一、FastDeploy 安装

由于编译配置较为困难（本地环境可能有误），建议大家使用已编译好的whl包。

FastDeploy 预编编译Python Wheel包

FastDeploy提供了在Windows/Linux/Mac上的预先编译Python Wheel包，开发者可以直接下载后安装，也可以自行编译代码。

使用如下命令即可在Linux的Pythotn 3.8环境安装支持CPU部署的FastDeploy

python -m pip install fastdeploy_python-0.2.0-cp38-cp38-manylinux1_x86_64.whl

1.注意事项

不要重复安装fastdeploy-python和fastdeploy-gpu-python
如已安装CPU版本的fastdeploy-python后，在安装GPU版本的fastdeploy-gpu-python，请先执行pip uninstall fastdeploy-python卸载已有版本

2.环境依赖

cuda >= 11.2
cudnn >= 8.0

3.下载地址

3.1 Linux x64平台

CPU 安装包	硬件	Python版本
fastdeploy_python-0.2.0-cp36-cp36m-manylinux1_x86_64.whl	CPU	3.6
fastdeploy_python-0.2.0-cp37-cp37m-manylinux1_x86_64.whl	CPU	3.7
fastdeploy_python-0.2.0-cp38-cp38-manylinux1_x86_64.whl	CPU	3.8
fastdeploy_python-0.2.0-cp39-cp39-manylinux1_x86_64.whl	CPU	3.9

GPU 安装包	硬件	Python版本
fastdeploy_gpu_python-0.2.0-cp36-cp36m-manylinux1_x86_64.whl	CPU/GPU	3.6
fastdeploy_gpu_python-0.2.0-cp37-cp37m-manylinux1_x86_64.whl	CPU/GPU	3.7
fastdeploy_gpu_python-0.2.0-cp38-cp38-manylinux1_x86_64.whl	CPU/GPU	3.8
fastdeploy_gpu_python-0.2.0-cp39-cp39-manylinux1_x86_64.whl	CPU/GPU	3.9

3.2 Windows 10 x64平台

CPU 安装包	硬件	Python版本
fastdeploy_python-0.2.0-cp38-cp38-win_amd64.whl	CPU	3.8
fastdeploy_python-0.2.0-cp39-cp39-win_amd64.whl	CPU	3.9

GPU 安装包	硬件	Python版本
fastdeploy_gpu_python-0.2.0-cp38-cp38-win_amd64.whl	CPU/GPU	3.8
fastdeploy_gpu_python-0.2.0-cp39-cp39-win_amd64.whl	CPU/GPU	3.9

3.3 Linux aarch64平台

安装包	硬件	Python版本
fastdeploy_python-0.2.0-cp36-cp36m-manylinux_2_17_aarch64.whl	CPU	3.6
fastdeploy_python-0.2.0-cp37-cp37m-manylinux_2_17_aarch64.whl	CPU	3.7
fastdeploy_python-0.2.0-cp38-cp38-manylinux_2_17_aarch64.whl	CPU	3.8
fastdeploy_python-0.2.0-cp39-cp39-manylinux_2_17_aarch64.whl	CPU	3.9

3.4 Mac OSX平台

架构	硬件	安装包	Python版本
x86_64	CPU	fastdeploy_python-0.2.0-cp36-cp36m-macosx_10_14_x86_64.whl	3.6
x86_64	CPU	fastdeploy_python-0.2.0-cp37-cp37m-macosx_10_14_x86_64.whl	3.7
x86_64	CPU	fastdeploy_python-0.2.0-cp38-cp38-macosx_10_14_x86_64.whl	3.8
x86_64	CPU	fastdeploy_python-0.2.0-cp39-cp39-macosx_10_14_x86_64.whl	3.9
arm64	CPU	fastdeploy_python-0.2.0-cp38-cp38-macosx_11_0_arm64.whl	3.8
arm64	CPU	fastdeploy_python-0.2.0-cp39-cp39-macosx_11_0_arm64.whl	3.9

4.其它文档

二、实践

1.git下载

 # git下载
 !git clone -b develop https://github.com/PaddlePaddle/FastDeploy.git --depth=1

Cloning into 'FastDeploy'...
remote: Enumerating objects: 1253, done.[K
remote: Counting objects: 100% (1253/1253), done.[K
remote: Compressing objects: 100% (965/965), done.[K
remote: Total 1253 (delta 309), reused 1046 (delta 242), pack-reused 0[K
Receiving objects: 100% (1253/1253), 2.37 MiB | 57.00 KiB/s, done.
Resolving deltas: 100% (309/309), done.
Checking connectivity... done.

