fabric.js 实现框选效果

需求

实现在背景图上框选，并且返回当前框选的范围。

实现效果

技术选型

因为现有的项目已经引进了 fabric.js，所以决定使用该框架来实现。

准备工作

下载 fabric.js
[fabric.js 入门](每一个用到canvas的小伙伴都应该了解的fabric.js - 掘金 (juejin.cn))

实现

index.html

<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <meta http-equiv="X-UA-Compatible" content="IE=edge">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <link rel="stylesheet" href="./style.css">
    <title>fabric demo</title>
</head>
<body>
    <script src="./fabric.js"></script>
    <canvas id="canvas" width="1200" height="600"></canvas>
    <script src="./main.js"></script>
</body>
</html>

style.css

* {
    margin: 0;
    padding: 0;
}
html, body {
    width: 100vw;
    height: 100vh;
}
body {
    display: flex;
    justify-content: center;
    align-items: center;
}

js部分

var selectionRectConfig = {
  width: 0,
  height: 0,
  left: 0,
  top: 0,
  fill: 'rgba(0, 0, 0, 0)',
  selectable: false,
  stroke: 'red',
  strokeWidth: 2,
  hoverCursor: 'default',
}
var selectionRect;

// hasClicked 用于标志当前用户按下鼠标准备框选
var hasClicked = true;
// 标志用户正按住鼠标左键拖拉框选
var isSelecting = false;

var canvas = new fabric.Canvas('canvas', {
  selectionColor: 'rgba(255,212,173, 0.2)',
  selectionLineWidth: 2,
  backgroundImage: './cell.jpg',
});
canvas.setDimensions({
  width: 1000,
  height: 700,
});

canvas.on('mouse:down', function({ e }) {
  hasClicked = true;
  selectionRectConfig.left = e.offsetX;
  selectionRectConfig.top = e.offsetY;
})
canvas.on('mouse:move', function() {
  if(hasClicked) {
    isSelecting = true;
    canvas.set('selectionBorderColor', 'green');
  }
})
canvas.on('mouse:up', function({ e }) {
  if(isSelecting) {
    // 清除之前的选中框
    canvas.remove(selectionRect);

    selectionRectConfig.width = e.offsetX - selectionRectConfig.left;
    selectionRectConfig.height = e.offsetY - selectionRectConfig.top;
    // 此时选中框的左上坐标以及宽度和高度
    console.log(`选中框 X 轴的范围：${selectionRectConfig.left} ~ ${selectionRectConfig.left + selectionRectConfig.width}`
              + `\n选中框 Y 轴的范围：${selectionRectConfig.top} ~ ${selectionRectConfig.top + selectionRectConfig.height}`);

    selectionRect = new fabric.Rect(selectionRectConfig);
    canvas.add(selectionRect);

    isSelecting = false;
    hasClicked = false;
  }
