spring boot 存储操作日志(mysql)

记录聊天app，操作日志存储实现

操作日志实体类

SQL(table 数据表)

create table if not exists `br_operate_log`
(
    `operate_type`   smallint unsigned null comment '操作人类别',
    `business_type`  smallint unsigned null comment '操作功能',
    `method`         varchar(16)       null comment '请求方法',
    `topic`          varchar(32)       null comment '主题',
    `summary`        varchar(120)      null comment '概况',
    `notes`          varchar(255)      null comment '备注',
    `url`            varchar(255)      null comment '请求url',
    `params`         varchar(514)      null comment '请求参数',
    `response`       varchar(2048)     null comment '请求响应体',
    `is_success`     boolean           null comment '成功处理',

    `id`             bigint(20) unsigned primary key,
    `create_at`      datetime          null comment '创建时间',
    `create_by`      bigint unsigned   null comment '创建人',
    `create_ip`      varchar(64)       null comment '创建ip',
    `create_address` varchar(64)       null comment '创建ip地址 "国家|区域|省|市|宽带"',
    `update_at`      datetime          null comment '最后更新时间',
    `update_by`      bigint unsigned   null comment '最后更新人',
    `update_ip`      varchar(64)       null comment '最后更新ip',
    `update_address` varchar(64)       null comment '最后更新ip地址 "国家|区域|省|市|宽带"',
    `remark`         varchar(256)      null comment '备注',
    `version`        int     default 0 null comment '乐观锁',
    `is_deleted`     boolean default false comment '逻辑删除 0 未删除 `null` 删除',
    `is_status`      boolean default true comment '是否启用 0 关闭  1 开启'
) auto_increment 100 comment '日志记录表';

BaseeEntity(基础实体类)

package com.bluereba.br_pojo.entity;

import com.baomidou.mybatisplus.annotation.*;
import io.swagger.annotations.ApiModel;
import io.swagger.annotations.ApiModelProperty;
import lombok.Data;

import java.io.Serializable;
import java.time.LocalDateTime;

/**
 * @author tuuuuuun
 * @since 2022/10/10 0:12
 */

@Data
@ApiModel(value = "基础实体类", description = "")
public class BaseEntity implements Serializable {

  private static final long serialVersionUID = 1L;

  @TableId(value = "id", type = IdType.ASSIGN_ID)
  private Long id;

  @ApiModelProperty("创建时间")
  @TableField(value = "create_at", fill = FieldFill.INSERT)
  private LocalDateTime createAt;

  @ApiModelProperty("创建人")
  @TableField(value = "create_by", fill = FieldFill.INSERT)
  private Long createBy;

  @ApiModelProperty("创建ip")
  @TableField(value = "create_ip", fill = FieldFill.INSERT)
  private String createIp;

  @ApiModelProperty("创建ip地址 "国家|区域|省|市|宽带"")
  @TableField(value = "create_address", fill = FieldFill.INSERT)
  private String createAddress;

  @ApiModelProperty("最后更新时间")
  @TableField(value = "update_at", fill = FieldFill.INSERT_UPDATE)
  private LocalDateTime updateAt;

  @ApiModelProperty("最后更新人")
  @TableField(value = "update_by", fill = FieldFill.INSERT_UPDATE)
  private Long updateBy;

  @ApiModelProperty("最后更新ip")
  @TableField(value = "update_ip", fill = FieldFill.INSERT_UPDATE)
  private String updateIp;

  @ApiModelProperty("最后更新ip地址 "国家|区域|省|市|宽带"")
  @TableField(value = "update_address", fill = FieldFill.INSERT_UPDATE)
  private String updateAddress;

  @ApiModelProperty("备注")
  @TableField("remark")
  private String remark;

  @ApiModelProperty("乐观锁")
  @TableField("version")
  @Version
  private Integer version;

  @ApiModelProperty("逻辑删除 0 未删除 `null` 删除")
  @TableField("is_deleted")
  @TableLogic
  private Boolean isDeleted;

  @ApiModelProperty("是否启用 0 关闭  1 开启")
  @TableField("is_status")
  private Boolean isStatus;
}

OperateLogEntity(日志实体类)

package com.bluereba.br_pojo.entity;

import com.baomidou.mybatisplus.annotation.TableField;
import com.baomidou.mybatisplus.annotation.TableName;
import com.bluereba.br_pojo.entity.type.BusinessType;
import com.bluereba.br_pojo.entity.type.OperatorType;
import io.swagger.annotations.ApiModel;
import io.swagger.annotations.ApiModelProperty;
import lombok.*;

