exception when others then execute sql_str using NEW; return null; end; end;
create trigger tri\_ins\_auth\_detail BEFORE insert on tb\_auth\_detail for each row EXECUTE PROCEDURE func\_tri\_auth\_detail();
-- tb\_auth\_detail权限记录表进行表分区设置:end
-- 定义ID自增序列---------------------------------------------------------------------------------------------------
alter table tb\_auth\_detail alter column auth\_detail\_id set default nextval('seq\_auth\_detail');
-- 添加索引---------------------------------------------------------------------------------------------------
create index idx\_auth\_detail\_person\_id on tb\_auth\_detail (person\_id);
create index idx\_auth\_detail\_dept\_id on tb\_auth\_detail (dept\_id);
create index idx\_auth\_detail\_dev\_id on tb\_auth\_detail (dev\_id);
create index idx\_auth\_detail\_door\_id on tb\_auth\_detail (door\_id);
create index idx\_auth\_detail\_sdev\_group\_id on tb\_auth\_detail (dev\_group\_id);
create index idx\_auth\_detail\_config\_time on tb\_auth\_detail (config\_time);
```
```
模拟数据构造：
```
```
-- N:数据量
-- 随机截取: N=1
select substr('cc3483bf-9d1f-4eaa-a6e2-a376ba312ff1',1,(random()\*26)::integer);
-- 随机复制: N=1
select repeat('cc3483bf-9d1f-4eaa-a6e2-a376ba312ff1',(random()\*40)::integer);
-- 生成序列
SELECT \* FROM generate\_series(1,5);
select id from generate\_series(1,10) t(id); -- 自定义column
-- 生成随机数
select (random()\*100)::int from generate\_series(1,10);
-- 序列、随机字符串、时间戳
select generate\_series(1,100000),md5(random()::text),clock\_timestamp();
-- 生成时间
SELECT date(generate\_series(now(), now() + '1 week', '1 day'));
-- 模拟随机数据
select
md5(random()::text) as person\_id,
md5(random()::text) as dept\_id,
md5(random()::text) as dev\_id,
md5(random()::text) as door\_id,
floor(random()\*2)+1 as auth\_status,
floor(random()\*3)+1 as finger\_status,
floor(random()\*4)+1 as face\_status,
floor(random()\*5)+1 as del\_card\_number,
md5(random()::text) as auth\_person\_schedule\_id,
md5(random()::text) as auth\_dept\_schedule\_id,
md5(random()::text) as auth\_person\_grp\_schedule\_id,
clock\_timestamp() as config\_time,
clock\_timestamp() as download\_time,
md5(random()::text) as dev\_group\_id,
md5(random()::text) as download\_code
from
generate\_series(1,10,1);
```
```
数据插入Example
```
```
explain analyze insert into tb\_auth\_detail(
"person\_id",
"dept\_id",
"dev\_id",
"door\_id",
"auth\_status",
"finger\_status",
"face\_status",
"del\_card\_number",
"auth\_person\_schedule\_id",
"auth\_dept\_schedule\_id",
"auth\_person\_grp\_schedule\_id",
"config\_time",
"download\_time",
"dev\_group\_id",
"download\_code"
)
select
floor(random()\*1000000)+1 as person\_id,
floor(random()\*1000000)+1 as dept\_id,
floor(random()\*1000000)+1 as dev\_id,
floor(random()\*1000000)+1 as door\_id,
floor(random()\*2)+1 as auth\_status,
floor(random()\*3)+1 as finger\_status,
floor(random()\*4)+1 as face\_status,
