概览

egg的分析整体因为涉及到的npm包太多，但对单个包逐一分析会破坏整体性，所以需要从整体入手然后对涉及到的npm包各个击破。

主要包括以下包

启动: egg-bin egg-script
多进程: egg-cluster
框架: egg egg-core egg-router
一些主要的依赖库: common-bin koa get-ready ready-callback

启动

我们先从启动开始，包含了 egg-bin 跟 egg-script 。

egg-bin

class DevCommand extends Command {
  constructor(rawArgv) {
    super(rawArgv);
    this.defaultPort = 7001;
    // 这里serverBin是egg-bin下的start-cluster文件
    this.serverBin = path.join(__dirname, '../start-cluster');
  }

  * run(context) {
    const devArgs = yield this.formatArgs(context);
    const env = {
      NODE_ENV: 'development',
      EGG_MASTER_CLOSE_TIMEOUT: 1000,
    };
    const options = {
      execArgv: context.execArgv,
      env: Object.assign(env, context.env),
    };
    debug('%s %j %j, %j', this.serverBin, devArgs, options.execArgv, options.env.NODE_ENV);
    // 其中forkNode，是对child_process.fork方法进行了promise的包装以及graceful的包装
    const task = this.helper.forkNode(this.serverBin, devArgs, options);
    this.proc = task.proc;
    yield task;
  }
}

其中，egg-bin start-cluster代码如下

#!/usr/bin/env node

'use strict';

const debug = require('debug')('egg-bin:start-cluster');
const options = JSON.parse(process.argv[2]);
debug('start cluster options: %j', options);
// 其中这里又执行了egg.js下的startCluster
require(options.framework).startCluster(options);

然后，egg.js的startCluster又指向了 egg-cluster 暴露的startCluster方法。

exports.startCluster = require('egg-cluster').startCluster;

问题: 这里的设计没有搞明白，为啥最开始没有指向 egg-cluster 呢？

egg-scripts

start命令

* run(context) {
    const { argv, env, cwd, execArgv } = context;
    const HOME = homedir();
    const logDir = path.join(HOME, 'logs');

    // egg-script start
    // egg-script start ./server
    // egg-script start /opt/app
    let baseDir = argv._[0] || cwd;
    if (!path.isAbsolute(baseDir)) baseDir = path.join(cwd, baseDir);
    argv.baseDir = baseDir;

    const isDaemon = argv.daemon;

    argv.framework = yield this.getFrameworkPath({
      framework: argv.framework,
      baseDir,
    });

    this.frameworkName = yield this.getFrameworkName(argv.framework);

    const pkgInfo = require(path.join(baseDir, 'package.json'));
    argv.title = argv.title || `egg-server-${pkgInfo.name}`;

    argv.stdout = argv.stdout || path.join(logDir, 'master-stdout.log');
    argv.stderr = argv.stderr || path.join(logDir, 'master-stderr.log');

    // normalize env
    env.HOME = HOME;
    env.NODE_ENV = 'production';

    // it makes env big but more robust
    env.PATH = env.Path = [
      // for nodeinstall
      path.join(baseDir, 'node_modules/.bin'),
      // support `.node/bin`, due to npm5 will remove `node_modules/.bin`
      path.join(baseDir, '.node/bin'),
      // adjust env for win
      env.PATH || env.Path,
    ].filter(x => !!x).join(path.delimiter);

    // for alinode
    env.ENABLE_NODE_LOG = 'YES';
    env.NODE_LOG_DIR = env.NODE_LOG_DIR || path.join(logDir, 'alinode');
    yield mkdirp(env.NODE_LOG_DIR);

    // cli argv -> process.env.EGG_SERVER_ENV -> `undefined` then egg will use `prod`
    if (argv.env) {
      // if undefined, should not pass key due to `spwan`, https://github.com/nodejs/node/blob/master/lib/child_process.js#L470
      env.EGG_SERVER_ENV = argv.env;
    }

    const command = argv.node || 'node';

    const options = {
      execArgv,
      env,
      stdio: 'inherit',
      detached: false,
    };

    this.logger.info('Starting %s application at %s', this.frameworkName, baseDir);

