要点

找资料找了好久，其实细细分析起来每一个实现都不难
是写在vue3中的，用的时候写在哪都一样
world.json文件可以去 echarts.apache.org/examples/da… 下载

单个国家颜色

要实现每个国家的颜色自定义就需要使用geo地图而不是series，要单独使用 registerMap在canvas上画一张地图，然后再加入到 globe.baseTexture上面

点击事件

点击事件要加在生成的baseTexture地图上面，使用 .on 来监听，其中 params.name 就是点击国家的名字，可以进行后续操作

<template>
    <div id="main" class="w-full h-full"></div>
</template>
<script setup>
import { reactive, onMounted } from 'vue'
import * as echarts from 'echarts'
import 'echarts-gl'
import geoJson from '@/views/minewar/static/world.json'

const emit = defineEmits(['clickCountry'])
let baseTexture = null
onMounted(() => {
    // 初始化echarts实例
    const myChart = echarts.init(document.getElementById('main'))
    echarts.registerMap('world', geoJson)
    let canvas = document.createElement('canvas')
    baseTexture = echarts.init(canvas, null, {
        width: 4096,
        height: 2048,
    })
    baseTexture.setOption({
        backgroundColor: '#1E288BFF', // 地球颜色
        geo: {
            show: true,
            map: `world`,
            left: 0,
            top: 0,
            right: 0,
            bottom: 0,
            boundingCoords: [
                [-180, 90],
                [180, -90],
            ],
            itemStyle: {
                normal: {
                    areaColor: '#8793D4',
                    borderColor: '#000',
                    borderWidth: 1,
                },
                emphasis: {
                    areaColor: '#DADCF5',
                    borderWidth: 0,
                },
            },
            regions: [
                {
                    name: 'China',
                    itemStyle: {
                        areaColor: '#aa381e',
                    },
                },
                {
                    name: 'Russia',
                    itemStyle: {
                        areaColor: '#12a182',
                    },
                },
            ],
        },
    })
    // 点击事件
    baseTexture.on('click', function (params) {
        console.log(params, 'params')
        if (params.componentType === 'geo') {
            // alert(`你点击了 ${params.name}`)
            emit('clickCountry', params.name)
        }
    })
    // 航线数据
    var alirl = [
        // Paris (2.3522, 48.8566) to Beijing (116.4074, 39.9042)
        [
            [2.3522, 48.8566],
            [116.4074, 39.9042],
        ],
        // Washington, D.C. (-77.0369, 38.9072) to Tokyo (139.6917, 35.6895)
        [
            [-77.0369, 38.9072],
            [139.6917, 35.6895],
        ],
        // London (-0.1276, 51.5074) to Canberra (149.131, -35.2809)
        [
            [-0.1276, 51.5074],
            [149.131, -35.2809],
        ],
        // Moscow (37.6173, 55.7558) to Berlin (13.405, 52.52)
        [
            [37.6173, 55.7558],
            [13.405, 52.52],
        ],
        // Ottawa (-75.6972, 45.4215) to Brasilia (-47.9292, -15.7801)
        [
            [-75.6972, 45.4215],
            [-47.9292, -15.7801],
        ],
    ]
    let option = {
        backgroundColor: '#05050F', // 背景颜色
        globe: {
            baseTexture: baseTexture,
            shading: 'color',
            light: {
                ambient: {
                    intensity: 0.4,
                },
                main: {
                    intensity: 0.4,
                },
            },
            viewControl: {
                targetCoord: [116.2, 39.55], // 当前定位经纬度
                autoRotate: false,
                distance: 210, // 地球缩放大小
            },
        },
        series: [
            {
                //航线的视图效果
                type: 'lines3D',
                coordinateSystem: 'globe',
                effect: {
                    show: true,
                    trailWidth: 5,
                    trailOpacity: 1,
                    trailLength: 0.2,
                    constantSpeed: 5,
                },
                blendMode: 'lighter',
                lineStyle: {
                    color: '#EBE806',
                    width: 1,
                    opacity: 1,
                },

                data: alirl,
            },
            {
                // 飞线效果
                name: 'lines3D',
                type: 'lines3D',
                coordinateSystem: 'globe',
                effect: {
                    show: true,
                    // period: 2,
                    // trailWidth: 3,
                    // trailLength: 0.5,
                    // trailOpacity: 1,
                    // trailColor: '#0087f4',
                },
                blendMode: 'lighter',
                lineStyle: {
                    width: 3,
                    // width: 1,
                    color: '#0087f4',
                    // opacity: 0,
                },
                data: [],
                silent: false,
            },
        ],
    }
    // 载入随机飞线数据
    for (let i = 0; i < 50; i++) {
        option.series[1].data = option.series[1].data.concat(rodamData())
    }
    myChart.setOption(option, true)
    function rodamData() {
        // let longitude = 105.18
        let longitude = Math.random() * 360 - 180
        let longitude2 = Math.random() * 360 - 180
        // let latitude = 37.51
        let latitude = Math.random() * 180 - 90
        let latitude2 = Math.random() * 180 - 90
        return {
            coords: [
                [longitude2, latitude2],
                [longitude, latitude],
            ],
            value: (Math.random() * 3000).toFixed(2),
        }
    }
})
</script>
<style lang="scss" scoped></style>

有用的话一定在评论区留下一句话，有问题的话也可以写在评论区
