神经网络：pytorch线性回归的从零实现

线性回归的从零实现

例子：用线性回归模型拟合带有服从-0.5 到 0.5 的均匀分布噪声的正弦函数

import numpy as np
from matplotlib import pyplot as plt
import torch
import random

生成数据集: 正弦函数+随机噪声

num_observations = 100
x = np.linspace(-3, 3, num_observations)
y = np.sin(x) + np.random.uniform(-0.5, 0.5, num_observations)

画出训练数据散点图

plt.xlabel("x")
plt.ylabel("y")
plt.plot(x, y, "ob")
plt.show()

实现一个小批量读取数据集的迭代器
每 10 个数据随机取 1 个

def data_iter(batch_size, features, labels):
    num_examples = len(features)
    indices = list(range(num_examples))
    random.shuffle(indices)
    for i in range(0, num_examples, batch_size):
        batch_indices = torch.tensor(indices[i: min(i + batch_size, num_examples)])
        yield features[batch_indices], labels[batch_indices]

转换数据格式，测试一下迭代器是否正常工作

batch_size = 10
features = torch.from_numpy(x).type(torch.float32).reshape(-1, 1)
labels = torch.from_numpy(y).type(torch.float32).reshape(-1, 1)

for _X, _y in data_iter(batch_size, features, labels):
    print(_X, '\n', _y)
    break

output:

tensor([[-2.2727],
        [ 1.9091],
        [ 0.0909],
        [ 2.5758],
        [-2.0303],
        [-1.0000],
        [ 2.3939],
        [ 1.1818],
        [ 0.1515],
        [-2.6364]])
 tensor([[-1.1310],
        [ 1.4419],
        [ 0.1782],
        [ 0.7734],
        [-1.1041],
        [-0.4980],
        [ 0.6712],
        [ 0.4336],
        [ 0.2011],
        [-0.3118]])

初始化模型参数

w = torch.ones((1,1), requires_grad=True, dtype=torch.float32)
b = torch.zeros(1, requires_grad=True, dtype=torch.float32)

定义模型

def linreg(X, w, b):
    """线性回归模型"""
    return torch.matmul(X, w) + b

定义损失函数

def squared_loss(y_hat, y):
    """均方损失"""
    return (y_hat - y.reshape(y_hat.shape)) ** 2 / 2

定义优化函数 SGD

def sgd(params, lr, batch_size):
    """小批量随机梯度下降"""
    with torch.no_grad():
        for param in params:
            param -= lr * param.grad / batch_size
            param.grad.zero_()

设置好各类参数

lr = 0.0001
num_epochs = 100
net = linreg
loss = squared_loss

开始训练

for epoch in range(num_epochs):
    for X, y in data_iter(batch_size, features, labels):
        l = loss(net(_X, w, b), y)
        l.sum().backward()
        sgd([w, b], lr, batch_size)
    with torch.no_grad():
        train_l = loss(net(X, w, b), y)
        print(f'epoch {epoch + 1}, loss {float(train_l.mean()):f}, w {w[0, 0]}, b {b[0]}')

output:

epoch 1, loss 1.053528, w 0.9966095089912415, b -5.746930037275888e-05
epoch 2, loss 0.865971, w 0.9933732748031616, b -0.00011485163850011304
epoch 3, loss 0.299636, w 0.9897872805595398, b -0.00017201804439537227
...
epoch 99, loss 0.395929, w 0.7071191072463989, b -0.0048923674039542675
epoch 100, loss 0.181151, w 0.7047168016433716, b -0.004934354219585657

展示训练结果

_y = net(features, w, b)
plt.title("linear model")
plt.xlabel("x")
plt.ylabel("y")
plt.plot(features.numpy(), labels.numpy(), 'ob')
plt.plot(features.numpy(), _y.detach().numpy(), 'r')
plt.show()

坑

• 注意对原始数据进行处理时,最后需要的维度是怎么样的,维度不对矩阵乘法运行不了
• 留意 tensor 中元素的数据类型
• 千万记得在自动求导后清除梯度(param.grad.zero_())

完整代码：pytorch线性回归的从零实现
参考内容：动手学深度学习v2 # 李沐