    // remove unused properties from stringify, alias had been remove by `removeAlias`
    const ignoreKeys = [ '_', '$0', 'env', 'daemon', 'stdout', 'stderr', 'timeout', 'ignore-stderr', 'node' ];
    const clusterOptions = stringify(argv, ignoreKeys);
    // Note: `spawn` is not like `fork`, had to pass `execArgv` youself
    const eggArgs = [ ...(execArgv || []), this.serverBin, clusterOptions, `--title=${argv.title}` ];
    this.logger.info('Run node %s', eggArgs.join(' '));

    // whether run in the background.
    if (isDaemon) {
      this.logger.info(`Save log file to ${logDir}`);
      const [ stdout, stderr ] = yield [ getRotatelog(argv.stdout), getRotatelog(argv.stderr) ];
      options.stdio = [ 'ignore', stdout, stderr, 'ipc' ];
      // 开启 detached，子进程常驻。
      options.detached = true;

      debug('Run spawn `%s %s`', command, eggArgs.join(' '));
      const child = this.child = spawn(command, eggArgs, options);
      this.isReady = false;
      child.on('message', msg => {
        // 当egg启动完毕，从master发送消息给parent进程，通知parent进程退出。
        if (msg && msg.action === 'egg-ready') {
          this.isReady = true;
          this.logger.info('%s started on %s', this.frameworkName, msg.data.address);
          // 让父进程不需要等待子进程结束，直接退出
          child.unref();
          child.disconnect();
          this.exit(0);
        }
      });

      // check start status
      yield this.checkStatus(argv);
    } else {
      options.stdio = [ 'inherit', 'inherit', 'inherit', 'ipc' ];
      debug('Run spawn `%s %s`', command, eggArgs.join(' '));
      const child = this.child = spawn(command, eggArgs, options);
      child.once('exit', code => {
        // command should exit after child process exit
        this.exit(code);
      });

      // attach master signal to child
      let signal;
      [ 'SIGINT', 'SIGQUIT', 'SIGTERM' ].forEach(event => {
        process.once(event, () => {
          debug('Kill child %s with %s', child.pid, signal);
          child.kill(event);
        });
      });
    }
  }

stop命令

* run(context) {
    const { argv } = context;

    this.logger.info(`stopping egg application ${argv.title ? `with --title=${argv.title}` : ''}`);
		// 通过类ps -ef来寻找进程中包括start-cluster的进程，也就是主进程
    // node /Users/tz/Workspaces/eggjs/egg-scripts/lib/start-cluster {"title":"egg-server","workers":4,"port":7001,"baseDir":"/Users/tz/Workspaces/eggjs/test/showcase","framework":"/Users/tz/Workspaces/eggjs/test/showcase/node_modules/egg"}
    let processList = yield this.helper.findNodeProcess(item => {
      const cmd = item.cmd;
      return argv.title ?
        cmd.includes('start-cluster') && cmd.includes(util.format(osRelated.titleTemplate, argv.title)) :
        cmd.includes('start-cluster');
    });
    let pids = processList.map(x => x.pid);

    if (pids.length) {
      this.logger.info('got master pid %j', pids);
      this.helper.kill(pids);
      // 当主进程被kill掉之后，主进程会通知agent worker进程退出，这里会等待5s来保证全部退出
      // wait for 5s to confirm whether any worker process did not kill by master
      yield sleep(argv.timeout || '5s');
    } else {
      this.logger.warn('can\'t detect any running egg process');
    }

		// 寻找没有被主进程杀死的agent、worker进程
    // node --debug-port=5856 /Users/tz/Workspaces/eggjs/test/showcase/node_modules/_egg-cluster@1.8.0@egg-cluster/lib/agent_worker.js {"framework":"/Users/tz/Workspaces/eggjs/test/showcase/node_modules/egg","baseDir":"/Users/tz/Workspaces/eggjs/test/showcase","port":7001,"workers":2,"plugins":null,"https":false,"key":"","cert":"","title":"egg-server","clusterPort":52406}
    // node /Users/tz/Workspaces/eggjs/test/showcase/node_modules/_egg-cluster@1.8.0@egg-cluster/lib/app_worker.js {"framework":"/Users/tz/Workspaces/eggjs/test/showcase/node_modules/egg","baseDir":"/Users/tz/Workspaces/eggjs/test/showcase","port":7001,"workers":2,"plugins":null,"https":false,"key":"","cert":"","title":"egg-server","clusterPort":52406}
    processList = yield this.helper.findNodeProcess(item => {
      const cmd = item.cmd;
      return argv.title ?
        (cmd.includes(osRelated.appWorkerPath) || cmd.includes(osRelated.agentWorkerPath)) && cmd.includes(util.format(osRelated.titleTemplate, argv.title)) :
        (cmd.includes(osRelated.appWorkerPath) || cmd.includes(osRelated.agentWorkerPath));
    });
    pids = processList.map(x => x.pid);

