NIO和Netty全文

Channel

  • 通道，通过它读取和写入数据
  • 双向，全双工，同时用于读写，可以异步读写

流，单向

  • 多种数据源，文件、网络socket
  • 用于在字节缓冲区和通道另一侧的实体之间有效地传输数据
  • 流程：写入，从通道中读取数据到缓冲区；读取，从缓冲区写入数据到通道
  • 重要的实现
  1. FileChannel从文件中
  2. DataGramChannel 通过UDP
  3. SocketChannel 通过TCP
  4. ServerSocketChannel 监听新进来TCP连接，类似服务器，当接收到一个链接时，创建一个SocketChannel

FileChannel

读取文件进buffer

//访问文件的部分内容，而不是把文件从头读到尾
//可以直接跳转到文件的任意地方来读写数据
RandomAccessFile af = new RandomAccessFile("/Users/mzx/Desktop/java/nio/test1.txt","rw");
//得到fc
FileChannel fc = af.getChannel();
ByteBuffer buf = ByteBuffer.allocate(1024);
//往buf里面读，文件中的字节长度
int readByte = fc.read(buf);
while (readByte != -1) {
    System.out.println("从文件里读取了 - " + readByte);
    //从buffer中再获取数据
    buf.flip();
    while(buf.hasRemaining()) {
        System.out.println("buf里面有 - " + (char)buf.get());
    }
    buf.clear();
    readByte = fc.read(buf);
}
//close...
  • 另一个案例
File file = new File("/Users/mzx/Desktop/java/netty/test.txt");
FileInputStream fis = new FileInputStream(file);
FileChannel fc = fis.getChannel();
ByteBuffer bb = ByteBuffer.allocate((int) file.length());
int read = fc.read(bb);
while (read != -1) {
    bb.flip();
    System.out.println(new String(bb.array(), 0, read));
    read = fc.read(bb);
}
fc.close();
fis.close();

获取fc

  • FileInputStream
FileInputStream fis = new FileInputStream("/Users/mzx/Desktop/java/nio/test1.txt");
FileChannel channel = fis.getChannel();
  • RandomAccessFile
RandomAccessFile af = new RandomAccessFile("/Users/mzx/Desktop/java/nio/test1.txt","rw");
//得到fc
FileChannel fc = af.getChannel();

往文件中写数据

RandomAccessFile rf = new RandomAccessFile("/Users/mzx/Desktop/java/nio/test1.txt", "rw");
FileChannel fc = rf.getChannel();
ByteBuffer bf = ByteBuffer.allocate(1024);
String s = "test33333333";
bf.clear();
//写入，将内容放入buffer中
bf.put(s.getBytes());
//读写转换
bf.flip();
//从buffer中读取数据，写入到文件中
while(bf.hasRemaining()) {
    //要循环写入，直到写完
    fc.write(bf);
}
fc.close();
rf.close();


拷贝文件

//项目目录下
FileInputStream fis = new FileInputStream("test.txt");
FileChannel fic = fis.getChannel();
FileOutputStream fos = new FileOutputStream("test2.txt");
FileChannel foc = fos.getChannel();
ByteBuffer bb = ByteBuffer.allocate(2);
int read = fic.read(bb);
while (read != -1) {
    //读完之后，反转
    bb.flip();
    foc.write(bb);
    //写完之后，清空
    //此时position与limit相等，如果不清空，会循环读到0，
    bb.clear();
    read = fic.read(bb);
}
fic.close();foc.close();fis.close();fos.close();

