1 效果2 关键内容2.1 显示时间2.2 隐藏标题栏2.3 隐藏标题栏可拖动3 全部代码
1 效果
今天闲来无事，来搞搞最近比较火的 华为太空人仪表盘 效果如下：
2 关键内容
2.1 显示时间
onSceneGraphInitialized:
{
mTimer.start();
}
property string peopleurl : "qrc:/people/Image/human ("
property int peopleindex : 2;
Timer
{
id:mTimer
repeat: true
interval: 25
onTriggered:
{
peopleindex = peopleindex + 1
if(peopleindex === 61)
{
peopleindex = 2
}
mPeople.source = peopleurl + peopleindex + ").jpg"
mTime.text = Qt.formatDateTime(new Date(),"hh:mm")
mTimess.text = Qt.formatDateTime(new Date(),"ss")
}
}
Text {
id: mTime
y:120
x:90
text: Qt.formatDateTime(new Date(),"hh:mm")
font.family: "DigifaceWide"
font.letterSpacing: -5
font.weight: Font.Light
font.pointSize: 60
}
Text {
id: mTimess
anchors.bottom: mTime.bottom
anchors.bottomMargin: 10
anchors.left: mTime.right
anchors.leftMargin: 5
text: Qt.formatDateTime(new Date(),"ss")
font.family: "DigifaceWide"
font.letterSpacing: -2
font.weight: Font.Light
font.pointSize: 26
}
Text {
id: mYear
x:340
y:285
text: Qt.formatDateTime(new Date(),"dddd\r\nMM-dd")
font.family: "黑体"
font.weight: Font.Light
font.pointSize: 15
}
显示时间主要是定时器，每25毫秒获取一次。
2.2 隐藏标题栏
flags: Qt.FramelessWindowHint | Qt.Window隐藏标题栏就这一句代码，注意后面的Qt.Window，这个是让程序在隐藏标题栏后依附任务栏的，不需要的可以去掉。
2.3 隐藏标题栏可拖动
MouseArea
{
anchors.fill: parent
property int m_x : 0;
property int m_y : 0;
onPressed:
{
m_x = mouse.x;
m_y = mouse.y;
}
onPositionChanged:
{
/*
实现窗口拖船，移动
*/
root.x = root.x + mouse.x - m_x
root.y = root.y + mouse.y - m_y
}
}
这个没啥可以说的，比Qwidget下简单多了
3 全部代码
import QtQuick 2.12
import QtQuick.Window 2.12
Window {
id:root
visible: true
width: 480
height: 480
flags: Qt.FramelessWindowHint | Qt.Window
color: "transparent"
Image {
id: back
source: "qrc:/image/Image/back.png"
}
Image {
id: mPeople
x:186
y:213
width: 108
height: 120
source: "qrc:/people/Image/human (2).jpg"
}
onSceneGraphInitialized:
{
mTimer.start();
}
property string peopleurl : "qrc:/people/Image/human ("
property int peopleindex : 2;
Timer
{
id:mTimer
repeat: true
interval: 25
onTriggered:
{
peopleindex = peopleindex + 1
if(peopleindex === 61)
{
peopleindex = 2
}
mPeople.source = peopleurl + peopleindex + ").jpg"
mTime.text = Qt.formatDateTime(new Date(),"hh:mm")
mTimess.text = Qt.formatDateTime(new Date(),"ss")
}
}
Text {
id: mTime
y:120
x:90
text: Qt.formatDateTime(new Date(),"hh:mm")
font.family: "DigifaceWide"
font.letterSpacing: -5
font.weight: Font.Light
font.pointSize: 60
}
Text {
id: mTimess
anchors.bottom: mTime.bottom
anchors.bottomMargin: 10
anchors.left: mTime.right
anchors.leftMargin: 5
text: Qt.formatDateTime(new Date(),"ss")
font.family: "DigifaceWide"
font.letterSpacing: -2
font.weight: Font.Light
font.pointSize: 26
}
Text {
id: mYear
x:340
y:285
text: Qt.formatDateTime(new Date(),"dddd\r\nMM-dd")
font.family: "黑体"
font.weight: Font.Light
font.pointSize: 15
}
Text {
id: mHeart
x:118
y:326
text:"93"
font.family: "黑体"
font.weight: Font.Light
font.pointSize: 18
}
Text {
id: mHeartHL
x:75
y:300
text:"66-123"
font.family: "黑体"
font.weight: Font.Light
font.pointSize: 14
}
Text {
id: mHFoot
x:340
y:328
text:"8869"
font.family: "黑体"
font.weight: Font.Light
font.pointSize: 18
}
Text {
id: mSleep
x:180
y:368
font.bold: true
font.wordSpacing: 10
font.letterSpacing: 1
text:"8h36m"
font.family: "黑体"
font.weight: Font.Light
font.pointSize: 18
}
Text {
id: mDistance
x:200
y:410
font.bold: true
font.wordSpacing: 10
font.letterSpacing: 1
text:"9.36Km"
font.family: "黑体"
font.weight: Font.Light
font.pointSize: 18
}
Text {
id: mAir
x:215
y:50
font.bold: true
text:"空气优质"
font.family: "黑体"
font.weight: Font.Light
font.pointSize: 12
}
Text {
id: mWeather
anchors.left: mAir.left
anchors.top: mAir.bottom
anchors.topMargin: 5
font.bold: true
text:"晴天"
font.family: "黑体"
font.weight: Font.Light
font.pointSize: 12
}
Image {
id: mWeatherpic
x:318
y:75
width: 40
height: 40
source: "qrc:/image/Image/other2.png"
}
Text {
id: mTemperatureH
x:260
y:72
font.bold: true
text:"26℃"
font.family: "黑体"
font.weight: Font.Light
font.pointSize: 12
}
Text {
id: mTemperatureL
x:260
y:95
font.bold: true
text:"17℃"
font.family: "黑体"
font.weight: Font.Light
font.pointSize: 12
}
Text {
id: mTemperatureCurrent
anchors.left: mWeather.left
anchors.bottom: mTemperatureL.bottom
font.bold: true
text:"22℃"
font.family: "黑体"
font.weight: Font.Light
font.pointSize: 12
}
Text {
id: mRocket
x:120
y:85
font.bold: true
text:"88%"
font.family: "黑体"
font.weight: Font.Normal
font.pointSize: 20
}
MouseArea
{
anchors.fill: parent
property int m_x : 0;
property int m_y : 0;
onPressed:
{
m_x = mouse.x;
m_y = mouse.y;
}
onPositionChanged:
{
/*
实现窗口拖船，移动
*/
root.x = root.x + mouse.x - m_x
root.y = root.y + mouse.y - m_y
}
}
}