    if (pids.length) {
      this.logger.info('got worker/agent pids %j that is not killed by master', pids);
      this.helper.kill(pids, 'SIGKILL');
    }

    this.logger.info('stopped');
  }

多进程

多进程主要包括 egg-cluster 。

时序图

在介绍egg-cluster之前，需要先看 get-ready 以及 ready-callback 这两个包，其中基本穿插着整个egg代码。

通信机制

get-ready

'use strict';

const is = require('is-type-of');

const IS_READY = Symbol('isReady');
const READY_CALLBACKS = Symbol('readyCallbacks');
const READY_ARG = Symbol('readyArg');

class Ready {
  constructor() {
    this[IS_READY] = false;
    // callback队列
    this[READY_CALLBACKS] = [];
  }

  ready(flagOrFunction) {
    // register a callback
    if (flagOrFunction === undefined || is.function(flagOrFunction)) {
      return this.register(flagOrFunction);
    }
    // emit callbacks
    this.emit(flagOrFunction);
  }


  /**
   * Call the callbacks that has been registerd, and clean the callback stack.
   * If the flag is not false, it will be marked as ready. Then the callbacks will be called immediatly when register.
   * @param {Boolean|Error} flag - Set a flag whether it had been ready. If the flag is an error, it's also ready, but the callback will be called with argument `error`
   */
  emit(flag) {
    // this.ready(true);
    // this.ready(false);
    // this.ready(err);
    this[IS_READY] = flag !== false;
    this[READY_ARG] = flag instanceof Error ? flag : undefined;
    // this.ready(true)
    if (this[IS_READY]) {
      this[READY_CALLBACKS]
        .splice(0, Infinity)
        // 把callback放到process.nextTick队列里，等待执行
        .forEach(callback => process.nextTick(() => callback(this[READY_ARG])));
    }
  }

  /**
   * @param {Object} obj - an object that be mixed
   */
  static mixin(obj) {
    if (!obj) return;
    const ready = new Ready();
    // delegate method
    obj.ready = flagOrFunction => ready.ready(flagOrFunction);
  }
}

function mixin(object) {
  Ready.mixin(object);
}

module.exports = mixin;
module.exports.mixin = mixin;
module.exports.Ready = Ready;

ready-callback

对get-ready的包装

'use strict';

const EventEmitter = require('events');
const ready = require('get-ready');
const debug = require('debug')('ready-callback');

const defaults = {
  timeout: 10000,
  isWeakDep: false,
};

/**
 * @class Ready
 */
class Ready extends EventEmitter {

  /**
   * @constructor
   * @param  {Object} opt
   *   - {Number} [timeout=10000] - emit `ready_timeout` when it doesn't finish but reach the timeout
   *   - {Boolean} [isWeakDep=false] - whether it's a weak dependency
   *   - {Boolean} [lazyStart=false] - will not check cache size automatically, if lazyStart is true
   */
  constructor(opt) {
    super();
    ready.mixin(this);

    this.opt = opt || {};
    this.isError = false;
    this.cache = new Map();

    if (!this.opt.lazyStart) {
      this.start();
    }
  }

  start() {
    // 在 check 阶段执行
    setImmediate(() => {
      // fire callback directly when no registered ready callback
      if (this.cache.size === 0) {
        debug('Fire callback directly');
        this.ready(true);
      }
    });
  }
}

如上源码展示，get-ready实现了一个语义化的事件模型，ready-callback对get-ready进行了包装，让其在 check 阶段进行执行。

接下来进入最核心的地方， egg-core 以及 egg 。

框架

在多进程里头的时序图里头，有 fork agent 以及 fork worker 的消息，其实这里就会进行实例化操作。其中，agent以及worker的继承关系如下图: 上图有些关键的信息

