using System
using System.Collections.Generic
using System.ComponentModel
using System.Data
using System.Drawing
using System.Linq
using System.Text
using System.Windows.Forms
using com.google.zxing.common
using AForge.Video.DirectShow
using com.google.zxing
using AForge.Video
namespace CameraQRCode
{
public partial class frmMain : Form
{
public frmMain()
{
InitializeComponent()
}
///调用AForge使用摄像头
FilterInfoCollection Use_Webcams = null
VideoCaptureDevice cam = null
OpenFileDialog openFileDialog1 = new OpenFileDialog()
/// <summary>
/// 生成二维码并保存图片
/// </summary>
/// <param name="sender"></param>
/// <param name="e"></param>
private void btnQRCode_Click(object sender, EventArgs e)
{
string content = txtInputForQR.Text
ByteMatrix byteMatrix = new MultiFormatWriter().encode(content, BarcodeFormat.QR_CODE, 300, 300)
Bitmap bitmap = toBitmap(byteMatrix)
pictureBox1.Image = bitmap
SaveFileDialog sFD = new SaveFileDialog()
sFD.Filter = "保存图片(*.png) |*.png|所有文件(*.*) |*.*"
sFD.DefaultExt = "*.png|*.png"
sFD.AddExtension = true
if (sFD.ShowDialog() == DialogResult.OK)
{
if (sFD.FileName != "")
{
writeToFile(byteMatrix, System.Drawing.Imaging.ImageFormat.Png, sFD.FileName)
}
}
}
/// <summary>
/// 解析
/// </summary>
/// <param name="sender"></param>
/// <param name="e"></param>
private void btnQRDeCode_Click(object sender, EventArgs e)
{
if (this.openFileDialog1.ShowDialog() != DialogResult.OK)
{
return
}
Image img = Image.FromFile(this.openFileDialog1.FileName)
Bitmap bmap
try
{
bmap = new Bitmap(img)
}
catch (System.IO.IOException ioe)
{
MessageBox.Show(ioe.ToString())
return
}
if (bmap == null)
{
MessageBox.Show("Could not decode image")
return
}
LuminanceSource source = new RGBLuminanceSource(bmap, bmap.Width, bmap.Height)
com.google.zxing.BinaryBitmap bitmap1 = new com.google.zxing.BinaryBitmap(new HybridBinarizer(source))
Result result
try
{
result = new MultiFormatReader().decode(bitmap1)
}
catch (ReaderException re)
{
MessageBox.Show(re.ToString())
return
}
txtOutputQR.Text = result.Text
//MessageBox.Show(result.Text)
}
/// <summary>
/// 关闭摄像头
/// </summary>
/// <param name="sender"></param>
/// <param name="e"></param>
private void btnStop_Click(object sender, EventArgs e)
{
if (cam != null)
{
//关闭摄像头
if (cam.IsRunning)
{
cam.Stop()
}
}
}
/// <summary>
/// 打开摄像头
/// </summary>
/// <param name="sender"></param>
/// <param name="e"></param>
private void btnOpen_Click(object sender, EventArgs e)
{
cam.Start()
if (!timer1.Enabled)
{
timer1.Enabled = true
}
}
private void Cam_NewFrame(object obj, NewFrameEventArgs eventArgs)
{
this.pictureBox1.Image = (Bitmap)eventArgs.Frame.Clone()
}
public static void writeToFile(ByteMatrix matrix, System.Drawing.Imaging.ImageFormat format, string file)
{
Bitmap bmap = toBitmap(matrix)
bmap.Save(file, format)
}
public static Bitmap toBitmap(ByteMatrix matrix)
{
int width = matrix.Width
int height = matrix.Height
Bitmap bmap = new Bitmap(width, height, System.Drawing.Imaging.PixelFormat.Format32bppArgb)
for (int x = 0
{
for (int y = 0
{
bmap.SetPixel(x, y, matrix.get_Renamed(x, y) != -1 ? ColorTranslator.FromHtml("0xFF000000") : ColorTranslator.FromHtml("0xFFFFFFFF"))
}
}
return bmap
}
/// <summary>
/// 扫描识别二维码
/// </summary>
/// <param name="sender"></param>
/// <param name="e"></param>
private void timer1_Tick(object sender, EventArgs e)
{
//识别图片中的二维码
Image img = this.pictureBox1.Image
if (img == null)
return
Bitmap bmap
try
{
bmap = new Bitmap(img)
}
catch (System.IO.IOException ioe)
{
MessageBox.Show(ioe.ToString())
return
}
if (bmap == null)
{
MessageBox.Show("Could not decode image")
return
}
LuminanceSource source = new RGBLuminanceSource(bmap, bmap.Width, bmap.Height)
com.google.zxing.BinaryBitmap bitmap1 = new com.google.zxing.BinaryBitmap(new HybridBinarizer(source))
Result result
try
{
result = new MultiFormatReader().decode(bitmap1)
}
catch (ReaderException re)
{
//MessageBox.Show(re.ToString())
return
}
txtOutputQR.Text = result.Text
this.timer1.Enabled = false
this.cam.Stop()
this.pictureBox1.Image = null
MessageBox.Show("图中二维码:" + result.Text)
}
private void frmMain_Load(object sender, EventArgs e)
{
//初始化AForge内容
Use_Webcams = new FilterInfoCollection(FilterCategory.VideoInputDevice)
if (Use_Webcams.Count > 0)
{
//实例化对象
cam = new VideoCaptureDevice(Use_Webcams[0].MonikerString)
//绑定事件
cam.NewFrame += new NewFrameEventHandler(Cam_NewFrame)
}
}
}
}
demo下载
https://download.csdn.net/download/lw112190/84384040
