二进制安装Kubernetes（k8s） v1.23.6
背景
kubernetes二进制安装
1.23.3 和 1.23.4 和 1.23.5 和 1.23.6 文档以及安装包已生成。
后续尽可能第一时间更新新版本文档
脚本项目地址：
手动项目地址：
1.环境
| 主机名称 | IP地址 | 说明 | 软件 |
|---|---|---|---|
| Master01 | 192.168.1.81 | master节点 | kube-apiserver、kube-controller-manager、kube-scheduler、etcd、kubelet、kube-proxy、nfs-client |
| Master02 | 192.168.1.82 | master节点 | kube-apiserver、kube-controller-manager、kube-scheduler、etcd、kubelet、kube-proxy、nfs-client |
| Master03 | 192.168.1.83 | master节点 | kube-apiserver、kube-controller-manager、kube-scheduler、etcd、kubelet、kube-proxy、nfs-client |
| Node01 | 192.168.1.84 | node节点 | kubelet、kube-proxy、nfs-client |
| Node02 | 192.168.1.85 | node节点 | kubelet、kube-proxy、nfs-client |
| Node03 | 192.168.1.86 | node节点 | kubelet、kube-proxy、nfs-client |
| Node04 | 192.168.1.87 | node节点 | kubelet、kube-proxy、nfs-client |
| Node05 | 192.168.1.88 | node节点 | kubelet、kube-proxy、nfs-client |
| Lb01 | 192.168.1.80 | Lb01节点 | haproxy、keepalived |
| Lb02 | 192.168.1.90 | Lb02节点 | haproxy、keepalived |
| 192.168.1.89 | VIP | ||
| 软件 | 版本 |
|---|---|
| 内核 | 4.18.0-373.el8.x86_64 |
| CentOS 8 | v8 或者 v7 |
| kube-apiserver、kube-controller-manager | |
| kube-scheduler、kubelet、kube-proxy | v1.23.6 |
| etcd | v3.5.3 |
| docker-ce | v20.10.14 |
| containerd | v1.5.11 |
| cfssl | v1.6.1 |
| cni | v1.1.1 |
| crictl | v1.23.0 |
| haproxy | v1.8.27 |
| keepalived | v2.1.5 |
网段
物理主机：192.168.1.0/24
service：10.96.0.0/12
pod：172.16.0.0/12
如果有条件建议k8s集群与etcd集群分开安装
1.1.k8s基础系统环境配置
1.2.配置IP
ssh root@192.168.1.161 "nmcli con mod ens18 ipv4.addresses 192.168.1.81/24; nmcli con mod ens18 ipv4.gateway 192.168.1.99; nmcli con mod ens18 ipv4.method manual; nmcli con mod ens18 ipv4.dns "8.8.8.8"; nmcli con up ens18"
ssh root@192.168.1.167 "nmcli con mod ens18 ipv4.addresses 192.168.1.82/24; nmcli con mod ens18 ipv4.gateway 192.168.1.99; nmcli con mod ens18 ipv4.method manual; nmcli con mod ens18 ipv4.dns "8.8.8.8"; nmcli con up ens18"
ssh root@192.168.1.137 "nmcli con mod ens18 ipv4.addresses 192.168.1.83/24; nmcli con mod ens18 ipv4.gateway 192.168.1.99; nmcli con mod ens18 ipv4.method manual; nmcli con mod ens18 ipv4.dns "8.8.8.8"; nmcli con up ens18"
ssh root@192.168.1.152 "nmcli con mod ens18 ipv4.addresses 192.168.1.84/24; nmcli con mod ens18 ipv4.gateway 192.168.1.99; nmcli con mod ens18 ipv4.method manual; nmcli con mod ens18 ipv4.dns "8.8.8.8"; nmcli con up ens18"
ssh root@192.168.1.198 "nmcli con mod ens18 ipv4.addresses 192.168.1.85/24; nmcli con mod ens18 ipv4.gateway 192.168.1.99; nmcli con mod ens18 ipv4.method manual; nmcli con mod ens18 ipv4.dns "8.8.8.8"; nmcli con up ens18"
ssh root@192.168.1.166 "nmcli con mod ens18 ipv4.addresses 192.168.1.86/24; nmcli con mod ens18 ipv4.gateway 192.168.1.99; nmcli con mod ens18 ipv4.method manual; nmcli con mod ens18 ipv4.dns "8.8.8.8"; nmcli con up ens18"
ssh root@192.168.1.171 "nmcli con mod ens18 ipv4.addresses 192.168.1.87/24; nmcli con mod ens18 ipv4.gateway 192.168.1.99; nmcli con mod ens18 ipv4.method manual; nmcli con mod ens18 ipv4.dns "8.8.8.8"; nmcli con up ens18"
ssh root@192.168.1.159 "nmcli con mod ens18 ipv4.addresses 192.168.1.88/24; nmcli con mod ens18 ipv4.gateway 192.168.1.99; nmcli con mod ens18 ipv4.method manual; nmcli con mod ens18 ipv4.dns "8.8.8.8"; nmcli con up ens18"
ssh root@192.168.1.122 "nmcli con mod ens18 ipv4.addresses 192.168.1.80/24; nmcli con mod ens18 ipv4.gateway 192.168.1.99; nmcli con mod ens18 ipv4.method manual; nmcli con mod ens18 ipv4.dns "8.8.8.8"; nmcli con up ens18"
ssh root@192.168.1.125 "nmcli con mod ens18 ipv4.addresses 192.168.1.90/24; nmcli con mod ens18 ipv4.gateway 192.168.1.99; nmcli con mod ens18 ipv4.method manual; nmcli con mod ens18 ipv4.dns "8.8.8.8"; nmcli con up ens18"
1.3.设置主机名
hostnamectl set-hostname k8s-master01
hostnamectl set-hostname k8s-master02
hostnamectl set-hostname k8s-master03
hostnamectl set-hostname k8s-node01
hostnamectl set-hostname k8s-node02
hostnamectl set-hostname k8s-node03
hostnamectl set-hostname k8s-node04
hostnamectl set-hostname k8s-node05
hostnamectl set-hostname lb01
hostnamectl set-hostname lb02
1.4.配置yum源
# 对于 CentOS 7
sudo sed -e 's|^mirrorlist=|#mirrorlist=|g' \
-e 's|^#baseurl=http://mirror.centos.org|baseurl=https://mirrors.tuna.tsinghua.edu.cn|g' \
-i.bak \
/etc/yum.repos.d/CentOS-*.repo
# 对于 CentOS 8
sudo sed -e 's|^mirrorlist=|#mirrorlist=|g' \
-e 's|^#baseurl=http://mirror.centos.org/$contentdir|baseurl=https://mirrors.tuna.tsinghua.edu.cn/centos|g' \
-i.bak \
/etc/yum.repos.d/CentOS-*.repo
sed -e 's|^mirrorlist=|#mirrorlist=|g' -e 's|^#baseurl=http://mirror.centos.org/\$contentdir|baseurl=http://192.168.1.123/centos|g' -i.bak /etc/yum.repos.d/CentOS-*.repo
1.5.安装一些必备工具
yum -y install wget jq psmisc vim net-tools nfs-utils telnet yum-utils device-mapper-persistent-data lvm2 git network-scripts tar curl -y
1.6.安装docker工具 (lb除外)
yum install -y yum-utils device-mapper-persistent-data lvm2
wget -O /etc/yum.repos.d/docker-ce.repo https://download.docker.com/linux/centos/docker-ce.repo
sudo sed -i 's+download.docker.com+mirrors.tuna.tsinghua.edu.cn/docker-ce+' /etc/yum.repos.d/docker-ce.repo
yum makecache
yum -y install docker-ce
systemctl enable --now docker
1.7.关闭防火墙
systemctl disable --now firewalld
1.8.关闭SELinux
setenforce 0
sed -i 's#SELINUX=enforcing#SELINUX=disabled#g' /etc/selinux/config
1.9.关闭交换分区
sed -ri 's/.*swap.*/#&/' /etc/fstab
swapoff -a && sysctl -w vm.swappiness=0
cat /etc/fstab
# /dev/mapper/centos-swap swap swap defaults 0 0
1.10.关闭NetworkManager 并启用 network (lb除外)
systemctl disable --now NetworkManager
systemctl start network && systemctl enable network
1.11.进行时间同步 (lb除外)
服务端
yum install chrony -y
cat > /etc/chrony.conf << EOF
pool ntp.aliyun.com iburst
driftfile /var/lib/chrony/drift
makestep 1.0 3
rtcsync
allow 192.168.1.0/24
local stratum 10
keyfile /etc/chrony.keys
leapsectz right/UTC
logdir /var/log/chrony
EOF
systemctl restart chronyd
systemctl enable chronyd
客户端
yum install chrony -y
vim /etc/chrony.conf
cat /etc/chrony.conf | grep -v "^#" | grep -v "^$"
pool 192.168.1.81 iburst
driftfile /var/lib/chrony/drift
makestep 1.0 3
rtcsync
keyfile /etc/chrony.keys
leapsectz right/UTC
logdir /var/log/chrony
systemctl restart chronyd ; systemctl enable chronyd
yum install chrony -y ; sed -i "s#2.centos.pool.ntp.org#192.168.1.81#g" /etc/chrony.conf ; systemctl restart chronyd ; systemctl enable chronyd
使用客户端进行验证
chronyc sources -v
1.12.配置ulimit
ulimit -SHn 65535
cat >> /etc/security/limits.conf <<EOF
* soft nofile 655360
* hard nofile 131072
* soft nproc 655350
* hard nproc 655350
* seft memlock unlimited
* hard memlock unlimitedd
EOF
1.13.配置免密登录
yum install -y sshpass
ssh-keygen -f /root/.ssh/id_rsa -P ''
export IP="192.168.1.81 192.168.1.82 192.168.1.83 192.168.1.84 192.168.1.85 192.168.1.86 192.168.1.87 192.168.1.88 192.168.1.80 192.168.1.90"
export SSHPASS=123123
for HOST in $IP;do
sshpass -e ssh-copy-id -o StrictHostKeyChecking=no $HOST
done
1.14.添加启用源 (lb除外)
为 RHEL-8或 CentOS-8配置源
yum install https://www.elrepo.org/elrepo-release-8.el8.elrepo.noarch.rpm
为 RHEL-7 SL-7 或 CentOS-7 安装 ELRepo
yum install https://www.elrepo.org/elrepo-release-7.el7.elrepo.noarch.rpm
查看可用安装包
yum --disablerepo="*" --enablerepo="elrepo-kernel" list available
1.15.升级内核至4.18版本以上 (lb除外)
安装最新的内核
# 我这里选择的是稳定版kernel-ml 如需更新长期维护版本kernel-lt
yum --enablerepo=elrepo-kernel install kernel-ml
查看已安装那些内核
rpm -qa | grep kernel
kernel-core-4.18.0-358.el8.x86_64
kernel-tools-4.18.0-358.el8.x86_64
kernel-ml-core-5.16.7-1.el8.elrepo.x86_64
kernel-ml-5.16.7-1.el8.elrepo.x86_64
kernel-modules-4.18.0-358.el8.x86_64
kernel-4.18.0-358.el8.x86_64
kernel-tools-libs-4.18.0-358.el8.x86_64
kernel-ml-modules-5.16.7-1.el8.elrepo.x86_64
查看默认内核
grubby --default-kernel
/boot/vmlinuz-5.16.7-1.el8.elrepo.x86_64
若不是最新的使用命令设置
grubby --set-default /boot/vmlinuz-「您的内核版本」.x86_64
重启生效
reboot
v8 整合命令为：
yum install https://www.elrepo.org/elrepo-release-8.el8.elrepo.noarch.rpm -y ; yum --disablerepo="*" --enablerepo="elrepo-kernel" list available -y ; yum --enablerepo=elrepo-kernel install kernel-ml -y ; grubby --default-kernel ; reboot
v7 整合命令为：
yum install https://www.elrepo.org/elrepo-release-7.el7.elrepo.noarch.rpm -y ; yum --disablerepo="*" --enablerepo="elrepo-kernel" list available -y ; yum --enablerepo=elrepo-kernel install kernel-ml -y ; grubby --set-default \$(ls /boot/vmlinuz-* | grep elrepo) ; grubby --default-kernel
1.16.安装ipvsadm (lb除外)
yum install ipvsadm ipset sysstat conntrack libseccomp -y
cat >> /etc/modules-load.d/ipvs.conf <<EOF
ip_vs
ip_vs_rr
ip_vs_wrr
ip_vs_sh
nf_conntrack
ip_tables
ip_set
xt_set
ipt_set
ipt_rpfilter
ipt_REJECT
ipip
EOF
systemctl restart systemd-modules-load.service
lsmod | grep -e ip_vs -e nf_conntrack
ip_vs_sh 16384 0
ip_vs_wrr 16384 0
ip_vs_rr 16384 0
ip_vs 180224 6 ip_vs_rr,ip_vs_sh,ip_vs_wrr
nf_conntrack 176128 1 ip_vs
nf_defrag_ipv6 24576 2 nf_conntrack,ip_vs
nf_defrag_ipv4 16384 1 nf_conntrack
libcrc32c 16384 3 nf_conntrack,xfs,ip_vs
1.17.修改内核参数 (lb除外)
cat <<EOF > /etc/sysctl.d/k8s.conf
net.ipv4.ip_forward = 1
net.bridge.bridge-nf-call-iptables = 1
fs.may_detach_mounts = 1
vm.overcommit_memory=1
vm.panic_on_oom=0
fs.inotify.max_user_watches=89100
fs.file-max=52706963
fs.nr_open=52706963
net.netfilter.nf_conntrack_max=2310720
net.ipv4.tcp_keepalive_time = 600
net.ipv4.tcp_keepalive_probes = 3
net.ipv4.tcp_keepalive_intvl =15
net.ipv4.tcp_max_tw_buckets = 36000