不论是agent还是worker进程，它的ready函数都是通过eggCore里的lifcecycle来提供的。
loader机制也是在eggcore里初始化的，注意这里说的是在eggCore里初始化的，虽然 egg-core 会有个默认的 loader 父类，但最终初始化的是 egg 包里提供的 agentLoader 跟 workLoader 子类。

egg-core

egg-core 里主要有两个东西 lifecycle 跟 loader ，这两个一个比一个令人头大，先搞最头大的 loader 吧。

loader

class AgentWorkerLoader extends EggLoader {

  /**
   * loadPlugin first, then loadConfig
   */
  loadConfig() {
    this.loadPlugin();
    super.loadConfig();
  }

  load() {
    this.loadAgentExtend();
    this.loadContextExtend();

    this.loadCustomAgent();
  }
}

module.exports = AgentWorkerLoader;

'use strict';

const EggLoader = require('egg-core').EggLoader;

/**
 * App worker process Loader, will load plugins
 * @see https://github.com/eggjs/egg-loader
 */
class AppWorkerLoader extends EggLoader {

  /**
   * loadPlugin first, then loadConfig
   * @since 1.0.0
   */
  loadConfig() {
    this.loadPlugin();
    super.loadConfig();
  }

  /**
   * Load all directories in convention
   * @since 1.0.0
   */
  load() {
    // app > plugin > core
    this.loadApplicationExtend();
    this.loadRequestExtend();
    this.loadResponseExtend();
    this.loadContextExtend();
    this.loadHelperExtend();

    this.loadCustomLoader();

    // app > plugin
    this.loadCustomApp();
    // app > plugin
    this.loadService();
    // app > plugin > core
    this.loadMiddleware();
    // app
    this.loadController();
    // app
    this.loadRouter(); // Dependent on controllers
  }

}

module.exports = AppWorkerLoader;

这两个都是调用loadConfig，然后再调用load方法。其中loadConfig里的调用就不介绍了，相对简单。

load****Extend

这种方法在agent以及worker进程里都会调用。

 /**
   * mixin Agent.prototype
   * @function EggLoader#loadAgentExtend
   * @since 1.0.0
   */
  loadAgentExtend() {
    this.loadExtend('agent', this.app);
  },

  /**
   * mixin Application.prototype
   * @function EggLoader#loadApplicationExtend
   * @since 1.0.0
   */
  loadApplicationExtend() {
    this.loadExtend('application', this.app);
  },

  /**
   * mixin Request.prototype
   * @function EggLoader#loadRequestExtend
   * @since 1.0.0
   */
  loadRequestExtend() {
    this.loadExtend('request', this.app.request);
  },

  /**
   * mixin Response.prototype
   * @function EggLoader#loadResponseExtend
   * @since 1.0.0
   */
  loadResponseExtend() {
    this.loadExtend('response', this.app.response);
  },

  /**
   * mixin Context.prototype
   * @function EggLoader#loadContextExtend
   * @since 1.0.0
   */
  loadContextExtend() {
    this.loadExtend('context', this.app.context);
  },

  /**
   * mixin app.Helper.prototype
   * @function EggLoader#loadHelperExtend
   * @since 1.0.0
   */
  loadHelperExtend() {
    if (this.app && this.app.Helper) {
      this.loadExtend('helper', this.app.Helper.prototype);
    }
  },

从代码可以看出，主要是调用 this.loadExtend 方法。

loadExtend(name, proto) {
    this.timing.start(`Load extend/${name}.js`);
    // All extend files
    const filepaths = this.getExtendFilePaths(name);
    // if use mm.env and serverEnv is not unittest
    const isAddUnittest = 'EGG_MOCK_SERVER_ENV' in process.env && this.serverEnv !== 'unittest';
    for (let i = 0, l = filepaths.length; i < l; i++) {
      const filepath = filepaths[i];
      filepaths.push(filepath + `.${this.serverEnv}`);
      if (isAddUnittest) filepaths.push(filepath + '.unittest');
    }

    const mergeRecord = new Map();
    for (let filepath of filepaths) {
      filepath = this.resolveModule(filepath);
      if (!filepath) {
        continue;
      } else if (filepath.endsWith('/index.js')) {
        // TODO: remove support at next version
        deprecate(`app/extend/${name}/index.js is deprecated, use app/extend/${name}.js instead`);
      }

      const ext = this.requireFile(filepath);

