该篇文章仅用于学习记录，复制博客，代码运行不起来的可以去参考原博主的：blog.csdn.net/xzy__007/ar…
方便后期用到找起来比较方便
- 功能介绍
- 默认展示主地图，点击某个省市区根据地区编码展示对应的省市区地图，当匹配不到对应的省市区编码则展示主地图。
- 根据地理位置坐标加标记。
-
功能实现
2.1 需要用到的省市区编码json数据 www.jianshu.com/p/add50f649…
2.2 初始化
<template>
<div>
<div id="echatsMap" style="width: 100%; height: 800px"></div>
</div>
</template>
<script>
import * as echarts from "echarts";
import axios from "axios";
import { cityCode } from "@/components/cityCode.js";
export default {
name: "echatsMap",
components: {},
data() {
return {
cityCode: cityCode,
myChart: "",
distributionOptions: "",
};
},
mounted() {},
methods: {},
};
</script>
2.3 创建地图 此处会用到外部链接来获取地图JSON数据（100000是主视图的地区编码）：datav.aliyun.com/portal/scho… 传递不同的编码，会返回不同省市区的JSON数据。
在json文件中添加：
// 在里面加上 用来改变文字展示坐标点
"cp": [ 103.823557, 36.058039 ],
修改后就不能用动态获取了，需要存放到本地，让其使用本地的文件示例如下（具体改哪来，）
// 初始化地图数据
init() {
// 主地图的JSON文件下载
let path = require('../../../../../public/mapJson/china.json');
echarts.registerMap("china", path );
this.changeOptions("china");
this.myChart = echarts.init(document.querySelector("#echatsMap"));
this.myChart.setOption(this.distributionOptions)
window.onresize = function () {
if (this.myChart) this.myChart.resize();
};
},
代码实现：
<template>
<div>
<div id="echatsMap" style="width: 100%; height: 800px"></div>
</div>
</template>
<script>
import * as echarts from "echarts";
import axios from "axios";
import { cityCode } from "@/components/cityCode.js";
export default {
name: "echatsMap",
components: {},
data() {
return {
cityCode: cityCode,
myChart: "",
distributionOptions: "",
};
},
mounted() {
this.$nextTick(() => {
this.init();
});
},
methods: {
// 初始化地图数据
init() {
// 主地图的JSON文件下载
let path = `https://geo.datav.aliyun.com/areas_v3/bound/100000_full.json`;
axios.get(path).then((res) => {
echarts.registerMap("china", res.data);
this.changeOptions("china");
this.myChart = echarts.init(document.querySelector("#echatsMap"));
this.myChart.setOption(this.distributionOptions)
});
window.onresize = function () {
if (this.myChart) this.myChart.resize();
};
},
// echarts 配置项
changeOptions(name) {
// 经纬度数据
const seriesList = [
{
data: [{ value: [106.9, 27.7] }, { value: [105.29, 27.32] }],
},
];
// 图标
const series = seriesList.map((v) => {
return {
type: "scatter", //配置显示方式为用户自定义
coordinateSystem: "geo",
data: v.data,
// 自定义图标的样式 支持svg与bse64
symbol: function (params, key) {
return "image://" + require("@/assets/logo.png");
},
symbolSize: 16,
};
});
// options
this.distributionOptions = {
tooltip: {
// 提示框组件
show: true, // 显示提示框组件
trigger: "item", // 触发类型
triggerOn: "mousemove", // 触发条件
formatter: "名称:{b}<br/>坐标:{c}",
},
series, // 数据
geo: {
map: name || "china", // 引入地图 省份或者 国家
layoutCenter: ["50%", "50%"], //设置后left/right/top/bottom等属性无效
layoutSize: "45%",
roam: true, //开启鼠标缩放
zoom: 2,
label: {
normal: {
//静态的时候展示样式
show: true, //是否显示地图省份得名称
textStyle: {
color: "#fff",
fontSize: 10,
fontFamily: "Arial",
},
},
emphasis: {
// 高亮状态下的样式
//动态展示的样式
color: "#fff",
},
},
itemStyle: {
// 地图区域的多边形 图形样式。
normal: {
borderColor: "#fff", // 边框颜色
areaColor: "#1c2f59", // 区域颜色
// areaColor: { // 使用背景图片
// type: "pattern",
// image: require("@/assets/texture.jpeg"), // 使用自己本地图片路径
// repeat: "repeat", //可选值repeat、no-repeat、repeat-x、repeat-y
// },
textStyle: {
// 文字颜色
color: "#fff",
},
// shadowBlur: 10, // 图形阴影的模糊大小
// shadowOffsetX: 10, // 阴影水平方向上的偏移距离。
},
emphasis: {
areaColor: "#1c2f59",
color: "#fff",
},
},
regions: [
//对不同的区块进行着色
// {
// name: "河南省", //区块名称
// itemStyle: {
// normal: {
// areaColor: "#281fe1",
// },
// },
// },
// {
// name: "浙江省", //区块名称
// itemStyle: {
// normal: {
// areaColor: "#193094",
// },
// },
// },
],
},
};
},
},
};
</script>
2.4 点击地图省市区展示省市区地图
- 大概就是点击省市区时根据名称与编码文件去匹配，把匹配到的编码通过外部接口去获取想要的省市区JSON地图数据。再次渲染echarts即可。
注意：如果没匹配到需跳主地图/获取不到此区域的JSON地图数据。2.5 china版地图完整代码
<template>
<div>
<div id="echatsMap" style="width: 100%; height: 800px"></div>
</div>
</template>
<script>
import * as echarts from "echarts";
import axios from "axios";
import { cityCode } from "@/components/cityCode.js";
export default {
name: "echatsMap",
components: {},
data() {
return {
cityCode: cityCode,
myChart: "",
distributionOptions: "",
};
},
mounted() {
this.$nextTick(() => {
this.init();
});
},
methods: {
// 初始化地图数据
init() {
// 主地图的JSON文件下载
let path = `https://geo.datav.aliyun.com/areas_v3/bound/100000_full.json`;
axios.get(path).then((res) => {
echarts.registerMap("china", res.data);
this.changeOptions("china");
this.myChart = echarts.init(document.querySelector("#echatsMap"));
this.myChart.setOption(this.distributionOptions);
// 点击省份子区域的时候可以切换到省份地图
this.myChart.on("click", (chinaParam) => {
// 如果没有下层则展示主地图
if (!this.cityCode) {
this.cityCode = cityCode;
// 100000 主地图
this.getProvinceMapOpt(100000, "")
return;
}
// 根据点击位置地图名字去跟编码数据匹配
let code = this.cityCode.find(
(x) => chinaParam.name.indexOf(x ? x.name : "") !== -1
);
// 找到正确的编码 去获取对应的地图数据
// 将该省市区的下级放入 -- 如果接口支持根据编码查询省市区所有下级子级就不需要这么写
if (code) {
this.cityCode = code.city;
this.getProvinceMapOpt(Number(code.adcode), chinaParam.name);
} else {
// 没有对应的编码跳主地图
this.cityCode = cityCode;
// 100000 主地图
this.getProvinceMapOpt(100000, "");
}
});
});
window.onresize = function () {
if (this.myChart) this.myChart.resize();
};
},
// 下载/显示各省地图
getProvinceMapOpt(provinceAlphabet, name) {
// 根据地区编码获取所在地区的JSON地图
let path = `https://geo.datav.aliyun.com/areas_v3/bound/${provinceAlphabet}_full.json`;
if (provinceAlphabet === 100000) {
path = "/mapJson/china.json";
}
axios.get(path).then((res) => {
// 获取完最新的JSON地图数据后，重新渲染
echarts.registerMap(name, res.data);
this.changeOptions(name);
this.myChart.setOption(this.distributionOptions, true);
});
},
// echarts 配置项
changeOptions(name) {
// 经纬度数据 --- 不存在的经纬度不会展示出来
const seriesList = [
{
data: [{ value: [106.9, 27.7] }, { value: [105.29, 27.32] }],
},
];
// 图标
const series = seriesList.map((v) => {
return {
type: "scatter", //配置显示方式为用户自定义
coordinateSystem: "geo",
data: v.data,
// 自定义图标的样式 支持svg与bse64
symbol: function (params, key) {
return "image://" + require("@/assets/logo.png");
},