/**
 * <p>
 * 日志记录表
 * </p>
 *
 * @author tuuuuuun
 * @since 2022-10-19 02:09:15
 */

@Data
@Builder
@NoArgsConstructor
@AllArgsConstructor
@TableName("br_operate_log")
@EqualsAndHashCode(callSuper = true)
@ApiModel(value = "日志实体", description = "记录操作日志")
public class OperateLogEntity extends BaseEntity {

    private static final long serialVersionUID = 1L;

    /**
     * <span style="color: #33c481;font-size: 1.2em">操作参数<spans/>
     */
    @TableField("operate_type")
    @ApiModelProperty(value = "操作人类别", example = "", notes = "")
    private OperatorType operateType;

    @TableField("business_type")
    @ApiModelProperty(value = "操作功能", example = "", notes = "")
    private BusinessType businessType;

    @TableField("is_success")
    @ApiModelProperty(value = "成功处理", example = "", notes = "")
    private Boolean isSuccess;

    @TableField("topic")
    @ApiModelProperty(value = "操作模块", example = "", notes = "")
    private String topic;

    @TableField("summary")
    @ApiModelProperty(value = "操作概括", example = "", notes = "")
    private String summary;

    @TableField("notes")
    @ApiModelProperty(value = "操作说明", example = "", notes = "")
    private String notes;

    /**
     * <span style="color: #33c481;font-size: 1.2em">请求参数<spans/>
     */
    @TableField("url")
    @ApiModelProperty(value = "请求url", example = "", notes = "")
    private String url;

    @TableField("method")
    @ApiModelProperty(value = "请求方法", example = "", notes = "")
    private String method;

    @TableField("params")
    @ApiModelProperty(value = "请求参数", example = "", notes = "")
    private String params;

    /**
     * <span style="color: #33c481;font-size: 1.2em">响应参数<spans/>
     */
    @ApiModelProperty(value = "响应实体", example = "", notes = "")
    private String response;
}

MybatisPlus

Config

@MapperScan("com.bluereba.br_dao.mapper") 指定 mapper 包路径，插件无所谓。也可以直接放到Spring Boot 启动类上

package com.bluereba.br_stomp.config;

import com.baomidou.mybatisplus.annotation.DbType;
import com.baomidou.mybatisplus.extension.plugins.MybatisPlusInterceptor;
import com.baomidou.mybatisplus.extension.plugins.inner.BlockAttackInnerInterceptor;
import com.baomidou.mybatisplus.extension.plugins.inner.OptimisticLockerInnerInterceptor;
import com.baomidou.mybatisplus.extension.plugins.inner.PaginationInnerInterceptor;
import org.mybatis.spring.annotation.MapperScan;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;

/**
 * MybatisPlus 配置类
 *
 * @author tuuuuuun
 * @since 2022/7/15 15:13
 */

@Configuration
@MapperScan("com.bluereba.br_dao.mapper")
public class MyBatisPlusConfig {

  @Bean
  public MybatisPlusInterceptor mybatisPlusInterceptor() {
    MybatisPlusInterceptor interceptor = new MybatisPlusInterceptor();
    // TODO.1 分页器
    interceptor.addInnerInterceptor(new PaginationInnerInterceptor(DbType.MYSQL));
    // TODO.2 乐观锁
    interceptor.addInnerInterceptor(new OptimisticLockerInnerInterceptor());
    // TODO.3 阻断全表更新、删除的操作
    interceptor.addInnerInterceptor(new BlockAttackInnerInterceptor());
    return interceptor;
  }
}

Mapper

BaseMapper 提供了许多单表操作的基础方法

package com.bluereba.br_dao.mapper;

import com.baomidou.mybatisplus.core.mapper.BaseMapper;
import com.bluereba.br_pojo.entity.OperateLogEntity;

/**
 * <p>
 * 日志记录表 Mapper 接口
 * </p>
 *
 * @author tuuuuuun
 * @since 2022-10-19 02:09:15
 */
public interface OperateLogMapper extends BaseMapper<OperateLogEntity> {}

Service

IService 定义了基础的业务方法，需要实现

package com.bluereba.br_service.service;

import com.baomidou.mybatisplus.extension.service.IService;
import com.bluereba.br_pojo.entity.OperateLogEntity;

/**
 * <p>
 * 日志记录表 服务类
 * </p>
 *
 * @author tuuuuuun
 * @since 2022-10-19 02:09:15
 */
public interface OperateLogService extends IService<OperateLogEntity> {}