floor(random()\*5)+1 as del\_card\_number,
floor(random()\*1000000)+1 as auth\_person\_schedule\_id,
floor(random()\*1000000)+1 as auth\_dept\_schedule\_id,
floor(random()\*1000000)+1 as auth\_person\_grp\_schedule\_id,
clock\_timestamp() as config\_time,
now() as download\_time,
floor(random()\*200)+1 as dev\_group\_id,
floor(random()\*1000000)+1 as download\_code
from
generate\_series(1,100000,1);
```
##### 性能分析
```
1.创建相同表结构的tb_auth_detail_all不进行分表
2.分别插入10W、100W、1000W数据进行测试
```
>
> 10W 数据
>
>
>
**`插入性能分析`**
* 分表
```
-- 0数据[初次建分区表耗时]
Insert on tb\_auth\_detail (cost=0.00..242.50 rows=1000 width=120) (actual time=118005.833..118005.833 rows=0 loops=1)
-> Subquery Scan on "\*SELECT\*" (cost=0.00..242.50 rows=1000 width=120) (actual time=18.495..7147.848 rows=100000 loops=1)
-> Function Scan on generate\_series (cost=0.00..145.00 rows=1000 width=0) (actual time=14.280..461.711 rows=100000 loops=1)
Planning time: 0.248 ms
Trigger tri\_ins\_auth\_detail: time=110770.614 calls=100000
Execution time: 118008.532 ms
```
```
-- 已有10W
Insert on tb\_auth\_detail (cost=0.00..242.50 rows=1000 width=120) (actual time=33649.149..33649.149 rows=0 loops=1)
-> Subquery Scan on "\*SELECT\*" (cost=0.00..242.50 rows=1000 width=120) (actual time=13.439..1652.186 rows=100000 loops=1)
-> Function Scan on generate\_series (cost=0.00..145.00 rows=1000 width=0) (actual time=13.396..411.380 rows=100000 loops=1)
Planning time: 0.187 ms
Trigger tri\_ins\_auth\_detail: time=31926.839 calls=100000
Execution time: 33651.926 ms
```
* 单表
```
-- 0数据
Insert on tb\_auth\_detail\_all (cost=0.00..242.50 rows=1000 width=120) (actual time=14424.540..14424.540 rows=0 loops=1)
-> Subquery Scan on "\*SELECT\*" (cost=0.00..242.50 rows=1000 width=120) (actual time=20.354..1273.261 rows=100000 loops=1)
-> Function Scan on generate\_series (cost=0.00..145.00 rows=1000 width=0) (actual time=19.205..273.179 rows=100000 loops=1)
Planning time: 0.552 ms
Execution time: 14429.240 ms
```
```
-- 已有10W
Insert on tb\_auth\_detail\_all (cost=0.00..242.50 rows=1000 width=120) (actual time=25942.760..25942.760 rows=0 loops=1)
-> Subquery Scan on "\*SELECT\*" (cost=0.00..242.50 rows=1000 width=120) (actual time=14.394..1307.630 rows=100000 loops=1)
-> Function Scan on generate\_series (cost=0.00..145.00 rows=1000 width=0) (actual time=14.282..283.456 rows=100000 loops=1)
Planning time: 0.281 ms
Execution time: 25948.271 ms
```
**`搜索性能分析`**
* 分表
```
explain analyze select \* from tb\_auth\_detail\_all;
Seq Scan on tb_auth_detail_all (cost=0.00..2635.00 rows=100000 width=86) (actual time=0.007..6.387 rows=100000 loops=1)
Planning time: 2.292 ms
Execution time: 7.462 ms
```
* 单表
```
explain analyze select \* from tb\_auth\_detail;
-> Seq Scan on tb_auth_detail_172 (cost=0.00..14.22 rows=522 width=86) (actual time=0.004..0.172 rows=522 loops=1)
....