net.ipv4.tcp_tw_reuse = 1
net.ipv4.tcp_max_orphans = 327680
net.ipv4.tcp_orphan_retries = 3
net.ipv4.tcp_syncookies = 1
net.ipv4.tcp_max_syn_backlog = 16384
net.ipv4.ip_conntrack_max = 65536
net.ipv4.tcp_max_syn_backlog = 16384
net.ipv4.tcp_timestamps = 0
net.core.somaxconn = 16384
EOF
sysctl --system
1.18.所有节点配置hosts本地解析
cat > /etc/hosts <<EOF
127.0.0.1 localhost localhost.localdomain localhost4 localhost4.localdomain4
::1 localhost localhost.localdomain localhost6 localhost6.localdomain6
192.168.1.81 k8s-master01
192.168.1.82 k8s-master02
192.168.1.83 k8s-master03
192.168.1.84 k8s-node01
192.168.1.85 k8s-node02
192.168.1.86 k8s-node03
192.168.1.87 k8s-node04
192.168.1.88 k8s-node05
192.168.1.80 lb01
192.168.1.90 lb02
192.168.1.89 lb-vip
EOF
2.k8s基本组件安装
2.1.所有k8s节点安装Containerd作为Runtime
yum install containerd -y
2.1.1配置Containerd所需的模块
cat <<EOF | sudo tee /etc/modules-load.d/containerd.conf
overlay
br_netfilter
EOF
2.1.2加载模块
systemctl restart systemd-modules-load.service
2.1.3配置Containerd所需的内核
cat <<EOF | sudo tee /etc/sysctl.d/99-kubernetes-cri.conf
net.bridge.bridge-nf-call-iptables = 1
net.ipv4.ip_forward = 1
net.bridge.bridge-nf-call-ip6tables = 1
EOF
# 加载内核
sysctl --system
2.1.4创建Containerd的配置文件
mkdir -p /etc/containerd
containerd config default | tee /etc/containerd/config.toml
修改Containerd的配置文件
sed -i "s#SystemdCgroup\ \=\ false#SystemdCgroup\ \=\ true#g" /etc/containerd/config.toml
cat /etc/containerd/config.toml | grep SystemdCgroup
# 找到containerd.runtimes.runc.options，在其下加入SystemdCgroup = true
[plugins."io.containerd.grpc.v1.cri".containerd.runtimes.runc.options]
SystemdCgroup = true
[plugins."io.containerd.grpc.v1.cri".cni]
# 将sandbox_image默认地址改为符合版本地址
sandbox_image = "registry.cn-hangzhou.aliyuncs.com/chenby/pause:3.6"
2.1.5启动并设置为开机启动
systemctl daemon-reload
systemctl enable --now containerd
2.1.6配置crictl客户端连接的运行时位置
cat > /etc/crictl.yaml <<EOF
runtime-endpoint: unix:///run/containerd/containerd.sock
image-endpoint: unix:///run/containerd/containerd.sock
timeout: 10
debug: false
EOF
systemctl restart containerd
2.2.k8s与etcd下载及安装（仅在master01操作）
2.2.1下载k8s安装包（你用哪个下哪个）
1.下载kubernetes1.23.+的二进制包
github二进制包下载地址：https://github.com/kubernetes/kubernetes/blob/master/CHANGELOG/CHANGELOG-1.23.md
wget https://dl.k8s.io/v1.23.6/kubernetes-server-linux-amd64.tar.gz
2.下载etcdctl二进制包
github二进制包下载地址：https://github.com/etcd-io/etcd/releases
wget https://github.com/etcd-io/etcd/releases/download/v3.5.3/etcd-v3.5.3-linux-amd64.tar.gz
3.docker-ce二进制包下载地址
二进制包下载地址：https://download.docker.com/linux/static/stable/x86_64/
这里需要下载20.10.+版本
wget https://download.docker.com/linux/static/stable/x86_64/docker-20.10.14.tgz
4.containerd二进制包下载
github下载地址：https://github.com/containerd/containerd/releases
containerd下载时下载带cni插件的二进制包。
wget https://github.com/containerd/containerd/releases/download/v1.6.2/cri-containerd-cni-1.6.2-linux-amd64.tar.gz
5.下载cfssl二进制包
github二进制包下载地址：https://github.com/cloudflare/cfssl/releases
wget https://github.com/cloudflare/cfssl/releases/download/v1.6.1/cfssl_1.6.1_linux_amd64
wget https://github.com/cloudflare/cfssl/releases/download/v1.6.1/cfssljson_1.6.1_linux_amd64
wget https://github.com/cloudflare/cfssl/releases/download/v1.6.1/cfssl-certinfo_1.6.1_linux_amd64
6.cni插件下载
github下载地址：https://github.com/containernetworking/plugins/releases
wget https://github.com/containernetworking/plugins/releases/download/v1.1.1/cni-plugins-linux-amd64-v1.1.1.tgz
7.crictl客户端二进制下载
github下载：https://github.com/kubernetes-sigs/cri-tools/releases
wget https://github.com/kubernetes-sigs/cri-tools/releases/download/v1.23.0/crictl-v1.23.0-linux-amd64.tar.gz
解压k8s安装文件
tar -xf kubernetes-server-linux-amd64.tar.gz --strip-components=3 -C /usr/local/bin kubernetes/server/bin/kube{let,ctl,-apiserver,-controller-manager,-scheduler,-proxy}
解压etcd安装文件
tar -xf etcd-v3.5.3-linux-amd64.tar.gz --strip-components=1 -C /usr/local/bin etcd-v3.5.3-linux-amd64/etcd{,ctl}
# 查看/usr/local/bin下内容
ls /usr/local/bin/
etcd etcdctl kube-apiserver kube-controller-manager kubectl kubelet kube-proxy kube-scheduler
已经整理好的：
wget https://github.com/cby-chen/Kubernetes/releases/download/v1.23.6/kubernetes-v1.23.6.tar
2.2.2查看版本
[root@k8s-master01 ~]# kubelet --version
Kubernetes v1.23.6
[root@k8s-master01 ~]# etcdctl version
etcdctl version: 3.5.3
API version: 3.5
[root@k8s-master01 ~]#
2.2.3将组件发送至其他k8s节点
Master='k8s-master02 k8s-master03'
Work='k8s-node01 k8s-node02 k8s-node03 k8s-node04 k8s-node05'
for NODE in $Master; do echo $NODE; scp /usr/local/bin/kube{let,ctl,-apiserver,-controller-manager,-scheduler,-proxy} $NODE:/usr/local/bin/; scp /usr/local/bin/etcd* $NODE:/usr/local/bin/; done
for NODE in $Work; do scp /usr/local/bin/kube{let,-proxy} $NODE:/usr/local/bin/ ; done
2.2.4克隆证书相关文件
git clone https://github.com/cby-chen/Kubernetes.git
2.2.5所有k8s节点创建目录
mkdir -p /opt/cni/bin
3.相关证书生成
master01节点下载证书生成工具
wget "https://github.com/cloudflare/cfssl/releases/download/v1.6.1/cfssl_1.6.1_linux_amd64" -O /usr/local/bin/cfssl
wget "https://github.com/cloudflare/cfssl/releases/download/v1.6.1/cfssljson_1.6.1_linux_amd64" -O /usr/local/bin/cfssljson
chmod +x /usr/local/bin/cfssl /usr/local/bin/cfssljson
3.1.生成etcd证书
特别说明除外，以下操作在所有master节点操作
3.1.1所有master节点创建证书存放目录
mkdir /etc/etcd/ssl -p
3.1.2master01节点生成etcd证书
cd Kubernetes/pki/
# 生成etcd证书和etcd证书的key（如果你觉得以后可能会扩容，可以在ip那多写几个预留出来）
cfssl gencert -initca etcd-ca-csr.json | cfssljson -bare /etc/etcd/ssl/etcd-ca
cfssl gencert \
-ca=/etc/etcd/ssl/etcd-ca.pem \
-ca-key=/etc/etcd/ssl/etcd-ca-key.pem \
-config=ca-config.json \
-hostname=127.0.0.1,k8s-master01,k8s-master02,k8s-master03,192.168.1.81,192.168.1.82,192.168.1.83 \
-profile=kubernetes \
etcd-csr.json | cfssljson -bare /etc/etcd/ssl/etcd
3.1.3将证书复制到其他节点
Master='k8s-master02 k8s-master03'
for NODE in $Master; do ssh $NODE "mkdir -p /etc/etcd/ssl"; for FILE in etcd-ca-key.pem etcd-ca.pem etcd-key.pem etcd.pem; do scp /etc/etcd/ssl/${FILE} $NODE:/etc/etcd/ssl/${FILE}; done; done
3.2.生成k8s相关证书
特别说明除外，以下操作在所有master节点操作
3.2.1所有k8s节点创建证书存放目录
mkdir -p /etc/kubernetes/pki
3.2.2master01节点生成k8s证书
# 生成一个根证书
cfssl gencert -initca ca-csr.json | cfssljson -bare /etc/kubernetes/pki/ca
# 10.96.0.1是service网段的第一个地址，需要计算，192.168.1.89为高可用vip地址
cfssl gencert \
-ca=/etc/kubernetes/pki/ca.pem \
-ca-key=/etc/kubernetes/pki/ca-key.pem \
-config=ca-config.json \
-hostname=10.96.0.1,192.168.1.89,127.0.0.1,kubernetes,kubernetes.default,kubernetes.default.svc,kubernetes.default.svc.cluster,kubernetes.default.svc.cluster.local,x.oiox.cn,k.oiox.cn,l.oiox.cn,o.oiox.cn,192.168.1.81,192.168.1.82,192.168.1.83,192.168.1.84,192.168.1.85,192.168.1.86,192.168.1.87,192.168.1.88,192.168.1.80,192.168.1.90,192.168.1.40,192.168.1.41 \
-profile=kubernetes apiserver-csr.json | cfssljson -bare /etc/kubernetes/pki/apiserver
3.2.3生成apiserver聚合证书
cfssl gencert -initca front-proxy-ca-csr.json | cfssljson -bare /etc/kubernetes/pki/front-proxy-ca
# 有一个警告，可以忽略
cfssl gencert \
-ca=/etc/kubernetes/pki/front-proxy-ca.pem \
-ca-key=/etc/kubernetes/pki/front-proxy-ca-key.pem \
-config=ca-config.json \
-profile=kubernetes front-proxy-client-csr.json | cfssljson -bare /etc/kubernetes/pki/front-proxy-client
3.2.4生成controller-manage的证书
cfssl gencert \
-ca=/etc/kubernetes/pki/ca.pem \
-ca-key=/etc/kubernetes/pki/ca-key.pem \
-config=ca-config.json \
-profile=kubernetes \
manager-csr.json | cfssljson -bare /etc/kubernetes/pki/controller-manager
# 设置一个集群项
kubectl config set-cluster kubernetes \
--certificate-authority=/etc/kubernetes/pki/ca.pem \
--embed-certs=true \
--server=https://192.168.1.89:8443 \
--kubeconfig=/etc/kubernetes/controller-manager.kubeconfig
# 设置一个环境项，一个上下文
kubectl config set-context system:kube-controller-manager@kubernetes \
--cluster=kubernetes \
--user=system:kube-controller-manager \
--kubeconfig=/etc/kubernetes/controller-manager.kubeconfig
# 设置一个用户项
kubectl config set-credentials system:kube-controller-manager \
--client-certificate=/etc/kubernetes/pki/controller-manager.pem \
--client-key=/etc/kubernetes/pki/controller-manager-key.pem \
--embed-certs=true \
--kubeconfig=/etc/kubernetes/controller-manager.kubeconfig
# 设置默认环境
kubectl config use-context system:kube-controller-manager@kubernetes \
--kubeconfig=/etc/kubernetes/controller-manager.kubeconfig
cfssl gencert \
-ca=/etc/kubernetes/pki/ca.pem \
-ca-key=/etc/kubernetes/pki/ca-key.pem \
-config=ca-config.json \
-profile=kubernetes \
scheduler-csr.json | cfssljson -bare /etc/kubernetes/pki/scheduler
kubectl config set-cluster kubernetes \
--certificate-authority=/etc/kubernetes/pki/ca.pem \
--embed-certs=true \
--server=https://192.168.1.89:8443 \
--kubeconfig=/etc/kubernetes/scheduler.kubeconfig
kubectl config set-credentials system:kube-scheduler \
--client-certificate=/etc/kubernetes/pki/scheduler.pem \
--client-key=/etc/kubernetes/pki/scheduler-key.pem \
--embed-certs=true \
--kubeconfig=/etc/kubernetes/scheduler.kubeconfig
kubectl config set-context system:kube-scheduler@kubernetes \
--cluster=kubernetes \
--user=system:kube-scheduler \
--kubeconfig=/etc/kubernetes/scheduler.kubeconfig
kubectl config use-context system:kube-scheduler@kubernetes \
--kubeconfig=/etc/kubernetes/scheduler.kubeconfig
cfssl gencert \
-ca=/etc/kubernetes/pki/ca.pem \
-ca-key=/etc/kubernetes/pki/ca-key.pem \
-config=ca-config.json \
-profile=kubernetes \
admin-csr.json | cfssljson -bare /etc/kubernetes/pki/admin
kubectl config set-cluster kubernetes \