2.查看系统环境

!python --version

Python 3.7.4

!nvidia-smi

Wed Aug 17 21:21:49 2022
+-----------------------------------------------------------------------------+
| NVIDIA-SMI 460.32.03    Driver Version: 460.32.03    CUDA Version: 11.2     |
|-------------------------------+----------------------+----------------------+
| GPU  Name        Persistence-M| Bus-Id        Disp.A | Volatile Uncorr. ECC |
| Fan  Temp  Perf  Pwr:Usage/Cap|         Memory-Usage | GPU-Util  Compute M. |
|                               |                      |               MIG M. |
|===============================+======================+======================|
|   0  Tesla V100-SXM2...  On   | 00000000:43:00.0 Off |                    0 |
| N/A   42C    P0    41W / 300W |      0MiB / 32510MiB |      0%      Default |
|                               |                      |                  N/A |
+-------------------------------+----------------------+----------------------+

+-----------------------------------------------------------------------------+
| Processes:                                                                  |
|  GPU   GI   CI        PID   Type   Process name                  GPU Memory |
|        ID   ID                                                   Usage      |
|=============================================================================|
|  No running processes found                                                 |
+-----------------------------------------------------------------------------+

可见环境满足条件

python 3.7
cuda 11.2

3.linux安装

!pip install https://bj.bcebos.com/paddlehub/fastdeploy/wheels/fastdeploy_gpu_python-0.2.0-cp37-cp37m-manylinux1_x86_64.whl

Looking in indexes: https://pypi.tuna.tsinghua.edu.cn/simple
Collecting fastdeploy-gpu-python==0.2.0
  Downloading https://bj.bcebos.com/paddlehub/fastdeploy/wheels/fastdeploy_gpu_python-0.2.0-cp37-cp37m-manylinux1_x86_64.whl (1508.4 MB)
[2K     [90m━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━[0m [32m1.5/1.5 GB[0m [31m711.9 kB/s[0m eta [36m0:00:00[0m00:01[0m00:01[0m
[?25hRequirement already satisfied: tqdm in /opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages (from fastdeploy-gpu-python==0.2.0) (4.27.0)
Requirement already satisfied: requests in /opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages (from fastdeploy-gpu-python==0.2.0) (2.24.0)
Requirement already satisfied: urllib3!=1.25.0,!=1.25.1,<1.26,>=1.21.1 in /opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages (from requests->fastdeploy-gpu-python==0.2.0) (1.25.6)
Requirement already satisfied: idna<3,>=2.5 in /opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages (from requests->fastdeploy-gpu-python==0.2.0) (2.8)
Requirement already satisfied: chardet<4,>=3.0.2 in /opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages (from requests->fastdeploy-gpu-python==0.2.0) (3.0.4)
Requirement already satisfied: certifi>=2017.4.17 in /opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages (from requests->fastdeploy-gpu-python==0.2.0) (2019.9.11)
Installing collected packages: fastdeploy-gpu-python
Successfully installed fastdeploy-gpu-python-0.2.0

[1m[[0m[34;49mnotice[0m[1;39;49m][0m[39;49m A new release of pip available: [0m[31;49m22.1.2[0m[39;49m -> [0m[32;49m22.2.2[0m
[1m[[0m[34;49mnotice[0m[1;39;49m][0m[39;49m To update, run: [0m[32;49mpip install --upgrade pip[0m

!python -m pip install --upgrade pip --user

Looking in indexes: https://pypi.tuna.tsinghua.edu.cn/simple
Requirement already satisfied: pip in /opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages (22.1.2)
Collecting pip
  Downloading https://pypi.tuna.tsinghua.edu.cn/packages/1f/2c/d9626f045e7b49a6225c6b09257861f24da78f4e5f23af2ddbdf852c99b8/pip-22.2.2-py3-none-any.whl (2.0 MB)
[2K     [90m━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━[0m [32m2.0/2.0 MB[0m [31m4.1 MB/s[0m eta [36m0:00:00[0m00:01[0m00:01[0m
[?25hInstalling collected packages: pip
Successfully installed pip-22.2.2

[1m[[0m[34;49mnotice[0m[1;39;49m][0m[39;49m A new release of pip available: [0m[31;49m22.1.2[0m[39;49m -> [0m[32;49m22.2.2[0m
[1m[[0m[34;49mnotice[0m[1;39;49m][0m[39;49m To update, run: [0m[32;49mpython -m pip install --upgrade pip[0m

4.运行

4.1下载PaddleSeg

!git clone https://gitee.com/PaddlePaddle/PaddleSeg.git --depth=1

Cloning into 'PaddleSeg'...
remote: Enumerating objects: 1815, done.[K
remote: Counting objects: 100% (1815/1815), done.[K
remote: Compressing objects: 100% (1450/1450), done.[K
remote: Total 1815 (delta 485), reused 1227 (delta 287), pack-reused 0[K
Receiving objects: 100% (1815/1815), 48.94 MiB | 9.42 MiB/s, done.
Resolving deltas: 100% (485/485), done.
Checking connectivity... done.

4.2 获取预训练模型

%cd ~/PaddleSeg/
!mkdir bisenet
%cd bisenet
!wget https://paddleseg.bj.bcebos.com/dygraph/cityscapes/bisenet_cityscapes_1024x1024_160k/model.pdparams
%cd ../..