ServiceImpl

ServiceImpl 实现了基础的业务方法

package com.bluereba.br_service.service.impl;

import com.baomidou.mybatisplus.extension.service.impl.ServiceImpl;
import com.bluereba.br_dao.mapper.OperateLogMapper;
import com.bluereba.br_pojo.entity.OperateLogEntity;
import com.bluereba.br_service.service.OperateLogService;
import org.springframework.stereotype.Service;

/**
 * <p>
 * 日志记录表 服务实现类
 * </p>
 *
 * @author tuuuuuun
 * @since 2022-10-19 02:09:15
 */

@Service
public class OperateLogServiceImpl extends ServiceImpl<OperateLogMapper, OperateLogEntity> implements OperateLogService {}

Aop

OperatorType 枚举 (操作人类型)

@EnumValue 指定数据库存储的字段

@JsonValue 响应前端的字段

package com.bluereba.br_pojo.entity.type;

import com.baomidou.mybatisplus.annotation.EnumValue;
import com.fasterxml.jackson.annotation.JsonValue;
import lombok.AllArgsConstructor;
import lombok.Getter;

/**
 * @author tuuuuuun
 * @since 2022/10/18 6:36
 */
@Getter
@AllArgsConstructor
public enum OperatorType {
  /**
   * 操作人类型
   */

  USER(1, "user"),
  GROUP(2, "group"),
  SYSTEM(3, "system");

  @EnumValue
  private final Integer id;

  @JsonValue
  private final String type;
}

BusinessType (操作动作类型)

@EnumValue 指定数据库存储的字段

@JsonValue 响应前端的字段

package com.bluereba.br_pojo.entity.type;

import com.baomidou.mybatisplus.annotation.EnumValue;
import com.fasterxml.jackson.annotation.JsonValue;
import lombok.AllArgsConstructor;
import lombok.Getter;

/**
 * @author tuuuuuun
 * @since 2022/10/18 6:36
 */
@Getter
@AllArgsConstructor
public enum BusinessType {
  /**
   * 操作动作
   */

  INSERT(1, "新增操作"),
  LOGIN(2, "登录操作"),
  LOGOUT(3, "登出操作"),
  UPDATE(4, "编辑操作"),
  DELETE(5, "删除操作"),
  FORCE(6, "强退"),
  IMPORT(7, "导入"),
  OTHER(8, "其他"),
  GENERATE(9, "生成代码"),
  CLEAN(10, "清空数据"),
  GRANT(11, "授权");

  @EnumValue
  private final Integer id;

  @JsonValue
  private final String type;
}

操作日志注解

package com.bluereba.br_operate_log;

import com.bluereba.br_pojo.entity.type.BusinessType;
import com.bluereba.br_pojo.entity.type.OperatorType;

import java.lang.annotation.*;

/**
 * @author tuuuuuun
 * @since 2022/10/18 6:32
 */
@Target(ElementType.METHOD)
@Retention(RetentionPolicy.RUNTIME)
@Documented
public @interface OperateLog {

  // 操作模块
  String topic() default "";

  // 操作概括
  String summary() default "";

  // 操作说明
  String notes() default "";

  // 操作功能（OTHER其他、INSERT新增、UPDATE修改、DELETE删除、GRANT授权、EXPORT导出、IMPORT导入、FORCE强退、GENCODE生成代码、CLEAN清空数据）
  BusinessType businessType() default BusinessType.OTHER;

  // 操作人类型（OTHER其他、MANAGE后台用户、MOBILE手机端用户）
  OperatorType operatorType() default OperatorType.USER;

  // 保存请求的参数
  boolean request() default true;

  // 保存响应的参数
  boolean response() default true;

  // 保存详情数据 {{@code ApiEntity<?> }}  save ? data
  boolean detail() default false;

}

OperateHelper(构建日志实体类辅助类)

响应参数
请求参数
操作参数

ApiEntity(响应实体类)

package com.bluereba.br_common.api;

import io.swagger.annotations.ApiModel;
import io.swagger.annotations.ApiModelProperty;
import lombok.AllArgsConstructor;
import lombok.Data;
import lombok.NoArgsConstructor;

import java.time.LocalDateTime;

/**
 * @author tuuuuuun
 * @since 2022/7/15 16:05
 */
@Data
@ApiModel("响应对象")
@AllArgsConstructor
@NoArgsConstructor
public class ApiEntity<T> {

  @ApiModelProperty(value = "状态码")
  Integer status;

  @ApiModelProperty(value = "消息")
  String message;

  @ApiModelProperty(value = "数据")
  T data;

