【手写数字识别】基于贝叶斯分类器实现手写数字识别matlab源码含GUI模型参考这里。gui_State = struc

一、简介

模型参考这里。

二、源代码

function varargout = Classification(varargin)
% Begin initialization code - DO NOT EDIT
gui_Singleton = 1;
gui_State = struct('gui_Name',       mfilename, ...
                   'gui_Singleton',  gui_Singleton, ...
                   'gui_OpeningFcn', @Classification_OpeningFcn, ...
                   'gui_OutputFcn',  @Classification_OutputFcn, ...
                   'gui_LayoutFcn',  [] , ...
                   'gui_Callback',   []);
if nargin && ischar(varargin{1})
    gui_State.gui_Callback = str2func(varargin{1});
end

if nargout
    [varargout{1:nargout}] = gui_mainfcn(gui_State, varargin{:});
else
    gui_mainfcn(gui_State, varargin{:});
end
% End initialization code - DO NOT EDIT


% --- Executes just before Classification is made visible.
function Classification_OpeningFcn(hObject, eventdata, handles, varargin)
handles.output = hObject;
% Update handles structure
guidata(hObject, handles);

%--------------------------------------------------------------------------
global flag
flag=0;

if exist('template.mat','file')~=0
    load template pattern;
else
    pattern(1,1).num=0;
    pattern(1,1).feature=[];

    pattern(1,2).num=0;
    pattern(1,2).feature=[];

    pattern(1,3).num=0;
    pattern(1,3).feature=[];

    pattern(1,4).num=0;
    pattern(1,4).feature=[];

    pattern(1,5).num=0;
    pattern(1,5).feature=[];

    pattern(1,6).num=0;
    pattern(1,6).feature=[];

    pattern(1,7).num=0;
    pattern(1,7).feature=[];

    pattern(1,8).num=0;
    pattern(1,8).feature=[];

    pattern(1,9).num=0;
    pattern(1,9).feature=[];

    pattern(1,10).num=0;
    pattern(1,10).feature=[];
    save template pattern;
end
%------------------------------------------------------------------------

% --- Outputs from this function are returned to the command line.
function varargout = Classification_OutputFcn(hObject, eventdata, handles)
varargout{1} = handles.output;


%--------------------------------------------------------------------------
%手写板实现---按下左键开始画直线
function figure1_WindowButtonDownFcn(hObject, eventdata, handles)
%clc

global flag
global pos0  %
global x0 y0

pos0=get(handles.WritingAxes,'currentpoint');
x0=pos0(1,1);
y0=pos0(1,2);
if (pos0(1,1)>=0&pos0(1,1)<=100) && (pos0(1,2)>=0&pos0(1,2)<=100)
    flag=1;
end
%--------------------------------------------------------------------------



%--------------------------------------------------------------------------
function figure1_WindowButtonMotionFcn(hObject, eventdata, handles)
%clc
%手写板实现---移动鼠标进行画线实现的程序

global flag
global pos0
global x0 y0

 pos=get(handles.WritingAxes,'currentpoint');
 x=pos(1,1);
 y=pos(1,2);
 if flag && (pos(1,1)>=0&pos(1,1)<100) && (pos(1,2)>=0&pos(1,2)<100)
      line(x,y, 'marker', '.','markerSize',18, 'LineStyle','-','LineWidth',2,'Color','Black');
      if x>x0
          stepX=0.1;
      else
          stepX=-0.1;
      end
      if y>y0
          stepY=0.1;
      else
          stepY=-0.1;
      end
      X=x0:stepX:x;

      if abs(x-x0)<0.01
          Y=y0:stepY:y;
      else
         Y=(y-y0)*(X-x0)/(x-x0)+y0;
      end
      line(X ,Y, 'marker', '.','markerSize',18, 'LineStyle','-','LineWidth',2,'Color','Black');
      x0=x;
      y0=y;
      pos0=pos;
 else
      flag=0;
 end
 %-------------------------------------------------------------------------


 %-------------------------------------------------------------------------
function figure1_WindowButtonUpFcn(hObject, eventdata, handles)
%clc
%手写板实现程序---释放鼠标左键结束画线的程序
global flag
flag=0;

%global data
data=[];
Img=getframe(handles.WritingAxes);
imwrite(Img.cdata,'当前手写数字.bmp','bmp');
I=imread('当前手写数字.bmp');
I=rgb2gray(I);
I=im2bw(I);
imwrite(I,'当前手写数字.bmp','bmp');
I=imread('当前手写数字.bmp');
data=GetFeature(I);
%--------------------------------------------------------------------------
function y=BayesLeastRisk(data)
clc;
load template pattern;

%将数字特征转化为0、1两个数值表示
for i=1:10
    for j=1:25
        for k=1:pattern(1,i).num
            if pattern(1,i).feature(j,k)>0.1
               pattern(1,i).feature(j,k)=1;
            else
                pattern(1,i).feature(j,k)=0;
            end
        end
    end
end

[pc_template,pc_data]=pcapro(data); %主成分分析
temp=0;
for i=1:10
    pattern(1,i).feature=pc_template(:,temp+1:temp+pattern(1,i).num);
    temp=temp+pattern(1,i).num;
end


%求协方差矩阵、协方差矩阵的逆矩阵、协方差矩阵的行列式
s_cov=[];
s_inv=[];
s_det=[];

for i=1:10
    s_cov(i).data=cov(pattern(1,i).feature');
    s_inv(i).data=inv(s_cov(i).data);
    s_det(i)=det(s_cov(i).data);
end