/home/aistudio/PaddleSeg
mkdir: cannot create directory ‘bisenet’: File exists
/home/aistudio/PaddleSeg/bisenet
--2022-08-17 21:41:56--  https://paddleseg.bj.bcebos.com/dygraph/cityscapes/bisenet_cityscapes_1024x1024_160k/model.pdparams
Resolving paddleseg.bj.bcebos.com (paddleseg.bj.bcebos.com)... 100.67.200.6
Connecting to paddleseg.bj.bcebos.com (paddleseg.bj.bcebos.com)|100.67.200.6|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 15301992 (15M) [application/octet-stream]
Saving to: ‘model.pdparams’

model.pdparams      100%[===================>]  14.59M  88.4MB/s    in 0.2s

2022-08-17 21:41:56 (88.4 MB/s) - ‘model.pdparams’ saved [15301992/15301992]

/home/aistudio

4.3导出静态模型

%cd ~/PaddleSeg/

# 设置1张可用的卡
!export CUDA_VISIBLE_DEVICES=0
# windows下请执行以下命令
# set CUDA_VISIBLE_DEVICES=0
!python export.py \
       --config configs/bisenet/bisenet_cityscapes_1024x1024_160k.yml \
       --model_path bisenet/model.pdparams \
       --save_dir output \
       --input_shape 1 3 512 1024

/home/aistudio/PaddleSeg
/home/aistudio/PaddleSeg/paddleseg/models/losses/rmi_loss.py:78: DeprecationWarning: invalid escape sequence \i
  """
W0817 21:43:59.497787  2170 gpu_resources.cc:61] Please NOTE: device: 0, GPU Compute Capability: 7.0, Driver API Version: 11.2, Runtime API Version: 10.1
W0817 21:43:59.501492  2170 gpu_resources.cc:91] device: 0, cuDNN Version: 7.6.
2022-08-17 21:44:01 [INFO]	Loaded trained params of model successfully.
2022-08-17 21:44:03 [INFO]	Model is saved in output.

!ls output/

deploy.yaml  model.pdiparams  model.pdiparams.info  model.pdmodel

三、预测

在部署前，需确认以下两个步骤

1. 软硬件环境满足要求，参考FastDeploy环境要求
1. FastDeploy Python whl包安装，参考FastDeploy Python安装

本目录下提供infer.py快速完成Unet在CPU/GPU，以及GPU上通过TensorRT加速部署的示例。执行如下脚本即可完成

- 下载部署示例代码
git clone https://github.com/PaddlePaddle/FastDeploy.git
cd FastDeploy/examples/vision/segmentation/paddleseg/python

# 下载Unet模型文件和测试图片
wget https://bj.bcebos.com/paddlehub/fastdeploy/Unet_cityscapes_without_argmax_infer.tgz
tar -xvf Unet_cityscapes_without_argmax_infer.tgz
wget https://paddleseg.bj.bcebos.com/dygraph/demo/cityscapes_demo.png


# CPU推理
python infer.py --model Unet_cityscapes_without_argmax_infer --image cityscapes_demo.png --device cpu
# GPU推理
python infer.py --model Unet_cityscapes_without_argmax_infer --image cityscapes_demo.png --device gpu
# GPU上使用TensorRT推理 （注意：TensorRT推理第一次运行，有序列化模型的操作，有一定耗时，需要耐心等待）
python infer.py --model Unet_cityscapes_without_argmax_infer --image cityscapes_demo.png --device gpu --use_trt True

运行完成可视化结果如下图所示

1. PaddleSegModel Python接口

fd.vision.segmentation.PaddleSegModel(model_file, params_file, config_file, runtime_option=None, model_format=Frontend.PADDLE)

PaddleSeg模型加载和初始化，其中model_file, params_file以及config_file为训练模型导出的Paddle inference文件，具体请参考其文档说明模型导出

参数

model_file(str): 模型文件路径

params_file(str): 参数文件路径

config_file(str): 推理部署配置文件

runtime_option(RuntimeOption): 后端推理配置，默认为None，即采用默认配置

model_format(Frontend): 模型格式，默认为Paddle格式

2.predict函数

PaddleSegModel.predict(input_image)
模型预测结口，输入图像直接输出检测结果。

参数

input_image(np.ndarray): 输入数据，注意需为HWC，BGR格式

返回

返回fastdeploy.vision.SegmentationResult结构体，结构体说明参考文档视觉模型预测结果

3.类成员属性

3.1 预处理参数

用户可按照自己的实际需求，修改下列预处理参数，从而影响最终的推理和部署效果

is_vertical_screen(bool): PP-HumanSeg系列模型通过设置此参数为true表明输入图片是竖屏，即height大于width的图片

3.2 后处理参数

with_softmax(bool): 当模型导出时，并未指定with_softmax参数，可通过此设置此参数为true，将预测的输出分割标签（label_map）对应的概率结果(score_map)做softmax归一化处理
