环境
| 角色 | 服务器配置 | 操作系统版本 | 公网IP |
|---|---|---|---|
| 即作为 slave 也作为 master | 阿里云ECS实例 server1 | Ubuntu 14.04 mysql 5.5.44 | 47.101.70.109 |
| 即作为 slave 也作为 master | 阿里云ECS实例 server2 | Ubuntu 14.04 mysql 5.5.44 | 106.14.151.244 |
修改配置文件
先从 server1 开始配置，server2 做同样配置。
- 修改 /etc/mysql/my.cnf
# 不指定远程访问的IP
# bind-address = 127.0.01
# 唯一标示ID，server1设置为1，server2设置为2
server-id = 1
# 忽略同步的数据库
replicate-ignore-db = mysql
replicate-ignore-db = information_schema
replicate-ignore-db = performance_schema
# 需要同步的库，如果有多个数据库需要同步，设置多行
binlog-do-db = shjyzxk
# 开启二进制日志，slave端可以通过该日志来确定执行操作
log_bin = master_01，server1设置为master_01，server2设置为master_01
- 重启本机 mysql
$ service mysql restart
开启远程访问
登录 server1->mysql，server2 做同样配置。
# 操作数据库mysql
mysql> use mysql;
# 查询root用户开放的host
mysql> select user,host from user where user='root';
+------+--------------+
| user | host |
+------+--------------+
| root | 127.0.0.1 |
+------+--------------+
# 如果没有"%"这个host值，就进行修改:
mysql> update user set host='%' where user='root' and host='127.0.0.1';
# 刷新生效
mysql> flush privileges;
# 授权可以远程访问
grant all privileges on *.* to root@'%'identified by 'passwd';
配置同步的Master
- 登录 server1->mysql
# 查看master状态
mysql> show master status;
+------------------+----------+--------------+------------------+
| File | Position | Binlog_Do_DB | Binlog_Ignore_DB |
+------------------+----------+--------------+------------------+
| master_01.000006 | 107 | test | |
+------------------+----------+--------------+------------------+
1 row in set (0.00 sec)
- 登录 server2->mysql
# 查看 master 状态
mysql> show master status;
+------------------+----------+--------------+------------------+
| File | Position | Binlog_Do_DB | Binlog_Ignore_DB |
+------------------+----------+--------------+------------------+
| master_02.000015 | 107 | test | |
+------------------+----------+--------------+------------------+
1 row in set (0.00 sec)
- 切换 server1->mysql
# 创建数据库test
mysql> create database test;
# 配置master
mysql> CHANGE MASTER TO MASTER_HOST='106.14.151.244 ',MASTER_USER='root',MASTER_PASSWORD='123456',MASTER_PORT=3306, MASTER_LOG_FILE='master_02.000015',MASTER_LOG_POS=107,MASTER_CONNECT_RETRY=2;
Query OK, 0 rows affected (0.01 sec)
# 启动slave
mysql> start slave;
# 查看slave状态
mysql> show slave status\G;
*************************** 1. row ***************************
Slave_IO_State: Waiting for master to send event
Master_Host: 106.14.151.244
Master_User: root
Master_Port: 3306
Connect_Retry: 2
Master_Log_File: master_02.000016
Read_Master_Log_Pos: 107
Relay_Log_File: mysqld-relay-bin.000003
Relay_Log_Pos: 253
Relay_Master_Log_File: master_02.000016
Slave_IO_Running: Yes
Slave_SQL_Running: Yes
Replicate_Do_DB:
Replicate_Ignore_DB:
Replicate_Do_Table:
Replicate_Ignore_Table:
Replicate_Wild_Do_Table:
Replicate_Wild_Ignore_Table:
Last_Errno: 0
Last_Error:
Skip_Counter: 0
Exec_Master_Log_Pos: 107
Relay_Log_Space: 556
Until_Condition: None
Until_Log_File:
Until_Log_Pos: 0
Master_SSL_Allowed: No
Master_SSL_CA_File:
