规则引擎简单使用

背景

某项规则分类或是校验规则繁多，使用规则引擎将业务规则与代码逻辑解耦。

规则引擎

使用liteflow.cc/实现

1. 具体使用

1. 操作

• 引入依赖：

<dependency>
    <groupId>com.yomahub</groupId>
    <artifactId>liteflow-spring-boot-starter</artifactId>
    <version>2.12.2.1</version>
</dependency>

• 在yaml文件中配置规则文件

liteflow:
  rule-source: config/flow.el.xml

• 定义规则文件

<?xml version="1.0" encoding="UTF-8"?>
<flow>
    <chain name="chain1">
        THEN(a, b, c);
    </chain>

</flow>

• 注入FlowExecutor直接使用

@Autowired
private FlowExecutor flowExecutor;

2. ### 案例实现

现在需要实现的逻辑是根据入参的code值，选择对应的价格

• 实体类：

//用于传参赋值的实体类
@Data
public class TestEntity{

    String code;

    String price;
}
//FlowExecutor接口所需的流程初始参数，此处无实际含义
@Data
public class FirstParam {
    String param;
}

• 定义规则文件：

<?xml version="1.0" encoding="UTF-8"?>
<flow>
<!--    选择组件-->
    <chain name="chooseModule">
        SWITCH(judgeCode).to(basic, higher, lower).DEFAULT(basic);
    </chain>
</flow>

• 组件：

package com.betterwood.user.cmp.test2;

import com.betterwood.user.cmp.FirstParam;
import com.betterwood.user.cmp.TestEntity;
import com.yomahub.liteflow.annotation.LiteflowComponent;
import com.yomahub.liteflow.core.NodeSwitchComponent;
import org.springframework.stereotype.Component;

/**
* @description :
* @author : wenjingwang
*/
@LiteflowComponent("judgeCode")//选择组件
public class JudgeCodeCmp extends NodeSwitchComponent {

    @Override
    public String processSwitch() throws Exception {
        FirstParam firstParam = this.getRequestData();
        TestEntity testEntity = this.getContextBean(TestEntity.class);
        return testEntity.getCode();
    }
}

package com.betterwood.user.cmp.test2;

import com.betterwood.user.cmp.FirstParam;
import com.betterwood.user.cmp.TestEntity;
import com.yomahub.liteflow.core.NodeComponent;
import org.springframework.stereotype.Component;

/**
* @description :
* @author : wenjingwang
*/
@Component("basic")//基础价格
public class BasicCmp extends NodeComponent {
    @Override
    public void process() {
        FirstParam firstParam = this.getRequestData();
        TestEntity testEntity = this.getContextBean(TestEntity.class);
        testEntity.setPrice("10.0");
    }
}

package com.betterwood.user.cmp.test2;

import com.betterwood.user.cmp.FirstParam;
import com.betterwood.user.cmp.TestEntity;
import com.yomahub.liteflow.core.NodeComponent;
import org.springframework.stereotype.Component;

/**
* @description :
* @author : wenjingwang
*/
@Component("higher")//更高价格
public class HigherCmp extends NodeComponent {
    @Override
    public void process()  {
        FirstParam firstParam = this.getRequestData();
        TestEntity testEntity = this.getContextBean(TestEntity.class);
        testEntity.setPrice("20.0");
    }
}

package com.betterwood.user.cmp.test2;

import com.betterwood.user.cmp.FirstParam;
import com.betterwood.user.cmp.TestEntity;
import com.yomahub.liteflow.core.NodeComponent;
import org.springframework.stereotype.Component;

/**
* @description :
* @author : wenjingwang
*/
@Component("lower") //更低价格
public class LowerCmp extends NodeComponent {
    @Override
    public void process() {
        FirstParam firstParam = this.getRequestData();
        TestEntity testEntity = this.getContextBean(TestEntity.class);
        testEntity.setPrice("5.0");
    }
}

• 测试方法：

@PostMapping("/check/testPrice")
public void testPrice(@RequestBody TestEntity testEntity){
    FirstParam firstParam = new FirstParam();
    LiteflowResponse response = flowExecutor.execute2Resp("chooseModule", firstParam, testEntity);
    System.out.println("testEntity的价格为:"+testEntity.getPrice());
}

• 测试结果：
