9.23. 导航tab超出显示“更多按钮”,下拉悬浮展示隐藏tab

1,465 阅读1分钟

需求:

动态增减tab,每个tab名称宽度不固定,超出展示 “更多按钮”,点击展示隐藏的tab。 鼠标右键点击,可关闭所有。
ps: vue项目


组件设计思路:

<ul class="tablist">
   <li class="tabItem"
    v-for="(tab,index) in tabHistory"
   :key="index"
   >{{tab.label}}</li>
</ul>

let right = 0,tabNum = 0;//right记录第一行最后一个tab的位置;tabNum 记录第一行tab的个数
for (let item of this.$refs.tabItem) {
    right = item.getBoundingclientRect().right;
    if (this.right < right) {
      this.right = right;
      tabNum++;
    } else {
      break;
    }
}

ul.tablist 只显示一行的高度,超出隐藏;
遍历tabHistory,获取li.tabItem右侧坐标,找出right变小的,记录此时的tabNum;
隐藏的个数即为 tabHistory.length-tabNum;

代码如下:

<template>
  <div class="cl_tab-history">
    <ul class="cl_tab-tablist" ref="tablist">
      <li
        class="cl_tab-tabItem"
        ref="tabItem"
        v-for="(tab, index) in tabHistory"
        :key="index"
        :class="{ 'cl_tab-active': tab.name === currentTab }"
        @click="switchTab(tab)"
      >
        <span style="padding: 0 10px">{{ tab.label }}</span>
        <i @click.stop="closeTab(tab.name)"></i>
      </li>
    </ul>

    <div
      class="cl_more-button"
      ref="arrowDownIcon"
      v-show="tabWrapList && tabWrapList.length"
      :style="`left:${right}px;top:${top}px;`"
      @click.stop="openMoreButton"
    >
      <i
        class="el-icon-d-arrow-right"
        style="margin-left:10px;margin-top:-45%;color:#fff;transformrotate(90deg);font-size:16px"
      ></i>
    </div>

    <div
      class="Tab__overflow"
      :style="`left:${boxLeft}px;top: ${top + 20}px;`"
      v-show="showMoreButton"
    >
      <div
        class="overflow-item"
        @contextmenu.prevent="showSloseAllTab"
        @click.stop="switchTab(item)"
        v-for="(item, index) in tabWrapList"
        :key="index"
      >
        <span
          style="padding-right: 5px"
          :class="{ 'cl_tab-active': item.name === currentTab }"
        >
          {{ item.label }}
        </span>
        <i @click.stop="closeTab(item.name)" class="icon el-icon-close"></i>
      </div>
    </div>

    <div
      class="cl_tab-closeAll"
      v-show="showCloseAll"
      :style="`top:${closeAllTop}px;right:calc(100%-${boxLeft}px);`"
    >
      <div
        v-for="(item, index) in closeList"
        :key="index"
        class="overflow-item"
        @click.stop="stopPropagation"
      >
        <span>{{ item.label }}</span>
        <i @click.stop="closeTab('', item.key)" class="icon el-icon-close"></i>
      </div>
    </div>
  </div>
</template>

<script>
export default {
  name: "oshTabHistory",
  data() {
    return {
      right: 0,
      boxLeft: 0,
      closeList: [
        {
          key: 2,
          label: "关闭其他",
        },
        {
          key: 3,
          label: "关闭全部",
        },
      ],
      tabwrapList: [],
      shovMoreButton: false,
      showCloseAll: false,
      closeAllTop: 0,
    };
  },
  props: {
    tabHistory: {
      type: Array,
      default: () => [],
    },
    top: {
      type: Number,
      defaut: 43,
    },
    currenitTab: {
      type: String,
      default: "dashboard",
    },
    defaultcomputedNum: {
      type: Number,
      default: 8,
    },
  },
  watch: {
    tabHistory() {
      //页签变化了重新计算下拉页签个数
      this.$nextTick(() => {
        this.computedTabNum();
      });
    },
  },
  mounted() {
    window.addEventListener("resize", this.computedTabNum()); //历史页签超出长度需要下拉展示
  },
  methods: {
    openMoreButton(e) {
      if (!this.showMoreButton) {
        this.boxLeft = e.clientx;
      }
      this.showMoreButton = !this.showMoreButton;
      this.showCloseAll = false;
    },
    //计算页面展示多少tab,大于8个才计算
    computedTabNum() {
      this.tablwrapList = [];
      this.right = 0;
      if (this.tabHistory && this.defaultComputedNum) {
        window.addEventlistener("click", () => {
          this.shovMoreButton = false;
          thisishowCloseAll = false;
        });
        //超过一行,才有下拉菜单
        if (this.$refs.tabList.getBoundingclientRect().height > 25) {
          let right = 0,
            tabNum = 0;
          for (let item of this.$refs.tabItem) {
            right = item.getBoundingclientRect().right;
            if (this.right < right) {
              this.right = right;
              tabNum++;
            } else {
              break;
            }
          }

          this.tabwrapList = this.tabHistory.slice(
            tabNum,
            this.tabHistory.slice(this.tabHistory.length)
          );
        }
      }
    },
    //点击下拉的页签,阻止冒泡
    stopPropagation() {
      return false;
    },
    //切换tab
    switchTab(tab) {
      this.$emit("switchTab", tab);
    },
    closeTab(name, key) {
      this.showCloseAll = false;
      if (key == 1) return false;
      this.$emit("closeTab", name, key);
      return false;
    },
    showSloseAllTab(e) {
      this.showCloseAll = true;
      this.closeAllTop = e.clientY;
    },
  },

  beforeDestory() {
    window.removeEventListener("resize", computedTabNum());
  },
};
</script>

<style lang="scss">
.cl_tab-history {
  height: 22px;
  overflow: hidden;
  color: #aaa;
  font-size: 14px;
  .cl_tab-active {
    color: $primary;
    font-weight: 600;
  }
  .cl_tab-tablist {
    width: calc(100% - 20px);
    .cl_tab-tabItem {
      display: inline-block;
      cursor: pointer;
      border-radius: 10px 10px 0 0;
      background-color: #fff;
      line-height: 20px;
    }
  }
}
</style>
