24分栏布局 - 24布局 - flex 等分布局

通过基础的 24 分栏，迅速简便地创建布局。

import 'dart:math' as math;

import 'package:flutter/material.dart';

void main() {
  runApp(
    const MaterialApp(
      home: LayoutGrid(),
    ),
  );
}

class LayoutGrid extends StatefulWidget {
  const LayoutGrid({
    super.key,
  });

  @override
  State<LayoutGrid> createState() => _LayoutGridState();
}

class _LayoutGridState extends State<LayoutGrid> {
  Color getRandomColor() {
    return Colors.primaries[math.Random().nextInt(Colors.primaries.length)];
  }

  _buildSingleColor() {
    return ColoredBox(
      color: getRandomColor(),
    );
  }

  @override
  Widget build(BuildContext context) {
    //   return Align(
    //     child: SizedBox(
    //       height: 40,
    //       child: Flex(
    //         direction: Axis.horizontal,
    //         mainAxisSize: MainAxisSize.max,
    //         children: [
    //           ElCol(
    //             flex: 6,
    //             child: _buildSingleColor(),
    //           ),
    //           ElCol(
    //             flex: 6,
    //             child: _buildSingleColor(),
    //           ),
    //           ElCol(
    //             flex: 6,
    //             child: _buildSingleColor(),
    //           ),
    //           ElCol(
    //             flex: 6,
    //             child: _buildSingleColor(),
    //           ),
    //         ],
    //       ),
    //     ),
    //   );
    // }
    return ElRow(
      constraints: BoxConstraints(
        maxWidth: double.infinity, // 此处必须是一个确定的值，否则会出现意外的情况
        maxHeight: 40,
      ),
      children: [
        ElCol(
          flex: 6,
          child: _buildSingleColor(),
        ),
        ElCol(
          flex: 12,
          child: _buildSingleColor(),
        ),
        ElCol(
          flex: 3,
          child: _buildSingleColor(),
        ),
        ElCol(
          flex: 3,
          child: _buildSingleColor(),
        ),
      ],
    );
  }
}

class ElRow extends StatelessWidget {
  const ElRow({super.key, required this.children, required this.constraints});
  final BoxConstraints constraints;
  final List<Widget> children;

  @override
  Widget build(BuildContext context) {
    return UnconstrainedBox(
      child: ConstrainedBox(
        constraints: constraints.tighten(
          width:
              math.min(MediaQuery.of(context).size.width, constraints.maxWidth),
          height: constraints.maxHeight,
        ),
        child: Flex(
          direction: Axis.horizontal,
          mainAxisSize: MainAxisSize.max,
          children: children,
        ),
      ),
    );
  }
}

class ElCol extends StatelessWidget {
  const ElCol({super.key, this.child, required this.flex});
  final int flex;
  final Widget? child;

  @override
  Widget build(BuildContext context) {
    return Flexible(
      fit: FlexFit.tight,
      flex: flex,
      child: SizedBox.expand(
        child: child,
      ),
    );
  }
}