  @ApiModelProperty(value = "时间")
  LocalDateTime timestamp;

  public ApiEntity(Integer status, T data) {
    this.status = status;
    this.data = data;
  }

  public ApiEntity(Integer status, String message, T data) {
    this.status = status;
    this.message = message;
    this.data = data;
  }

  public ApiEntity(Integer status, String message) {
    this.status = status;
    this.message = message;
  }
}

package com.bluereba.br_operate_log.utils;

import com.bluereba.br_common.api.ApiEntity;
import com.bluereba.br_operate_log.OperateLog;
import com.bluereba.br_pojo.entity.OperateLogEntity;
import com.fasterxml.jackson.core.JsonProcessingException;
import com.fasterxml.jackson.databind.ObjectMapper;
import io.swagger.annotations.Api;
import io.swagger.annotations.ApiOperation;
import lombok.AllArgsConstructor;
import lombok.NoArgsConstructor;
import org.apache.commons.lang3.StringUtils;
import org.aspectj.lang.JoinPoint;
import org.aspectj.lang.reflect.MethodSignature;
import org.springframework.beans.BeanUtils;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.lang.NonNull;
import org.springframework.lang.Nullable;
import org.springframework.stereotype.Component;
import org.springframework.web.context.request.RequestContextHolder;
import org.springframework.web.context.request.ServletRequestAttributes;

import javax.servlet.http.HttpServletRequest;
import java.util.Optional;

/**
 * 日志实体构建 辅助类
 *
 * @author tuuuuuun
 * @since 2022/10/18 20:15
 */

@AllArgsConstructor
@NoArgsConstructor
@Component
public class OperateHelper {

  private static ObjectMapper objectMapper;

  private OperateLogEntity.OperateLogEntityBuilder builder = null;
  private JoinPoint joinPoint = null;
  private ApiEntity<?> result = null;

  public static OperateHelper builder(@NonNull JoinPoint joinPoint,
                                      @Nullable ApiEntity<?> result
  ) {
    return new OperateHelper(OperateLogEntity.builder(), joinPoint, result);
  }

  /**
   * 获取 {{@code ApiOperation}} 注解
   *
   * @return ApiOperation annotation
   */
  public Optional<ApiOperation> getApiOperationAnnotation() {
    MethodSignature signature = (MethodSignature) joinPoint.getSignature();
    ApiOperation operation = signature.getMethod().getAnnotation(ApiOperation.class);
    return Optional.ofNullable(operation);
  }

  /**
   * 获取 {{@code Api}} 注解
   *
   * @return Api annotation
   */
  public Optional<Api> getApiAnnotation() {
    Api api = joinPoint.getTarget().getClass()
        .getAnnotation(Api.class);
    return Optional.ofNullable(api);
  }

  /**
   * 获取 {{@code OperateLog}} 注解
   *
   * @return OperateLog annotation
   */
  public Optional<OperateLog> getOperateLogAnnotation() {
    MethodSignature signature = (MethodSignature) joinPoint.getSignature();
    OperateLog operateLog = signature.getMethod().getAnnotation(OperateLog.class);
    return Optional.ofNullable(operateLog);
  }

  /**
   * 存储请求数据
   *
   * @return 结果
   */
  public boolean saveRequestData() {
    Optional<OperateLog> operateLog = getOperateLogAnnotation();
    if (operateLog.isPresent()) {
      OperateLog operate = operateLog.get();

      // 存储 请求参数
      return operate.response();
    }
    return false;
  }


  /**
   * 存储响应数据
   *
   * @return 结果
   */
  public boolean saveResponseData() {
    Optional<OperateLog> operateLog = getOperateLogAnnotation();
    if (operateLog.isPresent()) {
      OperateLog operate = operateLog.get();

      // 存储 响应参数
      return operate.response();
    }
    return false;
  }

  @Autowired
  public void setObjectMapper(ObjectMapper objectMapper) {
    OperateHelper.objectMapper = objectMapper;
  }

  /**
   * <span style="color: #33c481;font-size: 1.2em">操作参数<spans/>
   */
  public OperateHelper operate() {
    getOperateLogAnnotation().ifPresent(annotation -> {
      // 操作功能
      builder.businessType(annotation.businessType());

      // 操作人类型
      builder.operateType(annotation.operatorType());

      // 日志主题
      builder.topic(annotation.topic());

      // 日志概括
      builder.summary(annotation.summary());

      // 日志说明
      builder.notes(annotation.notes());
    });

    // 覆盖操作
    getApiAnnotation().ifPresent(annotation -> {
      String topic = StringUtils.join(annotation.tags(), "-");
      if (StringUtils.isNotBlank(topic)) {
        // 日志主题
        builder.topic(topic);
      }
    });

