介绍：Fabric.js 是一个强大而简单的 Javascript HTML5 画布库 Fabric 在画布元素之上提供交互式对象模型 Fabric 还具有 SVG-to-canvas（和 canvas-to-SVG）解析器
安装配置：
npm install fabric
全局引入main.js：
import { fabric } from 'fabric'
Vue.use(fabric);
局部引入：
import { fabric } from 'fabric'
初始化:
<canvas id="canvas"></canvas>
this.canvas = new fabric.Canvas('canvas');
修改canvas宽高：
this.canvas.setWidth(dragBox.offsetWidth);
this.canvas.setHeight(dragBox.offsetHeight);
全局配置（选中时的样式）：
// 全局配置
fabric.Object.prototype.transparentCorners = false;
fabric.Object.prototype.cornerColor = 'black';
fabric.Object.prototype.cornerStrokeColor = '#409EFF';
fabric.Object.prototype.cornerSize = 7;
fabric.Object.prototype.cornerStyle = 'circle';
fabric.Object.prototype.lockScalingX = true;
fabric.Object.prototype.lockScalingY = true;
fabric.Object.prototype.borderDashArray = [3, 3];
fabric.Object.prototype.padding = 0;
锁定尺寸（不能放到缩小）：
scaleX: 1,
scaleY: 1,
minScaleLimit: 1,
maxScaleLimit: 1,
绘制简单图形： Fabric 提供了 7 种基础形状：
- fabric.Circle (圆)
- fabric.Ellipse (椭圆)
- fabric.Line (线)
- fabric.Polyline (多条线绘制成图形)
- fabric.triangle (三角形)
- fabric.Rect (矩形)
- fabric.Polygon (多边形)
添加矩形：
function Add() {
var rect = new fabric.Rect({
left: 100,
top: 50,
fill: 'yellow',
width: 200,
height: 100,
objectCaching: false,
stroke: 'lightgreen',
strokeWidth: 4,
});
that.canvas.add(rect);
that.canvas.setActiveObject(rect);
}
动画：
rect.animate("left", 100, {
onChange: canvas.renderAll.bind(canvas),
duration: 1000,
});
rect.animate("angle", "+=90", {
onChange: canvas.renderAll.bind(canvas),
duration: 2000,
});
添加文字：
_this.text = new fabric.Text(
'我是文字',
{
right: 10,
top: 0,
fontSize: 12, //字号
color: 'grey',
hasControls: false,
}
);
_this.canvas.add(_this.text);
设置背景：
const imgUrl = `${_this.bg}?${Date.parse(new Date())}`;
fabric.Image.fromURL(imgUrl, (img) => {
img.set({
scaleX: _this.canvas.width / img.width,
scaleY: _this.canvas.height / img.height,
});
// 设置背景
_this.canvas.setBackgroundImage(img, _this.canvas.renderAll.bind(_this.canvas));
_this.canvas.renderAll();
});
绘制图片：主要有通过 url 和 img 标签绘制两种方式
//通过url绘制图片
fabric.Image.fromURL(
//本地图片需要通过require来引入,require("./xxx.jpeg")
"<https://gimg2.baidu.com/image_search/src=http%3A%2F%2Fimg.thaihot.com.cn%2Fuploadimg%2Fico%2F2021%2F0711%2F1625982535739193.jpg&refer=http%3A%2F%2Fimg.thaihot.com.cn&app=2002&size=f9999,10000&q=a80&n=0&g=0n&fmt=jpeg?sec=1630940858&t=e1d24ff0a7eaeea2ff89cedf656a9374>",
(img) => {
img.scale(0.5);
canvas.add(img);
}
);
//也可以通过标签绘制
let img = document.getElementById("img");
let image = new fabric.Image(img, {
left: 100,
top: 100,
opacity: 0.8,
});
canvas.add(image);
添加图片：
const imgInstance = fabric.Image.fromURL(
this.imageList[index].url,
(img) => {
img.set({
id: 3,
amount: this.imageList[index].amount || 1,
category: _this.parentList[+_this.parentName].id,
categoryName: _this.parentList[+_this.parentName].name,
left: _this.originLeft,
top: _this.originTop,
scaleX: 0.1,
scaleY: 0.1,
minScaleLimit: 0.1,
maxScaleLimit: 0.1,
lockScalingX: true,
lockScalingY: true,
});
_this.canvas.add(img).setActiveObject(img);
}, {crossOrigin: 'anonymous'}
);
图像滤镜: 目前 Fabric 为我们提供了以下内置滤镜- BaseFilter 基本过滤器
- Blur 模糊
- Brightness 亮度
- ColorMatrix 颜色矩阵
- Contrast 对比
- Convolute 卷积
- Gamma 伽玛
- Grayscale 灰度
- HueRotation 色调旋转
- Invert 倒置
- Noise 噪音
- Pixelate 像素化
- RemoveColor 移除颜色
- Resize 调整大小
- Saturation 饱和
添加滤镜：
// 添加滤镜
img.filters.push(
new fabric.Image.filters.Grayscale(),
new fabric.Image.filters.Sepia(), //色偏
new fabric.Image.filters.Brightness({ brightness: 0.2 }) //亮度
);
// 图片加载完成之后，应用滤镜效果
img.applyFilters();
添加复制删除按钮到图片上：
var deleteImg = document.createElement('img');
deleteImg.src = deleteIcon;
var cloneImg = document.createElement('img');
cloneImg.src = cloneIcon;
function renderIcon(icon) {
return function renderIcon(ctx, left, top, styleOverride, fabricObject) {
var size = this.cornerSize;
ctx.save();
ctx.translate(left, top);
ctx.rotate(fabric.util.degreesToRadians(fabricObject.angle));