symbolSize: 16,
};
});
// options
this.distributionOptions = {
tooltip: {
// 提示框组件
show: true, // 显示提示框组件
trigger: "item", // 触发类型
triggerOn: "mousemove", // 触发条件
formatter: "名称:{b}<br/>坐标:{c}",
},
series, // 数据
geo: {
map: name || "china", // 引入地图 省份或者 国家
layoutCenter: ["50%", "50%"], //设置后left/right/top/bottom等属性无效
layoutSize: "45%",
roam: true, //开启鼠标缩放
zoom: 2,
label: {
normal: {
//静态的时候展示样式
show: true, //是否显示地图省份得名称
textStyle: {
color: "#fff",
fontSize: 10,
fontFamily: "Arial",
},
},
emphasis: {
// 高亮状态下的样式
//动态展示的样式
color: "#fff",
},
},
itemStyle: {
// 地图区域的多边形 图形样式。
normal: {
borderColor: "#fff", // 边框颜色
areaColor: "#1c2f59", // 区域颜色
textStyle: {
// 文字颜色
color: "#fff",
},
// shadowBlur: 10, // 图形阴影的模糊大小
// shadowOffsetX: 10, // 阴影水平方向上的偏移距离。
},
emphasis: {
areaColor: "#1c2f59",
color: "#fff",
},
},
regions: [
//对不同的区块进行着色
// {
// name: "河南省", //区块名称
// itemStyle: {
// normal: {
// areaColor: "#281fe1",
// },
// },
// },
// {
// name: "浙江省", //区块名称
// itemStyle: {
// normal: {
// areaColor: "#193094",
// },
// },
// },
],
},
};
},
},
};
</script>
- 展示某个省的地图 3.1 展示某个省的地图的话，要做一些修改
- 修改默认请求的Json数据
- 修改默认展示的地图名字等
3.2 展示到县级别 县级别以上都是用的 geo.datav.aliyun.com/areas_v3/bo… 以下将以 4 展示某个省的地图完整代码进行修改
3.2.1 添加县级以上请求地图数据失败捕获
添加错误捕获
// 下载/显示各省地图
getProvinceMapOpt (provinceAlphabet, name) {
// console.log(provinceAlphabet);
// 根据地区编码获取所在地区的JSON地图
let path = `https://geo.datav.aliyun.com/areas_v3/bound/${provinceAlphabet}_full.json`;
// if (provinceAlphabet === 420000) {
// path = "/mapJson/china.json";
// }
axios.get(path).then((res) => {
// 获取完最新的JSON地图数据后，重新渲染
echarts.registerMap(name, res.data);
this.changeOptions(name);
this.myChart.setOption(this.distributionOptions, true);
}).catch((error) => {
// 请求出错时的处理逻辑 - 此时有可能是请求到县了，县的请求地址跟其他层级请求地址不一样
console.error('请求出错:', error);
});
},
添加请求县级的JSON地图数据方法
// 获取县级别的地图数据
getProvinceMapOptCounty (provinceAlphabet, name) {
// 根据地区编码获取所在地区的JSON地图
let path = `https://geo.datav.aliyun.com/areas_v3/bound/${provinceAlphabet}.json`;
axios.get(path).then((res) => {
// 获取完最新的JSON地图数据后，重新渲染
echarts.registerMap(name, res.data);
this.changeOptions(name);
this.myChart.setOption(this.distributionOptions, true);
}).catch((error) => {
// 请求出错时的处理逻辑 - 此时有可能是请求到县了，县的请求地址跟其他层级请求地址不一样
console.error('请求出错:', error);
});
},
- 此时在县级别以上获取数据失败时去请求，并记录此时请求到了县级别（因为没有县级以下的数据了，再点击县的话就返回第一级）
- 需要再点击县的话就返回第一级代码
data () {
return {
geoCounty: false,
}
}
// 初始化地图数据
init () {
// 主地图的JSON文件下载
let path = `https://geo.datav.aliyun.com/areas_v3/bound/420000_full.json`;
axios.get(path).then((res) => {
echarts.registerMap("湖北省", res.data);
this.changeOptions("湖北省");
this.myChart = echarts.init(document.querySelector("#echatsMap"));
this.myChart.setOption(this.distributionOptions);
// 点击省份子区域的时候可以切换到省份地图
this.myChart.on("click", (chinaParam) => {
// 如果没有下层则展示主地图
if (!this.cityCode) {
this.cityCode = cityCode;
// 420000 主地图
this.geoCounty = false
this.getProvinceMapOpt(420000, "")
return;
}
// 根据点击位置地图名字去跟编码数据匹配
let code = this.cityCode.find(
(x) => chinaParam.name.indexOf(x ? x.name : "") !== -1
);
// console.log(chinaParam.name,'---',code);
// 找到正确的编码 去获取对应的地图数据
// 将该省市区的下级放入 -- 如果接口支持根据编码查询省市区所有下级子级就不需要这么写
if (code) {
// 判断是否请求到了县级别
if (!this.geoCounty) {
this.getProvinceMapOpt(Number(code.adcode), chinaParam.name);
} else {
// this.getProvinceMapOptCounty(Number(code.adcode), chinaParam.name);
// 已经没有再下层的数据了，再点击返回主视图
this.cityCode = cityCode;
// 420000 主地图
this.geoCounty = false
this.getProvinceMapOpt(420000, "湖北省");
}
} else {
// 没有对应的编码跳主地图
this.cityCode = cityCode;
// 420000 主地图
this.geoCounty = false
this.getProvinceMapOpt(420000, "湖北省");
}
});
});
window.onresize = function () {
if (this.myChart) this.myChart.resize();
};
},
// 下载/显示各省地图
getProvinceMapOpt (provinceAlphabet, name) {
console.log(provinceAlphabet);
// 根据地区编码获取所在地区的JSON地图
let path = `https://geo.datav.aliyun.com/areas_v3/bound/${provinceAlphabet}_full.json`;
// if (provinceAlphabet === 420000) {
// path = "/mapJson/china.json";
// }
axios.get(path).then((res) => {
// 获取完最新的JSON地图数据后，重新渲染
echarts.registerMap(name, res.data);
this.changeOptions(name);
this.myChart.setOption(this.distributionOptions, true);
}).catch((error) => {
this.geoCounty = true
// 请求出错时的处理逻辑 - 此时有可能是请求到县了，县的请求地址跟其他层级请求地址不一样
this.getProvinceMapOptCounty(provinceAlphabet, name)
// console.error('请求出错:', error);
});
},
// 获取县级别的地图数据
getProvinceMapOptCounty (provinceAlphabet, name) {
// 根据地区编码获取所在地区的JSON地图
let path = `https://geo.datav.aliyun.com/areas_v3/bound/${provinceAlphabet}.json`;
axios.get(path).then((res) => {
// 获取完最新的JSON地图数据后，重新渲染
echarts.registerMap(name, res.data);
this.changeOptions(name);
this.myChart.setOption(this.distributionOptions, true);
}).catch((error) => {
// 请求出错时的处理逻辑 - 此时有可能是请求到县了，县的请求地址跟其他层级请求地址不一样
console.error('请求出错:', error);
});
},
- 不需要再点击县的话就返回第一级
// 下载/显示各省地图
getProvinceMapOpt (provinceAlphabet, name) {
// 根据地区编码获取所在地区的JSON地图
let path = `https://geo.datav.aliyun.com/areas_v3/bound/${provinceAlphabet}_full.json`;
// if (provinceAlphabet === 420000) {
// path = "/mapJson/china.json";
// }
axios.get(path).then((res) => {
// 获取完最新的JSON地图数据后，重新渲染
echarts.registerMap(name, res.data);
this.changeOptions(name);
this.myChart.setOption(this.distributionOptions, true);
}).catch((error) => {
this.geoCounty = true
// 请求出错时的处理逻辑 - 此时有可能是请求到县了，县的请求地址跟其他层级请求地址不一样
this.getProvinceMapOptCounty(provinceAlphabet, name)
// console.error('请求出错:', error);
});
},
// 获取县级别的地图数据
getProvinceMapOptCounty (provinceAlphabet, name) {
// 根据地区编码获取所在地区的JSON地图
let path = `https://geo.datav.aliyun.com/areas_v3/bound/${provinceAlphabet}.json`;
axios.get(path).then((res) => {
// 获取完最新的JSON地图数据后，重新渲染
echarts.registerMap(name, res.data);
this.changeOptions(name);
this.myChart.setOption(this.distributionOptions, true);
}).catch((error) => {
// 请求出错时的处理逻辑 - 此时有可能是请求到县了，县的请求地址跟其他层级请求地址不一样
console.error('请求出错:', error);
});
},
完整代码：【默认带再点击县的话就返回第一级】
<template>
<div>
<div id="echatsMap" style="width: 100%; height: 800px"></div>
</div>
</template>
<script>