    // 覆盖操作
    getApiOperationAnnotation().ifPresent(annotation -> {
      // 日志概括
      if (StringUtils.isNotBlank(annotation.value())) {
        builder.summary(annotation.value());
      }

      // 日志说明
      if (StringUtils.isNotBlank(annotation.notes())) {
        builder.notes(annotation.notes());
      }
    });
    return this;
  }

  /**
   * <span style="color: #33c481;font-size: 1.2em">请求参数<spans/>
   */
  public OperateHelper request() throws Exception {
    if (!saveRequestData()) {
      return this;
    }

    ServletRequestAttributes requestAttributes = (ServletRequestAttributes)
        RequestContextHolder.getRequestAttributes();

    if (requestAttributes != null) {
      HttpServletRequest request = requestAttributes.getRequest();
      Object[] requestParam = joinPoint.getArgs();
      String method = request.getMethod();
      String url = request.getRequestURI();

      String requestParams = objectMapper.writeValueAsString(requestParam);
      builder
          .params(requestParams)
          .method(method)
          .url(url);
    }
    return this;
  }

  /**
   * <span style="color: #33c481;font-size: 1.2em">响应参数<spans/>
   */
  public OperateHelper response() throws JsonProcessingException {
    if (!saveResponseData()) {
      return this;
    }

    // 响应实体
    Boolean saveDetail = getOperateLogAnnotation()
        .map(OperateLog::detail)
        .orElse(false);

    String result;
    if (!saveDetail) {
      // copy result, 直接修改默认的 result,会影响返回给前端的数据
      ApiEntity<String> copyEntity = new ApiEntity<>();
      BeanUtils.copyProperties(this.result, copyEntity);
      copyEntity.setData("*");

      result = objectMapper.writeValueAsString(copyEntity);
    } else {
      result = objectMapper.writeValueAsString(this.result);
    }

    builder.response(result);
    return this;
  }

  public OperateHelper success() {
    builder.isSuccess(true);
    return this;
  }

  public OperateHelper fail() {
    builder.isSuccess(false);
    return this;
  }

  public OperateLogEntity build() {
    return builder.build();
  }

}

Mybatis 自动填充

填充基础实体类字段(用户参数，创建、更新参数)

PrincipalContextHolder

获取 Spring Security 上下文用户配置

注： UserDetailsEntity(实现了 UserDetails)

package com.bluereba.br_service.utils;

import com.bluereba.br_pojo.entity.security.UserDetailsEntity;
import org.springframework.security.core.Authentication;
import org.springframework.security.core.context.SecurityContextHolder;

import java.util.Optional;

/**
 * @author tuuuuuun
 * @since 2022/10/16 2:28
 */

public class PrincipalContextHolder {

  /**
   * 获取 当前用户 ID
   *
   * @return 用户 id
   */
  public static Long getUserId() {
    Authentication authentication = SecurityContextHolder.getContext().getAuthentication();
    if (authentication != null) {
      Object principal = authentication.getPrincipal();
      if (principal instanceof UserDetailsEntity) {
        UserDetailsEntity userDetails = (UserDetailsEntity) authentication.getPrincipal();
        return userDetails.getUid();
      }
    }
    return null;
  }

  public static Optional<Long> getUserIdOpt() {
    return Optional.ofNullable(getUserId());
  }
}

MyMetaObjectHandler

当插入实体时，会调用 insertFill 方法

当更新实体时，会调用 updateFill 方法

注: 只有构建了实体对象才会调用方法

package com.bluereba.br_web.handler;

import cn.hutool.extra.servlet.ServletUtil;
import com.baomidou.mybatisplus.core.handlers.MetaObjectHandler;
import com.bluereba.br_common.utils.AddressTemplate;
import com.bluereba.br_service.utils.PrincipalContextHolder;
import lombok.RequiredArgsConstructor;
import lombok.extern.slf4j.Slf4j;
import org.apache.commons.lang3.ObjectUtils;
import org.apache.ibatis.reflection.MetaObject;
import org.lionsoul.ip2region.xdb.Searcher;
import org.springframework.stereotype.Component;

import javax.servlet.http.HttpServletRequest;
import java.time.LocalDateTime;

/**
 * mybatis 自动填充, 可能会有填充问题
 *
 * @author tuuuuuun
 * @since 2022/7/15 17:54
 */
@Slf4j
@Component
@RequiredArgsConstructor
public class MyMetaObjectHandler implements MetaObjectHandler {

  private final HttpServletRequest httpServletRequest;

  private final Searcher searcher;

  private final AddressTemplate addressTemplate;

