【避坑指“难”】umi3分包优化，提升首屏加载时间

提升首屏加载时间原理：把大体积的包，分成多个小体积的包进行加载，减少请求时间

chainWebpack配置

在 umi.js 或者 umi.ts 或者 .umirc.js 或者 config.js 中配置，使用 webpack 的优化模块optimization.splitChunks实现。

chunks配置

chunks 配置需要加上 umi，否则打包完后依旧是白屏，在控制台可看到 umi.js 和 umi.css 并没有引入。

compression-webpack-plugin服务端使用gzip进行压缩

打开 config/config.ts 文件(如果是 umi2 的项目则是 .umirc.js)

import { defineConfig } from 'umi';
import { join } from 'path';

import defaultSettings from './defaultSettings';
import proxy from './proxy';
import routers from './routes';

const CompressionWebpackPlugin = require('compression-webpack-plugin');
const prodGzipList = ['js', 'css'];

const { REACT_APP_ENV } = process.env;
export default defineConfig({
  hash: true,
  history: { type: 'hash' },
  publicPath: './',
  antd: {},
  dva: {
    hmr: true,
  },
  layout: {
    // https://umijs.org/zh-CN/plugins/plugin-layout
    locale: true,
    siderWidth: 208,
    ...defaultSettings,
  },
  // https://umijs.org/zh-CN/plugins/plugin-locale
  locale: {
    // default zh-CN
    default: 'zh-CN',
    antd: true,
    // default true, when it is true, will use `navigator.language` overwrite default
    baseNavigator: true,
  },
  dynamicImport: {
    loading: '@ant-design/pro-layout/es/PageLoading',
  },
  targets: {
    ie: 11,
  },
  routes: routers,
  // Theme for antd: https://ant.design/docs/react/customize-theme-cn
  theme: {
    'primary-color': defaultSettings.primaryColor,
  },
  // esbuild is father build tools
  // https://umijs.org/plugins/plugin-esbuild
  esbuild: {},
  title: false,
  ignoreMomentLocale: true,
  proxy: proxy[REACT_APP_ENV || 'dev'],
  manifest: {
    basePath: '/',
  },
  // Fast Refresh 热更新
  fastRefresh: {},
  openAPI: [
    {
      requestLibPath: "import { request } from 'umi'",
      // 或者使用在线的版本
      // schemaPath: "https://gw.alipayobjects.com/os/antfincdn/M%24jrzTTYJN/oneapi.json"
      schemaPath: join(__dirname, 'oneapi.json'),
      mock: false,
    },
    {
      requestLibPath: "import { request } from 'umi'",
      schemaPath: 'https://gw.alipayobjects.com/os/antfincdn/CA1dOm%2631B/openapi.json',
      projectName: 'swagger',
    },
  ],
  nodeModulesTransform: { type: 'none' },
  mfsu: {},
  webpack5: {},
  exportStatic: {},
  chunks: ['vendors', 'umi'],

  chainWebpack: (config) => {
    config
      .plugin('replace')
      .use(require('webpack').ContextReplacementPlugin)
      .tap(() => {
        return [/moment[/\\]locale$/, /zh-cn/];
      });
    config.merge({
      optimization: {
        minimize: true,
        splitChunks: {
          chunks: 'async',
          minSize: 30000,
          minChunks: 2,
          automaticNameDelimiter: '.',
          cacheGroups: {
            react: {
              name: 'react',
              priority: 20,
              test: /[\\/]node_modules[\\/](react|react-dom|react-dom-router)[\\/]/,
            },
            echarts: {
              name: 'echarts',
              chunks: 'async',
              test: /[\\/]node_modules[\\/](echarts|zrender)[\\/]/,
              priority: 10,
              enforce: true,
            },
            antdesigns: {
              name: 'antdesigns',
              chunks: 'all',
              test: /[\\/]node_modules[\\/](antd|@ant-design|antd-mobile)/,
              priority: 10,
              enforce: true,
            },
            antv: {
              name: 'antv',
              chunks: 'all',
              test: /[\\/]node_modules[\\/](@antv)[\\/]/,
              priority: 10,
              enforce: true,
            },
            lodash: {
              name: 'lodash',
              test: /[\\/]node_modules[\\/]lodash[\\/]/,
              priority: -2,
              enforce: true,
            },
            vendors: {
              name: 'vendors',
              test({ resource }: any) {
                return /[\\/]node_modules[\\/]/.test(resource)
              },
              priority: -11,
              enforce: true,
            },
          },
        },
      },
    });
    if (process.env.NODE_ENV === 'production') {  // 生产模式开启
      config.plugin('compression-webpack-plugin').use(
        new CompressionWebpackPlugin({
          algorithm: 'gzip',
          test: new RegExp('\\.(' + prodGzipList.join('|') + ')$'),
          threshold: 10240,
          minRatio: 0.6,
          deleteOriginalAssets: false, // 不删除源文件
        })
      );
    }
  },
});