import * as echarts from "echarts";
import axios from "axios";
import { cityCode } from "@/utils/cityCode.js";
export default {
name: "echatsMap",
components: {},
data() {
return {
cityCode: cityCode,
myChart: "",
distributionOptions: "",
geographicalCoordinates: [
{ name: "荆州市", value: [112.239741, 30.335165] },
],
// geoCounty: false,
};
},
mounted() {
this.$nextTick(() => {
this.init();
});
},
// 展示某个省的地图的话:
// 1. 修改默认请求的Json数据
// 2. 修改默认展示的地图名字等
methods: {
// 初始化地图数据
init() {
// 主地图的JSON文件下载
let path = `https://geo.datav.aliyun.com/areas_v3/bound/100000_full.json`;
axios.get(path).then((res) => {
echarts.registerMap("china", res.data);
this.changeOptions("china");
this.myChart = echarts.init(document.querySelector("#echatsMap"));
this.myChart.setOption(this.distributionOptions);
// 点击地图省市区展示省市区地图
this.myChart.on("click", (chinaParam) => {
// 如果没有下层则展示主地图
if (!this.cityCode) {
this.cityCode = cityCode;
// 100000 主地图
// this.geoCounty = false;
this.geographicalCoordinates = [
{ name: "荆州市", value: [112.239741, 30.335165] },
];
this.getProvinceMapOpt(100000, "");
return;
}
// 根据点击位置地图名字去跟编码数据匹配
let code = this.cityCode.find(
(x) => chinaParam.name.indexOf(x ? x.name : "") !== -1
);
// 找到正确的编码 去获取对应的地图数据
// 将该省市区的下级放入 -- 如果接口支持根据编码查询省市区所有下级子级就不需要这么写
if (code) {
this.cityCode = code.city;
this.geographicalCoordinates = [];
this.getProvinceMapOpt(Number(code.adcode), chinaParam.name);
// 判断是否请求到了县级别
// if (!this.geoCounty) {
// this.getProvinceMapOpt(Number(code.adcode), chinaParam.name);
// } else {
// // this.getProvinceMapOptCounty(Number(code.adcode), chinaParam.name);
// // 已经没有再下层的数据了，再点击返回主视图
// this.cityCode = cityCode;
// // 420000 主地图
// this.geoCounty = false;
// this.getProvinceMapOpt(100000, "");
// }
} else {
// 没有对应的编码跳主地图
this.cityCode = cityCode;
this.geographicalCoordinates = [
{ name: "荆州市", value: [112.239741, 30.335165] },
];
// this.geoCounty = false;
// 100000 主地图
this.getProvinceMapOpt(100000, "");
}
});
});
window.onresize = function () {
if (this.myChart) this.myChart.resize();
};
},
// 下载/显示各省地图
getProvinceMapOpt(provinceAlphabet, name) {
// 根据地区编码获取所在地区的JSON地图
let path = `https://geo.datav.aliyun.com/areas_v3/bound/${provinceAlphabet}_full.json`;
// if (provinceAlphabet === 100000) {
// path = "/mapJson/china.json";
// }
axios
.get(path)
.then((res) => {
// 获取完最新的JSON地图数据后，重新渲染
echarts.registerMap(name, res.data);
this.changeOptions(name);
this.myChart.setOption(this.distributionOptions, true);
})
.catch((error) => {
// 添加县级以上请求地图数据失败捕获
// 请求出错时的处理逻辑 - 此时有可能是请求到县了，县的请求地址跟其他层级请求地址不一样
console.error("请求出错:", error);
// this.geoCounty = true;
// this.getProvinceMapOptCounty(provinceAlphabet, name);
});
},
// 县级别以上都是用的 https://geo.datav.aliyun.com/areas_v3/bound/${区域编码}_full.json去获取的JSON地图数据，
// 但到了县这个请求地址就变了，变成了https://geo.datav.aliyun.com/areas_v3/bound/${区域编码}.json
// 获取县级别的地图数据
getProvinceMapOptCounty(provinceAlphabet, name) {
// 此时在县级别以上获取数据失败时去请求，并记录此时请求到了县级别（因为没有县级以下的数据了，再点击县的话就返回第一级）
// 需要再点击县的话就返回第一级代码
// 根据地区编码获取所在地区的JSON地图
let path = `https://geo.datav.aliyun.com/areas_v3/bound/${provinceAlphabet}.json`;
axios
.get(path)
.then((res) => {
// 获取完最新的JSON地图数据后，重新渲染
echarts.registerMap(name, res.data);
this.changeOptions(name);
this.myChart.setOption(this.distributionOptions, true);
})
.catch((error) => {
// 请求出错时的处理逻辑 - 此时有可能是请求到县了，县的请求地址跟其他层级请求地址不一样
console.error("请求出错:", error);
});
},
// echarts 配置项
changeOptions(name) {
// 经纬度数据 --- 不存在的经纬度不会展示出来
// const seriesList = [
// {
// data: [{ value: [106.9, 27.7] }, { value: [105.29, 27.32] }],
// },
// ];
const seriesList = [
{
data: this.geographicalCoordinates,
},
];
// 图标
const series = seriesList.map((v) => {
return {
type: "scatter", //配置显示方式为用户自定义
coordinateSystem: "geo",
data: v.data,
// 自定义图标的样式 支持svg与bse64
symbol: function (params, key) {
console.log(params, key);
return "image://" + require("@/assets/logo.png");
},
symbolSize: 16,
tooltip: {
trigger: "item",
// show:false,
formatter: function (params) {
// 自定义 tooltip 内容
return `名称:${params.data.name}<br/>坐标:<br/>经度:${params.data.value[0]}<br/>纬度:${params.data.value[1]}`;
},
},
};
});
// options
this.distributionOptions = {
tooltip: {
// 提示框组件
show: true, // 显示提示框组件
trigger: "item", // 触发类型
triggerOn: "mousemove", // 触发条件
formatter: "名称:{b}<br/>坐标:{c}",
},
series, // 数据
geo: {
map: name || "china", // 引入地图 省份或者 国家
layoutCenter: ["50%", "50%"], //设置后left/right/top/bottom等属性无效
layoutSize: "45%",
roam: true, //开启鼠标缩放
zoom: 2,
label: {
normal: {
//静态的时候展示样式
show: true, //是否显示地图省份得名称
textStyle: {
color: "#fff",
fontSize: 10,
fontFamily: "Arial",
},
},
emphasis: {
// 高亮状态下的样式
//动态展示的样式
color: "#fff",
},
},
itemStyle: {
// 地图区域的多边形 图形样式。
normal: {
borderColor: "rgba(147, 235, 248, 1)", // 边框颜色
borderWidth: 1,
// areaColor: "#1c2f59", // 区域颜色
areaColor: {
type: "radial",
x: 0.5,
y: 0.5,
r: 0.8,
colorStops: [
{
offset: 0,
color: "rgba(147, 235, 248, 0)", // 0% 处的颜色
},
{
offset: 1,
color: "rgba(147, 235, 248, .2)", // 100% 处的颜色
},
],
globalCoord: false, // 缺省为 false
},
// areaColor: { // 使用背景图片
// type: "pattern",
// image: require("@/assets/texture.jpeg"), // 使用自己本地图片路径
// repeat: "repeat", //可选值repeat、no-repeat、repeat-x、repeat-y
// },
shadowColor: "rgba(128, 217, 248, 1)",
// shadowColor: 'rgba(255, 255, 255, 1)',
shadowOffsetX: -2,
shadowOffsetY: 2,
shadowBlur: 10,
textStyle: {
// 文字颜色
color: "#fff",
},
// shadowBlur: 10, // 图形阴影的模糊大小
// shadowOffsetX: 10, // 阴影水平方向上的偏移距离。
},
emphasis: {
areaColor: "#1c2f59",
color: "#fff",
},
},
regions: [
//对不同的区块进行着色
// {
// name: "河南省", //区块名称
// itemStyle: {
// normal: {
// areaColor: "#281fe1",
// },
// },
// },
// {
// name: "浙江省", //区块名称
// itemStyle: {
// normal: {
// areaColor: "#193094",
// },
// },
// },
],
},
};
},
},
};
</script>
数据：
// cityCode.js
export const cityCode = [
{
name: "安徽",
adcode: "340000",
city: [
{
adcode: "340100",
name: "合肥",
},
{
adcode: "340200",
name: "芜湖",
},
{
adcode: "340300",
name: "蚌埠",
},
{
adcode: "340400",
name: "淮南",
},
{
adcode: "340500",
name: "马鞍山",
},
{
adcode: "340600",
name: "淮北",