Master_SSL_CA_Path:
Master_SSL_Cert:
Master_SSL_Cipher:
Master_SSL_Key:
Seconds_Behind_Master: 0
Master_SSL_Verify_Server_Cert: No
Last_IO_Errno: 0
Last_IO_Error:
Last_SQL_Errno: 0
Last_SQL_Error:
Replicate_Ignore_Server_Ids:
Master_Server_Id: 2
1 row in set (0.00 sec)
- 切换 server2->mysql
# 配置master
$ CHANGE MASTER TO MASTER_HOST='47.101.70.109 ',MASTER_USER='root',MASTER_PASSWORD='123456',MASTER_PORT=3306, MASTER_LOG_FILE='master_01.000006',MASTER_LOG_POS=107,MASTER_CONNECT_RETRY=1;
Query OK, 0 rows affected (0.01 sec)
# 启动slave
mysql> start slave;
# 查看slave状态
mysql> show slave status\G;
*************************** 1. row ***************************
Slave_IO_State: Waiting for master to send event
Master_Host: 47.101.70.109
Master_User: root
Master_Port: 3306
Connect_Retry: 1
Master_Log_File: master_01.000007
Read_Master_Log_Pos: 190
Relay_Log_File: mysqld-relay-bin.000003
Relay_Log_Pos: 336
Relay_Master_Log_File: master_01.000007
Slave_IO_Running: Yes
Slave_SQL_Running: Yes
Replicate_Do_DB:
Replicate_Ignore_DB:
Replicate_Do_Table:
Replicate_Ignore_Table:
Replicate_Wild_Do_Table:
Replicate_Wild_Ignore_Table:
Last_Errno: 0
Last_Error:
Skip_Counter: 0
Exec_Master_Log_Pos: 190
Relay_Log_Space: 1898
Until_Condition: None
Until_Log_File:
Until_Log_Pos: 0
Master_SSL_Allowed: No
Master_SSL_CA_File:
Master_SSL_CA_Path:
Master_SSL_Cert:
Master_SSL_Cipher:
Master_SSL_Key:
Seconds_Behind_Master: 0
Master_SSL_Verify_Server_Cert: No
Last_IO_Errno: 0
Last_IO_Error:
Last_SQL_Errno: 0
Last_SQL_Error:
Replicate_Ignore_Server_Ids:
Master_Server_Id: 1
1 row in set (0.00 sec)
上面返回的状态中，查看 Slave_IO_Running 和 Slave_SQL_Running 的状态是否为 Yes 。只有两个参数均显示 Yes，表示配置成功，完成主从同步功能。否则，请根据报错信息，定位错误原因，并进行修改。
- 参数说明
以下使用 server1 的参数配置来进行说明
|参数名|参数值|说明| |------------|------------| |MASTER_HOST|106.14.151.244|同步的服务器IP，这里为 server2 的公网IP| |MASTER_USER|root|同步服务器的 mysql 用户名| |MASTER_PASSWORD|123456|同步服务器的 mysql 密码| |MASTER_PORT|3306|数据库端口| |MASTER_LOG_FILE|master_02.000015|对应 server2 的 File 名| |MASTER_LOG_POS|107|对应 server2 的 Position| |MASTER_CONNECT_RETRY|2|对应 server2 的 server-id| |Slave_IO_Running |Yes |slave 与 master 的IO通信状态| |Slave_SQL_Running |Yes |slave 与 master 的 mysql 进程状态|
测试数据双向同步
- 登录 server1->mysql
# 操作数据库test
mysql> use test;
# 创建表table
CREATE TABLE `table1` (
`id` int(11) NOT NULL AUTO_INCREMENT,
PRIMARY KEY (`id`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8;
# 向表table插入记录
INSERT INTO `test`.`table1`(`id`) VALUES (1);
- 登录 server2->mysql
# 查看数据库
mysql> show databases;
+--------------------+
| Database |
+--------------------+
| information_schema |
| mysql |
| performance_schema |
| sys |
| test |
+--------------------+
5 rows in set (0.00 sec)
# 操作数据库test
mysql> use test;
Database changed
# 查看表table1
mysql> select * from table1;
+----+
| id |
+----+
| 1 |
+----+
2 rows in set (0.00 sec)
# 向表table插入记录
INSERT INTO `test`.`table1`(`id`) VALUES (2);
- 切换 server1->mysql
# 查看表table1
mysql> select * from table1;
+----+
| id |
+----+
| 1 |
| 2 |
+----+
可以看到，数据双向同步成功。