      // 获取一个对象的属性list，包含了symbol。
      // 注: Object.keys以及Object.getOwnPropertyNames都只能获得对象的非symbol属性list
      const properties = Object.getOwnPropertyNames(ext)
        .concat(Object.getOwnPropertySymbols(ext));

      for (const property of properties) {
        if (mergeRecord.has(property)) {
          debug('Property: "%s" already exists in "%s"，it will be redefined by "%s"',
            property, mergeRecord.get(property), filepath);
        }

        // 获取一个agent扩展里一个方法的描述符
        let descriptor = Object.getOwnPropertyDescriptor(ext, property);
        // 从要注入的对象里获得当前方法的描述符
        let originalDescriptor = Object.getOwnPropertyDescriptor(proto, property);
        if (!originalDescriptor) {
          // try to get descriptor from originalPrototypes
          const originalProto = originalPrototypes[name];
          if (originalProto) {
            // 从koa层获取当前方法的描述符
            originalDescriptor = Object.getOwnPropertyDescriptor(originalProto, property);
          }
        }
        // 如果从 注入的对象或koa原生上获取到描述符,则对初始描述符做merge操作，以初始描述符优先级最高
        if (originalDescriptor) {
          // don't override descriptor
          descriptor = Object.assign({}, descriptor);
          if (!descriptor.set && originalDescriptor.set) {
            descriptor.set = originalDescriptor.set;
          }
          if (!descriptor.get && originalDescriptor.get) {
            descriptor.get = originalDescriptor.get;
          }
        }
        // 注入描述符到要扩展的对象上
        Object.defineProperty(proto, property, descriptor);
        // 进入set结构，之后进行重复提示
        mergeRecord.set(property, filepath);
      }
      debug('merge %j to %s from %s', Object.keys(ext), name, filepath);
    }
    this.timing.end(`Load extend/${name}.js`);
  }

// 不用care有没有定义app/extend，直接Join起来，后边进行判断，举例
// /Users/ld/Documents/bytedance/test/showcase/node_modules/egg-view/app/extend/agent
// Users/ld/Documents/bytedance/test/showcase/node_modules/egg/app/extend/agent
// /Users/ld/Documents/bytedance/test/showcase/app/extend/agent
getExtendFilePaths(name) {
   // getLoadUnits方法返回了所有上层框架层、egg层、以及这两者所涉及到的enable的插件目录
    return this.getLoadUnits().map(unit => path.join(unit.path, 'app/extend', name));
  },

loadService

loadService(opt) {
    this.timing.start('Load Service');
    // 载入到 app.serviceClasses
    opt = Object.assign({
      call: true,
      caseStyle: 'lower',
      fieldClass: 'serviceClasses',
      directory: this.getLoadUnits().map(unit => path.join(unit.path, 'app/service')),
    }, opt);
    const servicePaths = opt.directory;
    this.loadToContext(servicePaths, 'service', opt);
    this.timing.end('Load Service');
  },

可以看到，最主要的是 this.loadContext 方法，事实上，只要你想着往 ctx 上挂载东西，都需要调用 this.loadToContext 方法。

loadToContext(directory, property, opt) {
    opt = Object.assign({}, {
      directory,
      property,
      inject: this.app,
    }, opt);

    const timingKey = `Load "${String(property)}" to Context`;
    this.timing.start(timingKey);
    new ContextLoader(opt).load();
    this.timing.end(timingKey);
  }

'use strict';

const assert = require('assert');
const is = require('is-type-of');
const FileLoader = require('./file_loader');
const CLASSLOADER = Symbol('classLoader');
const EXPORTS = FileLoader.EXPORTS;

class ClassLoader {

  constructor(options) {
    assert(options.ctx, 'options.ctx is required');
    const properties = options.properties;
    this._cache = new Map();
    this._ctx = options.ctx;

    for (const property in properties) {
      this.defineProperty(property, properties[property]);
    }
  }

  defineProperty(property, values) {
    Object.defineProperty(this, property, {
      get() {
        let instance = this._cache.get(property);
        if (!instance) {
          instance = getInstance(values, this._ctx);
          this._cache.set(property, instance);
        }
        return instance;
      },
    });
  }
}

/**
 * Same as {@link FileLoader}, but it will attach file to `inject[fieldClass]`. The exports will be lazy loaded, such as `ctx.group.repository`.
 * @extends FileLoader
 * @since 1.0.0
 */
class ContextLoader extends FileLoader {