},
{
adcode: "340700",
name: "铜陵",
},
{
adcode: "340800",
name: "安庆",
},
{
adcode: "341000",
name: "黄山",
},
{
adcode: "341100",
name: "滁州",
},
{
adcode: "341200",
name: "阜阳",
},
{
adcode: "341300",
name: "宿州",
},
{
adcode: "341500",
name: "六安",
},
{
adcode: "341600",
name: "亳州",
},
{
adcode: "341700",
name: "池州",
},
{
adcode: "341800",
name: "宣城",
},
],
},
{
name: "福建",
adcode: "350000",
city: [
{
adcode: "350100",
name: "福州",
},
{
adcode: "350200",
name: "厦门",
},
{
adcode: "350300",
name: "莆田",
},
{
adcode: "350400",
name: "三明",
},
{
adcode: "350500",
name: "泉州",
},
{
adcode: "350600",
name: "漳州",
},
{
adcode: "350700",
name: "南平",
},
{
adcode: "350800",
name: "龙岩",
},
{
adcode: "350900",
name: "宁德",
},
],
},
{
name: "广东",
adcode: "440000",
city: [
{
adcode: "440100",
name: "广州",
},
{
adcode: "440200",
name: "韶关",
},
{
adcode: "440300",
name: "深圳",
},
{
adcode: "440400",
name: "珠海",
},
{
adcode: "440500",
name: "汕头",
},
{
adcode: "440600",
name: "佛山",
},
{
adcode: "440700",
name: "江门",
},
{
adcode: "440800",
name: "湛江",
},
{
adcode: "440900",
name: "茂名",
},
{
adcode: "441200",
name: "肇庆",
},
{
adcode: "441300",
name: "惠州",
},
{
adcode: "441400",
name: "梅州",
},
{
adcode: "441500",
name: "汕尾",
},
{
adcode: "441600",
name: "河源",
},
{
adcode: "441700",
name: "阳江",
},
{
adcode: "441800",
name: "清远",
},
{
adcode: "441900",
name: "东莞",
},
{
adcode: "442000",
name: "中山",
},
{
adcode: "445100",
name: "潮州",
},
{
adcode: "445200",
name: "揭阳",
},
{
adcode: "445300",
name: "云浮",
},
],
},
{
name: "广西",
adcode: "450000",
city: [
{
adcode: "450100",
name: "南宁",
},
{
adcode: "450200",
name: "柳州",
},
{
adcode: "450300",
name: "桂林",
},
{
adcode: "450400",
name: "梧州",
},
{
adcode: "450500",
name: "北海",
},
{
adcode: "450600",
name: "防城港",
},
{
adcode: "450700",
name: "钦州",
},
{
adcode: "450800",
name: "贵港",
},
{
adcode: "450900",
name: "玉林",
},
{
adcode: "451000",
name: "百色",
},
{
adcode: "451100",
name: "贺州",
},
{
adcode: "451200",
name: "河池",
},
{
adcode: "451300",
name: "来宾",
},
{
adcode: "451400",
name: "崇左",
},
],
},
{
name: "贵州",
adcode: "520000",
city: [
{
adcode: "520100",
name: "贵阳",
},
{
adcode: "520200",
name: "六盘水",
},
{
adcode: "520300",
name: "遵义",
},
{
adcode: "520400",
name: "安顺",
},
{
adcode: "520500",
name: "毕节",
},
{
adcode: "520600",
name: "铜仁",
},
{
adcode: "522300",
name: "黔西南布依族苗族自治州",
},
{
adcode: "522600",
name: "黔东南苗族侗族自治州",
},
{
adcode: "522700",
name: "黔南布依族苗族自治州",
},
],
},
{
name: "甘肃",
adcode: "620000",
city: [
{
adcode: "620100",
name: "兰州",
},
{
adcode: "620200",
name: "嘉峪关",
},
{
adcode: "620300",
name: "金昌",
},
{
adcode: "620400",
name: "白银",
},
{
adcode: "620500",
name: "天水",
},
{
adcode: "620600",
name: "武威",
},
{
adcode: "620700",
name: "张掖",
},
{
adcode: "620800",
name: "平凉",
},
{
adcode: "620900",
name: "酒泉",
},
{
adcode: "621000",
name: "庆阳",
},
{
adcode: "621100",
name: "定西",
},
{
adcode: "621200",
name: "陇南",
},
{
adcode: "622900",
name: "临夏回族自治州",
},
{
adcode: "623000",
name: "甘南藏族自治州",
},
],
},
{
name: "河北",
adcode: "130000",
city: [
{
adcode: "130100",
name: "石家庄",
},
{
adcode: "130200",
name: "唐山",
},
{
adcode: "130300",
name: "秦皇岛",
},
{
adcode: "130400",
name: "邯郸",
},
{
adcode: "130500",
name: "邢台",
},
{
adcode: "130600",
name: "保定",
},
{
adcode: "130700",
name: "张家口",
},
{
adcode: "130800",
name: "承德",
},
{
adcode: "130900",
name: "沧州",
},
{
adcode: "131000",
name: "廊坊",
},
{
adcode: "131100",
name: "衡水",
},
],
},
{
name: "黑龙江",
adcode: "230000",
city: [
{
adcode: "230100",
name: "哈尔滨",
},
{
adcode: "230200",
name: "齐齐哈尔",
},
{
adcode: "230300",
name: "鸡西",
},
{
adcode: "230400",
name: "鹤岗",
},
{
adcode: "230500",
name: "双鸭山",
},
{
adcode: "230600",
name: "大庆",
},
{
adcode: "230700",
name: "伊春",
},
{
adcode: "230800",
name: "佳木斯",
},
{
adcode: "230900",
name: "七台河",
},
{
adcode: "231000",
name: "牡丹江",
},
{
adcode: "231100",
name: "黑河",
},
{
adcode: "231200",
name: "绥化",
},
{
adcode: "232700",
name: "大兴安岭",
},
],
},
{
name: "河南省",
adcode: "410000",
city: [
{
adcode: "410100",
name: "郑州",
},
{
adcode: "410200",
name: "开封",
},
{
adcode: "410300",
name: "洛阳",
},
{
adcode: "410400",
name: "平顶山",
},
{
adcode: "410500",
name: "安阳",
},
{
adcode: "410600",
name: "鹤壁",
},
{
adcode: "410700",
name: "新乡",
},
{
adcode: "410800",
name: "焦作",
},
{
adcode: "410900",
name: "濮阳",
},
{
adcode: "411000",
name: "许昌市",
},
{
adcode: "411100",
name: "漯河",
},
{
adcode: "411200",
name: "三门峡",
},
{
adcode: "411300",
name: "南阳",
},
{
adcode: "411400",
name: "商丘",
},
{
adcode: "411500",
name: "信阳",
},
{
adcode: "411600",
name: "周口",
},
{
adcode: "411700",
name: "驻马店",
},
{
adcode: "419001",
name: "济源",
},
],
},
{
name: "湖北",
adcode: "420000",
city: [
{
adcode: "420100",
name: "武汉",
},
{
adcode: "420200",
name: "黄石",
},
{
adcode: "420300",
name: "十堰",
},
{
adcode: "420500",
name: "宜昌",
},
{
adcode: "420600",
name: "襄阳",
},
{
adcode: "420700",
name: "鄂州",
},
{
adcode: "420800",
name: "荆门",
},
{
adcode: "420900",
name: "孝感",
},
{
adcode: "421000",
name: "荆州",
},
{
adcode: "421100",
name: "黄冈",
},
{
adcode: "421200",
name: "咸宁",
},
{
adcode: "421300",
name: "随州",
},
{
adcode: "422800",
name: "恩施土家族苗族自治州",
},
{
adcode: "429004",
name: "仙桃",
},
{
adcode: "429005",
name: "潜江",
},
{
adcode: "429006",
name: "天门",
},
{
adcode: "429021",
name: "神农架林区",
},
],
},
{
name: "湖南",
adcode: "430000",
city: [
{
adcode: "430100",
name: "长沙",
},
{
adcode: "430200",
name: "株洲",
},
{
adcode: "430300",
name: "湘潭",
},
{
adcode: "430400",
name: "衡阳",
},
{
adcode: "430500",
name: "邵阳",
},
{
adcode: "430600",
name: "岳阳",
},
{
adcode: "430700",
name: "常德",
},
{
adcode: "430800",
name: "张家界",
},
{
adcode: "430900",
name: "益阳",
},
{
adcode: "431000",
name: "郴州",
},
{
adcode: "431100",
name: "永州",
},
{
adcode: "431200",
name: "怀化",
},
{
adcode: "431300",
name: "娄底",
},
{
adcode: "433100",
name: "湘西土家族苗族自治州",
},
],
},
{
name: "海南",
adcode: "460000",
city: [
{
adcode: "460100",
name: "海口",
},
{
adcode: "460200",
name: "三亚",
},
{
adcode: "460300",
name: "三沙",
},
{
adcode: "460400",
name: "儋州",
},
],
},
{
name: "吉林",