ctx.drawImage(icon, -size/2, -size/2, size, size);
ctx.restore();
}
}
fabric.Object.prototype.controls.deleteControl = new fabric.Control({
x: 0.5,
y: -0.5,
offsetY: -16,
offsetX: 16,
cursorStyle: 'pointer',
mouseUpHandler: deleteObject,
render: renderIcon(deleteImg),
cornerSize: 24
});
fabric.Object.prototype.controls.clone = new fabric.Control({
x: -0.5,
y: -0.5,
offsetY: -16,
offsetX: -16,
cursorStyle: 'pointer',
mouseUpHandler: cloneObject,
render: renderIcon(cloneImg),
cornerSize: 24
});
function deleteObject(eventData, transform) {
var target = transform.target;
var canvas = target.canvas;
canvas.remove(target);
canvas.requestRenderAll();
}
function cloneObject(eventData, transform) {
var target = transform.target;
var canvas = target.canvas;
target.clone(function(cloned) {
cloned.left += 10;
cloned.top += 10;
canvas.add(cloned);
});
}
自定义删除事件：
deleteBtn() {
const el = this.canvas.getActiveObject(); // 获取active元素
console.log(el);
if (el) {
this.$confirm('确定删除？', '提示', {
confirmButtonText: ‘确定’,
cancelButtonText: ‘取消’
})
.then(() => {
// 选中多个的删除
if (el && el._objects && el._objects.length) {
el._objects.forEach(item => {
this.canvas.remove(item);
});
this.$message.success('删除成功')
return;
}
// 单个的删除
this.canvas.remove(el);
this.$message.success('删除成功')
})
.catch(() => {
})
} else {
this.$message.error(‘请选中删除的产品')
}
},
自定义复制事件：
copyBtn() {
const _this = this
const el = _this.canvas.getActiveObject()
if (!el) {
_this.$message.error('请选择要复制的元素') } else {
el.clone(function (clonedObj) {
console.log(el);
const attr = {
left: clonedObj.left + 10,
top: clonedObj.top + 10,
id: el.id,
evented: true,
amount: el.amount,
category: el.category,
categoryName: el.categoryName,
transparentCorners: false,
cornerColor: 'black',
cornerStrokeColor: '#409EFF',
borderColor: '#409EFF',
cornerSize: el.cornerSize,
padding: 0,
cornerStyle: 'circle',
borderDashArray: [3, 3],
minScaleLimit: 1,
maxScaleLimit: 1,
lockRotation: el.lockRotation,
lockScalingX: true,
lockScalingY: true,
angle: el.angle,
lockUniScaling: el.lockUniScaling,
hasControls: el.hasControls,
}
_this.canvas.discardActiveObject();
clonedObj.set(attr, {crossOrigin: 'anonymous'});
if (clonedObj.type === 'activeSelection') {
// active selection needs a reference to the canvas.
clonedObj.canvas = _this.canvas;
clonedObj.forEachObject(function (obj, index) {
obj.id = el._objects[index].id;
obj.amount = el._objects[index].amount;
obj.category = el._objects[index].category
obj.categoryName = el._objects[index].categoryName
_this.canvas.add(obj);
});
// this should solve the unselectability
clonedObj.setCoords();
} else {
_this.canvas.add(clonedObj).setActiveObject(clonedObj);
}
clonedObj.top += 10;
clonedObj.left += 10;
_this.canvas.setActiveObject(clonedObj);
_this.canvas.requestRenderAll();
});
}
},
canvas添加鼠标事件：
this.canvas.on('mouse:down', opt => {
this.mouseDown = true
this.getMouseCoords(opt);
})
this.canvas.on('mouse:up', opt => {
this.mouseDown = false
this.getMouseLeft(opt);
})
this.canvas.on('mouse:move', opt => {
var delta = new fabric.Point(opt.e.movementX, opt.e.movementY);
if (this.panning && this.mouseDown){
this.canvas.relativePan(delta)
}
})
自由绘画：
// 自由绘画
canvas.isDrawingMode = true;
canvas.freeDrawingBrush.color = "blue";
canvas.freeDrawingBrush.width = 5;
生成预览图片：
preview() {
let _this = this;
_this.canvas.discardActiveObject().renderAll(); // 取消所有选中
const currState = this.canvas.toJSON(['id', 'category', 'categoryName', 'amount']); // 获取所有参数，包括自定义的
if (!currState.backgroundImage || !currState.backgroundImage.src || !currState.objects || !currState.objects.length) {
this.$message.error('请制图')
return;
}
// 不带尺子
const scale = 3
html2canvas(document.getElementById('dragBox'), {useCORS: true, scale: scale}).then(function (canvas) {
_this.imgBlob = canvas.toDataURL('image/jpeg', 1.0) // 将图片转为base64
_this.previewDialogShow = true;
const data = {
purpose: 'game',
file: _this.imgBlob
};
_this.uploading = false
});
}
