实验拓扑图如下
AR2路由器配置如下
<Huawei>system-view
[Huawei]sysname Server
//方式一：使用密码登录网络设备
[Server]int g0/0/0
[Server-GigabitEthernet0/0/0]ip add 1.1.1.2 24
[Server-GigabitEthernet0/0/0]q
[Server]user-interface vty 0 4
[Server-ui-vty0-4]set authentication password cipher huawei
[Server-ui-vty0-4]user privilege level 3
//方式二：使用账号密码登录设备
[Server]aaa
[Server-aaa]local-user user001 password cipher huawei
[Server-aaa]local-user user001 privilege level 3
[Server-aaa]local-user user001 service-type telnet
[Server-aaa]local-user console password cipher huawei
[Server-aaa]local-user console privilege level 3
[Server-aaa]q
[Server]user-interface vty 0 4
[Server-ui-vty0-4]authentication-mode aaa
[Server-ui-vty0-4]q
[Server-ui-console0]user privilege level 3
//配置ftp服务
[Server]int g0/0/1
[Server-GigabitEthernet0/0/1]ip add 2.2.2.2 24
[Server-GigabitEthernet0/0/1]q
[Server]aaa
[Server-aaa]local-user ftp password cipher ftp
[Server-aaa]local-user ftp privilege level 3
[Server-aaa]local-user ftp ftp-directory flash:/
[Server-aaa]local-user ftp service-type ftp
[Server-aaa]q
[Server]ftp server enable
AR1路由telnet登录AR2服务器操作如下
<Huawei>system-view
[Huawei]sysname PC
[PC]int g0/0/0
[PC-GigabitEthernet0/0/0]ip add 1.1.1.1 24
[PC-GigabitEthernet0/0/0]q
[PC]q使用ftp
<PC>telnet 1.1.1.2
Client1客户端配置如下
点击客户端信息选项卡，按照如下信息填入，点击登录，即可下载和上传文件