adcode: "220000",
city: [
{
adcode: "220100",
name: "长春",
},
{
adcode: "220200",
name: "吉林",
},
{
adcode: "220300",
name: "四平",
},
{
adcode: "220400",
name: "辽源",
},
{
adcode: "220500",
name: "通化",
},
{
adcode: "220600",
name: "白山",
},
{
adcode: "220700",
name: "松原",
},
{
adcode: "220800",
name: "白城",
},
{
adcode: "222400",
name: "延边朝鲜族自治州",
},
],
},
{
name: "江苏",
adcode: "320000",
city: [
{
adcode: "320100",
name: "南京",
},
{
adcode: "320200",
name: "无锡",
},
{
adcode: "320300",
name: "徐州",
},
{
adcode: "320400",
name: "常州",
},
{
adcode: "320500",
name: "苏州",
},
{
adcode: "320600",
name: "南通",
},
{
adcode: "320700",
name: "连云港",
},
{
adcode: "320800",
name: "淮安",
},
{
adcode: "320900",
name: "盐城",
},
{
adcode: "321000",
name: "扬州",
},
{
adcode: "321100",
name: "镇江",
},
{
adcode: "321200",
name: "泰州",
},
{
adcode: "321300",
name: "宿迁",
},
],
},
{
name: "江西",
adcode: "360000",
city: [
{
adcode: "360100",
name: "南昌",
},
{
adcode: "360200",
name: "景德镇",
},
{
adcode: "360300",
name: "萍乡",
},
{
adcode: "360400",
name: "九江",
},
{
adcode: "360500",
name: "新余",
},
{
adcode: "360600",
name: "鹰潭",
},
{
adcode: "360700",
name: "赣州",
},
{
adcode: "360800",
name: "吉安",
},
{
adcode: "360900",
name: "宜春",
},
{
adcode: "361000",
name: "抚州",
},
{
adcode: "361100",
name: "上饶",
},
],
},
{
name: "辽宁",
adcode: "210000",
city: [
{
adcode: "210100",
name: "沈阳",
},
{
adcode: "210200",
name: "大连",
},
{
adcode: "210300",
name: "鞍山",
},
{
adcode: "210400",
name: "抚顺",
},
{
adcode: "210500",
name: "本溪",
},
{
adcode: "210600",
name: "丹东",
},
{
adcode: "210700",
name: "锦州",
},
{
adcode: "210800",
name: "营口",
},
{
adcode: "210900",
name: "阜新",
},
{
adcode: "211000",
name: "辽阳",
},
{
adcode: "211100",
name: "盘锦",
},
{
adcode: "211200",
name: "铁岭",
},
{
adcode: "211300",
name: "朝阳",
},
{
adcode: "211400",
name: "葫芦岛",
},
],
},
{
name: "内蒙古",
adcode: "150000",
city: [
{
adcode: "150100",
name: "呼和浩特",
},
{
adcode: "150200",
name: "包头",
},
{
adcode: "150300",
name: "乌海",
},
{
adcode: "150400",
name: "赤峰",
},
{
adcode: "150500",
name: "通辽",
},
{
adcode: "150600",
name: "鄂尔多斯",
},
{
adcode: "150700",
name: "呼伦贝尔",
},
{
adcode: "150800",
name: "巴彦淖尔",
},
{
adcode: "150900",
name: "乌兰察布",
},
{
adcode: "152200",
name: "兴安盟",
},
{
adcode: "152500",
name: "锡林郭勒盟",
},
{
adcode: "152900",
name: "阿拉善盟",
},
],
},
{
name: "宁夏",
adcode: "640000",
city: [
{
adcode: "640100",
name: "银川",
},
{
adcode: "640200",
name: "石嘴山",
},
{
adcode: "640300",
name: "吴忠",
},
{
adcode: "640400",
name: "固原",
},
{
adcode: "640500",
name: "中卫",
},
],
},
{
name: "青海",
adcode: "630000",
city: [
{
adcode: "630100",
name: "西宁",
},
{
adcode: "630200",
name: "海东",
},
{
adcode: "632200",
name: "海北藏族自治州",
},
{
adcode: "632300",
name: "黄南藏族自治州",
},
{
adcode: "632500",
name: "海南藏族自治州",
},
{
adcode: "632600",
name: "果洛藏族自治州",
},
{
adcode: "632700",
name: "玉树藏族自治州",
},
{
adcode: "632800",
name: "海西蒙古族藏族自治州",
},
],
},
{
name: "山西",
adcode: "140000",
city: [
{
adcode: "140100",
name: "太原",
},
{
adcode: "140200",
name: "大同",
},
{
adcode: "140300",
name: "阳泉",
},
{
adcode: "140400",
name: "长治",
},
{
adcode: "140500",
name: "晋城",
},
{
adcode: "140600",
name: "朔州",
},
{
adcode: "140700",
name: "晋中",
},
{
adcode: "140800",
name: "运城",
},
{
adcode: "140900",
name: "忻州",
},
{
adcode: "141000",
name: "临汾",
},
{
adcode: "141100",
name: "吕梁",
},
],
},
{
name: "山东",
adcode: "370000",
city: [
{
adcode: "370100",
name: "济南",
},
{
adcode: "370200",
name: "青岛",
},
{
adcode: "370300",
name: "淄博",
},
{
adcode: "370400",
name: "枣庄",
},
{
adcode: "370500",
name: "东营",
},
{
adcode: "370600",
name: "烟台",
},
{
adcode: "370700",
name: "潍坊",
},
{
adcode: "370800",
name: "济宁",
},
{
adcode: "370900",
name: "泰安",
},
{
adcode: "371000",
name: "威海",
},
{
adcode: "371100",
name: "日照",
},
{
adcode: "371200",
name: "莱芜",
},
{
adcode: "371300",
name: "临沂",
},
{
adcode: "371400",
name: "德州",
},
{
adcode: "371500",
name: "聊城",
},
{
adcode: "371600",
name: "滨州",
},
{
adcode: "371700",
name: "菏泽",
},
],
},
{
name: "四川",
adcode: "510000",
city: [
{
adcode: "510100",
name: "成都",
},
{
adcode: "510300",
name: "自贡",
},
{
adcode: "510400",
name: "攀枝花",
},
{
adcode: "510500",
name: "泸州",
},
{
adcode: "510600",
name: "德阳",
},
{
adcode: "510700",
name: "绵阳",
},
{
adcode: "510800",
name: "广元",
},
{
adcode: "510900",
name: "遂宁",
},
{
adcode: "511000",
name: "内江",
},
{
adcode: "511100",
name: "乐山",
},
{
adcode: "511300",
name: "南充",
},
{
adcode: "511400",
name: "眉山",
},
{
adcode: "511500",
name: "宜宾",
},
{
adcode: "511600",
name: "广安",
},
{
adcode: "511700",
name: "达州",
},
{
adcode: "511800",
name: "雅安",
},
{
adcode: "511900",
name: "巴中",
},
{
adcode: "512000",
name: "资阳",
},
{
adcode: "513200",
name: "阿坝藏族羌族自治州",
},
{
adcode: "513300",
name: "甘孜藏族自治州",
},
{
adcode: "513400",
name: "凉山彝族自治州",
},
],
},
{
name: "陕西",
adcode: "610000",
city: [
{
adcode: "610100",
name: "西安",
},
{
adcode: "610200",
name: "铜川",
},
{
adcode: "610300",
name: "宝鸡",
},
{
adcode: "610400",
name: "咸阳",
},
{
adcode: "610500",
name: "渭南",
},
{
adcode: "610600",
name: "延安",
},
{
adcode: "610700",
name: "汉中",
},
{
adcode: "610800",
name: "榆林",
},
{
adcode: "610900",
name: "安康",
},
{
adcode: "611000",
name: "商洛",
},
],
},
{
name: "西藏",
adcode: "540000",
city: [
{
adcode: "540100",
name: "拉萨",
},
{
adcode: "540200",
name: "日喀则",
},
{
adcode: "540300",
name: "昌都",
},
{
adcode: "540400",
name: "林芝",
},
{
adcode: "540500",
name: "山南",
},
{
adcode: "540600",
name: "那曲",
},
{
adcode: "542500",
name: "阿里",
},
],
},
{
name: "新疆",
adcode: "650000",
city: [
{
adcode: "650100",
name: "乌鲁木齐",
},
{
adcode: "650200",
name: "克拉玛依",
},
{
adcode: "650400",
name: "吐鲁番",
},
{
adcode: "650500",
name: "哈密",
},
{
adcode: "652300",
name: "昌吉回族自治州",
},
{
adcode: "652700",
name: "博尔塔拉蒙古自治州",
},
{
adcode: "652800",
name: "巴音郭楞蒙古自治州",
},
{
adcode: "652900",
name: "阿克苏",
},
{
adcode: "653000",
name: "克孜勒苏柯尔克孜自治州",
},
{
adcode: "653100",
name: "喀什",
},
{
adcode: "653200",
name: "和田",
},
{
adcode: "654000",
name: "伊犁哈萨克自治州",
},
{
adcode: "654200",
name: "塔城",
},
{
adcode: "654300",