通道间数据传输

  • position
  1. 获取指向文件的当前位置，或者指定当前指向文件的位置
  2. 如果将位置设置在文件结束符之后，会撑大文件，造成文件空洞，磁盘上物理文件中写入的数据有空隙
//获取fromFc当前在文件中的位置
long position = fromFc.position();
//指定位置
fromFc.position(position+3);
  • transferFrom
RandomAccessFile rf1 = new RandomAccessFile("/Users/mzx/Desktop/java/nio/test1.txt", "rw");
FileChannel fromFc = rf1.getChannel();
RandomAccessFile rf2 = new RandomAccessFile("/Users/mzx/Desktop/java/nio/test2.txt", "rw");
FileChannel toFc = rf2.getChannel();
//from 传输到 to中
//文件大小
long size = fromFc.size();
//将fromFc中的内容，复制到toFc中，从7开始，size大小
toFc.transferFrom(fromFc, 7, size);
//close...
  • transferTo
RandomAccessFile rf1 = new RandomAccessFile("/Users/mzx/Desktop/java/nio/test1.txt", "rw");
FileChannel fromFc = rf1.getChannel();
RandomAccessFile rf2 = new RandomAccessFile("/Users/mzx/Desktop/java/nio/test3.txt", "rw");
FileChannel toFc = rf2.getChannel();
//from 传输到 to中
//指定位置
fromFc.position(position+3);
//文件大小
long size = fromFc.size();
//将fromF中，从起始位置，size大小的内容，传输到toFc中
fromFc.transferTo(fromFc.position(), size, toFc);
//close...

Socket通道

  • 可以设置非阻塞模式，具有伸缩性和灵活性
  • 一个线程可以管理多个socket连接
  • ServerSocketChannle负责监听传入的连接和创建新的SocketChannel对象，内部没有实现读和写的接口，不传输数据
  • socket通道可以被重复操作使用
  • 非阻塞模式适用于服务端；客户端也可以使用，可以用于维护维护一个用户请求和多个服务器的回话

ServerSocketChannel

  • 只是一个监听器
int port = 8888;
ByteBuffer bf = ByteBuffer.wrap("ServerSocketChannel".getBytes());
//打开
ServerSocketChannel ssc = ServerSocketChannel.open();
//绑定
ssc.socket().bind(new InetSocketAddress(port));
//设置非阻塞模式
ssc.configureBlocking(false);
//监听是否有新的连接
while(true) {
    System.out.println("waiting...");
    //阻塞模式运行，没有连接，会一直阻塞等待
    SocketChannel sc = ssc.accept();
    if (sc == null) { //没有新的连接传入
        System.out.println(sc);
        Thread.sleep(2000);
    } else {
        System.out.println("Connection from: " + sc.socket().getRemoteSocketAddress());
        bf.rewind(); //指针指向最开始
        sc.write(bf);
        sc.close();
    }
}

SocketChannle

  • 适用于TCP连接的网络套接字的通道，实现了可选择通道，可以被多路复用
//创建
//SocketChannel sc = SocketChannel.open(new InetSocketAddress("www.baidu.com", 80));
SocketChannel sc = SocketChannel.open();
sc.connect(new InetSocketAddress("www.baidu.com", 80));

System.out.println(sc.isOpen()); //sc是否打开
System.out.println(sc.isConnected()); //是否被连接
System.out.println(sc.isConnectionPending()); //是否正在进行连接
System.out.println(sc.finishConnect()); //正在进行套接字连接的sc是否已经完成连接
//设置阻塞模式
sc.configureBlocking(false);
//读
ByteBuffer bf = ByteBuffer.allocate(1024);
sc.read(bf);
//设置参数
sc.setOption(StandardSocketOptions.SO_KEEPALIVE, Boolean.TRUE);
System.out.println(sc.getOption(StandardSocketOptions.SO_KEEPALIVE));
sc.close();