-> Seq Scan on tb_auth_detail_100 (cost=0.00..14.06 rows=506 width=86) (actual time=0.004..0.099 rows=506 loops=1)
-> Seq Scan on tb_auth_detail_72 (cost=0.00..12.80 rows=480 width=86) (actual time=0.005..0.197 rows=480 loops=1)
Planning time: 419.074 ms
Execution time: 79.472 ms
```
**`配置约束`**
>
> 官网解释 (避免扫描 PostgreSQL 分区表所有分区 )
>
>
>
```
constraint_exclusion 的含义是：当PG生产执行计划时是否考虑表上的约束，这个参数有三个选项
"off,on ,partition" ，默认参数为 off, 意思不使用表上的 constraint 来生成计划，如果设置成
on ,则对所有表生效，生成 PLAN 时会考虑表上的 constraint, 建议设置成 partition,只对分区表
生效，从而避免扫描分区表所有分区。
```
```
-- constraint\_exclusion = partition # on, off, or partition
set constraint\_exclusion = off;
```
>
> 10W数据
>
>
>
`插入`
```
-- off
Insert on tb\_auth\_detail\_all (cost=0.00..242.50 rows=1000 width=120) (actual time=7993.545..7993.545 rows=0 loops=1)
-> Subquery Scan on "\*SELECT\*" (cost=0.00..242.50 rows=1000 width=120) (actual time=13.112..1516.601 rows=100000 loops=1)
-> Function Scan on generate\_series (cost=0.00..145.00 rows=1000 width=0) (actual time=12.765..287.764 rows=100000 loops=1)
Planning time: 0.402 ms
Execution time: 7997.900 ms
```
```
-- on
Insert on tb\_auth\_detail\_all (cost=0.00..242.50 rows=1000 width=120) (actual time=8746.615..8746.615 rows=0 loops=1)
-> Subquery Scan on "\*SELECT\*" (cost=0.00..242.50 rows=1000 width=120) (actual time=13.932..1342.997 rows=100000 loops=1)
-> Function Scan on generate\_series (cost=0.00..145.00 rows=1000 width=0) (actual time=13.331..275.213 rows=100000 loops=1)
Planning time: 0.732 ms
Execution time: 8751.193 ms
```
```
-- partition
Insert on tb\_auth\_detail\_all (cost=0.00..242.50 rows=1000 width=120) (actual time=10885.670..10885.670 rows=0 loops=1)
-> Subquery Scan on "\*SELECT\*" (cost=0.00..242.50 rows=1000 width=120) (actual time=14.209..1342.818 rows=100000 loops=1)
-> Function Scan on generate\_series (cost=0.00..145.00 rows=1000 width=0) (actual time=14.165..290.517 rows=100000 loops=1)
Planning time: 0.124 ms
Execution time: 10888.549 ms
```
`搜索`
```
explain analyze select * from tb_auth_detail where dev_group_id = 21;
```
```
-- off
Append (cost=0.00..882.51 rows=1176 width=87) (actual time=10.694..13.909 rows=976 loops=1)
-> Seq Scan on tb_auth_detail (cost=0.00..0.00 rows=1 width=1464) (actual time=0.003..0.003 rows=0 loops=1)
Filter: (dev_group_id = 21)
-> Index Scan using idx_tb_auth_detail_192_sid on tb_auth_detail_192 (cost=0.28..4.29 rows=1 width=86) (actual time=0.215..0.215 rows=0 loops=1)
Index Cond: (dev_group_id = 21)
...
