使用场景
偶然翻阅微信开发者文档,发现微信提供了OCR检测能力. 最近正好研究OCR功能, OCR检测有2种使用方法，一种是输入一张静态图片进行检测，另一种是通过摄像头实时检测。决定使用摄像头实时检测看看什么效果.
代码分析
微信官方示例代码： 此处有坑
const session = wx.createVKSession({
track: {
OCR: { mode: 1 } // mode: 1 - 使用摄像头；2 - 手动传入图像
},
version: 'v1'
})
// 摄像头实时检测模式下，监测到文字时，updateAnchors 事件会连续触发 （每帧触发一次）
session.on('updateAnchors', anchors => {
console.log('anchors.text',"".concat(anchors.map(anchor=>anchor.text)))
})
// 当文字区域从相机中离开时，会触发 removeAnchors 事件
session.on('removeAnchors', () => {
console.log('removeAnchors')
})
微信文档大家都懂得, 到处都是坑.果然,复制到项目里面,啥效果也没有.
于是调研 createVKSession 函数, 发现真实用法.
首先初始化参数不同:
// 以下 demo 以 v2 为例
// 创建 session 对象
const ssession = wx.createVKSession({
track: {
plane: {mode: 3},
},
version: 'v2',
gl, // WebGLRenderingContext
})
创建以后调用 start 启动:
// 逐帧分析
const onFrame = timestamp => {
// 开发者可以自己控制帧率
const frame = session.getVKFrame(canvasWidth, canvasHeight)
if (frame) {
// 分析完毕，可以拿到帧对象
doRender(frame)
}
session.requestAnimationFrame(onFrame)
}
session.start(err => {
if (!err) session.requestAnimationFrame(onFrame)
})
// 渲染函数
const doRender = frame => {
// ...
}
session.requestAnimationFrame(onFrame) 类似 requestAnimationFrame用法.
const frame = session.getVKFrame(canvasWidth, canvasHeight) 才会触发OCR分析.
代码实现
技术方案使用
Taro创建Canvas, type使用webgl,
html 代码:
<Canvas
type="webgl"
id="webgl"
style={{
width: "100vw",
height: "100vh",
}}
></Canvas>
js 代码:
useEffect(() => {
Taro.createSelectorQuery()
.select("#webgl")
.node()
.exec((res) => {
var canvas = res[0].node;
const gl = canvas.getContext("webgl");
//@ts-ignore
const session = Taro.createVKSession({
track: {
plane: {
mode: 3,
},
OCR: {
mode: 1,
},
},
version: "v1",
gl,
});
session.start((err) => {
if (err) return console.error("VK error: ", err);
const onFrame = (timestamp) => {
const frame = session.getVKFrame(canvas.width, canvas.height);
if (frame) {
gl.disable(gl.DEPTH_TEST);
const { yTexture, uvTexture } = frame.getCameraTexture(gl, "yuv");
const displayTransform = frame.getDisplayTransform();
draw(gl);
function draw(gl) {
// 编写着色器
const currentProgram = gl.getParameter(gl.CURRENT_PROGRAM);
const vs = `
attribute vec2 a_position;
attribute vec2 a_texCoord;
uniform mat3 displayTransform;
varying vec2 v_texCoord;
void main() {
vec3 p = displayTransform * vec3(a_position, 0);
gl_Position = vec4(p, 1);
v_texCoord = a_texCoord;
}
`;
const fs = `
precision highp float;
uniform sampler2D y_texture;
uniform sampler2D uv_texture;
varying vec2 v_texCoord;
void main() {
vec4 y_color = texture2D(y_texture, v_texCoord);
vec4 uv_color = texture2D(uv_texture, v_texCoord);
float Y, U, V;
float R ,G, B;
Y = y_color.r;
U = uv_color.r - 0.5;
V = uv_color.a - 0.5;
R = Y + 1.402 * V;
G = Y - 0.344 * U - 0.714 * V;
B = Y + 1.772 * U;
gl_FragColor = vec4(R, G, B, 1.0);
}
`;
const vertShader = gl.createShader(gl.VERTEX_SHADER);
gl.shaderSource(vertShader, vs);
gl.compileShader(vertShader);
const fragShader = gl.createShader(gl.FRAGMENT_SHADER);
gl.shaderSource(fragShader, fs);
