1_串口

main.cpp

#include <stdio.h>
#include <sys/fcntl.h>
#include <sys/errno.h>
#include <sys/unistd.h>
#include <sys/select.h>
#include "freertos/FreeRTOS.h"
#include "freertos/task.h"
#include "esp_log.h"
#include "esp_vfs.h"
#include "esp_vfs_dev.h"
#include "driver/uart.h"

//UART0
#define RX0_BUF_SIZE (1024)
#define TX0_BUF_SIZE (512)

void uart0_rx_task();

void uart_init(void)
{
//串口配置结构体
uart_config_t uart0_config;

//串口参数配置->uart0
uart0_config.baud_rate = 115200; //波特率
uart0_config.data_bits = UART_DATA_8_BITS; //数据位
uart0_config.parity = UART_PARITY_DISABLE; //校验位
uart0_config.stop_bits = UART_STOP_BITS_1; //停止位
uart0_config.flow_ctrl = UART_HW_FLOWCTRL_DISABLE; //硬件流控

uart_param_config(UART_NUM_0, &uart0_config); //设置串口

//注册串口服务即使能+设置缓存区大小
uart_driver_install(UART_NUM_0, RX0_BUF_SIZE * 2, TX0_BUF_SIZE * 2, 0, NULL, 0);

}

void app_main()
{
//串口初始化
uart_init();

//创建串口1接收任务
xTaskCreate(uart0_rx_task, "uart0_rx_task", 1024*2, NULL, configMAX_PRIORITIES, NULL);

//串口1数据发送测试
uart_write_bytes(UART_NUM_0, "uart0 test OK ", strlen("uart0 test OK "));

}

/*
* 串口0接收任务
*/

void uart0_rx_task()
{
uint8_t* data = (uint8_t*) malloc(RX0_BUF_SIZE+1);//分配内存，用于串口接收

while(1){

//获取串口0接收的数据
const int rxBytes = uart_read_bytes(UART_NUM_0, data, RX0_BUF_SIZE, 10 / portTICK_RATE_MS);

if(rxBytes > 0) {
    data[rxBytes] = 0;//在串口接收的数据增加结束符

    //将接收到的数据发出去
    uart_write_bytes(UART_NUM_0, (char *)data, rxBytes);
    }
}

free(data);//释放申请的内存

}

2_ADC

#include <stdio.h>
#include <stdlib.h>
#include "freertos/FreeRTOS.h"
#include "freertos/task.h"
#include "driver/gpio.h"
#include "driver/adc.h"
#include "esp_adc_cal.h"

#define DEFAULT_VREF    1100        //Use adc2_vref_to_gpio() to obtain a better estimate
#define NO_OF_SAMPLES   64          //Multisampling

static esp_adc_cal_characteristics_t *adc_chars;
#if CONFIG_IDF_TARGET_ESP32
static const adc_channel_t channel = ADC_CHANNEL_6;     //GPIO34 if ADC1, GPIO14 if ADC2
static const adc_bits_width_t width = ADC_WIDTH_BIT_12;
#elif CONFIG_IDF_TARGET_ESP32S2
static const adc_channel_t channel = ADC_CHANNEL_6;     // GPIO7 if ADC1, GPIO17 if ADC2
static const adc_bits_width_t width = ADC_WIDTH_BIT_13;
#endif
static const adc_atten_t atten = ADC_ATTEN_DB_0;
static const adc_unit_t unit = ADC_UNIT_1;


static void check_efuse(void)
{
#if CONFIG_IDF_TARGET_ESP32
    //Check if TP is burned into eFuse
    if (esp_adc_cal_check_efuse(ESP_ADC_CAL_VAL_EFUSE_TP) == ESP_OK) {
        printf("eFuse Two Point: Supported\n");
    } else {
        printf("eFuse Two Point: NOT supported\n");
    }
    //Check Vref is burned into eFuse
    if (esp_adc_cal_check_efuse(ESP_ADC_CAL_VAL_EFUSE_VREF) == ESP_OK) {
        printf("eFuse Vref: Supported\n");
    } else {
        printf("eFuse Vref: NOT supported\n");
    }
#elif CONFIG_IDF_TARGET_ESP32S2
    if (esp_adc_cal_check_efuse(ESP_ADC_CAL_VAL_EFUSE_TP) == ESP_OK) {
        printf("eFuse Two Point: Supported\n");
    } else {
        printf("Cannot retrieve eFuse Two Point calibration values. Default calibration values will be used.\n");
    }
#else
#error "This example is configured for ESP32/ESP32S2."
#endif
}


static void print_char_val_type(esp_adc_cal_value_t val_type)
{
    if (val_type == ESP_ADC_CAL_VAL_EFUSE_TP) {
        printf("Characterized using Two Point Value\n");
    } else if (val_type == ESP_ADC_CAL_VAL_EFUSE_VREF) {
        printf("Characterized using eFuse Vref\n");
    } else {
        printf("Characterized using Default Vref\n");
    }
}


void app_main(void)
{
    //Check if Two Point or Vref are burned into eFuse
    check_efuse();

    //Configure ADC
    if (unit == ADC_UNIT_1) {
        adc1_config_width(width);
        adc1_config_channel_atten(channel, atten);
    } else {
        adc2_config_channel_atten((adc2_channel_t)channel, atten);
    }

    //Characterize ADC
    adc_chars = calloc(1, sizeof(esp_adc_cal_characteristics_t));
    esp_adc_cal_value_t val_type = esp_adc_cal_characterize(unit, atten, width, DEFAULT_VREF, adc_chars);
    print_char_val_type(val_type);

    //Continuously sample ADC1
    while (1) {
        uint32_t adc_reading = 0;
        //Multisampling
        for (int i = 0; i < NO_OF_SAMPLES; i++) {
            if (unit == ADC_UNIT_1) {
                adc_reading += adc1_get_raw((adc1_channel_t)channel);
            } else {
                int raw;
                adc2_get_raw((adc2_channel_t)channel, width, &raw);
                adc_reading += raw;
            }
        }
        adc_reading /= NO_OF_SAMPLES;
        //Convert adc_reading to voltage in mV
        uint32_t voltage = esp_adc_cal_raw_to_voltage(adc_reading, adc_chars);
        printf("Raw: %d\tVoltage: %dmV\n", adc_reading, voltage);
        vTaskDelay(pdMS_TO_TICKS(1000));
    }
}
