效果如下
实现方案
使用uniapp官方组件 movable-area和movable-view
代码解析
-
在components新建一个xxx.vue组件
-
重点在于movable-area与movable-view需要分别增加pointer-events: none和pointer-events: auto用于组件事件穿透与恢复组件事件(此处不加会导致引用该组件的父组件无法使用事件)
-
组件代码如下:
$all_width: 96rpx; $all_height:96rpx; .movable-area { height: 100vh; width: 750rpx; top: 0; position: fixed; pointer-events: none; //此处要加,鼠标事件可以渗透 .movable-view { width: $all_width; height: $all_height; pointer-events: auto; //恢复鼠标事件 image { width: $all_width; height: $all_height; } } }
组件生成后可mian.js全局挂载,后续不需要每个页面都进行引入
import App from './App'
import Vue from 'vue'
import myHome from '@/components/my_home.vue' //引入组件
Vue.config.productionTip = false
App.mpType = 'app'
const app = new Vue({
...App
})
Vue.component('my-home',myHome) //进行全局挂载
app.$mount()
全局挂载后可在需要使用的页面使用
<template>
<view class="content">
<!--组件引用-->
<my-home></my-home>
</view>
</template>
