【实例】Canvas之环形进度条步骤：完成圆弧上渐变色主要是每一小段圆弧上对应一个颜色完成缓动动画主要是每次移动

实现样例

完成代码

<!DOCTYPE html>
<html lang="en">
<head>
  <meta charset="UTF-8">
  <meta name="viewport" content="width=device-width, initial-scale=1.0">
  <title>Document</title>
  <style>
    canvas{
      border:1px solid #000;
    }
  </style>
</head>
<body>
  <canvas id="myCanvas" width="800" height="600"></canvas>
  <script>
    let canvas = document.getElementById('myCanvas')
    let ctx = canvas.getContext('2d')
    let w = canvas.width , h = canvas.height
    const step = 0.2
    function print(ctx,lineWidth,x,y,r,colors,deg){
      let startAngle = 0
      let endAngle = 2 * Math.PI  * deg


      ctx.lineWidth = 10
      ctx.lineCap = 'round'

      let stepTime = (endAngle - startAngle) / step

      let colorObj = getStepColor(colors,stepTime)
      let startColor = colors[0]
      let startRGB = colorRgb(colors[0])
      let endRGB = colorRgb(colors[1])
      // 循环次数
      for(let i=1;i<=stepTime;i++){
        ctx.beginPath()
        let color = `rgb(${parseInt(startRGB[0] + i * colorObj.colorR)},${parseInt(startRGB[1] + i * colorObj.colorG)},${parseInt(startRGB[2] + i * colorObj.colorB)})`
        ctx.strokeStyle = color
        ctx.arc(x,y,r,startAngle,startAngle + step,false)
        ctx.stroke()
        startAngle += step
      }
    }

    // 生成每个颜色的间隔
    function getStepColor(colors,step){
      if(colors && !colors.length){
        return false
      }
      if(step == 0){
        return false
      }
      let startColor = colors[0]
      let endColor = colors[1]

      let startColor_rgb = colorRgb(startColor)
      let endColor_rgb = colorRgb(endColor)
      let colorR = (endColor_rgb[0] - startColor_rgb[0]) ? (endColor_rgb[0] - startColor_rgb[0]) / step : 0
      let colorG = (endColor_rgb[1] - startColor_rgb[1]) ? (endColor_rgb[1] - startColor_rgb[1]) / step : 0
      let colorB = (endColor_rgb[2] - startColor_rgb[2]) ? (endColor_rgb[2] - startColor_rgb[2]) / step : 0
      return {step,colorR,colorG,colorB}
    }

    //将16进制转换成10进制的rgb
    function colorRgb(color){
      let colors = []
      for(let i=1 ;i<7;i+=2){
        colors.push(
          parseInt(`0x${color.slice(i,i+2)}`)
        )
      }
      return colors
    }

    let a  = 0.1
    let start = 0 , end = 1
    ctx.translate(w/2,h/2)
    ctx.rotate(-90 * Math.PI / 180)

    function move(){
      window.requestAnimationFrame(move)
      ctx.clearRect(0,0,w,h)
      let v = (end - start) * a
      start += v
      if(start >= 0.999){
        start = 1
      }
      print(ctx,20,0,0,100,['#ff6464','#3586ff'], start)
    }
    move()
  </script>
</body>
</html>

步骤：

完成圆弧上渐变色
- 主要是每一小段圆弧上对应一个颜色
完成缓动动画
- 主要是每次移动的距离是开始结束差值的十分之一