name: "阿勒泰",
},
{
adcode: "659001",
name: "石河子",
},
{
adcode: "659002",
name: "阿拉尔",
},
{
adcode: "659003",
name: "图木舒克",
},
{
adcode: "659004",
name: "五家渠",
},
],
},
{
name: "云南",
adcode: "530000",
city: [
{
adcode: "530100",
name: "昆明",
},
{
adcode: "530300",
name: "曲靖",
},
{
adcode: "530400",
name: "玉溪",
},
{
adcode: "530500",
name: "保山",
},
{
adcode: "530600",
name: "昭通",
},
{
adcode: "530700",
name: "丽江",
},
{
adcode: "530800",
name: "普洱",
},
{
adcode: "530900",
name: "临沧",
},
{
adcode: "532300",
name: "楚雄彝族自治州",
},
{
adcode: "532500",
name: "红河哈尼族彝族自治州",
},
{
adcode: "532600",
name: "文山壮族苗族自治州",
},
{
adcode: "532800",
name: "西双版纳傣族自治州",
},
{
adcode: "532900",
name: "大理白族自治州",
},
{
adcode: "533100",
name: "德宏傣族景颇族自治州",
},
{
adcode: "533300",
name: "怒江傈僳族自治州",
},
{
adcode: "533400",
name: "迪庆藏族自治州",
},
],
},
{
name: "浙江",
adcode: "330000",
city: [
{
adcode: "330100",
name: "杭州",
},
{
adcode: "330200",
name: "宁波",
},
{
adcode: "330300",
name: "温州",
},
{
adcode: "330400",
name: "嘉兴",
},
{
adcode: "330500",
name: "湖州",
},
{
adcode: "330600",
name: "绍兴",
},
{
adcode: "330700",
name: "金华",
},
{
adcode: "330800",
name: "衢州",
},
{
adcode: "330900",
name: "舟山",
},
{
adcode: "331000",
name: "台州",
},
{
adcode: "331100",
name: "丽水",
},
],
},
{
adcode: "310000",
name: "上海",
city: [
{
adcode: "310100",
name: "市辖区",
},
{
adcode: "310101",
name: "黄浦区",
},
{
adcode: "310104",
name: "徐汇区",
},
{
adcode: "310105",
name: "长宁区",
},
{
adcode: "310106",
name: "静安区",
},
{
adcode: "310107",
name: "普陀区",
},
{
adcode: "310108",
name: "闸北区",
},
{
adcode: "310109",
name: "虹口区",
},
{
adcode: "310110",
name: "杨浦区",
},
{
adcode: "310112",
name: "闵行区",
},
{
adcode: "310113",
name: "宝山区",
},
{
adcode: "310114",
name: "嘉定区",
},
{
adcode: "310115",
name: "浦东新区",
},
{
adcode: "310116",
name: "金山区",
},
{
adcode: "310117",
name: "松江区",
},
{
adcode: "310118",
name: "青浦区",
},
{
adcode: "310120",
name: "奉贤区",
},
{
adcode: "310230",
name: "崇明县",
},
],
},
{
name: "重庆",
adcode: "500000",
city: [
{
adcode: "500100",
name: "市辖区",
},
{
adcode: "500101",
name: "万州区",
},
{
adcode: "500102",
name: "涪陵区",
},
{
adcode: "500103",
name: "渝中区",
},
{
adcode: "500104",
name: "大渡口区",
},
{
adcode: "500105",
name: "江北区",
},
{
adcode: "500106",
name: "沙坪坝区",
},
{
adcode: "500107",
name: "九龙坡区",
},
{
adcode: "500108",
name: "南岸区",
},
{
adcode: "500109",
name: "北碚区",
},
{
adcode: "500110",
name: "綦江区",
},
{
adcode: "500111",
name: "大足区",
},
{
adcode: "500112",
name: "渝北区",
},
{
adcode: "500113",
name: "巴南区",
},
{
adcode: "500114",
name: "黔江区",
},
{
adcode: "500115",
name: "长寿区",
},
{
adcode: "500222",
name: "綦江区",
},
{
adcode: "500223",
name: "潼南县",
},
{
adcode: "500224",
name: "铜梁县",
},
{
adcode: "500225",
name: "大足区",
},
{
adcode: "500226",
name: "荣昌县",
},
{
adcode: "500227",
name: "璧山县",
},
{
adcode: "500228",
name: "梁平县",
},
{
adcode: "500229",
name: "城口县",
},
{
adcode: "500230",
name: "丰都县",
},
{
adcode: "500231",
name: "垫江县",
},
{
adcode: "500232",
name: "武隆县",
},
{
adcode: "500233",
name: "忠县",
},
{
adcode: "500234",
name: "开县",
},
{
adcode: "500235",
name: "云阳县",
},
{
adcode: "500236",
name: "奉节县",
},
{
adcode: "500237",
name: "巫山县",
},
{
adcode: "500238",
name: "巫溪县",
},
{
adcode: "500240",
name: "石柱土家族自治县",
},
{
adcode: "500241",
name: "秀山土家族苗族自治县",
},
{
adcode: "500242",
name: "酉阳土家族苗族自治县",
},
{
adcode: "500243",
name: "彭水苗族土家族自治县",
},
{
adcode: "500381",
name: "江津区",
},
{
adcode: "500382",
name: "合川区",
},
{
adcode: "500383",
name: "永川区",
},
{
adcode: "500384",
name: "南川区",
},
],
},
{
name: "北京",
adcode: "110000",
city: [
{
adcode: "110101",
name: "东城区",
},
{
adcode: "110102",
name: "西城区",
},
{
adcode: "110105",
name: "朝阳区",
},
{
adcode: "110106",
name: "丰台区",
},
{
adcode: "110107",
name: "石景山区",
},
{
adcode: "110108",
name: "海淀区",
},
{
adcode: "110109",
name: "门头沟区",
},
{
adcode: "110111",
name: "房山区",
},
{
adcode: "110112",
name: "通州区",
},
{
adcode: "110113",
name: "顺义区",
},
{
adcode: "110114",
name: "昌平区",
},
{
adcode: "110115",
name: "大兴区",
},
{
adcode: "110116",
name: "怀柔区",
},
{
adcode: "110117",
name: "平谷区",
},
{
adcode: "110118",
name: "亦庄开发区",
},
{
adcode: "110228",
name: "密云县",
},
{
adcode: "110229",
name: "延庆县",
},
],
},
{
name: "天津",
adcode: "120000",
city: [
{
adcode: "120101",
name: "和平区",
},
{
adcode: "120102",
name: "河东区",
},
{
adcode: "120103",
name: "河西区",
},
{
adcode: "120104",
name: "南开区",
},
{
adcode: "120105",
name: "河北区",
},
{
adcode: "120106",
name: "红桥区",
},
{
adcode: "120107",
name: "塘沽区",
},
{
adcode: "120108",
name: "汉沽区",
},
{
adcode: "120109",
name: "大港区",
},
{
adcode: "120110",
name: "东丽区",
},
{
adcode: "120111",
name: "西青区",
},
{
adcode: "120112",
name: "津南区",
},
{
adcode: "120113",
name: "北辰区",
},
{
adcode: "120114",
name: "武清区",
},
{
adcode: "120115",
name: "宝坻区",
},
{
adcode: "120221",
name: "宁河县",
},
{
adcode: "120223",
name: "静海县",
},
{
adcode: "120225",
name: "蓟县",
},
],
},
{
name: "台湾",
adcode: "710000",
city: [
{
adcode: "719002",
name: "台北",
},
{
adcode: "719019",
name: "高雄",
},
{
adcode: "719017",
name: "台中",
},
{
adcode: "719016",
name: "台南",
},
{
adcode: "719010",
name: "新北",
},
{
adcode: "719011",
name: "基隆",
},
{
adcode: "719006",
name: "新竹",
},
{
adcode: "719004",
name: "嘉义",
},
],
},
{
name: "香港特别行政区",
adcode: "810000",
},
{
name: "澳门特别行政区",
adcode: "820000",
},
];
// areaCode.js
export const areaCode = [
{
adcode: "420100",
name: "武汉",
},
{
adcode: "420200",
name: "黄石",
},
{
adcode: "420300",
name: "十堰",
},
{
adcode: "420500",
name: "宜昌",
},
{
adcode: "420600",
name: "襄阳",
},
{
adcode: "420700",
name: "鄂州",
},
{
adcode: "420800",
name: "荆门",
},
{
adcode: "420900",
name: "孝感",
},
{
adcode: "421000",
name: "荆州",
},
{
adcode: "421100",
name: "黄冈",
},
{
adcode: "421200",
name: "咸宁",
},
{
adcode: "421300",
name: "随州",
},
{
adcode: "422800",
name: "恩施土家族苗族自治州",
},
{
adcode: "429004",
name: "仙桃",
},
{
adcode: "429005",
name: "潜江",
},
{
adcode: "429006",
name: "天门",
},
{
adcode: "429021",
name: "神农架林区",
},
];
----------------------------dmeo测试----------------------------
<template>
