可以使用以下3种方式构建模型：

1. 继承nn.Module基类构建自定义模型。
2. 使用nn.Sequential按层顺序构建模型。
3. 继承nn.Module基类构建模型并辅助应用模型容器进行封装(nn.Sequential,nn.ModuleList,nn.ModuleDict)。

其中 第1种方式最为常见，第2种方式最简单，第3种方式最为灵活也较为复杂。

一、继承nn.Module基类构建自定义模型

模型中的用到的层一般在init函数中定义，然后在forward方法中定义模型的正向传播逻辑。

代码：

class Net(nn.Module):


    def __init__(self):
        super(Net,self).__init__()
        self.conv1 = nn.Conv2d(in_channels=3,out_channels=32,kernel_size=3)
        self.pool1 = nn.MaxPool2d(kernel_size=2,stride=2)
        self.conv2 = nn.Conv2d(in_channels=32,out_channels=64,kernel_size=5)
        self.pool2 = nn.MaxPool2d(kernel_size=2,stride=2)
        self.dropout = nn.Dropout2d(p = 0.1)
        self.adaptive_pool = nn.AdaptiveAvgPool2d((1,1))
        self.flatten = nn.Flatten()
        self.linear1 = nn.Linear(64,32)
        self.relu = nn.ReLU()
        self.linear2 = nn.Linear(32,1)
        self.sigmoid = nn.Sigmoid()

    def forward(self,x):

        x = self.conv1(x)
        x = self.pool1(x)
        x = self.conv2(x)
        x = self.pool2(x)
        x = self.dropout(x)
        x = self.adaptive_pool(x)
        x = self.flatten(x)
        x = self.linear1(x)
        x = self.relu(x)
        x = self.linear2(x)
        y = self.sigmoid(x)
        return y

net = Net()
#net = torchkeras.Model(net)
print(net)

输出：

Net(
  (conv1): Conv2d(3, 32, kernel_size=(3, 3), stride=(1, 1))
  (pool1): MaxPool2d(kernel_size=2, stride=2, padding=0, dilation=1, ceil_mode=False)
  (conv2): Conv2d(32, 64, kernel_size=(5, 5), stride=(1, 1))
  (pool2): MaxPool2d(kernel_size=2, stride=2, padding=0, dilation=1, ceil_mode=False)
  (dropout): Dropout2d(p=0.1, inplace=False)
  (adaptive_pool): AdaptiveAvgPool2d(output_size=(1, 1))
  (flatten): Flatten()
  (linear1): Linear(in_features=64, out_features=32, bias=True)
  (relu): ReLU()
  (linear2): Linear(in_features=32, out_features=1, bias=True)
  (sigmoid): Sigmoid()
)

使用summary查看模型：

summary(net,input_shape=(3,32,32))

二、使用nn.Sequential按层顺序构建模型

nn.Sequential按层顺序构建模型

nn.Sequetial是nn.Module的容器，用于按顺序包装一组网络层，有以下两个特性。

• 顺序性：各网络层之间严格按照顺序构建，我们在构建网络时，一定要注意前后网络层之间输入和输出数据之间的形状是否匹配
• 自带forward()函数：在nn.Sequetial的forward()函数里通过 for 循环依次读取每个网络层，执行前向传播运算。这使得我们我们构建的模型更加简洁

代码

1，利用add_module方法：可以指定各层名称

net = nn.Sequential()
net.add_module('conv1',nn.Conv2d(in_channels=3,out_channels = 32,kernel_size = 3))
net.add_module('pool1',nn.MaxPool2d(kernel_size = 2,stride = 2))
net.add_module('conv2',nn.Conv2d(in_channels = 32,out_channels= 64,kernel_size =5))
net.add_module('pool2',nn.MaxPool2d(kernel_size = 2,stride=2))
net.add_module('dropout',nn.Dropout2d(p = 0.1))
net.add_module('adaptive_pool',nn.AdaptiveAvgPool2d((1,1)))
net.add_module('flatten',nn.Flatten())
net.add_module('linear1',nn.Linear(64,32))
net.add_module('relu',nn.ReLU())
net.add_module('linear2',nn.Linear(32,1))
net.add_module('sigmod',nn.Sigmoid())

print(net)

2，利用变长参数：不能指定各层名称

net = nn.Sequential(
    nn.Conv2d(in_channels=3,out_channels=32,kernel_size = 3),
    nn.MaxPool2d(kernel_size = 2,stride = 2),
    nn.Conv2d(in_channels=32,out_channels=64,kernel_size = 5),
    nn.MaxPool2d(kernel_size = 2,stride = 2),
    nn.Dropout2d(p = 0.1),
    nn.AdaptiveMaxPool2d((1,1)),
    nn.Flatten(),
    nn.Linear(64,32),
    nn.ReLU(),
    nn.Linear(32,1),
    nn.Sigmoid()
)

print(net)

