if (caller_location != nullptr) { android_namespace_t boot_namespace = FindExportedNamespace(caller_location); if (boot_namespace != nullptr) { const android_dlextinfo dlextinfo = { .flags = ANDROID_DLEXT_USE_NAMESPACE, .library_namespace = boot_namespace, }; 最终调用android_dlopen_ext打开 void* handle = android_dlopen_ext(path, RTLD_NOW, &dlextinfo); if (handle == nullptr) { *error_msg = strdup(dlerror()); } return handle; } }
// Check if the library is in NATIVELOADER_DEFAULT_NAMESPACE_LIBS and should // be loaded from the kNativeloaderExtraLibs namespace. { Result<void*> handle = TryLoadNativeloaderExtraLib(path); if (!handle.ok()) { *error_msg = strdup(handle.error().message().c_str()); return nullptr; } if (handle.value() != nullptr) { return handle.value(); } }
// Fall back to the system namespace. This happens for preloaded JNI // libraries in the zygote. // TODO(b/185833744): Investigate if this should fall back to the app main // namespace (aka anonymous namespace) instead. void* handle = OpenSystemLibrary(path, RTLD_NOW); if (handle == nullptr) { *error_msg = strdup(dlerror()); } return handle; }
std::lock_guardstd::mutex guard(g_namespaces_mutex); NativeLoaderNamespace* ns; 涉及到了namespace，如果当前classloader没有，则创建，但是这属于异常情况 if ((ns = g_namespaces->FindNamespaceByClassLoader(env, class_loader)) == nullptr) { // This is the case where the classloader was not created by ApplicationLoaders // In this case we create an isolated not-shared namespace for it. Result<NativeLoaderNamespace*> isolated_ns = CreateClassLoaderNamespaceLocked(env, target_sdk_version, class_loader, /is_shared=/false, /dex_path=/nullptr, library_path, /permitted_path=/nullptr, /uses_library_list=/nullptr); if (!isolated_ns.ok()) { *error_msg = strdup(isolated_ns.error().message().c_str()); return nullptr; } else { ns = *isolated_ns; } }
return OpenNativeLibraryInNamespace(ns, path, needs_native_bridge, error_msg);
这里我们打断一下，我们看到上面代码分析，如果当前classloader的namespace如果为null，则创建，这里我们也知道一个信息，namespace是跟classloader绑定的。同时我们也知道，classloader在创建的时候，其实就会绑定一个namespace。我们在app加载的时候，就会通过LoadedApk这个class去加载一个pathclassloader
frameworks/base/core/java/android/app/LoadedApk.java
if (!mIncludeCode) { if (mDefaultClassLoader == null) { StrictMode.ThreadPolicy oldPolicy = allowThreadDiskReads(); mDefaultClassLoader = ApplicationLoaders.getDefault().getClassLoader( "" /* codePath /, mApplicationInfo.targetSdkVersion, isBundledApp, librarySearchPath, libraryPermittedPath, mBaseClassLoader, null / classLoaderName */); setThreadPolicy(oldPolicy); mAppComponentFactory = AppComponentFactory.DEFAULT; }
if (mClassLoader == null) { mClassLoader = mAppComponentFactory.instantiateClassLoader(mDefaultClassLoader, new ApplicationInfo(mApplicationInfo)); }
return; }
之后ApplicationLoaders.getDefault().getClassLoader会调用createClassLoader
public static ClassLoader createClassLoader(String dexPath, String librarySearchPath, String libraryPermittedPath, ClassLoader parent, int targetSdkVersion, boolean isNamespaceShared, String classLoaderName, List sharedLibraries, List nativeSharedLibraries, List sharedLibrariesAfter) {
final ClassLoader classLoader = createClassLoader(dexPath, librarySearchPath, parent, classLoaderName, sharedLibraries, sharedLibrariesAfter);
String sonameList = ""; if (nativeSharedLibraries != null) { sonameList = String.join(":", nativeSharedLibraries); }
Trace.traceBegin(Trace.TRACE_TAG_ACTIVITY_MANAGER, "createClassloaderNamespace"); 这里就讲上述的属性传入，创建了一个属于该classloader的namespace String errorMessage = createClassloaderNamespace(classLoader, targetSdkVersion, librarySearchPath, libraryPermittedPath, isNamespaceShared, dexPath, sonameList); Trace.traceEnd(Trace.TRACE_TAG_ACTIVITY_MANAGER);
if (errorMessage != null) { throw new UnsatisfiedLinkError("Unable to create namespace for the classloader " + classLoader + ": " + errorMessage); }
return classLoader; }
这里我们得到的主要消息是，我们的classloader的namespace，里面的so检索路径，其实都在创建的时候就被定下来了（这个也是，为什么想要实现so动态加载，其中的一个方案就是替换classloader的原因，因为我们当前使用的classloader的namespace检索路径，已经是固定了，后续对classloader本身的检索路径添加，是不会同步给namespace的，只有创建的时候才会同步）
好了，我们继续回到OpenNativeLibrary，内部其实调用android_dlopen_ext打开
void* android_dlopen_ext(const char* filename, int flag, const android_dlextinfo* extinfo) { const void* caller_addr = __builtin_return_address(0); return __loader_android_dlopen_ext(filename, flag, extinfo, caller_addr); }
这里不知道大家有没有觉得眼熟，这里肯定最终调用就是dlopen，只不过谷歌为了限制dlopen的调起方，采用了__builtin_return_address 内建函数作为卡口，限制了普通app调哟dlopen（这里也是有破解方法的）
之后的经历android_dlopen_ext -> dlopen_ext ->do_dlopen，最终到了最后加载的方法了
void* do_dlopen(const char* name, int flags, const android_dlextinfo* extinfo, const void* caller_addr) { std::string trace_prefix = std::string("dlopen: ") + (name == nullptr ? "(nullptr)" : name); ScopedTrace trace(trace_prefix.c_str()); ScopedTrace loading_trace((trace_prefix + " - loading and linking").c_str()); soinfo* const caller = find_containing_library(caller_addr); // 找到调用者，属于哪个namespace android_namespace_t* ns = get_caller_namespace(caller);