--certificate-authority=/etc/kubernetes/pki/ca.pem \
--embed-certs=true \
--server=https://192.168.1.89:8443 \
--kubeconfig=/etc/kubernetes/admin.kubeconfig
kubectl config set-credentials kubernetes-admin \
--client-certificate=/etc/kubernetes/pki/admin.pem \
--client-key=/etc/kubernetes/pki/admin-key.pem \
--embed-certs=true \
--kubeconfig=/etc/kubernetes/admin.kubeconfig
kubectl config set-context kubernetes-admin@kubernetes \
--cluster=kubernetes \
--user=kubernetes-admin \
--kubeconfig=/etc/kubernetes/admin.kubeconfig
kubectl config use-context kubernetes-admin@kubernetes --kubeconfig=/etc/kubernetes/admin.kubeconfig
3.2.5创建ServiceAccount Key ——secret
openssl genrsa -out /etc/kubernetes/pki/sa.key 2048
openssl rsa -in /etc/kubernetes/pki/sa.key -pubout -out /etc/kubernetes/pki/sa.pub
3.2.6将证书发送到其他master节点
for NODE in k8s-master02 k8s-master03; do for FILE in $(ls /etc/kubernetes/pki | grep -v etcd); do scp /etc/kubernetes/pki/${FILE} $NODE:/etc/kubernetes/pki/${FILE}; done; for FILE in admin.kubeconfig controller-manager.kubeconfig scheduler.kubeconfig; do scp /etc/kubernetes/${FILE} $NODE:/etc/kubernetes/${FILE}; done; done
3.2.7查看证书
ls /etc/kubernetes/pki/
admin.csr apiserver-key.pem ca.pem front-proxy-ca.csr front-proxy-client-key.pem scheduler.csr
admin-key.pem apiserver.pem controller-manager.csr front-proxy-ca-key.pem front-proxy-client.pem scheduler-key.pem
admin.pem ca.csr controller-manager-key.pem front-proxy-ca.pem sa.key scheduler.pem
apiserver.csr ca-key.pem controller-manager.pem front-proxy-client.csr sa.pub
# 一共23个就对了
ls /etc/kubernetes/pki/ |wc -l
23
4.k8s系统组件配置
4.1.etcd配置
4.1.1master01配置
cat > /etc/etcd/etcd.config.yml << EOF
name: 'k8s-master01'
data-dir: /var/lib/etcd
wal-dir: /var/lib/etcd/wal
snapshot-count: 5000
heartbeat-interval: 100
election-timeout: 1000
quota-backend-bytes: 0
listen-peer-urls: 'https://192.168.1.81:2380'
listen-client-urls: 'https://192.168.1.81:2379,http://127.0.0.1:2379'
max-snapshots: 3
max-wals: 5
cors:
initial-advertise-peer-urls: 'https://192.168.1.81:2380'
advertise-client-urls: 'https://192.168.1.81:2379'
discovery:
discovery-fallback: 'proxy'
discovery-proxy:
discovery-srv:
initial-cluster: 'k8s-master01=https://192.168.1.81:2380,k8s-master02=https://192.168.1.82:2380,k8s-master03=https://192.168.1.83:2380'
initial-cluster-token: 'etcd-k8s-cluster'
initial-cluster-state: 'new'
strict-reconfig-check: false
enable-v2: true
enable-pprof: true
proxy: 'off'
proxy-failure-wait: 5000
proxy-refresh-interval: 30000
proxy-dial-timeout: 1000
proxy-write-timeout: 5000
proxy-read-timeout: 0
client-transport-security:
cert-file: '/etc/kubernetes/pki/etcd/etcd.pem'
key-file: '/etc/kubernetes/pki/etcd/etcd-key.pem'
client-cert-auth: true
trusted-ca-file: '/etc/kubernetes/pki/etcd/etcd-ca.pem'
auto-tls: true
peer-transport-security:
cert-file: '/etc/kubernetes/pki/etcd/etcd.pem'
key-file: '/etc/kubernetes/pki/etcd/etcd-key.pem'
peer-client-cert-auth: true
trusted-ca-file: '/etc/kubernetes/pki/etcd/etcd-ca.pem'
auto-tls: true
debug: false
log-package-levels:
log-outputs: [default]
force-new-cluster: false
EOF
4.1.2master02配置
cat > /etc/etcd/etcd.config.yml << EOF
name: 'k8s-master02'
data-dir: /var/lib/etcd
wal-dir: /var/lib/etcd/wal
snapshot-count: 5000
heartbeat-interval: 100
election-timeout: 1000
quota-backend-bytes: 0
listen-peer-urls: 'https://192.168.1.82:2380'
listen-client-urls: 'https://192.168.1.82:2379,http://127.0.0.1:2379'
max-snapshots: 3
max-wals: 5
cors:
initial-advertise-peer-urls: 'https://192.168.1.82:2380'
advertise-client-urls: 'https://192.168.1.82:2379'
discovery:
discovery-fallback: 'proxy'
discovery-proxy:
discovery-srv:
initial-cluster: 'k8s-master01=https://192.168.1.81:2380,k8s-master02=https://192.168.1.82:2380,k8s-master03=https://192.168.1.83:2380'
initial-cluster-token: 'etcd-k8s-cluster'
initial-cluster-state: 'new'
strict-reconfig-check: false
enable-v2: true
enable-pprof: true
proxy: 'off'
proxy-failure-wait: 5000
proxy-refresh-interval: 30000
proxy-dial-timeout: 1000
proxy-write-timeout: 5000
proxy-read-timeout: 0
client-transport-security:
cert-file: '/etc/kubernetes/pki/etcd/etcd.pem'
key-file: '/etc/kubernetes/pki/etcd/etcd-key.pem'
client-cert-auth: true
trusted-ca-file: '/etc/kubernetes/pki/etcd/etcd-ca.pem'
auto-tls: true
peer-transport-security:
cert-file: '/etc/kubernetes/pki/etcd/etcd.pem'
key-file: '/etc/kubernetes/pki/etcd/etcd-key.pem'
peer-client-cert-auth: true
trusted-ca-file: '/etc/kubernetes/pki/etcd/etcd-ca.pem'
auto-tls: true
debug: false
log-package-levels:
log-outputs: [default]
force-new-cluster: false
EOF
4.1.3master03配置
cat > /etc/etcd/etcd.config.yml << EOF
name: 'k8s-master03'
data-dir: /var/lib/etcd
wal-dir: /var/lib/etcd/wal
snapshot-count: 5000
heartbeat-interval: 100
election-timeout: 1000
quota-backend-bytes: 0
listen-peer-urls: 'https://192.168.1.83:2380'
listen-client-urls: 'https://192.168.1.83:2379,http://127.0.0.1:2379'
max-snapshots: 3
max-wals: 5
cors:
initial-advertise-peer-urls: 'https://192.168.1.83:2380'
advertise-client-urls: 'https://192.168.1.83:2379'
discovery:
discovery-fallback: 'proxy'
discovery-proxy:
discovery-srv:
initial-cluster: 'k8s-master01=https://192.168.1.81:2380,k8s-master02=https://192.168.1.82:2380,k8s-master03=https://192.168.1.83:2380'
initial-cluster-token: 'etcd-k8s-cluster'
initial-cluster-state: 'new'
strict-reconfig-check: false
enable-v2: true
enable-pprof: true
proxy: 'off'
proxy-failure-wait: 5000
proxy-refresh-interval: 30000
proxy-dial-timeout: 1000
proxy-write-timeout: 5000
proxy-read-timeout: 0
client-transport-security:
cert-file: '/etc/kubernetes/pki/etcd/etcd.pem'
key-file: '/etc/kubernetes/pki/etcd/etcd-key.pem'
client-cert-auth: true
trusted-ca-file: '/etc/kubernetes/pki/etcd/etcd-ca.pem'
auto-tls: true
peer-transport-security:
cert-file: '/etc/kubernetes/pki/etcd/etcd.pem'
key-file: '/etc/kubernetes/pki/etcd/etcd-key.pem'
peer-client-cert-auth: true
trusted-ca-file: '/etc/kubernetes/pki/etcd/etcd-ca.pem'
auto-tls: true
debug: false
log-package-levels:
log-outputs: [default]
force-new-cluster: false
EOF
4.2.创建service（所有master节点操作）
4.2.1创建etcd.service并启动
cat > /usr/lib/systemd/system/etcd.service << EOF
[Unit]
Description=Etcd Service
Documentation=https://coreos.com/etcd/docs/latest/
After=network.target
[Service]
Type=notify
ExecStart=/usr/local/bin/etcd --config-file=/etc/etcd/etcd.config.yml
Restart=on-failure
RestartSec=10
LimitNOFILE=65536
[Install]
WantedBy=multi-user.target
Alias=etcd3.service
EOF
4.2.2创建etcd证书目录
mkdir /etc/kubernetes/pki/etcd
ln -s /etc/etcd/ssl/* /etc/kubernetes/pki/etcd/
systemctl daemon-reload
systemctl enable --now etcd
4.2.3查看etcd状态
export ETCDCTL_API=3
etcdctl --endpoints="192.168.1.83:2379,192.168.1.82:2379,192.168.1.81:2379" --cacert=/etc/kubernetes/pki/etcd/etcd-ca.pem --cert=/etc/kubernetes/pki/etcd/etcd.pem --key=/etc/kubernetes/pki/etcd/etcd-key.pem endpoint status --write-out=table
+-------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
| ENDPOINT | ID | VERSION | DB SIZE | IS LEADER | IS LEARNER | RAFT TERM | RAFT INDEX | RAFT APPLIED INDEX | ERRORS |
+-------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
| 192.168.1.83:2379 | 7cb7be3df5c81965 | 3.5.2 | 20 kB | false | false | 2 | 9 | 9 | |
| 192.168.1.82:2379 | c077939949ab3f8b | 3.5.2 | 20 kB | false | false | 2 | 9 | 9 | |
| 192.168.1.81:2379 | 2ee388f67565dac9 | 3.5.2 | 20 kB | true | false | 2 | 9 | 9 | |
+-------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
[root@k8s-master01 pki]#
5.高可用配置
5.1在lb01和lb02两台服务器上操作
5.1.1安装keepalived和haproxy服务
systemctl disable --now firewalld
setenforce 0
sed -i 's#SELINUX=enforcing#SELINUX=disabled#g' /etc/selinux/config
yum -y install keepalived haproxy
5.1.2修改haproxy配置文件（两台配置文件一样）
# cp /etc/haproxy/haproxy.cfg /etc/haproxy/haproxy.cfg.bak
cat >/etc/haproxy/haproxy.cfg<<"EOF"
global
maxconn 2000
ulimit-n 16384
log 127.0.0.1 local0 err
stats timeout 30s
defaults
log global
mode http
option httplog
timeout connect 5000
timeout client 50000
timeout server 50000
timeout http-request 15s
timeout http-keep-alive 15s
frontend monitor-in
bind *:33305
mode http
option httplog
monitor-uri /monitor
frontend k8s-master
bind 0.0.0.0:8443
bind 127.0.0.1:8443
mode tcp
option tcplog
tcp-request inspect-delay 5s
default_backend k8s-master
backend k8s-master
mode tcp
option tcplog
option tcp-check
balance roundrobin
default-server inter 10s downinter 5s rise 2 fall 2 slowstart 60s maxconn 250 maxqueue 256 weight 100
server k8s-master01 192.168.1.81:6443 check
server k8s-master02 192.168.1.82:6443 check
server k8s-master03 192.168.1.83:6443 check
EOF
5.1.3lb01配置keepalived master节点
#cp /etc/keepalived/keepalived.conf /etc/keepalived/keepalived.conf.bak
cat > /etc/keepalived/keepalived.conf << EOF
! Configuration File for keepalived
global_defs {
router_id LVS_DEVEL
}
vrrp_script chk_apiserver {
script "/etc/keepalived/check_apiserver.sh"
interval 5
weight -5
fall 2
rise 1
}
vrrp_instance VI_1 {
state MASTER
interface ens18
mcast_src_ip 192.168.1.80
virtual_router_id 51
priority 100
nopreempt
advert_int 2
authentication {
auth_type PASS
auth_pass K8SHA_KA_AUTH
}
virtual_ipaddress {
192.168.1.89
}
track_script {
chk_apiserver
} }
EOF
5.1.4lb02配置keepalived backup节点
# cp /etc/keepalived/keepalived.conf /etc/keepalived/keepalived.conf.bak
cat > /etc/keepalived/keepalived.conf << EOF
