基于Vue实现页面的引导操作

6,960 阅读3分钟

引导操作是一个非必须的功能,但是有这个功能的话,对第一次进入系统的人来说,是一个比较友好的体验,能快速的介绍自己系统的一些简单功能,我们可以基于driver.js很轻松的实现这个效果。

看看效果

图片丢失

安装

首先,我们需要通过npm或者yarn安装driver.js

npm

npm install --save driver.js

yarn

yarn add driver.js

开始

因为driver.js是需要操作dom节点的,所以使用的时候需要等到节点渲染完成,需要在onMounted里面使用:

setup() {
    const driver = new Driver()
    const show = () => {
        driver.highlight(
            {
                element: '#logo',
                popover: {
                    title: 'Title for the Popover',
                    description: 'Description for it',
                    position: 'bottom',
                    offset: 20,
                }
            }
        )
    }
​
    onMounted(() => {
        setTimeout(() => {
            show()
        })
    })
}

这里我也不知道为啥,在onMounted里面直接调用driver.js的方法没用,甚至加了nextTick也不会有效果,只有在setTimeout里面才会有效果,有大佬指教?

highlight就是driver.js提供的高亮效果,但是我们的引导操作并会只有一个,一般会有许多个这样的操作,所以这样一个一个设置就不大现实了。

driver.js提供了defineSteps这个方法,来实现一系列的引导操作:

setup() {
    const driver = new Driver()
    const show = () => {
      driver.defineSteps([
        {
          element: '#logo',
          popover: {
            title: '图标',
            description: '这是Vue的图标',
            position: 'bottom',
            offset: 20,
          }
        }
      ])
​
      driver.start()
    }
}

通过defineSteps定义之后,需要使用start方法来开始引导。

公共配置

我们可以在实例化Driver的时候,传入一些公共配置,这样的话,就很方便了,例如下一步,上一步的文案原来是英文的,我们可以在实例化时直接传入:

setup() {
    const driver = new Driver({
      doneBtnText: '完成',
      closeBtnText: '关闭',
      nextBtnText: '下一步',
      prevBtnText: '上一步'
    })
    const show = () => {
      driver.defineSteps([
        {
          element: '#logo',
          popover: {
            title: '图标',
            description: '这是Vue的图标',
            position: 'bottom',
            offset: 20
          }
        }
      ])
​
      driver.start()
    }
}

当然,这个配置也可以在options里面覆盖掉driver.js还提供了许多的内置配置:

const driver = new Driver({
  className: 'scoped-class',        // className to wrap driver.js popover
  animate: true,                    // Whether to animate or not
  opacity: 0.75,                    // Background opacity (0 means only popovers and without overlay)
  padding: 10,                      // Distance of element from around the edges
  allowClose: true,                 // Whether the click on overlay should close or not
  overlayClickNext: false,          // Whether the click on overlay should move next
  doneBtnText: 'Done',              // Text on the final button
  closeBtnText: 'Close',            // Text on the close button for this step
  stageBackground: '#ffffff',       // Background color for the staged behind highlighted element
  nextBtnText: 'Next',              // Next button text for this step
  prevBtnText: 'Previous',          // Previous button text for this step
  showButtons: false,               // Do not show control buttons in footer
  keyboardControl: true,            // Allow controlling through keyboard (escape to close, arrow keys to move)
  scrollIntoViewOptions: {},        // We use `scrollIntoView()` when possible, pass here the options for it if you want any
  onHighlightStarted: (Element) => {}, // Called when element is about to be highlighted
  onHighlighted: (Element) => {},      // Called when element is fully highlighted
  onDeselected: (Element) => {},       // Called when element has been deselected
  onReset: (Element) => {},            // Called when overlay is about to be cleared
  onNext: (Element) => {},                    // Called when moving to next step on any step
  onPrevious: (Element) => {},                // Called when moving to previous step on any step
});

driver.js生成的popover,会根据目标节点的大小生成的,所以如果popover过不合适的话,可以看看原来的dom节点是什么样子的。

内置方法和属性

driver.js还内置了一些比较方便的方法,像defineStepsstart就是内置的方法:

  • isActivated:是否正在引导过程中;
  • defineSteps: 定义引导步骤;
  • start(step = 0):开始引导,可以传入一个number参数,表示从第几步开始,比如步骤过多的情况,我们可以做一个记录,下次用户点进来就可以从中间开始查看引导了。
  • moveNext:移动到下一个步骤的引导;
  • movePrevious:移动到上一个步骤的引导;
  • hasNextStep:是否有下一个步骤的引导;
  • hasPreviousStep:是否有上一个步骤的引导;

其他的还有很多方法,可以查看官网