DatagramChannel

  • 关联DatagramSocket对象，每一个数据报对象都是一个自包含的实体，拥有他自己的目的地址及不依赖其他数据报的数据负载
  • 面向UDP连接，包导向无连接协议
  • 可以将数据包发送到任意地址，也可以从任意地址获取数据包
@Test
public void sendDatagram() throws Exception {
    //发送包
    DatagramChannel sendDc = DatagramChannel.open();
    InetSocketAddress sendAdd = new InetSocketAddress("localhost", 9999);
    //发送
    while (true) {
        ByteBuffer bf = ByteBuffer.wrap("发送sendDatagramChannel".getBytes("UTF-8"));
        //数据和地址
        sendDc.send(bf, sendAdd);
        System.out.println("send-finished");
        Thread.sleep(1000);
    }
}
@Test
public void receiveDatagram() throws Exception {
    //接收包
    DatagramChannel receiveDc = DatagramChannel.open();
    //绑定
    receiveDc.bind(new InetSocketAddress(9999));
    //接收
    ByteBuffer bf = ByteBuffer.allocate(1024);
    while (true) {
        bf.clear();
        SocketAddress sa = receiveDc.receive(bf);
        bf.flip();
        System.out.println(sa.toString());
        System.out.println(Charset.forName("UTF-8").decode(bf));
    }
}
  • 连接
public void testCon() throws Exception {
    DatagramChannel conDc = DatagramChannel.open();
    conDc.bind(new InetSocketAddress(9999));
    //创建连接，9999向8888发数据
    conDc.connect(new InetSocketAddress("127.0.0.1", 8888));
    //write
    conDc.write(ByteBuffer.wrap("发送testCon".getBytes("UTF-8")));
    //read
    ByteBuffer readBf = ByteBuffer.allocate(1024);
    while (true) {
        readBf.clear();
        conDc.read(readBf);
        readBf.flip();
        System.out.println(Charset.forName("UTF-8").decode(readBf));
    }
}
  • 8888向9999写
@Test
public void receiveDatagram() throws Exception {
    //接收包
    DatagramChannel receiveDc = DatagramChannel.open();
    //绑定
    receiveDc.bind(new InetSocketAddress(8888));
    receiveDc.connect(new InetSocketAddress("127.0.0.1", 9999));
    while (true) {
        receiveDc.write(ByteBuffer.wrap("receiveDatagram".getBytes("UTF-8")));
        System.out.println("send-finished");
    }
}
@Test
public void testCon() throws Exception {
    DatagramChannel conDc = DatagramChannel.open();
    conDc.bind(new InetSocketAddress(9999));
    conDc.connect(new InetSocketAddress("127.0.0.1", 8888));
    ByteBuffer readBf = ByteBuffer.allocate(1024);
    while (true) {
        readBf.clear();
        conDc.read(readBf);
        readBf.flip();
        System.out.println(Charset.forName("UTF-8").decode(readBf));
    }
}

分散和聚集

  • 针对Channel中读取和写入的操作
  • 分散，scatter，从通道中读取数据后，将数据写入到多个buffer中

读取时，是依次填满的

  • 聚集，gather，往通道中写数据时，从多个buffer获取
  • 传输由消息头和消息体组成的消息，可以将消息头和消息体分散到不同的buffer中
  • UDP实现
@Test
public void writeDatagram() throws Exception {
    DatagramChannel writeDc = DatagramChannel.open();
    //绑定
    writeDc.bind(new InetSocketAddress(8888));
    writeDc.connect(new InetSocketAddress("127.0.0.1", 9999));
    ByteBuffer header = ByteBuffer.wrap("I am header".getBytes("UTF-8"));
    ByteBuffer body = ByteBuffer.wrap("I am Body".getBytes("UTF-8"));
    ByteBuffer[] bfArr = {header, body};
    while (true) {
        long len = writeDc.write(bfArr);
        System.out.println("send finished - " + len);
        Thread.sleep(1000);
        header = ByteBuffer.wrap("I am header".getBytes());
        body = ByteBuffer.wrap("I am Body".getBytes());
        bfArr = new ByteBuffer[]{header, body};
    }
}
@Test
public void readDatagram() throws Exception {
    DatagramChannel readDc = DatagramChannel.open();
    readDc.bind(new InetSocketAddress(9999));
    //创建连接，9999向8888发数据
    readDc.connect(new InetSocketAddress("127.0.0.1", 8888));
    ByteBuffer header = ByteBuffer.allocate(10);
    ByteBuffer body = ByteBuffer.allocate(20);
    ByteBuffer[] bfArr = {header, body};
    while (true) {
        for (ByteBuffer bf : bfArr) {
            bf.clear();
        }
        long len = readDc.read(bfArr);
        System.out.println("read - " + len);
        for (ByteBuffer bf : bfArr) {
            bf.flip();
            System.out.println(Charset.forName("UTF-8").decode(bf));
        }
    }
}