-> Index Scan using idx_tb_auth_detail_39_sid on tb_auth_detail_39 (cost=0.28..4.29 rows=1 width=86) (actual time=0.041..0.041 rows=0 loops=1)
Index Cond: (dev_group_id = 21)
Planning time: 652.183 ms
Execution time: 17.949 ms
```
```
-- on
Append (cost=0.00..28.20 rows=977 width=87) (actual time=0.110..1.498 rows=976 loops=1)
-> Seq Scan on tb_auth_detail (cost=0.00..0.00 rows=1 width=1464) (actual time=0.003..0.003 rows=0 loops=1)
Filter: (dev_group_id = 21)
-> Seq Scan on tb_auth_detail_21 (cost=0.00..28.20 rows=976 width=86) (actual time=0.105..1.472 rows=976 loops=1)
Filter: (dev_group_id = 21)
Planning time: 536.421 ms
Execution time: 2.257 ms
```
```
-- partition
Append (cost=0.00..28.20 rows=977 width=87) (actual time=0.009..0.170 rows=976 loops=1)
-> Seq Scan on tb_auth_detail (cost=0.00..0.00 rows=1 width=1464) (actual time=0.001..0.001 rows=0 loops=1)
Filter: (dev_group_id = 21)
-> Seq Scan on tb_auth_detail_21 (cost=0.00..28.20 rows=976 width=86) (actual time=0.007..0.153 rows=976 loops=1)
Filter: (dev_group_id = 21)
Planning time: 409.550 ms
Execution time: 0.841 ms
```
```
explain analyze select * from tb_auth_detail_all where dev_group_id = 20;
```
```
-- off
Bitmap Heap Scan on tb_auth_detail_all (cost=68.16..2746.17 rows=999 width=86) (actual time=1.079..48.217 rows=993 loops=1)
Recheck Cond: (dev_group_id = 20)
Heap Blocks: exact=876
-> Bitmap Index Scan on idx_auth_detail_all_sdev_group_id (cost=0.00..67.91 rows=999 width=0) (actual time=0.901..0.901 rows=993 loops=1)
Index Cond: (dev_group_id = 20)
Planning time: 2.386 ms
Execution time: 48.690 ms
```
```
-- on
Append (cost=0.00..28.20 rows=977 width=87) (actual time=0.110..1.498 rows=976 loops=1)
-> Seq Scan on tb_auth_detail (cost=0.00..0.00 rows=1 width=1464) (actual time=0.003..0.003 rows=0 loops=1)
Filter: (dev_group_id = 21)
-> Seq Scan on tb_auth_detail_21 (cost=0.00..28.20 rows=976 width=86) (actual time=0.105..1.472 rows=976 loops=1)
Filter: (dev_group_id = 21)
Planning time: 536.421 ms
Execution time: 2.257 ms
```
```
-- partition
Bitmap Heap Scan on tb_auth_detail_all (cost=68.16..2746.17 rows=999 width=86) (actual time=0.195..0.751 rows=993 loops=1)
Recheck Cond: (dev_group_id = 20)
Heap Blocks: exact=876
-> Bitmap Index Scan on idx_auth_detail_all_sdev_group_id (cost=0.00..67.91 rows=999 width=0) (actual time=0.112..0.112 rows=993 loops=1)
Index Cond: (dev_group_id = 20)
Planning time: 0.138 ms
Execution time: 0.889 ms
```
>
> 分析约束对于搜索的影响
>
>
>
* 必须将constraint\_exclusion设置为on或partition，否则planner将无法正常跳过不符合条件的分区表，也即无法发挥表分区的优势
(当constraint\_exclusion为on或者partition时，查询计划器会根据分区表的检查限制将对主表的查询限制在符合检查限制条件的分区表上，直接避免了对不符合条件的分区表的扫描。)
* 单表(10W)情况下，性能差异不大
* 分表(10W)情况下，开启约束对于有where条件子句的可以明显提高性能。
#### 其他方案
* 使用Rule将对主表的插入请求重定向到对应的子表
```
CREATE RULE almart\_rule\_2015\_12\_31 AS
ON INSERT TO almart
WHERE
date\_key = DATE '2015-12-31'
DO INSTEAD
INSERT INTO almart\_2015\_12\_31 VALUES (NEW.\*);
```
>
> 与Trigger相比，Rule会带来更大的额外开销，但每个请求只造成一次开销而非每条数据都引入一次开销，所以该方法对大批量的数据插入操作更具优势。然而，实际上在绝大部分场景下，Trigger比Rule的效率更高。同时，COPY操作会忽略Rule，而可以正常触发Trigger。另外，如果使用Rule方式，没有比较简单的方法处理没有被Rule覆盖到的插入操作。此时该数据会被插入到主表中而不会报错，从而无法有效利用表分区的优势。除了使用表继承外，还可使用UNION ALL的方式达到表分区的效果。
>
>
>
```
CREATE VIEW almart AS
SELECT \* FROM almart\_2015\_12\_10
UNION ALL
SELECT \* FROM almart\_2015\_12\_11
UNION ALL
SELECT \* FROM almart\_2015\_12\_12
...