  /**
   * @class
   * @param {Object} options - options same as {@link FileLoader}
   * @param {String} options.fieldClass - determine the field name of inject object.
   */
  constructor(options) {
    assert(options.property, 'options.property is required');
    assert(options.inject, 'options.inject is required');
    const target = options.target = {};
    if (options.fieldClass) {
      options.inject[options.fieldClass] = target;
    }
    super(options);

    const app = this.options.inject;
    const property = options.property;

    // define ctx.service
    Object.defineProperty(app.context, property, {
      get() {
        // distinguish property cache,
        // cache's lifecycle is the same with this context instance
        // e.x. ctx.service1 and ctx.service2 have different cache
        if (!this[CLASSLOADER]) {
          this[CLASSLOADER] = new Map();
        }
        const classLoader = this[CLASSLOADER];

        let instance = classLoader.get(property);
        if (!instance) {
          instance = getInstance(target, this);
          classLoader.set(property, instance);
        }
        return instance;
      },
    });
  }
}

module.exports = ContextLoader;


function getInstance(values, ctx) {
  // it's a directory when it has no exports
  // then use ClassLoader
  const Class = values[EXPORTS] ? values : null;
  let instance;
  if (Class) {
    if (is.class(Class)) {
      instance = new Class(ctx);
    } else {
      // it's just an object
      instance = Class;
    }
  // Can't set property to primitive, so check again
  // e.x. module.exports = 1;
  } else if (is.primitive(values)) {
    instance = values;
  } else {
    instance = new ClassLoader({ ctx, properties: values });
  }
  return instance;
}

fileLoder的load方法

load() {
    const items = this.parse();
    const target = this.options.target;
    for (const item of items) {
      debug('loading item %j', item);
      // item { properties: [ 'a', 'b', 'c'], exports }
      // => target.a.b.c = exports
      item.properties.reduce((target, property, index) => {
        let obj;
        const properties = item.properties.slice(0, index + 1).join('.');
        if (index === item.properties.length - 1) {
          if (property in target) {
            if (!this.options.override) throw new Error(`can't overwrite property '${properties}' from ${target[property][FULLPATH]} by ${item.fullpath}`);
          }
          obj = item.exports;
          if (obj && !is.primitive(obj)) {
            obj[FULLPATH] = item.fullpath;
            obj[EXPORTS] = true;
          }
        } else {
          obj = target[property] || {};
        }
        target[property] = obj;
        debug('loaded %s', properties);
        return obj;
      }, target);
    }
    return target;
  }

先说个总流程，在 loaderService 的时候，他并不是向 loaderExtend 那样，直接全部挂载到ctx上，怀疑是因为业务的service会无限大，如果每次请求的时候把所有service都挂载到 ctx 上，会导致内存消耗巨大。

所以目前的实现方式是，会把所有的service都放到一个闭包里头，当初次访问ctx.service的时候会返回每个serviceClass包装的classLoader对象所组成的大对象，如果接着往下访问， getInstance 会判断你是否是个class，如果是个class，他就会返回实例。

所以，比如当执行 ctx.service.index.index() 的时候，流程图如下:

不论是在获取ctx.service对象，还是获取ctx.service.index的时候，都有map存在，但都是在一个请求下才会生效。

loadToApp

loadToApp(directory, property, opt) {
    const target = this.app[property] = {};
    opt = Object.assign({}, {
      directory,
      target,
      inject: this.app,
    }, opt);

    const timingKey = `Load "${String(property)}" to Application`;
    this.timing.start(timingKey);
    new FileLoader(opt).load();
    this.timing.end(timingKey);
  }

loadToApp方法相对粗暴，就是直接挂载到 app 上，这里不做赘述。

loadController loadMiddleware

其中 loadMiddleware 相对简单，把获取到的中间件 use 下即可，对于 controller 则需要对齐进行 methodToMiddleware 的包装。

loadMiddleware 的链路走的是 this.loadToApp ，存储到 app.middleware 里，之后startServer的时候，use一波。

对于 loadController ，也是经过 this.loadToApp 将controller挂载到 app 上，但是这里因为跟路由挂钩的关系，需要将 controller wrap一层，搞成一个中间件。然后接下来访问的时候，还是走的 koa-router 的逻辑。

lifecycle

user-images.githubusercontent.com/40081831/47…

看这个官方图就够了。

结束

终于完结了，总体感受下来，egg的源码阅读起来有点零碎，有好多自己封装的npm包，但整体的设计还是很棒的。

egg源码分析

概览

启动