! Configuration File for keepalived
global_defs {
router_id LVS_DEVEL
}
vrrp_script chk_apiserver {
script "/etc/keepalived/check_apiserver.sh"
interval 5
weight -5
fall 2
rise 1
}
vrrp_instance VI_1 {
state BACKUP
interface ens18
mcast_src_ip 192.168.1.90
virtual_router_id 51
priority 50
nopreempt
advert_int 2
authentication {
auth_type PASS
auth_pass K8SHA_KA_AUTH
}
virtual_ipaddress {
192.168.1.89
}
track_script {
chk_apiserver
} }
EOF
5.1.5健康检查脚本配置（两台lb主机）
cat > /etc/keepalived/check_apiserver.sh << EOF
#!/bin/bash
err=0
for k in \$(seq 1 3)
do
check_code=\$(pgrep haproxy)
if [[ \$check_code == "" ]]; then
err=\$(expr \$err + 1)
sleep 1
continue
else
err=0
break
fi
done
if [[ \$err != "0" ]]; then
echo "systemctl stop keepalived"
/usr/bin/systemctl stop keepalived
exit 1
else
exit 0
fi
EOF
# 给脚本授权
chmod +x /etc/keepalived/check_apiserver.sh
5.1.6启动服务
systemctl daemon-reload
systemctl enable --now haproxy
systemctl enable --now keepalived
5.1.7测试高可用
# 能ping同
[root@k8s-node02 ~]# ping 192.168.1.89
# 能telnet访问
[root@k8s-node02 ~]# telnet 192.168.1.89 8443
# 关闭主节点，看vip是否漂移到备节点
6.k8s组件配置（区别于第4点）
所有k8s节点创建以下目录
mkdir -p /etc/kubernetes/manifests/ /etc/systemd/system/kubelet.service.d /var/lib/kubelet /var/log/kubernetes
6.1.创建apiserver（所有master节点）
6.1.1master01节点配置
cat > /usr/lib/systemd/system/kube-apiserver.service << EOF
[Unit]
Description=Kubernetes API Server
Documentation=https://github.com/kubernetes/kubernetes
After=network.target
[Service]
ExecStart=/usr/local/bin/kube-apiserver \
--v=2 \
--logtostderr=true \
--allow-privileged=true \
--bind-address=0.0.0.0 \
--secure-port=6443 \
--insecure-port=0 \
--advertise-address=192.168.1.81 \
--service-cluster-ip-range=10.96.0.0/12 \
--service-node-port-range=30000-32767 \
--etcd-servers=https://192.168.1.81:2379,https://192.168.1.82:2379,https://192.168.1.83:2379 \
--etcd-cafile=/etc/etcd/ssl/etcd-ca.pem \
--etcd-certfile=/etc/etcd/ssl/etcd.pem \
--etcd-keyfile=/etc/etcd/ssl/etcd-key.pem \
--client-ca-file=/etc/kubernetes/pki/ca.pem \
--tls-cert-file=/etc/kubernetes/pki/apiserver.pem \
--tls-private-key-file=/etc/kubernetes/pki/apiserver-key.pem \
--kubelet-client-certificate=/etc/kubernetes/pki/apiserver.pem \
--kubelet-client-key=/etc/kubernetes/pki/apiserver-key.pem \
--service-account-key-file=/etc/kubernetes/pki/sa.pub \
--service-account-signing-key-file=/etc/kubernetes/pki/sa.key \
--service-account-issuer=https://kubernetes.default.svc.cluster.local \
--kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname \
--enable-admission-plugins=NamespaceLifecycle,LimitRanger,ServiceAccount,DefaultStorageClass,DefaultTolerationSeconds,NodeRestriction,ResourceQuota \
--authorization-mode=Node,RBAC \
--enable-bootstrap-token-auth=true \
--requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.pem \
--proxy-client-cert-file=/etc/kubernetes/pki/front-proxy-client.pem \
--proxy-client-key-file=/etc/kubernetes/pki/front-proxy-client-key.pem \
--requestheader-allowed-names=aggregator \
--requestheader-group-headers=X-Remote-Group \
--requestheader-extra-headers-prefix=X-Remote-Extra- \
--requestheader-username-headers=X-Remote-User \
--enable-aggregator-routing=true
# --token-auth-file=/etc/kubernetes/token.csv
Restart=on-failure
RestartSec=10s
LimitNOFILE=65535
[Install]
WantedBy=multi-user.target
EOF
6.1.2master02节点配置
cat > /usr/lib/systemd/system/kube-apiserver.service << EOF
[Unit]
Description=Kubernetes API Server
Documentation=https://github.com/kubernetes/kubernetes
After=network.target
[Service]
ExecStart=/usr/local/bin/kube-apiserver \
--v=2 \
--logtostderr=true \
--allow-privileged=true \
--bind-address=0.0.0.0 \
--secure-port=6443 \
--insecure-port=0 \
--advertise-address=192.168.1.82 \
--service-cluster-ip-range=10.96.0.0/12 \
--service-node-port-range=30000-32767 \
--etcd-servers=https://192.168.1.81:2379,https://192.168.1.82:2379,https://192.168.1.83:2379 \
--etcd-cafile=/etc/etcd/ssl/etcd-ca.pem \
--etcd-certfile=/etc/etcd/ssl/etcd.pem \
--etcd-keyfile=/etc/etcd/ssl/etcd-key.pem \
--client-ca-file=/etc/kubernetes/pki/ca.pem \
--tls-cert-file=/etc/kubernetes/pki/apiserver.pem \
--tls-private-key-file=/etc/kubernetes/pki/apiserver-key.pem \
--kubelet-client-certificate=/etc/kubernetes/pki/apiserver.pem \
--kubelet-client-key=/etc/kubernetes/pki/apiserver-key.pem \
--service-account-key-file=/etc/kubernetes/pki/sa.pub \
--service-account-signing-key-file=/etc/kubernetes/pki/sa.key \
--service-account-issuer=https://kubernetes.default.svc.cluster.local \
--kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname \
--enable-admission-plugins=NamespaceLifecycle,LimitRanger,ServiceAccount,DefaultStorageClass,DefaultTolerationSeconds,NodeRestriction,ResourceQuota \
--authorization-mode=Node,RBAC \
--enable-bootstrap-token-auth=true \
--requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.pem \
--proxy-client-cert-file=/etc/kubernetes/pki/front-proxy-client.pem \
--proxy-client-key-file=/etc/kubernetes/pki/front-proxy-client-key.pem \
--requestheader-allowed-names=aggregator \
--requestheader-group-headers=X-Remote-Group \
--requestheader-extra-headers-prefix=X-Remote-Extra- \
--requestheader-username-headers=X-Remote-User \
--enable-aggregator-routing=true
# --token-auth-file=/etc/kubernetes/token.csv
Restart=on-failure
RestartSec=10s
LimitNOFILE=65535
[Install]
WantedBy=multi-user.target
EOF
6.1.3master03节点配置
cat > /usr/lib/systemd/system/kube-apiserver.service << EOF
[Unit]
Description=Kubernetes API Server
Documentation=https://github.com/kubernetes/kubernetes
After=network.target
[Service]
ExecStart=/usr/local/bin/kube-apiserver \
--v=2 \
--logtostderr=true \
--allow-privileged=true \
--bind-address=0.0.0.0 \
--secure-port=6443 \
--insecure-port=0 \
--advertise-address=192.168.1.83 \
--service-cluster-ip-range=10.96.0.0/12 \
--service-node-port-range=30000-32767 \
--etcd-servers=https://192.168.1.81:2379,https://192.168.1.82:2379,https://192.168.1.83:2379 \
--etcd-cafile=/etc/etcd/ssl/etcd-ca.pem \
--etcd-certfile=/etc/etcd/ssl/etcd.pem \
--etcd-keyfile=/etc/etcd/ssl/etcd-key.pem \
--client-ca-file=/etc/kubernetes/pki/ca.pem \
--tls-cert-file=/etc/kubernetes/pki/apiserver.pem \
--tls-private-key-file=/etc/kubernetes/pki/apiserver-key.pem \
--kubelet-client-certificate=/etc/kubernetes/pki/apiserver.pem \
--kubelet-client-key=/etc/kubernetes/pki/apiserver-key.pem \
--service-account-key-file=/etc/kubernetes/pki/sa.pub \
--service-account-signing-key-file=/etc/kubernetes/pki/sa.key \
--service-account-issuer=https://kubernetes.default.svc.cluster.local \
--kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname \
--enable-admission-plugins=NamespaceLifecycle,LimitRanger,ServiceAccount,DefaultStorageClass,DefaultTolerationSeconds,NodeRestriction,ResourceQuota \
--authorization-mode=Node,RBAC \
--enable-bootstrap-token-auth=true \
--requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.pem \
--proxy-client-cert-file=/etc/kubernetes/pki/front-proxy-client.pem \
--proxy-client-key-file=/etc/kubernetes/pki/front-proxy-client-key.pem \
--requestheader-allowed-names=aggregator \
--requestheader-group-headers=X-Remote-Group \
--requestheader-extra-headers-prefix=X-Remote-Extra- \
--requestheader-username-headers=X-Remote-User \
--enable-aggregator-routing=true
# --token-auth-file=/etc/kubernetes/token.csv
Restart=on-failure
RestartSec=10s
LimitNOFILE=65535
[Install]
WantedBy=multi-user.target
EOF
6.1.4启动apiserver（所有master节点）
systemctl daemon-reload && systemctl enable --now kube-apiserver
# 注意查看状态是否启动正常
systemctl status kube-apiserver
6.2.配置kube-controller-manager service
所有master节点配置，且配置相同
172.16.0.0/12为pod网段，按需求设置你自己的网段
cat > /usr/lib/systemd/system/kube-controller-manager.service << EOF
[Unit]
Description=Kubernetes Controller Manager
Documentation=https://github.com/kubernetes/kubernetes
After=network.target
[Service]
ExecStart=/usr/local/bin/kube-controller-manager \
--v=2 \
--logtostderr=true \
--address=127.0.0.1 \
--root-ca-file=/etc/kubernetes/pki/ca.pem \
--cluster-signing-cert-file=/etc/kubernetes/pki/ca.pem \
--cluster-signing-key-file=/etc/kubernetes/pki/ca-key.pem \
--service-account-private-key-file=/etc/kubernetes/pki/sa.key \
--kubeconfig=/etc/kubernetes/controller-manager.kubeconfig \
--leader-elect=true \
--use-service-account-credentials=true \
--node-monitor-grace-period=40s \
--node-monitor-period=5s \
--pod-eviction-timeout=2m0s \
--controllers=*,bootstrapsigner,tokencleaner \
--allocate-node-cidrs=true \
--cluster-cidr=172.16.0.0/12 \
--requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.pem \
--node-cidr-mask-size=24
Restart=always
RestartSec=10s
[Install]
WantedBy=multi-user.target
EOF
6.2.1启动kube-controller-manager，并查看状态
systemctl daemon-reload
systemctl enable --now kube-controller-manager
systemctl status kube-controller-manager
6.3.配置kube-scheduler service
6.3.1所有master节点配置，且配置相同
cat > /usr/lib/systemd/system/kube-scheduler.service << EOF
[Unit]
Description=Kubernetes Scheduler
Documentation=https://github.com/kubernetes/kubernetes
After=network.target
[Service]
ExecStart=/usr/local/bin/kube-scheduler \
--v=2 \
--logtostderr=true \
--address=127.0.0.1 \
--leader-elect=true \
--kubeconfig=/etc/kubernetes/scheduler.kubeconfig
Restart=always
RestartSec=10s
[Install]
WantedBy=multi-user.target
EOF
6.3.2启动并查看服务状态
systemctl daemon-reload
systemctl enable --now kube-scheduler
systemctl status kube-scheduler
