Quartz-SchedulerListener解读

小小工匠
87 阅读3分钟

文章目录

在这里插入图片描述

概述

SchedulerListener 是在 Scheduler 级别的事件产生时得到通知，不管是增加还是移除 Scheduler 中的 Job，或者是 Scheduler 遭遇到了严重的错误时。那些事件多是关于对 Scheduler 管理的，而不是专注于 Job 或 Trigger 的。

org.quartz.SchedulerListener 接口包含了一系列的回调方法，它们会在 Scheduler 的生命周期中有关键事件发生时被调用。

SchedulerListener接口方法解读

我们先看下SchedulerListener的源码

public interface SchedulerListener {
   public void jobScheduled(Trigger trigger);
    public void jobUnscheduled(String triggerName, String triggerGroup);
    public void triggerFinalized(Trigger trigger);
    public void triggersPaused(String triggerName, String triggerGroup);
    public void triggersResumed(String triggerName,String triggerGroup);
    public void jobsPaused(String jobName, String jobGroup);
    public void jobsResumed(String jobName, String jobGroup);
    public void schedulerError(String msg, SchedulerException cause);
    public void schedulerShutdown();
}
  • jobScheduled() 和 jobUnscheduled()：Scheduler 在有新的 JobDetail 部署或卸载时调用这两个中的相应方法。
  • triggerFinalized() ：当一个 Trigger 来到了再也不会触发的状态时调用这个方法。除非这个 Job 已设置成了持久性，否则它就会从 Scheduler 中移除。
  • triggersPaused()：Scheduler 调用这个方法是发生在一个 Trigger 或 Trigger 组被暂停时。假如是 Trigger 组的话，triggerName 参数将为 null。
  • triggersResumed()：Scheduler 调用这个方法是发生成一个 Trigger 或 Trigger 组从暂停中恢复时。假如是 Trigger 组的话，triggerName 参数将为 null。
  • jobsPaused()：当一个或一组 JobDetail 暂停时调用这个方法。
  • jobsResumed()：当一个或一组 Job 从暂停上恢复时调用这个方法。假如是一个 Job 组，jobName 参数将为 null。
  • schedulerError()：在 Scheduler 的正常运行期间产生一个严重错误时调用这个方法。错误的类型会各式的，但是下面列举了一些错误例子：

初始化 Job 类的问题
试图去找到下一 Trigger 的问题
JobStore 中重复的问题
数据存储连接的问题

你可以使用 SchedulerException 的 getErrorCode() 或者 getUnderlyingException() 方法或获取到特定错误的更详尽的信息。

  • schedulerShutdown()：Scheduler 调用这个方法用来通知 SchedulerListener Scheduler 将要被关闭。

示例

Job复用TriggerListener中的SimpleJob1

详见 Quartz-TriggerListener解读

自定义SchedulerListener

package com.xgj.quartz.quartzItself.listener.schedulerListener;

import org.quartz.JobDetail;
import org.quartz.JobKey;
import org.quartz.SchedulerException;
import org.quartz.SchedulerListener;
import org.quartz.Trigger;
import org.quartz.TriggerKey;

public class MySchedulerListener implements SchedulerListener {

	@Override
	public void jobScheduled(Trigger trigger) {
		System.out.println("MySchedulerListener jobScheduled trigger");

	}

	@Override
	public void jobUnscheduled(TriggerKey triggerKey) {
		System.out.println("MySchedulerListener jobScheduled triggerKey");

	}

	@Override
	public void triggerFinalized(Trigger trigger) {
		System.out.println("MySchedulerListener triggerFinalized");

	}

	@Override
	public void triggerPaused(TriggerKey triggerKey) {
		System.out.println("MySchedulerListener triggerPaused");

	}

	@Override
	public void triggersPaused(String triggerGroup) {
		System.out.println("MySchedulerListener triggersPaused");

	}

	@Override
	public void triggerResumed(TriggerKey triggerKey) {
		System.out.println("MySchedulerListener triggerResumed triggerKey");

	}

	@Override
	public void triggersResumed(String triggerGroup) {
		System.out.println("MySchedulerListener triggerResumed triggerGroup");

	}

	@Override
	public void jobAdded(JobDetail jobDetail) {
		System.out.println("MySchedulerListener jobAdded");
	}

	@Override
	public void jobDeleted(JobKey jobKey) {
		System.out.println("MySchedulerListener jobDeleted");

	}

	@Override
	public void jobPaused(JobKey jobKey) {
		System.out.println("MySchedulerListener jobPaused jobKey");

	}

	@Override
	public void jobsPaused(String jobGroup) {
		System.out.println("MySchedulerListener jobsPaused jobGroup");

	}

	@Override
	public void jobResumed(JobKey jobKey) {
		System.out.println("MySchedulerListener jobResumed  jobKey");

	}

	@Override
	public void jobsResumed(String jobGroup) {
		System.out.println("MySchedulerListener jobsResumed  jobGroup");

	}

	@Override
	public void schedulerError(String msg, SchedulerException cause) {
		System.out.println("MySchedulerListener schedulerError");

