`Android`自定义`View`

简单复习一下Android中自定义View的流程:

创建一个类CustomView继承自View然后实现如下方法:

onDraw方法: 进行绘制操作, 确定自身的内容
onMeasure方法: 进行测量操作, 确定自身的大小, 位置由parent决定
onTouchEvent方法: 进行手势处理

class CustomView(context: Context, attrs: AttributeSet?) : View(context, attrs) {

    override fun onTouchEvent(event: MotionEvent?): Boolean {
        //进行手势处理
        return super.onTouchEvent(event)
    }

    override fun onMeasure(widthMeasureSpec: Int, heightMeasureSpec: Int) {
        //进行测量操作, 确定自身的大小, 位置由parent决定
    }

    override fun onDraw(canvas: Canvas) {
        //进行绘制操作, 确定自身的内容
    }

}

自定义属性通过xml配置:

<?xml version="1.0" encoding="utf-8"?>
<resources>
    <declare-styleable name="CustomView">
        <attr name="custom_attr" format="boolean" />
    </declare-styleable>
</resources>

这样一个自定义View就实现了...

`Flutter`自定义`Widget`

那么在Flutter中, 怎么自定义Widget呢? 准确来说, 应该是自定义RenderObject.

这里请忽略CustomPaint小部件...

class CustomRenderObject extends RenderBox {

  @override
  bool hitTestSelf(Offset position) {
    return true;
  }

  @override
  void handleEvent(PointerEvent event, BoxHitTestEntry entry) {
    //进行手势处理, 这里需要注意的是,
    //如果想要`handleEvent`方法被回调, 那么`hitTestSelf`必须返回true
  }

  @override
  void performLayout() {
    //进行测量操作, 确定自身的大小, 位置由parent决定
  }

  @override
  void paint(PaintingContext context, Offset offset) {
    //进行绘制操作, 确定自身的内容
  }
}

class CustomWidget extends LeafRenderObjectWidget {
  const CustomWidget({super.key});

  @override
  RenderObject createRenderObject(BuildContext context) {
    return CustomRenderObject();
  }
}

这里的CustomWidget相对于Android中自定义View的配置属性.

注意

如果想要handleEvent回调, 那么hitTestSelf方法必须返回true, 否则不会触发.

总结

	Android	Flutter
绘制入口	View.onDraw	RenderObject.paint
测量入口	View.onMeasure	RenderObject.performLayout
手势入口	View.onTouchEvent	RenderObject.handleEvent
属性配置	xml	Widget
`绘制相关`	`Canvas`	`PaintingContext.canvas`
绘制`图像`	Canvas.drawBitmap	Canvas.drawImage
绘制`图形`	Canvas.drawPath	Canvas.drawPath
绘制`文本`	Canvas.drawText	TextPainter.paint
触发`重新绘制`	View.invalidate	RenderObject.markNeedsPaint
触发`重新布局`	View.requestLayout	RenderObject.markNeedsLayout

完整示例代码:

class CustomWidget extends LeafRenderObjectWidget {
  const CustomWidget({super.key});

  @override
  RenderObject createRenderObject(BuildContext context) {
    return CustomRenderObject();
  }
}

/// [RenderSliver]
class CustomRenderObject extends RenderBox {
  Offset localPosition = Offset.zero;

  @override
  bool hitTestSelf(Offset position) {
    return true;
  }

  @override
  void handleEvent(PointerEvent event, BoxHitTestEntry entry) {
    //进行手势处理, 这里需要注意的是,
    //如果想要`handleEvent`方法被回调, 那么`hitTestSelf`必须返回true
    localPosition = event.localPosition;
    markNeedsPaint();
    //markNeedsLayout();
  }

  @override
  void performLayout() {
    //进行测量操作, 确定自身的大小, 位置由parent决定
    size = constraints.constrain(const Size(100, 100));
  }

  @override
  void paint(PaintingContext context, Offset offset) {
    //进行绘制操作, 确定自身的内容
    //context.canvas.drawImage(image, offset, paint);
    //context.canvas.drawPath(path, paint);
    //TextPainter()..layout()..paint(canvas, offset);

    context.canvas.drawRect(
      paintBounds.shift(offset),
      Paint()
        ..style = PaintingStyle.stroke
        ..color = Colors.purpleAccent,
    );

    context.canvas.drawCircle(
      localPosition + offset,
      10,
      Paint()
        ..style = PaintingStyle.fill
        ..color = Colors.purpleAccent,
    );

    TextPainter(
        text: TextSpan(
          text: localPosition.toString(),
          style: const TextStyle(
            color: Colors.purpleAccent,
            fontSize: 8,
          ),
        ),
        textDirection: TextDirection.ltr)
      ..layout()
      ..paint(context.canvas, offset);
  }
}

这里介绍一下LeafRenderObjectWidget SingleChildRenderObjectWidget和MultiChildRenderObjectWidget的区别:

类名	说明
LeafRenderObjectWidget	不接受任何子`Widget`
SingleChildRenderObjectWidget	接受一个子`Widget`
MultiChildRenderObjectWidget	接受一组子`Widget`

附加

RenderObject有2个关键的子类RenderBox和RenderSliver

RenderBox对应的是BoxConstraints约束, 也叫盒子约束; RenderSliver对应的是SliverConstraints约束, 也叫条子约束;

BoxConstraints

const BoxConstraints({
  this.minWidth = 0.0,
  this.maxWidth = double.infinity,
  this.minHeight = 0.0,
  this.maxHeight = double.infinity,
});

盒子约束, 就是简单的约束大小使用. 这个在Flutter非常常见, 也是用得最多的一种约束.只要宽高即可.

SliverConstraints

const SliverConstraints({
  required this.axisDirection,
  required this.growthDirection,
  required this.userScrollDirection,
  required this.scrollOffset,
  required this.precedingScrollExtent,
  required this.overlap,
  required this.remainingPaintExtent,
  required this.crossAxisExtent,
  required this.crossAxisDirection,
  required this.viewportMainAxisExtent,
  required this.remainingCacheExtent,
  required this.cacheOrigin,
});