7.TLS Bootstrapping配置
7.1在master01上配置
cd /root/Kubernetes/bootstrap
kubectl config set-cluster kubernetes \
--certificate-authority=/etc/kubernetes/pki/ca.pem \
--embed-certs=true --server=https://192.168.1.89:8443 \
--kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig
kubectl config set-credentials tls-bootstrap-token-user \
--token=c8ad9c.2e4d610cf3e7426e \
--kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig
kubectl config set-context tls-bootstrap-token-user@kubernetes \
--cluster=kubernetes \
--user=tls-bootstrap-token-user \
--kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig
kubectl config use-context tls-bootstrap-token-user@kubernetes \
--kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig
# token的位置在bootstrap.secret.yaml，如果修改的话到这个文件修改
mkdir -p /root/.kube ; cp /etc/kubernetes/admin.kubeconfig /root/.kube/config
7.2查看集群状态，没问题的话继续后续操作
kubectl get cs
Warning: v1 ComponentStatus is deprecated in v1.19+
NAME STATUS MESSAGE ERROR
scheduler Healthy ok
controller-manager Healthy ok
etcd-0 Healthy {"health":"true","reason":""}
etcd-2 Healthy {"health":"true","reason":""}
etcd-1 Healthy {"health":"true","reason":""}
kubectl create -f bootstrap.secret.yaml
8.node节点配置
8.1.在master01上将证书复制到node节点
cd /etc/kubernetes/
for NODE in k8s-master02 k8s-master03 k8s-node01 k8s-node02 k8s-node03 k8s-node04 k8s-node05; do ssh $NODE mkdir -p /etc/kubernetes/pki; for FILE in pki/ca.pem pki/ca-key.pem pki/front-proxy-ca.pem bootstrap-kubelet.kubeconfig; do scp /etc/kubernetes/$FILE $NODE:/etc/kubernetes/${FILE}; done; done
8.2.kubelet配置
8.2.1所有k8s节点创建相关目录
mkdir -p /var/lib/kubelet /var/log/kubernetes /etc/systemd/system/kubelet.service.d /etc/kubernetes/manifests/
所有k8s节点配置kubelet service
cat > /usr/lib/systemd/system/kubelet.service << EOF
[Unit]
Description=Kubernetes Kubelet
Documentation=https://github.com/kubernetes/kubernetes
After=docker.service
Requires=docker.service
[Service]
ExecStart=/usr/local/bin/kubelet \
--bootstrap-kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig \
--kubeconfig=/etc/kubernetes/kubelet.kubeconfig \
--config=/etc/kubernetes/kubelet-conf.yml \
--network-plugin=cni \
--cni-conf-dir=/etc/cni/net.d \
--cni-bin-dir=/opt/cni/bin \
--container-runtime=remote \
--runtime-request-timeout=15m \
--container-runtime-endpoint=unix:///run/containerd/containerd.sock \
--cgroup-driver=systemd \
--node-labels=node.kubernetes.io/node=''
Restart=always
StartLimitInterval=0
RestartSec=10
[Install]
WantedBy=multi-user.target
EOF
8.2.2所有k8s节点创建kubelet的配置文件
cat > /etc/kubernetes/kubelet-conf.yml <<EOF
apiVersion: kubelet.config.k8s.io/v1beta1
kind: KubeletConfiguration
address: 0.0.0.0
port: 10250
readOnlyPort: 10255
authentication:
anonymous:
enabled: false
webhook:
cacheTTL: 2m0s
enabled: true
x509:
clientCAFile: /etc/kubernetes/pki/ca.pem
authorization:
mode: Webhook
webhook:
cacheAuthorizedTTL: 5m0s
cacheUnauthorizedTTL: 30s
cgroupDriver: systemd
cgroupsPerQOS: true
clusterDNS:
- 10.96.0.10
clusterDomain: cluster.local
containerLogMaxFiles: 5
containerLogMaxSize: 10Mi
contentType: application/vnd.kubernetes.protobuf
cpuCFSQuota: true
cpuManagerPolicy: none
cpuManagerReconcilePeriod: 10s
enableControllerAttachDetach: true
enableDebuggingHandlers: true
enforceNodeAllocatable:
- pods
eventBurst: 10
eventRecordQPS: 5
evictionHard:
imagefs.available: 15%
memory.available: 100Mi
nodefs.available: 10%
nodefs.inodesFree: 5%
evictionPressureTransitionPeriod: 5m0s
failSwapOn: true
fileCheckFrequency: 20s
hairpinMode: promiscuous-bridge
healthzBindAddress: 127.0.0.1
healthzPort: 10248
httpCheckFrequency: 20s
imageGCHighThresholdPercent: 85
imageGCLowThresholdPercent: 80
imageMinimumGCAge: 2m0s
iptablesDropBit: 15
iptablesMasqueradeBit: 14
kubeAPIBurst: 10
kubeAPIQPS: 5
makeIPTablesUtilChains: true
maxOpenFiles: 1000000
maxPods: 110
nodeStatusUpdateFrequency: 10s
oomScoreAdj: -999
podPidsLimit: -1
registryBurst: 10
registryPullQPS: 5
resolvConf: /etc/resolv.conf
rotateCertificates: true
runtimeRequestTimeout: 2m0s
serializeImagePulls: true
staticPodPath: /etc/kubernetes/manifests
streamingConnectionIdleTimeout: 4h0m0s
syncFrequency: 1m0s
volumeStatsAggPeriod: 1m0s
EOF
8.2.3启动kubelet
systemctl daemon-reload
systemctl restart kubelet
systemctl enable --now kubelet
8.2.4查看集群
[root@k8s-master01 ~]# kubectl get node
NAME STATUS ROLES AGE VERSION
k8s-master01 NotReady <none> 14h v1.23.5
k8s-master02 NotReady <none> 14h v1.23.5
k8s-master03 NotReady <none> 14h v1.23.5
k8s-node01 NotReady <none> 14h v1.23.5
k8s-node02 NotReady <none> 14h v1.23.5
k8s-node03 NotReady <none> 14h v1.23.5
k8s-node04 NotReady <none> 14h v1.23.5
k8s-node05 NotReady <none> 14h v1.23.5
[root@k8s-master01 ~]#
8.3.kube-proxy配置
8.3.1此配置只在master01操作
cd /root/Kubernetes/
kubectl -n kube-system create serviceaccount kube-proxy
kubectl create clusterrolebinding system:kube-proxy \
--clusterrole system:node-proxier \
--serviceaccount kube-system:kube-proxy
SECRET=$(kubectl -n kube-system get sa/kube-proxy \
--output=jsonpath='{.secrets[0].name}')
JWT_TOKEN=$(kubectl -n kube-system get secret/$SECRET \
--output=jsonpath='{.data.token}' | base64 -d)
PKI_DIR=/etc/kubernetes/pki
K8S_DIR=/etc/kubernetes
kubectl config set-cluster kubernetes \
--certificate-authority=/etc/kubernetes/pki/ca.pem \
--embed-certs=true \
--server=https://192.168.1.89:8443 \
--kubeconfig=${K8S_DIR}/kube-proxy.kubeconfig
kubectl config set-credentials kubernetes \
--token=${JWT_TOKEN} \
--kubeconfig=/etc/kubernetes/kube-proxy.kubeconfig
kubectl config set-context kubernetes \
--cluster=kubernetes \
--user=kubernetes \
--kubeconfig=/etc/kubernetes/kube-proxy.kubeconfig
kubectl config use-context kubernetes \
--kubeconfig=/etc/kubernetes/kube-proxy.kubeconfig
8.3.2将kubeconfig发送至其他节点
for NODE in k8s-master02 k8s-master03; do scp /etc/kubernetes/kube-proxy.kubeconfig $NODE:/etc/kubernetes/kube-proxy.kubeconfig; done
for NODE in k8s-node01 k8s-node02 k8s-node03 k8s-node04 k8s-node05; do scp /etc/kubernetes/kube-proxy.kubeconfig $NODE:/etc/kubernetes/kube-proxy.kubeconfig; done
8.3.3所有k8s节点添加kube-proxy的配置和service文件
cat > /usr/lib/systemd/system/kube-proxy.service << EOF
[Unit]
Description=Kubernetes Kube Proxy
Documentation=https://github.com/kubernetes/kubernetes
After=network.target
[Service]
ExecStart=/usr/local/bin/kube-proxy \
--config=/etc/kubernetes/kube-proxy.yaml \
--v=2
Restart=always
RestartSec=10s
[Install]
WantedBy=multi-user.target
EOF
cat > /etc/kubernetes/kube-proxy.yaml << EOF apiVersion: kubeproxy.config.k8s.io/v1alpha1 bindAddress: 0.0.0.0 clientConnection: acceptContentTypes: "" burst: 10 contentType: application/vnd.kubernetes.protobuf kubeconfig: /etc/kubernetes/kube-proxy.kubeconfig qps: 5 clusterCIDR: 172.16.0.0/12 configSyncPeriod: 15m0s conntrack: max: null maxPerCore: 32768 min: 131072 tcpCloseWaitTimeout: 1h0m0s tcpEstablishedTimeout: 24h0m0s enableProfiling: false healthzBindAddress: 0.0.0.0:10256 hostnameOverride: "" iptables: masqueradeAll: false masqueradeBit: 14 minSyncPeriod: 0s syncPeriod: 30s ipvs: masqueradeAll: true minSyncPeriod: 5s scheduler: "rr" syncPeriod: 30s kind: KubeProxyConfiguration metricsBindAddress: 127.0.0.1:10249 mode: "ipvs" nodePortAddresses: null oomScoreAdj: -999 portRange: "" udpIdleTimeout: 250ms
EOF
### 8.3.4启动kube-proxy
systemctl daemon-reload systemctl enable --now kube-proxy
9.安装Calico
==========
9.1以下步骤只在master01操作
-------------------
### 9.1.1更改calico网段
cd /root/Kubernetes/calico/ sed -i "s#POD_CIDR#172.16.0.0/12#g" calico.yaml grep "IPV4POOL_CIDR" calico.yaml -A 1 - name: CALICO_IPV4POOL_CIDR value: "172.16.0.0/12"
# 创建
kubectl apply -f calico.yaml
### 9.1.2查看容器状态
[root@k8s-master01 ~]# kubectl get pod -A NAMESPACE NAME READY STATUS RESTARTS AGE kube-system calico-kube-controllers-6f6595874c-nb95g 1/1 Running 0 2m54s kube-system calico-node-67dn4 1/1 Running 0 2m54s kube-system calico-node-79zxj 1/1 Running 0 2m54s kube-system calico-node-85bsf 1/1 Running 0 2m54s kube-system calico-node-8trsm 1/1 Running 0 2m54s kube-system calico-node-dvz72 1/1 Running 0 2m54s kube-system calico-node-qqzwx 1/1 Running 0 2m54s kube-system calico-node-rngzq 1/1 Running 0 2m55s kube-system calico-node-w8gqp 1/1 Running 0 2m54s kube-system calico-typha-6b6cf8cbdf-2b454 1/1 Running 0 2m55s [root@k8s-master01 ~]#
[root@k8s-master01 ~]# kubectl get node NAME STATUS ROLES AGE VERSION k8s-master01 Ready 14h v1.23.5 k8s-master02 Ready 14h v1.23.5 k8s-master03 Ready 14h v1.23.5 k8s-node01 Ready 14h v1.23.5 k8s-node02 Ready 14h v1.23.5 k8s-node03 Ready 14h v1.23.5 k8s-node04 Ready 14h v1.23.5 k8s-node05 Ready 14h v1.23.5 [root@k8s-master01 ~]#
10.安装CoreDNS
============
10.1以下步骤只在master01操作
--------------------
### 10.1.1修改文件
cd /root/Kubernetes/CoreDNS/ sed -i "s#KUBEDNS_SERVICE_IP#10.96.0.10#g" coredns.yaml
cat coredns.yaml | grep clusterIP: clusterIP: 10.96.0.10
### 10.1.2安装
kubectl create -f coredns.yaml serviceaccount/coredns created clusterrole.rbac.authorization.k8s.io/system:coredns created clusterrolebinding.rbac.authorization.k8s.io/system:coredns created configmap/coredns created deployment.apps/coredns created service/kube-dns created
11.安装Metrics Server
===================
11.1以下步骤只在master01操作
--------------------
### 11.1.1安装Metrics-server
在新版的Kubernetes中系统资源的采集均使用Metrics-server，可以通过Metrics采集节点和Pod的内存、磁盘、CPU和网络的使用率
安装metrics server cd /root/Kubernetes/metrics-server/
kubectl create -f .