3，利用OrderedDict：可以指定各层名称

from collections import OrderedDict

net = nn.Sequential(OrderedDict(
          [("conv1",nn.Conv2d(in_channels=3,out_channels=32,kernel_size = 3)),
            ("pool1",nn.MaxPool2d(kernel_size = 2,stride = 2)),
            ("conv2",nn.Conv2d(in_channels=32,out_channels=64,kernel_size = 5)),
            ("pool2",nn.MaxPool2d(kernel_size = 2,stride = 2)),
            ("dropout",nn.Dropout2d(p = 0.1)),
            ("adaptive_pool",nn.AdaptiveMaxPool2d((1,1))),
            ("flatten",nn.Flatten()),
            ("linear1",nn.Linear(64,32)),
            ("relu",nn.ReLU()),
            ("linear2",nn.Linear(32,1)),
            ("sigmoid",nn.Sigmoid())
          ])
        )
print(net)

三、继承nn.Module基类构建模型并辅助应用模型容器进行封装

当模型的结构比较复杂时，我们可以应用模型容器(nn.Sequential,nn.ModuleList,nn.ModuleDict)对模型的部分结构进行封装。

这样做会让模型整体更加有层次感，有时候也能减少代码量。

1，nn.Sequential作为模型容器

class Net(nn.Module):

    def __init__(self):
        super(Net,self).__init__()
        self.conv = nn.Sequential(
            nn.Conv2d(in_channels = 3,out_channels = 32,kernel_size = 3),
            nn.MaxPool2d(kernel_size = 2,stride = 2),
            nn.Conv2d(in_channels=  32,out_channels = 64,kernel_size = 5),
            nn.MaxPool2d(kernel_size=2,stride=2),
            nn.Dropout2d(p = 0.1),
            nn.AdaptiveAvgPool2d((1,1))
        )
        self.dense = nn.Sequential(
            nn.Flatten(),
            nn.Linear(64,32),
            nn.ReLU(),
            nn.Linear(32,1),
            nn.Sigmoid()
        )

    def forward(self,x):
        x = self.conv(x)
        y = self.dense(x)
        return y

net1 = Net()
print(net1)

##############################################
# 或者使用下面的例子
class CnnModel(nn.Module):
    def __init__(self):
        super().__init__()
        self.layers = nn.ModuleList([
            nn.Conv2d(in_channels=1,out_channels=32,kernel_size = 3),
            nn.MaxPool2d(kernel_size = 2,stride = 2),
            nn.Conv2d(in_channels=32,out_channels=64,kernel_size = 5),
            nn.MaxPool2d(kernel_size = 2,stride = 2),
            nn.Dropout2d(p = 0.1),
            nn.AdaptiveMaxPool2d((1,1)),
            nn.Flatten(),
            nn.Linear(64,32),
            nn.ReLU(),
            nn.Linear(32,10)]
        )
    def forward(self,x):
        **for layer in self.layers:
            x = layer(x)**
        return x
model = torchkeras.Model(CnnModel())    # 封装成了keras里面模型的格式
print(model)

model.summary(input_shape=(1, 32, 32))

2，nn.ModuleList作为模型容器

注意下面中的ModuleList不能用Python中的列表list代替。

class Net(nn.Module):

    def __init__(self):
        super(Net, self).__init__()
        self.layers = nn.ModuleList([
            nn.Conv2d(in_channels=3,out_channels=32,kernel_size = 3),
            nn.MaxPool2d(kernel_size = 2,stride = 2),
            nn.Conv2d(in_channels=32,out_channels=64,kernel_size = 5),
            nn.MaxPool2d(kernel_size = 2,stride = 2),
            nn.Dropout2d(p = 0.1),
            nn.AdaptiveMaxPool2d((1,1)),
            nn.Flatten(),
            nn.Linear(64,32),
            nn.ReLU(),
            nn.Linear(32,1),
            nn.Sigmoid()]
        )
    def forward(self,x):
        for layer in self.layers:
            x = layer(x)
        return x
net = Net()
print(net)

3，nn.ModuleDict作为模型容器

注意下面中的ModuleDict不能用Python中的字典dict代替。

class Net(nn.Module):

    def __init__(self):
        super(Net, self).__init__()
        self.layers_dict = nn.ModuleDict({"conv1":nn.Conv2d(in_channels=3,out_channels=32,kernel_size = 3),
               "pool": nn.MaxPool2d(kernel_size = 2,stride = 2),
               "conv2":nn.Conv2d(in_channels=32,out_channels=64,kernel_size = 5),
               "dropout": nn.Dropout2d(p = 0.1),
               "adaptive":nn.AdaptiveMaxPool2d((1,1)),
               "flatten": nn.Flatten(),
               "linear1": nn.Linear(64,32),
               "relu":nn.ReLU(),
               "linear2": nn.Linear(32,1),
               "sigmoid": nn.Sigmoid()
              })
    def forward(self,x):
        layers = ["conv1","pool","conv2","pool","dropout","adaptive",
                  "flatten","linear1","relu","linear2","sigmoid"]
        for layer in layers:
            x = self.layers_dict[layer](x)
        return x
net = Net()
print(net)

容器总结

• nn.Sequetial：顺序性，各网络层之间严格按照顺序执行，常用于 block 构建，在前向传播时的代码调用变得简洁
• nn.ModuleList：迭代行，常用于大量重复网络构建，通过 for 循环实现重复构建
• nn.ModuleDict：索引性，常用于可选择的网络层

参考

• 模型构建 love2017.asia/2021/08/11/…
• zhuanlan.zhihu.com/p/158205868
• 模型构建的三种方式 blog.csdn.net/Zzz_zhongqi…