  @Override
  public void insertFill(MetaObject metaObject) {
    PrincipalContextHolder.getUserIdOpt().ifPresent(uid -> {
      // 填充创建人,更新人
      this.strictInsertFill(metaObject, "createBy", Long.class, uid);

      this.strictInsertFill(metaObject, "updateBy", Long.class, uid);
    });

    // 填充创建时间 和 更新时间
    this.strictInsertFill(metaObject, "createAt", LocalDateTime::now,
        LocalDateTime.class);
    this.strictInsertFill(metaObject, "updateAt", LocalDateTime::now,
        LocalDateTime.class);

    // 填充 ip 已经 ip address
    try {
      // 糊涂包 工具类, 获取实际请求ip (包括nginx代理)
      String ip = ServletUtil.getClientIP(httpServletRequest);

      // ip2region 包, 离线将 ip 转 地址("国家|区域|省|市|宽带")
      String address = searcher.search(ip);

      this.strictInsertFill(metaObject, "createIp", String.class, ip);
      this.strictInsertFill(metaObject, "createAddress", String.class, address);

      this.strictInsertFill(metaObject, "updateIp", String.class, ip);
      this.strictInsertFill(metaObject, "updateAddress", String.class, address);
    } catch (Exception e) {
      log.error(e.getMessage(), e);
    }
  }

  @Override
  public void updateFill(MetaObject metaObject) {
    PrincipalContextHolder.getUserIdOpt().ifPresent(uid -> {
      // 填充创建人,更新人
      this.strictUpdateFill(metaObject, "updateBy", Long.class, uid);
    });

    // 填充 ip 已经 ip address
    try {
      String ip = ServletUtil.getClientIP(httpServletRequest);
      String address = searcher.search(ip);
      this.strictUpdateFill(metaObject, "updateIp", String.class, ip);
      this.strictUpdateFill(metaObject, "updateAddress", String.class, address);
    } catch (Exception e) {
      log.error(e.getMessage(), e);
    }

    // 填充更新时间
    /*this.strictUpdateFill(metaObject, "updateAt", LocalDateTime::now,
        LocalDateTime.class);*/
    this.setFieldValByName("updateAt", LocalDateTime.now(), metaObject);
  }

}

Aspect

package com.bluereba.br_operate_log.aspect;

import com.bluereba.br_common.api.ApiEntity;
import com.bluereba.br_operate_log.utils.OperateHelper;
import com.bluereba.br_pojo.entity.OperateLogEntity;
import com.bluereba.br_service.service.OperateLogService;
import lombok.RequiredArgsConstructor;
import lombok.SneakyThrows;
import lombok.extern.slf4j.Slf4j;
import org.aspectj.lang.JoinPoint;
import org.aspectj.lang.annotation.AfterReturning;
import org.aspectj.lang.annotation.AfterThrowing;
import org.aspectj.lang.annotation.Aspect;
import org.aspectj.lang.annotation.Pointcut;
import org.springframework.scheduling.annotation.Async;
import org.springframework.stereotype.Component;

/**
 * @author tuuuuuun
 * @since 2022/3/2 20:43
 */

@Slf4j
@Aspect
@Component
@RequiredArgsConstructor
public class OperateLogAspect {

  private final OperateLogService operateLogService;

  /**
   * 通过注解类标识 控制操作 (OperateLog 注解标识)
   */
  @Pointcut("@annotation(com.bluereba.br_operate_log.OperateLog)")
  public void operateLog() {
  }

  /**
   * 方法成功执行
   */
  @Async
  @SneakyThrows
  @AfterReturning(value = "operateLog()", returning = "result")
  public void afterReturnOperate(JoinPoint joinPoint, ApiEntity<?> result) {
    OperateLogEntity operateEntity = OperateHelper.builder(joinPoint, result)
        .request()
        .response()
        .operate()
        .success()
        .build();

    // 由 mybatis plus 提供 向数据库中插入一条数据
    operateLogService.save(operateEntity);
  }


  /**
   * 方法执行中异常
   */
  @Async
  @SneakyThrows
  @AfterThrowing(pointcut = "operateLog()", throwing = "e")
  public void afterThrowingOperate(JoinPoint joinPoint, Throwable e) {
    OperateLogEntity operateEntity = OperateHelper.builder(joinPoint, null)
        .request()
        .operate()
        .fail()
        .build();