gl.compileShader(fragShader);
const program = gl.createProgram();
gl.attachShader(program, vertShader);
gl.attachShader(program, fragShader);
gl.deleteShader(vertShader);
gl.deleteShader(fragShader);
gl.linkProgram(program);
gl.useProgram(program);
const uniformYTexture = gl.getUniformLocation(
program,
"y_texture"
);
gl.uniform1i(uniformYTexture, 5);
const uniformUVTexture = gl.getUniformLocation(
program,
"uv_texture"
);
gl.uniform1i(uniformUVTexture, 6);
const dt = gl.getUniformLocation(program, "displayTransform");
gl.useProgram(currentProgram);
// 初始化 VAO
const ext = gl.getExtension("OES_vertex_array_object");
const currentVAO = gl.getParameter(gl.VERTEX_ARRAY_BINDING);
const vao = ext.createVertexArrayOES();
ext.bindVertexArrayOES(vao);
const posAttr = gl.getAttribLocation(program, "a_position");
const pos = gl.createBuffer();
gl.bindBuffer(gl.ARRAY_BUFFER, pos);
gl.bufferData(
gl.ARRAY_BUFFER,
new Float32Array([1, 1, -1, 1, 1, -1, -1, -1]),
gl.STATIC_DRAW
);
gl.vertexAttribPointer(posAttr, 2, gl.FLOAT, false, 0, 0);
gl.enableVertexAttribArray(posAttr);
vao.posBuffer = pos;
const texcoordAttr = gl.getAttribLocation(
program,
"a_texCoord"
);
const texcoord = gl.createBuffer();
gl.bindBuffer(gl.ARRAY_BUFFER, texcoord);
gl.bufferData(
gl.ARRAY_BUFFER,
new Float32Array([1, 1, 0, 1, 1, 0, 0, 0]),
gl.STATIC_DRAW
);
gl.vertexAttribPointer(texcoordAttr, 2, gl.FLOAT, false, 0, 0);
gl.enableVertexAttribArray(texcoordAttr);
vao.texcoordBuffer = texcoord;
ext.bindVertexArrayOES(currentVAO);
if (yTexture && uvTexture) {
const currentProgram = gl.getParameter(gl.CURRENT_PROGRAM);
const currentActiveTexture = gl.getParameter(
gl.ACTIVE_TEXTURE
);
const currentVAO = gl.getParameter(gl.VERTEX_ARRAY_BINDING);
gl.useProgram(program);
ext.bindVertexArrayOES(vao);
// 传入调整矩阵
gl.uniformMatrix3fv(dt, false, displayTransform);
gl.pixelStorei(gl.UNPACK_ALIGNMENT, 1);
// 传入 y 通道纹理
gl.activeTexture(gl.TEXTURE0 + 5);
const bindingTexture5 = gl.getParameter(
gl.TEXTURE_BINDING_2D
);
gl.bindTexture(gl.TEXTURE_2D, yTexture);
// 传入 uv 通道纹理
gl.activeTexture(gl.TEXTURE0 + 6);
const bindingTexture6 = gl.getParameter(
gl.TEXTURE_BINDING_2D
);
gl.bindTexture(gl.TEXTURE_2D, uvTexture);
gl.drawArrays(gl.TRIANGLE_STRIP, 0, 4);
gl.bindTexture(gl.TEXTURE_2D, bindingTexture6);
gl.activeTexture(gl.TEXTURE0 + 5);
gl.bindTexture(gl.TEXTURE_2D, bindingTexture5);
gl.useProgram(currentProgram);
gl.activeTexture(currentActiveTexture);
ext.bindVertexArrayOES(currentVAO);
}
}
}
session.requestAnimationFrame(onFrame);
};
session.requestAnimationFrame(onFrame);
session.on("addAnchors", () => {
console.log("anchor add");
});
// 摄像头实时检测模式下，监测到文字时，updateAnchors 事件会连续触发 （每帧触发一次）
session.on("updateAnchors", (anchors) => {
throttleHandle(() => {
setTextList(
anchors.map((anchor) => {
console.log("--->206:", anchor);
return anchor.text;
})
);
});
});
// 当文字区域从相机中离开时，会触发 removeAnchors 事件
session.on("removeAnchors", () => {
console.log("removeAnchors");
});
});
});
}, []);
实现效果:
