k8s测试环境简单安装

fish_ly
460 阅读2分钟

1、安装centos7

2、网络设置

  • vi /etc/sysconfig/network-scripts/ifcfg-enp**
  • ONBOOT=yes
  • 重启网络服务
    • service network restart或者systemctl start network.service
    • 查看IP：ip addr
  • 运行 vim **/etc/ssh/sshd_config 命令
  • 2、在键盘上按 I 键，进入编辑状态。 将 22 端口修改 成目标 端口** ，以 1022 端口 为例，在Port 22下输入 Port 1022
  • 3、在键盘上按 ESC，输入：wq 退出编辑状态。

3、配置hosts

  • 192.168.31.253  k8s-master01
  • 192.168.31.138  k8s-node01
  • 192.168.20.10   k8s-master-lb # vip
  • 修改hostname hostnamectl set-hostname k8s-master01

4 关闭防火墙、selinux、dnsmasq、swap

  • firewalld-cmd --list-all
  • systemctl disable --now firewalld
  • systemctl disable --now dnsmasq
  • systemctl disable --now NetworkManager
  • swapoff -a && sysctl -w vm.swappiness=0
  • setenforce 0
  • SELINUX=disabled
# /etc/sysconfig/selinux文件中的SELINUX改为disabled
#grep -vE "#|^$" /etc/sysconfig/selinux
SELINUX=disabled
SELINUXTYPE=targeted

5 修改内核参数 （配置iptables）

cat <<EOF > /etc/sysctl.d/k8s.conf
net.bridge.bridge-nf-call-ip6tables = 1
net.bridge.bridge-nf-call-iptables = 1
EOF

#swappiness参数调整，修改/etc/sysctl.d/k8s.conf添加下面一行：
vm.swappiness=0

执行sysctl -p /etc/sysctl.d/k8s.conf使修改生效

sysctl --system

6 所有节点同步时间

#  所有节点同步时间。所有节点同步时间是必须的，并且需要加到开机自启动和计划中，如果节点时间不同步
# 会造成Etcd存储Kubernetes信息的键-值(key - value)数据库同步数据不正常，也会造成证书出现问题。时间同步配置如下：

ln -sf /usr/share/zoneinfo/Asia/Shanghai /etc/localtime
echo 'Asia/Shanghai' > /etc/timezone
# 安装ntpdate
ntpdate time2.aliyun.com
# 加入到crontab
crontab -e
*/5 * * * * ntpdate time2.aliyun.com
# 加入到开机自动同步
vi /etc/rc.local
ntpdate time2.aliyun.com

#####

# 所有节点配置limit

ulimit -SHn 65535
vi /etc/security/limits.conf
soft nofile 655360
hard nofile 131072
soft ntproc 655350
hard ntproc 655350
soft memlock unlimited
hard memlock unlimited

7 免登录主机证书安装

# 免密登陆其他主机： ssh-copy-id -i /root/.ssh/id_rsa.pub $remote_ip
# sshpass -p $pwds ssh-copy-id -i /root/.ssh/id_rsa.pub $remote_ip -o StrictHostKeyChecking=no
ssh-keygen -t rsa
for i in k8s-master01 k8s-node01;do
ssh-copy-id -i .ssh/id_rsa.pub $i;done

# master01节点子啊崽安装文件，安装文件都在 chap01/1.1目录中
for i in k8s-master01 k8s-node01;do
scp -r /root/k8s/chap01/1.1/repo/ $i:/opt ;done

8 常用工具安装

# tools
yum install wget jq psmisc vim net-tools -y

9 内核升级(默认升级到5.x，网卡未开启，退回安装4.x，问题待解决)

查看版本kernel: uname -srm
wget http://mirrors.aliyun.com/elrepo/kernel/el7/x86_64/RPMS/kernel-lt-4.4.184-1.el7.elrepo.x86_64.rpm
yum  install  kernel-lt-4.4.184-1.el7.elrepo.x86_64.rpm -y
# 设置内核默认启动顺序
grub2-set-default 0 && grub2-mkconfig -o /etc/grub2.cfg
grubby --args="user_namespace.enable=1" --update-kernel="$(grubby --default-kernel)"

reboot


# 同时装了3 4 5，会按倒序排列，设为0则默认启动5，设为1则默认启动4

10 docker安装

yum install -y yum-utils
yum-config-manager \
    --add-repo \
    https://download.docker.com/linux/centos/docker-ce.repo
# yum install docker-ce docker-ce-cli containerd.io docker-compose-plugin -y
### 以上默认安装最新版本20.x


# yum list docker-ce --showduplicates | sort -r
# yum install docker-ce-<VERSION_STRING> docker-ce-cli-<VERSION_STRING> containerd.io docker-compose-plugin

yum install -y docker-ce-19.03.12 docker-ce-cli-19.03.12 containerd.io docker-compose-plugin

### 修改镜像源
# vi /etc/docker/daemon.json
{

 "registry-mirrors" : ["https://q5bf287q.mirror.aliyuncs.com", "https://registry.docker-cn.com","http://hub-mirror.c.163.com"],

 "exec-opts": ["native.cgroupdriver=systemd"],

 "insecure-registries":["192.168.31.138"]

}
# 192.168.31.138  为私有仓库地址
#重新加载配置
systemctl daemon-reload
#重启docker
systemctl restart docker

systemctl enable docker   设置docker开机自启

11 k8s master节点环境安装

# kubernetes repo

cat <<EOF > kubernetes.repo
[kubernetes]
name=Kubernetes
baseurl=https://mirrors.aliyun.com/kubernetes/yum/repos/kubernetes-el7-x86_64
enabled=1
gpgcheck=1
repo_gpgcheck=0
gpgkey=https://mirrors.aliyun.com/kubernetes/yum/doc/yum-key.gpg https://mirrors.aliyun.com/kubernetes/yum/doc/rpm-package-key.gpg
EOF

#清除缓存
yum clean all

#把服务器的包信息下载到本地电脑缓存起来，makecache建立一个缓存
yum makecache -y


# 报错信息
failure: repodata/repomd.xml from kubernetes: [Errno 256] No more mirrors to try.
https://mirrors.aliyun.com/kubernetes/yum/repos/kubernetes-el7-x86_64/repodata/repomd.xml: [Errno -1] repomd.xml signature could not be verified for kubernetes
# 编辑 /etc/yum.repos.d/kubernetes.repo 文件
# 修改一下参数：
# repo_gpgcheck=0

mv kubernetes.repo /etc/yum.repos.d/
# master节点 安装指定版本的kubelet,kubeadm,kubectl
yum install -y kubelet-1.19.3-0 kubeadm-1.19.3-0 kubectl-1.19.3-0
# node节点无需安装kubectl
yum install -y kubelet-1.19.3-0 kubeadm-1.19.3-0 --disableexcludes=kubernetes


启动kubelet并设置开机启动服务
#重新加载配置文件
systemctl daemon-reload

#启动kubelet
systemctl start kubelet

#查看kubelet启动状态
systemctl status kubelet
#没启动成功,报错先不管,后面的kubeadm init会拉起

#设置开机自启动
systemctl enable kubelet

#查看kubelet开机启动状态 enabled:开启, disabled:关闭
systemctl is-enabled kubelet

#查看日志
journalctl -xefu kubelet


# 初始化k8s集群Master

# master 节点
kubeadm init --image-repository registry.aliyuncs.com/google_containers --apiserver-advertise-address=192.168.31.253 --kubernetes-version=v1.19.3 --pod-network-cidr=10.244.0.0/16 --service-cidr=10.1.0.0/16

#   按提示要求执行如下命令:
mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config


# node节点 join master节点
kubeadm join 192.168.31.253:6443 --token fu9o5w.9sakylb77sawmoon \
    --discovery-token-ca-cert-hash sha256:4d83a199abf5238aff732548c199256f9e04f6b9010fd8679cb3f0b201c9f257

# 查看节点, NotReady是还未安装CNI网络插件
kubectl get nodes
#输出如下:
NAME            STATUS   ROLES    AGE   VERSION
k8s-master001   NotReady    master   14h   v1.19.3
k8s-node001     NotReady    <none>   14h   v1.19.3


#####
## 安装flannel网络插件(CNI)
----------------------------------------------------------------
# 安装错误 版本不匹配
error: unable to recognize "calico.yaml": no matches for kind "PodDisruptionBudget" in version "policy/v1"
----------------------------------------------------------------
curl -O https://docs.projectcalico.org/v3.20/manifests/calico.yaml
kubectl apply -f calico.yaml

kubectl get nodes
#输出如下:
NAME            STATUS   ROLES    AGE   VERSION
k8s-master001   Ready    master   14h   v1.19.3
k8s-node001     Ready    <none>   14h   v1.19.3

安装中出现的错误处理

### 错误：kubectl get cs  => connection refused

/etc/kubernetes/manifests下的kube-controller-manager.yaml和kube-scheduler.yaml设置的默认端口是0，在文件中注释掉就可以了
kube-controller-manager.yaml文件修改：注释掉27行
kube-scheduler.yaml配置修改：注释掉19行

机器均重启kubelet
systemctl restart kubelet.service


[root@k8s-master0001 manifests]# kubectl get cs
Warning: v1 ComponentStatus is deprecated in v1.19+
NAME                 STATUS    MESSAGE             ERROR
controller-manager   Healthy   ok
scheduler            Healthy   ok
etcd-0               Healthy   {"health":"true"}



#############################
### kubectl get nodes => notready
------
    关闭各个节点的防火墙:
    systemctl status firewalld
    systemctl stop firewalld
    systemctl enable firewalld
    重启node节点：

    systemctl daemon-reload
    systemctl restart docker
    systemctl restart kubelet
    systemctl restart kube-proxy
------

### 安装失败，重新安装
- kubeadm reset
- kubeadm init

------

### 机器重启

12 centos 安装图形界面

1 列出所有可用的[Environment]Groups
yum group list
yum groupinfo "GNOME Desktop"

2 选择GNOME Desktop软件包组进行安装
yum groupinstall -y 'GNOME Desktop'

3 如果要通过[GUI]配置网络需要安装Server with GUI
yum groups install -y "Server with GUI"

4 修改default target启用GUI
systemctl set-default graphical.target
systemctl get-default

reboot