    // 由 mybatis plus 提供 向数据库中插入一条数据
    operateLogService.save(operateEntity);
  }

}

处理 RestController 返回的 ApiEntity 实体

当消息为空或消息为默认消息将替换为 swagger注解 {{@ApiOperation value}} 值

package com.bluereba.br_common.handler;


import com.bluereba.br_common.api.ApiEntity;
import com.bluereba.br_common.api.type.base.ApiEnum;
import io.swagger.annotations.ApiOperation;
import org.apache.commons.lang3.StringUtils;
import org.springframework.core.MethodParameter;
import org.springframework.http.MediaType;
import org.springframework.http.converter.HttpMessageConverter;
import org.springframework.http.server.ServerHttpRequest;
import org.springframework.http.server.ServerHttpResponse;
import org.springframework.lang.NonNull;
import org.springframework.lang.Nullable;
import org.springframework.web.bind.annotation.RestControllerAdvice;
import org.springframework.web.servlet.mvc.method.annotation.ResponseBodyAdvice;

import java.time.LocalDateTime;

/**
 * @author tuuuuuun
 * @since 2022/10/17 21:38
 */

@RestControllerAdvice
public class ResponseBodyHandler implements ResponseBodyAdvice<ApiEntity<?>> {

  @Override
  public boolean supports(@NonNull MethodParameter returnType,
                          @NonNull Class<? extends HttpMessageConverter<?>> converterType) {

    // 只处理 {{@code ApiEntity }} 对象
    Class<?> c = returnType.getParameterType();
    return c == ApiEntity.class;
  }

  @Override
  public ApiEntity<?> beforeBodyWrite(@Nullable ApiEntity<?> body,
                                      @NonNull MethodParameter returnType,
                                      @NonNull MediaType selectedContentType,
                                      @NonNull Class<? extends HttpMessageConverter<?>> selectedConverterType,
                                      @NonNull ServerHttpRequest request,
                                      @NonNull ServerHttpResponse response) {

    if (body != null) {
      // 获取 {{@code ApiOperation}} 注解
      ApiOperation apiOperation = returnType.getAnnotatedElement()
          .getAnnotation(ApiOperation.class);

      if (apiOperation != null) {
        // {{@code ApiOperation}} 注解 @value
        String message = apiOperation.value();

        // 响应对象 消息
        String bodyMessage = body.getMessage();

        // 默认成功消息
        String successMessage = ApiEnum.OK.getMessage();

        // 当消息为空 或 消息为默认消息 将替换为 swagger注解{{@ApiOperation value}}
        if (StringUtils.isEmpty(bodyMessage) || successMessage.equals(bodyMessage)) {
          body.setMessage(message);
        }
      }
      body.setTimestamp(LocalDateTime.now());
    }
    return body;
  }
}

使用

UserController

success 静态方法是对 ApiEnity 进行的封装

package com.bluereba.br_stomp.controller;

import com.bluereba.br_common.api.ApiEntity;
import com.bluereba.br_operate_log.OperateLog;
import com.bluereba.br_pojo.dto.UserLoginDto;
import com.bluereba.br_pojo.entity.UserEntity;
import com.bluereba.br_pojo.entity.type.BusinessType;
import com.bluereba.br_pojo.vo.UserRegisterVo;
import com.bluereba.br_service.service.UserService;
import com.github.xiaoymin.knife4j.annotations.ApiSupport;
import io.swagger.annotations.Api;
import io.swagger.annotations.ApiOperation;
import lombok.RequiredArgsConstructor;
import org.springframework.web.bind.annotation.*;

import static com.bluereba.br_common.api.ApiRes.success;

/**
 * @author tuuuuuun
 * @since 2022/10/9 19:15
 */

@Api(tags = "用户模块")  // Api.tags 将成为 操作日志的主题(topic)
@RestController
@RequestMapping("user")
@RequiredArgsConstructor
public class UserController {

  private final UserService userService;

  @PostMapping("/login")
  @ApiOperation(value = "用户登陆")  // ApiOperation.value 将成为 操作日志的操作概况(summary)
  @OperateLog(businessType = BusinessType.LOGIN)
  public ApiEntity<UserLoginDto> login(@RequestBody UserRegisterVo vo) {
    UserLoginDto dto = userService.signUp(vo);
    return success(dto);
  }

  @DeleteMapping("/logout")
  @ApiOperation(value = "用户退出")
  @OperateLog(businessType = BusinessType.LOGOUT)
  public ApiEntity<?> logout() {
    userService.logout();
    return success();
  }

  @GetMapping("/info")
  @ApiOperation(value = "用户信息")
  public ApiEntity<UserEntity> info() {
    UserEntity info = userService.info();
    return success(info);
  }