serviceaccount/metrics-server created clusterrole.rbac.authorization.k8s.io/system:aggregated-metrics-reader created clusterrole.rbac.authorization.k8s.io/system:metrics-server created rolebinding.rbac.authorization.k8s.io/metrics-server-auth-reader created clusterrolebinding.rbac.authorization.k8s.io/metrics-server:system:auth-delegator created clusterrolebinding.rbac.authorization.k8s.io/system:metrics-server created service/metrics-server created deployment.apps/metrics-server created apiservice.apiregistration.k8s.io/v1beta1.metrics.k8s.io created
### 11.1.2稍等片刻查看状态
kubectl top node NAME CPU(cores) CPU% MEMORY(bytes) MEMORY% k8s-master01 154m 1% 1715Mi 21% k8s-master02 151m 1% 1274Mi 16% k8s-master03 523m 6% 1345Mi 17% k8s-node01 84m 1% 671Mi 8% k8s-node02 73m 0% 727Mi 9% k8s-node03 96m 1% 769Mi 9% k8s-node04 68m 0% 673Mi 8% k8s-node05 82m 1% 679Mi 8%
12.集群验证
=======
12.1部署pod资源
-----------
cat<<EOF | kubectl apply -f - apiVersion: v1 kind: Pod metadata: name: busybox namespace: default spec: containers: - name: busybox image: busybox:1.28 command: - sleep - "3600" imagePullPolicy: IfNotPresent restartPolicy: Always EOF
# 查看
kubectl get pod NAME READY STATUS RESTARTS AGE busybox 1/1 Running 0 17s
12.2用pod解析默认命名空间中的kubernetes
----------------------------
kubectl get svc NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE kubernetes ClusterIP 10.96.0.1 443/TCP 17h
kubectl exec busybox -n default -- nslookup kubernetes 3Server: 10.96.0.10 Address 1: 10.96.0.10 kube-dns.kube-system.svc.cluster.local
Name: kubernetes Address 1: 10.96.0.1 kubernetes.default.svc.cluster.local
12.3测试跨命名空间是否可以解析
-----------------
kubectl exec busybox -n default -- nslookup kube-dns.kube-system Server: 10.96.0.10 Address 1: 10.96.0.10 kube-dns.kube-system.svc.cluster.local
Name: kube-dns.kube-system Address 1: 10.96.0.10 kube-dns.kube-system.svc.cluster.local
12.4每个节点都必须要能访问Kubernetes的kubernetes svc 443和kube-dns的service 53
----------------------------------------------------------------
telnet 10.96.0.1 443 Trying 10.96.0.1... Connected to 10.96.0.1. Escape character is '^]'.
telnet 10.96.0.10 53 Trying 10.96.0.10... Connected to 10.96.0.10. Escape character is '^]'.
curl 10.96.0.10:53 curl: (52) Empty reply from server
12.5Pod和Pod之前要能通
----------------
kubectl get po -owide NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES busybox 1/1 Running 0 17m 172.27.14.193 k8s-node02
kubectl get po -n kube-system -owide NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES calico-kube-controllers-5dffd5886b-4blh6 1/1 Running 0 77m 172.25.244.193 k8s-master01 calico-node-fvbdq 1/1 Running 1 (75m ago) 77m 192.168.1.81 k8s-master01 calico-node-g8nqd 1/1 Running 0 77m 192.168.1.84 k8s-node01 calico-node-mdps8 1/1 Running 0 77m 192.168.1.85 k8s-node02 calico-node-nf4nt 1/1 Running 0 77m 192.168.1.83 k8s-master03 calico-node-sq2ml 1/1 Running 0 77m 192.168.1.82 k8s-master02 calico-typha-8445487f56-mg6p8 1/1 Running 0 77m 192.168.1.85 k8s-node02 calico-typha-8445487f56-pxbpj 1/1 Running 0 77m 192.168.1.81 k8s-master01 calico-typha-8445487f56-tnssl 1/1 Running 0 77m 192.168.1.84 k8s-node01 coredns-5db5696c7-67h79 1/1 Running 0 63m 172.25.92.65 k8s-master02 metrics-server-6bf7dcd649-5fhrw 1/1 Running 0 61m 172.18.195.1 k8s-master03
# 进入busybox ping其他节点上的pod
kubectl exec -ti busybox -- sh / # ping 192.168.1.84 PING 192.168.1.84 (192.168.1.84): 56 data bytes 64 bytes from 192.168.1.84: seq=0 ttl=63 time=0.358 ms 64 bytes from 192.168.1.84: seq=1 ttl=63 time=0.668 ms 64 bytes from 192.168.1.84: seq=2 ttl=63 time=0.637 ms 64 bytes from 192.168.1.84: seq=3 ttl=63 time=0.624 ms 64 bytes from 192.168.1.84: seq=4 ttl=63 time=0.907 ms
# 可以连通证明这个pod是可以跨命名空间和跨主机通信的
12.6创建三个副本，可以看到3个副本分布在不同的节点上（用完可以删了）
------------------------------------
cat > deployments.yaml << EOF apiVersion: apps/v1 kind: Deployment metadata: name: nginx-deployment labels: app: nginx spec: replicas: 3 selector: matchLabels: app: nginx template: metadata: labels: app: nginx spec: containers: - name: nginx image: nginx:1.14.2 ports: - containerPort: 80
EOF
kubectl apply -f deployments.yaml deployment.apps/nginx-deployment created
kubectl get pod NAME READY STATUS RESTARTS AGE busybox 1/1 Running 0 6m25s nginx-deployment-9456bbbf9-4bmvk 1/1 Running 0 8s nginx-deployment-9456bbbf9-9rcdk 1/1 Running 0 8s nginx-deployment-9456bbbf9-dqv8s 1/1 Running 0 8s
# 删除nginx
[root@k8s-master01 ~]# kubectl delete -f deployments.yaml
13.安装dashboard
==============
cd /root/Kubernetes/dashboard/
kubectl create -f . serviceaccount/admin-user created clusterrolebinding.rbac.authorization.k8s.io/admin-user created namespace/kubernetes-dashboard created serviceaccount/kubernetes-dashboard created service/kubernetes-dashboard created secret/kubernetes-dashboard-certs created secret/kubernetes-dashboard-csrf created secret/kubernetes-dashboard-key-holder created configmap/kubernetes-dashboard-settings created role.rbac.authorization.k8s.io/kubernetes-dashboard created clusterrole.rbac.authorization.k8s.io/kubernetes-dashboard created rolebinding.rbac.authorization.k8s.io/kubernetes-dashboard created clusterrolebinding.rbac.authorization.k8s.io/kubernetes-dashboard created deployment.apps/kubernetes-dashboard created service/dashboard-metrics-scraper created deployment.apps/dashboard-metrics-scraper created
13.1创建管理员用户
-----------
cat > admin.yaml << EOF apiVersion: v1 kind: ServiceAccount metadata: name: admin-user
namespace: kube-system
apiVersion: rbac.authorization.k8s.io/v1 kind: ClusterRoleBinding metadata: name: admin-user annotations: rbac.authorization.kubernetes.io/autoupdate: "true" roleRef: apiGroup: rbac.authorization.k8s.io kind: ClusterRole name: cluster-admin subjects:
- kind: ServiceAccount name: admin-user namespace: kube-system
EOF
13.2执行yaml文件
------------
kubectl apply -f admin.yaml -n kube-system
serviceaccount/admin-user created clusterrolebinding.rbac.authorization.k8s.io/admin-user created
13.3更改dashboard的svc为NodePort，如果已是请忽略
------------------------------------
kubectl edit svc kubernetes-dashboard -n kubernetes-dashboard type: NodePort
13.4查看端口号
---------
kubectl get svc kubernetes-dashboard -n kubernetes-dashboard NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE kubernetes-dashboard NodePort 10.98.201.22 443:31245/TCP 10m
13.5查看token
-----------
kubectl -n kube-system describe secret (kubectl -n kube-system get secret | grep admin-user | awk '{print 1}') Name: admin-user-token-5vfk4 Namespace: kube-system Labels: Annotations: kubernetes.io/service-account.name: admin-user kubernetes.io/service-account.uid: fc2535ae-8760-4037-9026-966f03ab9bf9
Type: kubernetes.io/service-account-token
Data
ca.crt: 1363 bytes namespace: 11 bytes token: eyJhbGciOiJSUzI1NiIsImtpZCI6InVOMnhMdHFTRWxweUlfUm93VmhMZTVXZW1FXzFrT01nQ0dTcE5uYjJlNWMifQ.eyJpc3MiOiJrdWJlcm5ldGVzL3NlcnZpY2VhY2NvdW50Iiwia3ViZXJuZXRlcy5pby9zZXJ2aWNlYWNjb3VudC9uYW1lc3BhY2UiOiJrdWJlLXN5c3RlbSIsImt1YmVybmV0ZXMuaW8vc2VydmljZWFjY291bnQvc2VjcmV0Lm5hbWUiOiJhZG1pbi11c2VyLXRva2VuLTV2Zms0Iiwia3ViZXJuZXRlcy5pby9zZXJ2aWNlYWNjb3VudC9zZXJ2aWNlLWFjY291bnQubmFtZSI6ImFkbWluLXVzZXIiLCJrdWJlcm5ldGVzLmlvL3NlcnZpY2VhY2NvdW50L3NlcnZpY2UtYWNjb3VudC51aWQiOiJmYzI1MzVhZS04NzYwLTQwMzctOTAyNi05NjZmMDNhYjliZjkiLCJzdWIiOiJzeXN0ZW06c2VydmljZWFjY291bnQ6a3ViZS1zeXN0ZW06YWRtaW4tdXNlciJ9.HSU1FeqY6pDVoXVIv4Lu27TDhCYHM-FzGsGybYL5QPJ5-P0b3tQqUH9i3AQlisiGPB--jCFT5CUeOeXneOyfV7XkC7frbn6VaQoh51n6ztkIvjUm8Q4xj_LQ2OSFfWlFUnaZsaYTdD-RCldwh63pX362T_FjgDknO4q1wtKZH5qR0mpL1dOjas50gnOSyBY0j-nSPrifhnNq3_GcDLE4LxjuzO1DfGNTEHZ6TojPJ_5ZElMolaYJsVejn2slfeUQEWdiD5AHFZlRd4exODCHyvUhRpzb9jO2rovN2LMqdE_vxBtNgXp19evQB9AgZyMMSmu1Ch2C2UAi4NxjKw8HNA
13.6登录dashboard
---------------
https://192.168.1.81:31245/
eyJhbGciOiJSUzI1NiIsImtpZCI6InYzV2dzNnQzV3hHb2FQWnYzdnlOSmpudmtpVmNjQW5VM3daRi12SFM4dEEifQ.eyJpc3MiOiJrdWJlcm5ldGVzL3NlcnZpY2VhY2NvdW50Iiwia3ViZXJuZXRlcy5pby9zZXJ2aWNlYWNjb3VudC9uYW1lc3BhY2UiOiJrdWJlLXN5c3RlbSIsImt1YmVybmV0ZXMuaW8vc2VydmljZWFjY291bnQvc2VjcmV0Lm5hbWUiOiJhZG1pbi11c2VyLXRva2VuLWs1NDVrIiwia3ViZXJuZXRlcy5pby9zZXJ2aWNlYWNjb3VudC9zZXJ2aWNlLWFjY291bnQubmFtZSI6ImFkbWluLXVzZXIiLCJrdWJlcm5ldGVzLmlvL3NlcnZpY2VhY2NvdW50L3NlcnZpY2UtYWNjb3VudC51aWQiOiJjMzA4MDcxYy00Y2Y1LTQ1ODMtODNhMi1lYWY3ODEyNTEyYjQiLCJzdWIiOiJzeXN0ZW06c2VydmljZWFjY291bnQ6a3ViZS1zeXN0ZW06YWRtaW4tdXNlciJ9.pshvZPi9ZJkXUWuWilcYs1wawTpzV-nMKesgF3d\_l7qyTPaK2N5ofzIThd0SjzU7BFNb4\_rOm1dw1Be5kLeHjY\_YW5lDnM5TAxVPXmZQ0HJ2pAQ0pjQqCHFnPD0bZFIYkeyz8pZx0Hmwcd3ZdC1yztr0ADpTAmMgI9NC2ZFIeoFFo4Ue9ZM\_ulhqJQjmgoAlI\_qbyjuKCNsWeEQBwM6HHHAsH1gOQIdVxqQ83OQZUuynDQRpqlHHFIndbK2zVRYFA3GgUnTu2-VRQ-DXBFRjvZR5qArnC1f383jmIjGT6VO7l04QJteG\_LFetRbXa-T4mcnbsd8XutSgO0INqwKpjw
14.ingress安装
============
14.1写入配置文件，并执行
--------------
[root@hello ~/yaml]# vim deploy.yaml [root@hello ~/yaml]# [root@hello ~/yaml]# [root@hello ~/yaml]# cat deploy.yaml apiVersion: v1 kind: Namespace metadata: name: ingress-nginx labels: app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx
