配置sofia profile ，这个配置修改后不能实时生效的，需要重启FreeSWITCH,或者通过执行命令相关命令才可以生效。
- 添加删除sofia profile 需要重启fs，或者执行reload mod_sofia,才生效。
- 添加了网关需要执行命令 sofia profile [profilename] rescan
- 删除了网关需要执行命令sofia profile [profilename] killgw [gatewayname]
- 修改了网关配置需要先执行删除命令sofia profile [profilename] killgw [gatewayname]，然后执行 sofia profile [profilename] rescan。
- 取消网关注册 sofia profile [profilename] unregister [gatewayname]
- 重新注册网关 sofia profile [profilename] register [gatewayname]
通过往redis 通道 config@domain 发送通知，也可以执行命令
| ``` { "type": "cli", "cmd": "命令", "arg": "参数, "response": "执行结果写回的redis通道，如果不需要执行接口，可以设置" }
| ---------------------------------------------------------------------------------------------------- |
## [](http://www.ddrj.com/callcenter/sip.html#%E9%85%8D%E7%BD%AE "配置")配置
cti_sip_profile@domain [哈希表]
1. key sofia profile 名字
1. value sofia profole 配置内容
| ```
{ "domains": { "alias": "false", "parse": "false", "name": "" }, "settings": { "user-agent-string": "ddtswitch", "debug": "0", "sip-trace": "no", "sip-capture": "no", "dialplan": "XML", "sip-port": "46729", "sip-ip": "$${local_ip_v4}", "rtp-ip": "$${local_ip_v4}", "ext-sip-ip": "auto-nat", "ext-rtp-ip": "auto-nat", "inbound-codec-prefs": "$${global_codec_prefs}", "outbound-codec-prefs": "$${outbound_codec_prefs}", "inbound-codec-negotiation": "generous", "inbound-late-negotiation": "true", "apply-nat-acl": "nat.auto", "aggressive-nat-detection": "true", "NDLB-force-rport": "true", "rfc2833-pt": "101", "dtmf-duration": "2000", "rtp-timer-name": "soft", "rtp-timeout-sec": "30", "rtp-hold-timeout-sec": "180", "challenge-realm": "auto_from", "auth-calls": "true", "auth-calls-acl-only": "false", "log-auth-failures": "true", "auth-all-packets": "false", "disable-register": "false", "inbound-reg-force-matching-username": "true", "force-register-domain": "$${domain}", "force-register-db-domain": "$${domain}", "force-subscription-domain": "$${domain}", "manage-presence": "false", "hold-music": "$${hold_music}", "local-network-acl": "localnet.auto", "nonce-ttl": "60", "username": "ddt", "inbound-zrtp-passthru": "true", "forward-unsolicited-mwi-notify": "false", "context": "test", "outbound-use-uuid-as-callid": "true", "inbound-use-callid-as-uuid": "true" }, "gateway": "" }
``` |
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
这个参数太多了，上面也只列出了部分，就不一一列出，只调几个重要的介绍
- domains 设置别名和是否解析分机中配置的网关， cti没使用这些特性，直接不配置这个
- gateway 配置这个sofia 关联的网关，多个网关用逗好隔开
- settings sofia profile的配置
- sip-ip 本机SIP IP
- rtp-ip 本机RTP IP
- ext-sip-ip 如果通过路由器映射外网可以访问，配置路由器的公网IP
- ext-rtp-ip 如果通过路由器映射外网可以访问，配置路由器的公网IP
- sip-port Sip端口
- inbound-codec-prefs 呼入的声音编码 $${global_codec_prefs} 就是使用vars.xml里面global_codec_prefs 这个的配置
- outbound-codec-prefs 呼出的的声音编码
- context 呼入时dialplan的context.
- outbound-use-uuid-as-callid 呼出时，使用通道的UUID做SIP的callid。
- inbound-use-callid-as-uuid 呼入时，使用sip的callid做通道的UUID。为了防止通道UUID不是唯一的，可以设置为false。
- auth-calls 呼入需要认证
- disable-register 禁止注册
- log-auth-failures 认证失败信息记录到日志
- auth-calls-acl-only 只有通过ACL认证的，才可以呼入，分机不能呼入。
建议参考ccadmin程序使用的配置\
ccsadmin external的配置 auth-calls：true,disable-register:false,auth-calls-acl-only:false\
ccsadmin internal的配置 auth-calls：false,disable-register:true,auth-calls-acl-only:false