<div
id="echatsMap"
style="
width: 100vw;
height: 100vh; /* 使用视口高度 */
position: relative;
z-index: 1;
"
></div>
</template>
<script>
import * as echarts from "echarts";
import axios from "axios";
import { cityCode } from "@/utils/cityCode.js";
import { getPointAreas } from "@/api/screen";
export default {
name: "echatsMap",
components: {},
data() {
return {
cityCode: cityCode,
myChart: "",
distributionOptions: "",
geographicalCoordinates: [{ name: "荆州市", value: [118.8062, 31.9208] }],
pointList: [],
};
},
// 省是0，市是1，区县是2
async mounted() {
await this.queryPointDatas({
code: "",
});
this.$nextTick(async () => {
await this.init();
});
},
// 展示某个省的地图的话:
// 1. 修改默认请求的Json数据
// 2. 修改默认展示的地图名字等
methods: {
async queryPointDatas(params) {
this.pointList = [];
await getPointAreas({
...params,
}).then((res) => {
if (res.data.code == 200) {
this.pointList = res.data.result;
console.log("pointList", this.pointList);
}
});
},
// 初始化地图数据
init() {
// 主地图的JSON文件下载
let path = `https://geo.datav.aliyun.com/areas_v3/bound/100000_full.json`;
axios.get(path).then((res) => {
echarts.registerMap("china", res.data);
this.changeOptions("china");
this.myChart = echarts.init(document.querySelector("#echatsMap"));
this.myChart.setOption(this.distributionOptions);
this.myChart.on("dataZoom", () => {
this.myChart.resize();
});
// 点击地图省市区展示省市区地图
this.myChart.on("click", async (chinaParam) => {
// 如果没有下层则展示主地图
if (!this.cityCode) {
this.cityCode = cityCode;
await this.queryPointDatas({
code: "",
});
// 100000 主地图
this.geographicalCoordinates = [];
this.getProvinceMapOpt(100000, "");
return;
}
// 根据点击位置地图名字去跟编码数据匹配
let code = this.cityCode.find(
(x) => chinaParam.name.indexOf(x ? x.name : "") !== -1
);
// 找到正确的编码 去获取对应的地图数据
// 将该省市区的下级放入 -- 如果接口支持根据编码查询省市区所有下级子级就不需要这么写
if (code) {
console.log("进入22222");
this.cityCode = code.city;
await this.queryPointDatas({
code: code.adcode,
});
this.getProvinceMapOpt(Number(code.adcode), chinaParam.name);
}
console.log(
"获取位置名称，经纬度----",
Number(code.adcode),
chinaParam.name
);
});
});
window.onresize = function () {
if (this.myChart) this.myChart.resize();
};
},
// 下载/显示各省地图
getProvinceMapOpt(provinceAlphabet, name) {
// 根据地区编码获取所在地区的JSON地图
let path = `https://geo.datav.aliyun.com/areas_v3/bound/${provinceAlphabet}_full.json`;
// if (provinceAlphabet === 100000) {
// path = "/mapJson/china.json";
// }
axios
.get(path)
.then((res) => {
// 获取完最新的JSON地图数据后，重新渲染
echarts.registerMap(name, res.data);
this.changeOptions(name);
this.myChart.setOption(this.distributionOptions, true);
this.myChart.on("dataZoom", () => {
this.myChart.resize();
});
})
.catch((error) => {
// 添加县级以上请求地图数据失败捕获
// 请求出错时的处理逻辑 - 此时有可能是请求到县了，县的请求地址跟其他层级请求地址不一样
console.error("请求出错:", error);
});
},
// 县级别以上都是用的 https://geo.datav.aliyun.com/areas_v3/bound/${区域编码}_full.json去获取的JSON地图数据，
// 但到了县这个请求地址就变了，变成了https://geo.datav.aliyun.com/areas_v3/bound/${区域编码}.json
// echarts 配置项
changeOptions(name) {
// 经纬度数据 --- 不存在的经纬度不会展示出来
// const seriesList = [
// {
// data: [
// { name: "11", value: [117.12, 34.2] },
// { name: "22", value: [117.2, 34.3] },
// ],
// },
// ];
// const seriesList = [
// {
// data: this.geographicalCoordinates,
// },
// ];
let arr = [];
this.pointList.forEach((item) => {
// 省，市（展示一个点）
if (item.type != 2) {
arr.push({
name: item.name,
value: [item.lon, item.lat],
size: item.size,
type: item.type,
});
} else {
// 区：展示所有点
item.list.forEach((ele) => {
arr.push({
name: ele.name,
value: [ele.lon, ele.lat],
person: ele.person,
targetLevelName: ele.targetLevelName,
telephone: ele.telephone,
type: item.type,
});
// arr = [
// {
// name: "111",
// value: [118.8465671, 31.95852687],
// person: "person",
// targetLevelName: "targetLevelName",
// telephone: "telephone",
// type: 2,
// },
// ];
});
}
});
let seriesList = [
{
data: arr,
},
];
// let seriesList1 = [
// {
// data: [
// {
// name: "测试江苏省的点位",
// size: 1,
// type: 0,
// value: [118.7695516, 32.06677694],
// },
// ],
// },
// ];
// 图标
const series = seriesList.map((v) => {
return {
type: "effectScatter", //配置显示方式为用户自定义
coordinateSystem: "geo",
data: v.data,
// data: [
// // ------------------省----------------------------
// // {
// // name: "江苏省",
// // visualMap: false,
// // value: [118.767413, 32.041544],
// // },
// // {
// // name: "安徽省",
// // visualMap: false,
// // value: [117.283042, 31.86119],
// // },
// // {
// // name: "浙江省",
// // visualMap: false,
// // value: [120.153576, 30.287459],
// // },
// // ------------------市----------------------------
// // {
// // name: "南京市",
// // visualMap: false,
// // value: [118.767413, 32.041544],
// // },
// // {
// // name: "常州市",
// // visualMap: false,
// // value: [119.946973, 31.772752],
// // },
// // {
// // name: "连云港市",
// // visualMap: false,
// // value: [119.178821, 34.600018],
// // },
// // ----------------区------------------------------
// // {
// // name: "六合区",
// // visualMap: false,
// // value: [118.8413, 32.34222],
// // },
// // {
// // name: "江宁区",
// // visualMap: false,
// // value: [118.8399, 31.95263],
// // },
// // {
// // name: "雨花台区",
// // visualMap: false,
// // value: [118.7799, 31.99202],
// // },
// ],
showEffectOn: "render",
zlevel: 2,
rippleEffect: {
period: 15,
scale: 4,
brushType: "fill",
},
hoverAnimation: true,
label: {
normal: {
show: false,
},
},
itemStyle: {
normal: {
// color: (param) => {
// return colorArr[param.dataIndex];
// },
color: "#d97d21",
shadowBlur: 10,
shadowColor: "#333",
},
},
symbolSize: 12,
// // 自定义图标的样式 支持svg与bse64
// symbol: function (params, key) {
// console.log(params, key);
// // return "image://" + require("@/assets/logo.png");
// },
// symbolSize: 16,
// tooltip: {
// trigger: "item",
// // show:false,
// formatter: function (params) {
// // 自定义 tooltip 内容
// return `名称:${params.data.name}<br/>坐标:<br/>经度:${params.data.value[0]}<br/>纬度:${params.data.value[1]}`;
// },
// },
};
});
// options
this.distributionOptions = {
tooltip: {
// 提示框组件
show: true, // 显示提示框组件
trigger: "item", // 触发类型
triggerOn: "mousemove", // 触发条件