# Source: ingress-nginx/templates/controller-serviceaccount.yaml apiVersion: v1 kind: ServiceAccount metadata: labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: controller name: ingress-nginx namespace: ingress-nginx automountServiceAccountToken: true
# Source: ingress-nginx/templates/controller-configmap.yaml apiVersion: v1 kind: ConfigMap metadata: labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: controller name: ingress-nginx-controller namespace: ingress-nginx data: allow-snippet-annotations: 'true'
# Source: ingress-nginx/templates/clusterrole.yaml apiVersion: rbac.authorization.k8s.io/v1 kind: ClusterRole metadata: labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm name: ingress-nginx rules: - apiGroups: - '' resources: - configmaps - endpoints - nodes - pods - secrets - namespaces verbs: - list - watch - apiGroups: - '' resources: - nodes verbs: - get - apiGroups: - '' resources: - services verbs: - get - list - watch - apiGroups: - networking.k8s.io resources: - ingresses verbs: - get - list - watch - apiGroups: - '' resources: - events verbs: - create - patch - apiGroups: - networking.k8s.io resources: - ingresses/status verbs: - update - apiGroups: - networking.k8s.io resources: - ingressclasses verbs: - get - list - watch
# Source: ingress-nginx/templates/clusterrolebinding.yaml apiVersion: rbac.authorization.k8s.io/v1 kind: ClusterRoleBinding metadata: labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm name: ingress-nginx roleRef: apiGroup: rbac.authorization.k8s.io kind: ClusterRole name: ingress-nginx subjects: - kind: ServiceAccount name: ingress-nginx namespace: ingress-nginx
# Source: ingress-nginx/templates/controller-role.yaml apiVersion: rbac.authorization.k8s.io/v1 kind: Role metadata: labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: controller name: ingress-nginx namespace: ingress-nginx rules: - apiGroups: - '' resources: - namespaces verbs: - get - apiGroups: - '' resources: - configmaps - pods - secrets - endpoints verbs: - get - list - watch - apiGroups: - '' resources: - services verbs: - get - list - watch - apiGroups: - networking.k8s.io resources: - ingresses verbs: - get - list - watch - apiGroups: - networking.k8s.io resources: - ingresses/status verbs: - update - apiGroups: - networking.k8s.io resources: - ingressclasses verbs: - get - list - watch - apiGroups: - '' resources: - configmaps resourceNames: - ingress-controller-leader verbs: - get - update - apiGroups: - '' resources: - configmaps verbs: - create - apiGroups: - '' resources: - events verbs: - create - patch
# Source: ingress-nginx/templates/controller-rolebinding.yaml apiVersion: rbac.authorization.k8s.io/v1 kind: RoleBinding metadata: labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: controller name: ingress-nginx namespace: ingress-nginx roleRef: apiGroup: rbac.authorization.k8s.io kind: Role name: ingress-nginx subjects: - kind: ServiceAccount name: ingress-nginx namespace: ingress-nginx
# Source: ingress-nginx/templates/controller-service-webhook.yaml apiVersion: v1 kind: Service metadata: labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: controller name: ingress-nginx-controller-admission namespace: ingress-nginx spec: type: ClusterIP ports: - name: https-webhook port: 443 targetPort: webhook appProtocol: https selector: app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/component: controller
# Source: ingress-nginx/templates/controller-service.yaml apiVersion: v1 kind: Service metadata: annotations: labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: controller name: ingress-nginx-controller namespace: ingress-nginx spec: type: NodePort externalTrafficPolicy: Local ipFamilyPolicy: SingleStack ipFamilies: - IPv4 ports: - name: http port: 80 protocol: TCP targetPort: http appProtocol: http - name: https port: 443 protocol: TCP targetPort: https appProtocol: https selector: app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/component: controller
# Source: ingress-nginx/templates/controller-deployment.yaml apiVersion: apps/v1 kind: Deployment metadata: labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: controller name: ingress-nginx-controller namespace: ingress-nginx spec: selector: matchLabels: app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/component: controller revisionHistoryLimit: 10 minReadySeconds: 0 template: metadata: labels: app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/component: controller spec: dnsPolicy: ClusterFirst containers: - name: controller image: registry.cn-hangzhou.aliyuncs.com/chenby/controller:v1.1.3 imagePullPolicy: IfNotPresent lifecycle: preStop: exec: command: - /wait-shutdown args: - /nginx-ingress-controller - --election-id=ingress-controller-leader - --controller-class=k8s.io/ingress-nginx - --configmap=$(POD_NAMESPACE)/ingress-nginx-controller - --validating-webhook=:8443 - --validating-webhook-certificate=/usr/local/certificates/cert - --validating-webhook-key=/usr/local/certificates/key securityContext: capabilities: drop: - ALL add: - NET_BIND_SERVICE runAsUser: 101 allowPrivilegeEscalation: true env: - name: POD_NAME valueFrom: fieldRef: fieldPath: metadata.name - name: POD_NAMESPACE valueFrom: fieldRef: fieldPath: metadata.namespace - name: LD_PRELOAD value: /usr/local/lib/libmimalloc.so livenessProbe: failureThreshold: 5 httpGet: path: /healthz port: 10254 scheme: HTTP initialDelaySeconds: 10 periodSeconds: 10 successThreshold: 1 timeoutSeconds: 1 readinessProbe: failureThreshold: 3 httpGet: path: /healthz port: 10254 scheme: HTTP initialDelaySeconds: 10 periodSeconds: 10 successThreshold: 1 timeoutSeconds: 1 ports: - name: http containerPort: 80 protocol: TCP - name: https containerPort: 443 protocol: TCP - name: webhook containerPort: 8443 protocol: TCP volumeMounts: - name: webhook-cert mountPath: /usr/local/certificates/ readOnly: true resources: requests: cpu: 100m memory: 90Mi nodeSelector: kubernetes.io/os: linux serviceAccountName: ingress-nginx terminationGracePeriodSeconds: 300 volumes: - name: webhook-cert secret: secretName: ingress-nginx-admission
# Source: ingress-nginx/templates/controller-ingressclass.yaml # We don't support namespaced ingressClass yet # So a ClusterRole and a ClusterRoleBinding is required apiVersion: networking.k8s.io/v1 kind: IngressClass metadata: labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: controller name: nginx namespace: ingress-nginx spec: controller: k8s.io/ingress-nginx
# Source: ingress-nginx/templates/admission-webhooks/validating-webhook.yaml # before changing this value, check the required kubernetes version # kubernetes.io/docs/refere… apiVersion: admissionregistration.k8s.io/v1 kind: ValidatingWebhookConfiguration metadata: labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: admission-webhook name: ingress-nginx-admission webhooks: - name: validate.nginx.ingress.kubernetes.io matchPolicy: Equivalent rules: - apiGroups: - networking.k8s.io apiVersions: - v1 operations: - CREATE - UPDATE resources: - ingresses failurePolicy: Fail sideEffects: None admissionReviewVersions: - v1 clientConfig: service: namespace: ingress-nginx name: ingress-nginx-controller-admission path: /networking/v1/ingresses
# Source: ingress-nginx/templates/admission-webhooks/job-patch/serviceaccount.yaml apiVersion: v1 kind: ServiceAccount metadata: name: ingress-nginx-admission namespace: ingress-nginx annotations: helm.sh/hook: pre-install,pre-upgrade,post-install,post-upgrade helm.sh/hook-delete-policy: before-hook-creation,hook-succeeded labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: admission-webhook
# Source: ingress-nginx/templates/admission-webhooks/job-patch/clusterrole.yaml apiVersion: rbac.authorization.k8s.io/v1 kind: ClusterRole metadata: name: ingress-nginx-admission annotations: helm.sh/hook: pre-install,pre-upgrade,post-install,post-upgrade helm.sh/hook-delete-policy: before-hook-creation,hook-succeeded labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: admission-webhook rules: - apiGroups: - admissionregistration.k8s.io resources: - validatingwebhookconfigurations verbs: - get - update
# Source: ingress-nginx/templates/admission-webhooks/job-patch/clusterrolebinding.yaml apiVersion: rbac.authorization.k8s.io/v1 kind: ClusterRoleBinding metadata: name: ingress-nginx-admission annotations: helm.sh/hook: pre-install,pre-upgrade,post-install,post-upgrade helm.sh/hook-delete-policy: before-hook-creation,hook-succeeded labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: admission-webhook roleRef: apiGroup: rbac.authorization.k8s.io kind: ClusterRole name: ingress-nginx-admission subjects: - kind: ServiceAccount name: ingress-nginx-admission namespace: ingress-nginx
# Source: ingress-nginx/templates/admission-webhooks/job-patch/role.yaml apiVersion: rbac.authorization.k8s.io/v1 kind: Role metadata: name: ingress-nginx-admission namespace: ingress-nginx annotations: helm.sh/hook: pre-install,pre-upgrade,post-install,post-upgrade helm.sh/hook-delete-policy: before-hook-creation,hook-succeeded labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: admission-webhook rules: - apiGroups: - '' resources: - secrets verbs: - get - create
# Source: ingress-nginx/templates/admission-webhooks/job-patch/rolebinding.yaml apiVersion: rbac.authorization.k8s.io/v1 kind: RoleBinding metadata: name: ingress-nginx-admission namespace: ingress-nginx annotations: helm.sh/hook: pre-install,pre-upgrade,post-install,post-upgrade helm.sh/hook-delete-policy: before-hook-creation,hook-succeeded labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: admission-webhook roleRef: apiGroup: rbac.authorization.k8s.io kind: Role name: ingress-nginx-admission subjects: - kind: ServiceAccount name: ingress-nginx-admission namespace: ingress-nginx
# Source: ingress-nginx/templates/admission-webhooks/job-patch/job-createSecret.yaml apiVersion: batch/v1 kind: Job metadata: name: ingress-nginx-admission-create namespace: ingress-nginx annotations: helm.sh/hook: pre-install,pre-upgrade helm.sh/hook-delete-policy: before-hook-creation,hook-succeeded labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: admission-webhook spec: template: metadata: name: ingress-nginx-admission-create labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: admission-webhook spec: containers: - name: create image: registry.cn-hangzhou.aliyuncs.com/chenby/kube-webhook-certgen:v1.1.1 imagePullPolicy: IfNotPresent args: - create - --host=ingress-nginx-controller-admission,ingress-nginx-controller-admission.