	}

	@Override
	public void schedulerInStandbyMode() {
		System.out.println("MySchedulerListener schedulerInStandbyMode");

	}

	@Override
	public void schedulerStarted() {
		System.out.println("MySchedulerListener schedulerStarted");

	}

	@Override
	public void schedulerStarting() {
		System.out.println("MySchedulerListener schedulerStarting");

	}

	@Override
	public void schedulerShutdown() {
		System.out.println("MySchedulerListener schedulerShutdown");

	}

	@Override
	public void schedulerShuttingdown() {
		System.out.println("MySchedulerListener schedulerShuttingdown");

	}

	@Override
	public void schedulingDataCleared() {
		System.out.println("MySchedulerListener schedulingDataCleared");

	}

}

调度类

package com.xgj.quartz.quartzItself.listener.schedulerListener;

import static org.quartz.JobBuilder.newJob;
import static org.quartz.TriggerBuilder.newTrigger;

import org.quartz.JobDetail;
import org.quartz.Scheduler;
import org.quartz.SchedulerFactory;
import org.quartz.SchedulerListener;
import org.quartz.SchedulerMetaData;
import org.quartz.Trigger;
import org.quartz.impl.StdSchedulerFactory;

import com.xgj.quartz.quartzItself.listener.triggerListener.SimpleJob1;

public class SchedulerListenerDemo {

	public static void main(String[] args) throws Exception {

		System.out.println("------- 初始化 ----------------------");

		// Scheduler
		SchedulerFactory schedulerFactory = new StdSchedulerFactory();
		Scheduler scheduler = schedulerFactory.getScheduler();

		// 添加监听器
		SchedulerListener schedulerListener = new MySchedulerListener();
		scheduler.getListenerManager().addSchedulerListener(schedulerListener);

		// Job
		JobDetail job = newJob(SimpleJob1.class).withIdentity("job1", "group1")
				.build();

		// Tirgger
		Trigger trigger = newTrigger().withIdentity("trigger1", "group1")
				.startNow().build();

		// 将job任务加入到调度器
		scheduler.scheduleJob(job, trigger);

		// 开始任务
		System.out.println("------- 开始执行调度器 Scheduler ----------------");
		scheduler.start();

		try {
			System.out.println("------- 等待 30 秒... --------------");
			Thread.sleep(30L * 1000L);
		} catch (Exception e) {
			e.printStackTrace();
		}

		scheduler.shutdown(true);
		System.out.println("------- 关闭调度器 -----------------");

		SchedulerMetaData metaData = scheduler.getMetaData();
		System.out.println("~~~~~~~~~~  执行了 "
				+ metaData.getNumberOfJobsExecuted() + " 个 jobs.");

	}
}

运行结果

------- 初始化 ----------------------
INFO  StdSchedulerFactory - Using default implementation for ThreadExecutor
INFO  SimpleThreadPool - Job execution threads will use class loader of thread: main
INFO  SchedulerSignalerImpl - Initialized Scheduler Signaller of type: class org.quartz.core.SchedulerSignalerImpl
INFO  QuartzScheduler - Quartz Scheduler v.2.2.3 created.
INFO  RAMJobStore - RAMJobStore initialized.
INFO  QuartzScheduler - Scheduler meta-data: Quartz Scheduler (v2.2.3) 'DefaultQuartzScheduler' with instanceId 'NON_CLUSTERED'
  Scheduler class: 'org.quartz.core.QuartzScheduler' - running locally.
  NOT STARTED.
  Currently in standby mode.
  Number of jobs executed: 0
  Using thread pool 'org.quartz.simpl.SimpleThreadPool' - with 10 threads.
  Using job-store 'org.quartz.simpl.RAMJobStore' - which does not support persistence. and is not clustered.

INFO  StdSchedulerFactory - Quartz scheduler 'DefaultQuartzScheduler' initialized from default resource file in Quartz package: 'quartz.properties'
INFO  StdSchedulerFactory - Quartz scheduler version: 2.2.3
MySchedulerListener jobAdded
MySchedulerListener jobScheduled trigger
------- 开始执行调度器 Scheduler ----------------
MySchedulerListener schedulerStarting
INFO  QuartzScheduler - Scheduler DefaultQuartzScheduler_$_NON_CLUSTERED started.
MySchedulerListener schedulerStarted
------- 等待 30 秒... --------------

Job1 - 任务key group1.job1执行时间：2017-11-16 22:14:33
MySchedulerListener triggerFinalized
MySchedulerListener jobDeleted
INFO  QuartzScheduler - Scheduler DefaultQuartzScheduler_$_NON_CLUSTERED shutting down.
INFO  QuartzScheduler - Scheduler DefaultQuartzScheduler_$_NON_CLUSTERED paused.
MySchedulerListener schedulerInStandbyMode
MySchedulerListener schedulerShuttingdown
MySchedulerListener schedulerShutdown
INFO  QuartzScheduler - Scheduler DefaultQuartzScheduler_$_NON_CLUSTERED shutdown complete.
------- 关闭调度器 -----------------
~~~~~~~~~~  执行了 1 个 jobs.

示例源码

代码已托管到Github—> github.com/yangshangwe…
