dipole Antenna/panel antenna/smart antenna/omni antenna 5dBi .Dipole Antenna 2.4GHz/5GHz of frequency DRA2G5G5D001 1. Feature
* External type dipole antenna
* 2.4GHz/5GHz of frequency
* SMA Pluginterface
* Plastic rod of black
* RoHS compliance
2. Application
* 2.4GHz/5GHz Wireless Communication
* WLAN device, WLAN Router, e.g., AP, PIC Wireless Card
3. Description
This miniature antenna is designed for 2.4GHz/5GHz applications and can be easily built-in portable devices with MHF processes. It has excellent stability and sensitivity to consistently provide high signal reception efficiency.
- | ** General Data** | | ----------------- |
-
\
-
Product Name [5dBi]"5dBi") Dual band Dipole Antenna Part No. DRA2G5G5D001 Frequency 2.4 2.5GHz&5.155.85GHzV.S.W.R <2.0 Gain (dBi) 2.4GHz .0dBi 5GHz 5.0dBi Polarization Linear,Vertical Storage Temp -10°C 〜+70°C Operating Temperature -10°C 〜+60°C Impedance with Matching 50Q Weight 21.5 g Antenna Type SMAPLUG Dimension L195X φ 13 (mm)