}

脱敏

UserRegisterVo

package com.bluereba.br_pojo.vo;

import com.bluereba.br_pojo.json.ChineseNameSerialize;
import com.bluereba.br_pojo.json.PasswordSerialize;
import com.fasterxml.jackson.databind.annotation.JsonSerialize;
import io.swagger.annotations.ApiModel;
import io.swagger.annotations.ApiModelProperty;
import lombok.AllArgsConstructor;
import lombok.Data;
import lombok.NoArgsConstructor;

import javax.validation.constraints.NotNull;
import java.io.Serializable;

/**
 * 登录视图
 *
 * @author tuuuuuun
 * @since 2022/10/10 0:00
 */

@Data
@NoArgsConstructor
@AllArgsConstructor
@ApiModel(value = "登陆vo", description = "")
public class UserRegisterVo implements Serializable {

  @NotNull(message = "登陆用户名不能为空")
  @ApiModelProperty(value = "用户名", example = "", notes = "")
  @JsonSerialize(using = ChineseNameSerialize.class)
  private String username;

  @NotNull(message = "用户密码不能为空")
  @ApiModelProperty(value = "用户密码", example = "", notes = "")
  @JsonSerialize(using = PasswordSerialize.class)
  private String password;

  @ApiModelProperty(value = "记住我", example = "false",
      notes = "true, false, 1, 0, True, False")
  private Boolean readme = false;

}

ChineseNameSerialize(中文名序列化)

package com.bluereba.br_pojo.json;

import cn.hutool.core.util.DesensitizedUtil;
import com.fasterxml.jackson.core.JsonGenerator;
import com.fasterxml.jackson.databind.JsonSerializer;
import com.fasterxml.jackson.databind.SerializerProvider;

import java.io.IOException;

/**
 * @author tuuuuuun
 * @since 2022/10/18 23:00
 */
public class ChineseNameSerialize extends JsonSerializer<String> {

  @Override
  public void serialize(String v, JsonGenerator g, SerializerProvider s)
      throws IOException {

    // DesensitizedUtil 糊涂包下的脱敏工具类,
    // chineseName 方法是对首字符后的字符串串进行 * 替换
    g.writeString(DesensitizedUtil.chineseName(v));
  }
}

PasswordSerialize(密码序列化)

package com.bluereba.br_pojo.json;

import cn.hutool.core.util.DesensitizedUtil;
import com.fasterxml.jackson.core.JsonGenerator;
import com.fasterxml.jackson.databind.JsonSerializer;
import com.fasterxml.jackson.databind.SerializerProvider;

import java.io.IOException;

/**
 * @author tuuuuuun
 * @since 2022/10/18 23:00
 */
public class PasswordSerialize extends JsonSerializer<String> {

  @Override
  public void serialize(String v, JsonGenerator g, SerializerProvider s)
      throws IOException {

    // DesensitizedUtil 糊涂包下的脱敏工具类,
    // password 方法是对全字符串进行 * 替换
    g.writeString(DesensitizedUtil.password(v));
  }
}

spring boot 存储操作日志(mysql)

spring boot 存储操作日志(mysql)

操作日志实体类

SQL(table 数据表)

BaseeEntity(基础实体类)

OperateLogEntity(日志实体类)

MybatisPlus

Config

Mapper

Service

ServiceImpl

Aop

OperatorType 枚举 (操作人类型)

BusinessType (操作动作类型)

操作日志注解

OperateHelper(构建日志实体类辅助类)

ApiEntity(响应实体类)

Mybatis 自动填充

PrincipalContextHolder

MyMetaObjectHandler

Aspect

处理 RestController 返回的 ApiEntity 实体

使用

UserController

脱敏

UserRegisterVo

ChineseNameSerialize(中文名序列化)

PasswordSerialize(密码序列化)

效果

Success

接口

请求登陆接口

数据库存储

Fail

接口

数据存储

spring boot 存储操作日志(mysql)

spring boot 存储操作日志(mysql)

操作日志实体类

SQL(table 数据表)

BaseeEntity(基础实体类)

OperateLogEntity(日志实体类)

MybatisPlus

Config

Mapper

Service

ServiceImpl

Aop

OperatorType 枚举 (操作人类型)

BusinessType (操作动作 类型)

操作日志注解

OperateHelper(构建日志实体类辅助类)

ApiEntity(响应实体类)

Mybatis 自动填充

PrincipalContextHolder

MyMetaObjectHandler

Aspect

处理 RestController 返回的 ApiEntity 实体

使用

UserController

脱敏

UserRegisterVo

ChineseNameSerialize(中文名序列化)

PasswordSerialize(密码序列化)

效果

Success

接口

请求登陆接口

数据库存储

Fail

接口

数据存储

BusinessType (操作动作类型)