(POD_NAMESPACE) - --secret-name=ingress-nginx-admission env: - name: POD_NAMESPACE valueFrom: fieldRef: fieldPath: metadata.namespace securityContext: allowPrivilegeEscalation: false restartPolicy: OnFailure serviceAccountName: ingress-nginx-admission nodeSelector: kubernetes.io/os: linux securityContext: runAsNonRoot: true runAsUser: 2000
# Source: ingress-nginx/templates/admission-webhooks/job-patch/job-patchWebhook.yaml apiVersion: batch/v1 kind: Job metadata: name: ingress-nginx-admission-patch namespace: ingress-nginx annotations: helm.sh/hook: post-install,post-upgrade helm.sh/hook-delete-policy: before-hook-creation,hook-succeeded labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: admission-webhook spec: template: metadata: name: ingress-nginx-admission-patch labels: helm.sh/chart: ingress-nginx-4.0.10 app.kubernetes.io/name: ingress-nginx app.kubernetes.io/instance: ingress-nginx app.kubernetes.io/version: 1.1.0 app.kubernetes.io/managed-by: Helm app.kubernetes.io/component: admission-webhook spec: containers: - name: patch image: registry.cn-hangzhou.aliyuncs.com/chenby/kube-webhook-certgen:v1.1.1 imagePullPolicy: IfNotPresent args: - patch - --webhook-name=ingress-nginx-admission - --namespace=$(POD_NAMESPACE) - --patch-mutating=false - --secret-name=ingress-nginx-admission - --patch-failure-policy=Fail env: - name: POD_NAMESPACE valueFrom: fieldRef: fieldPath: metadata.namespace securityContext: allowPrivilegeEscalation: false restartPolicy: OnFailure serviceAccountName: ingress-nginx-admission nodeSelector: kubernetes.io/os: linux securityContext: runAsNonRoot: true runAsUser: 2000 [root@hello ~/yaml]#
14.2启用后端，写入配置文件执行
-----------------
[root@hello ~/yaml]# vim backend.yaml [root@hello ~/yaml]# cat backend.yaml apiVersion: apps/v1 kind: Deployment metadata: name: default-http-backend labels: app.kubernetes.io/name: default-http-backend namespace: kube-system spec: replicas: 1 selector: matchLabels: app.kubernetes.io/name: default-http-backend template: metadata: labels: app.kubernetes.io/name: default-http-backend spec: terminationGracePeriodSeconds: 60 containers: - name: default-http-backend image: registry.cn-hangzhou.aliyuncs.com/chenby/defaultbackend-amd64:1.5 livenessProbe: httpGet: path: /healthz port: 8080 scheme: HTTP initialDelaySeconds: 30 timeoutSeconds: 5 ports: - containerPort: 8080 resources: limits: cpu: 10m memory: 20Mi requests: cpu: 10m memory: 20Mi
apiVersion: v1 kind: Service metadata: name: default-http-backend namespace: kube-system labels: app.kubernetes.io/name: default-http-backend spec: ports: - port: 80 targetPort: 8080 selector: app.kubernetes.io/name: default-http-backend [root@hello ~/yaml]#
14.3安装测试应用
----------
[root@hello ~/yaml]# vim ingress-demo-app.yaml [root@hello ~/yaml]# [root@hello ~/yaml]# cat ingress-demo-app.yaml apiVersion: apps/v1 kind: Deployment metadata: name: hello-server spec: replicas: 2 selector: matchLabels: app: hello-server template: metadata: labels: app: hello-server spec: containers: - name: hello-server image: registry.cn-hangzhou.aliyuncs.com/lfy_k8s_images/hello-server ports: - containerPort: 9000
apiVersion: apps/v1 kind: Deployment metadata: labels: app: nginx-demo name: nginx-demo spec: replicas: 2 selector: matchLabels: app: nginx-demo template: metadata: labels: app: nginx-demo spec: containers: - image: nginx name: nginx
apiVersion: v1 kind: Service metadata: labels: app: nginx-demo name: nginx-demo spec: selector: app: nginx-demo ports: - port: 8000 protocol: TCP targetPort: 80
apiVersion: v1 kind: Service metadata: labels: app: hello-server name: hello-server spec: selector: app: hello-server ports: - port: 8000 protocol: TCP targetPort: 9000
apiVersion: networking.k8s.io/v1 kind: Ingress metadata: name: ingress-host-bar spec: ingressClassName: nginx rules: - host: "hello.chenby.cn" http: paths: - pathType: Prefix path: "/" backend: service: name: hello-server port: number: 8000 - host: "demo.chenby.cn" http: paths: - pathType: Prefix path: "/nginx" backend: service: name: nginx-demo port: number: 8000 [root@hello ~/yaml]# [root@hello ~/yaml]# kubectl get ingress NAME CLASS HOSTS ADDRESS PORTS AGE ingress-demo-app app.demo.com 192.168.1.11 80 20m ingress-host-bar nginx hello.chenby.cn,demo.chenby.cn 192.168.1.11 80 2m17s [root@hello ~/yaml]#
14.4执行部署
--------
root@hello:# kubectl apply -f deploy.yaml
namespace/ingress-nginx created
serviceaccount/ingress-nginx created
configmap/ingress-nginx-controller created
clusterrole.rbac.authorization.k8s.io/ingress-nginx created
clusterrolebinding.rbac.authorization.k8s.io/ingress-nginx created
role.rbac.authorization.k8s.io/ingress-nginx created
rolebinding.rbac.authorization.k8s.io/ingress-nginx created
service/ingress-nginx-controller-admission created
service/ingress-nginx-controller created
deployment.apps/ingress-nginx-controller created
ingressclass.networking.k8s.io/nginx created
validatingwebhookconfiguration.admissionregistration.k8s.io/ingress-nginx-admission created
serviceaccount/ingress-nginx-admission created
clusterrole.rbac.authorization.k8s.io/ingress-nginx-admission created
clusterrolebinding.rbac.authorization.k8s.io/ingress-nginx-admission created
role.rbac.authorization.k8s.io/ingress-nginx-admission created
rolebinding.rbac.authorization.k8s.io/ingress-nginx-admission created
job.batch/ingress-nginx-admission-create created
job.batch/ingress-nginx-admission-patch created
root@hello:#
root@hello:# kubectl apply -f backend.yaml
deployment.apps/default-http-backend created
service/default-http-backend created
root@hello:#
root@hello:# kubectl apply -f ingress-demo-app.yaml
deployment.apps/hello-server created
deployment.apps/nginx-demo created
service/nginx-demo created
service/hello-server created
ingress.networking.k8s.io/ingress-host-bar created
root@hello:#
14.5过滤查看ingress端口
-----------------
[root@hello ~/yaml]# kubectl get svc -A | grep ingress default ingress-demo-app ClusterIP 10.68.231.41 80/TCP 51m ingress-nginx ingress-nginx-controller NodePort 10.68.93.71 80:32746/TCP,443:30538/TCP 32m ingress-nginx ingress-nginx-controller-admission ClusterIP 10.68.146.23 443/TCP 32m [root@hello ~/yaml]#
15.安装命令行自动补全功能
==============
yum install bash-completion -y source /usr/share/bash-completion/bash_completion source <(kubectl completion bash) echo "source <(kubectl completion bash)" >> ~/.bashrc
附录：
===
配置kube-controller-manager有效期100年（能不能生效的先配上再说）
vim /usr/lib/systemd/system/kube-controller-manager.service
# [Service]下找个地方加上
--cluster-signing-duration=876000h0m0s \
# 重启
systemctl daemon-reload systemctl restart kube-controller-manager
防止漏洞扫描
vim /etc/systemd/system/kubelet.service.d/10-kubelet.conf
[Service] Environment="KUBELET_KUBECONFIG_ARGS=--kubeconfig=/etc/kubernetes/kubelet.kubeconfig --bootstrap-kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig" Environment="KUBELET_SYSTEM_ARGS=--network-plugin=cni --cni-conf-dir=/etc/cni/net.d --cni-bin-dir=/opt/cni/bin" Environment="KUBELET_CONFIG_ARGS=--config=/etc/kubernetes/kubelet-conf.yml --pod-infra-container-image=registry.cn-hangzhou.aliyuncs.com/google_containers/pause:3.6" Environment="KUBELET_EXTRA_ARGS=--tls-cipher-suites=TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256,TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384 --image-pull-progress-deadline=30m" ExecStart= ExecStart=/usr/local/bin/kubelet KUBELET_CONFIG_ARGS KUBELET_EXTRA_ARGS
预留空间，按需分配
vim /etc/kubernetes/kubelet-conf.yml
rotateServerCertificates: true allowedUnsafeSysctls:
- "net.core*" - "net.ipv4.*" kubeReserved: cpu: "1" memory: 1Gi ephemeral-storage: 10Gi systemReserved: cpu: "1" memory: 1Gi ephemeral-storage: 10Gi
数据盘要与系统盘分开；etcd使用ssd磁盘
> https://www.oiox.cn/
>
> https://www.chenby.cn/
>
> https://cby-chen.github.io/
>
> https://blog.csdn.net/qq\_33921750
>
> https://my.oschina.net/u/3981543
>
> https://www.zhihu.com/people/chen-bu-yun-2
>
> https://segmentfault.com/u/hppyvyv6/articles
>
> https://juejin.cn/user/3315782802482007
>
> https://cloud.tencent.com/developer/column/93230
>
> https://www.jianshu.com/u/0f894314ae2c
>
> https://www.toutiao.com/c/user/token/MS4wLjABAAAAeqOrhjsoRZSj7iBJbjLJyMwYT5D0mLOgCoo4pEmpr4A/
>
> CSDN、GitHub、知乎、开源中国、思否、掘金、简书、腾讯云、今日头条、个人博客、全网可搜《小陈运维》
>
> 文章主要发布于微信公众号：《Linux运维交流社区》
> 本文使用 [文章同步助手](https://juejin.cn/post/6940875049587097631) 同步