// formatter: "名称:{b}<br/>坐标:{c}",
formatter: function (params) {
if (params.data.type != 2) {
// 自定义 tooltip 内容
return `${params.data.name}<br/>点位数量: ${params.data.size}个`;
} else {
return `点位名称: ${params.data.name}<br/>经纬度值: ${params.value[0]}, ${params.value[1]}<br/>联系人: ${params.data.name}<br/>
目标水质: ${params.data.targetLevelName}<br/>联系电话: ${params.data.telephone}`;
}
},
},
series, // 数据
geo: {
map: name || "china", // 引入地图 省份或者 国家
layoutCenter: ["60%", "70%"], //设置后left/right/top/bottom等属性无效
layoutSize: "45%",
// center: [104.114129, 37.550339], // 中国中心点
// left: 1,
// top: "10%",
// right: 9,
// bottom: 50,
roam: true, //开启鼠标缩放
zoom: 4,
label: {
normal: {
//静态的时候展示样式
show: true, //是否显示地图省份得名称
textStyle: {
color: "#fff",
fontSize: 16,
fontFamily: "Arial",
},
},
emphasis: {
// 高亮状态下的样式
//动态展示的样式
color: "#fff",
},
},
itemStyle: {
// 地图区域的多边形 图形样式。
normal: {
borderColor: "rgba(147, 235, 248, 1)", // 边框颜色
borderWidth: 1,
// areaColor: "#1c2f59", // 区域颜色
areaColor: {
type: "radial",
x: 0.5,
y: 0.5,
r: 0.8,
colorStops: [
{
offset: 0,
color: "rgba(147, 235, 248, 0)", // 0% 处的颜色
},
{
offset: 1,
color: "rgba(147, 235, 248, .2)", // 100% 处的颜色
},
],
globalCoord: false, // 缺省为 false
},
// areaColor: { // 使用背景图片
// type: "pattern",
// image: require("@/assets/texture.jpeg"), // 使用自己本地图片路径
// repeat: "repeat", //可选值repeat、no-repeat、repeat-x、repeat-y
// },
shadowColor: "rgba(128, 217, 248, 1)",
// shadowColor: 'rgba(255, 255, 255, 1)',
shadowOffsetX: -2,
shadowOffsetY: 2,
shadowBlur: 10,
textStyle: {
// 文字颜色
color: "#fff",
},
// shadowBlur: 10, // 图形阴影的模糊大小
// shadowOffsetX: 10, // 阴影水平方向上的偏移距离。
},
emphasis: {
areaColor: "#1c2f59",
color: "#fff",
},
},
regions: [
//对不同的区块进行着色
// {
// name: "河南省", //区块名称
// itemStyle: {
// normal: {
// areaColor: "#281fe1",
// },
// },
// },
// {
// name: "浙江省", //区块名称
// itemStyle: {
// normal: {
// areaColor: "#193094",
// },
// },
// },
],
},
};
},
// ==========测试输入点位功能=================================
changeOptions2(name) {
let arr = [];
this.pointList.forEach((item) => {
// 省，市（展示一个点）
if (item.type != 2) {
arr.push({
name: item.name,
value: [item.lon, item.lat],
size: item.size,
type: item.type,
});
} else {
// 区：展示所有点
item.list.forEach((ele) => {
arr.push({
name: ele.name,
value: [ele.lon, ele.lat],
person: ele.person,
targetLevelName: ele.targetLevelName,
telephone: ele.telephone,
type: item.type,
});
});
}
});
let seriesList1 = [
{
data: [
{
name: "测试江苏省的点位",
size: 1,
type: 0,
value: [118.7695516, 32.06677694],
},
],
},
];
// 图标
const series = seriesList1.map((v) => {
return {
type: "effectScatter", //配置显示方式为用户自定义
coordinateSystem: "geo",
data: v.data,
showEffectOn: "render",
zlevel: 2,
rippleEffect: {
period: 15,
scale: 4,
brushType: "fill",
},
hoverAnimation: true,
label: {
normal: {
show: false,
},
},
itemStyle: {
normal: {
// color: (param) => {
// return colorArr[param.dataIndex];
// },
color: "#d97d21",
shadowBlur: 10,
shadowColor: "#333",
},
},
symbolSize: 12,
};
});
// options
this.distributionOptions = {
tooltip: {
// 提示框组件
show: true, // 显示提示框组件
trigger: "item", // 触发类型
triggerOn: "mousemove", // 触发条件
// formatter: "名称:{b}<br/>坐标:{c}",
formatter: function (params) {
if (params.data.type != 2) {
// 自定义 tooltip 内容
return `${params.data.name}<br/>点位数量: ${params.data.size}个`;
} else {
return `点位名称: ${params.data.name}<br/>经纬度值: ${params.value[0]}, ${params.value[1]}<br/>联系人: ${params.data.name}<br/>
目标水质: ${params.data.targetLevelName}<br/>联系电话: ${params.data.telephone}`;
}
},
},
series, // 数据
geo: {
map: name || "china", // 引入地图 省份或者 国家
layoutCenter: ["60%", "70%"], //设置后left/right/top/bottom等属性无效
layoutSize: "45%",
// center: [104.114129, 37.550339], // 中国中心点
// left: 1,
// top: "10%",
// right: 9,
// bottom: 50,
roam: true, //开启鼠标缩放
zoom: 4,
label: {
normal: {
//静态的时候展示样式
show: true, //是否显示地图省份得名称
textStyle: {
color: "#fff",
fontSize: 16,
fontFamily: "Arial",
},
},
emphasis: {
// 高亮状态下的样式
//动态展示的样式
color: "#fff",
},
},
itemStyle: {
// 地图区域的多边形 图形样式。
normal: {
borderColor: "rgba(147, 235, 248, 1)", // 边框颜色
borderWidth: 1,
// areaColor: "#1c2f59", // 区域颜色
areaColor: {
type: "radial",
x: 0.5,
y: 0.5,
r: 0.8,
colorStops: [
{
offset: 0,
color: "rgba(147, 235, 248, 0)", // 0% 处的颜色
},
{
offset: 1,
color: "rgba(147, 235, 248, .2)", // 100% 处的颜色
},
],
globalCoord: false, // 缺省为 false
},
shadowColor: "rgba(128, 217, 248, 1)",
// shadowColor: 'rgba(255, 255, 255, 1)',
shadowOffsetX: -2,
shadowOffsetY: 2,
shadowBlur: 10,
textStyle: {
// 文字颜色
color: "#fff",
},
// shadowBlur: 10, // 图形阴影的模糊大小
// shadowOffsetX: 10, // 阴影水平方向上的偏移距离。
},
emphasis: {
areaColor: "#1c2f59",
color: "#fff",
},
},
regions: [],
},
};
},
handleSelectChoose() {
// 主地图的JSON文件下载
let path = `https://geo.datav.aliyun.com/areas_v3/bound/100000_full.json`;
axios.get(path).then((res) => {
echarts.registerMap("china", res.data);
this.changeOptions2("china");
this.myChart = echarts.init(document.querySelector("#echatsMap"));
this.myChart.setOption(this.distributionOptions);
this.myChart.on("dataZoom", () => {
this.myChart.resize();
});
// 点击地图省市区展示省市区地图
this.myChart.on("click", async (chinaParam) => {
// 如果没有下层则展示主地图
if (!this.cityCode) {
this.cityCode = cityCode;
await this.queryPointDatas({
code: "",
});
// 100000 主地图
this.geographicalCoordinates = [];
this.getProvinceMapOpt(100000, "");
return;
}
// 根据点击位置地图名字去跟编码数据匹配
let code = this.cityCode.find(
(x) => chinaParam.name.indexOf(x ? x.name : "") !== -1
);
// 找到正确的编码 去获取对应的地图数据
// 将该省市区的下级放入 -- 如果接口支持根据编码查询省市区所有下级子级就不需要这么写
if (code) {
console.log("进入22222");
this.cityCode = code.city;
await this.queryPointDatas({
code: code.adcode,
});
this.getProvinceMapOpt(Number(code.adcode), chinaParam.name);
}
console.log(
"获取位置名称，经纬度----",
Number(code.adcode),
chinaParam.name
);
});
});
window.onresize = function () {
if (this.myChart) this.myChart.resize();
};
},
},
};
</script>
<style scoped lang="less">
// 全屏状态下，地图高度显示不全
::v-deep canvas[data-zr-dom-id="zr_0"] {
width: 100vw !important; /* 全屏宽度 */
height: 100vh !important; /* 全屏高度 */
}
</style>
需要的pointList数据形式：
