• 参考页面：原神-观测枢-提瓦特大地图

• 技术栈：vue，vue2-leaflet

项目初体验：学习并熟悉leaflet（maker和popup）

• 代码效果

目标是还原提瓦特大地图！虽然当前进度只有0.01%.. T^T

• 代码：

<template>
  <div>
    <l-map
      ref="map"
      style="width: 100%; height: 600px;"
      :zoom="zoom"
      :center="center"
      @click="selectPoint(-1)"
    >
      <l-tile-layer :url="url" />
      <l-marker
        v-for="(item,index) in markers"
        :key="index"
        :lat-lng="item.oneLatLang"
        :icon="selectId===item.id?selectIcon:oneIcon"
        :opacity="item.isMark?0.3:1.0"
        @click="selectPoint(item.id)"
      >
        <l-popup :content="setText(item)" />
      </l-marker>
    </l-map>
  </div>
</template>

data() {
    return {
      selectId: -1,
      map: '',
      zoom: 2,
      center: L.latLng(39.550339, 116.114129),
      url: 'http://webrd01.is.autonavi.com/appmaptile?lang=zh_cn&size=1&scale=1&style=7&x={x}&y={y}&z={z}',
      markers: [{
        id: 100,
        isMark: false,
        oneLatLang: L.latLng(51.5, -0.09),
        name: '七天神像',
        type: '传送点'
      }, {
        id: 200,
        isMark: true,
        oneLatLang: L.latLng(39.5, 116.1),
        name: '七天神像',
        type: '传送点'
      }],
      oneLatLang: L.latLng(47.413220, -1.219482), // 添加的标签
      text: `marker<button>标记</button>`,
      oneIcon: L.divIcon({
        html: `<div class="mhy-game-gis-icon"><div class="gis-icon"></div><div/>`,
        iconSize: [32, 32],
        className: 'mhy-game-gis-marker'
      }),
      selectIcon: L.divIcon({
        html: `<div class="mhy-game-gis-icon"><div class="gis-icon"></div><div/>`,
        iconSize: [48, 48],
        className: 'mhy-game-gis-marker'
      })
    }
  },

methods: {
    selectPoint(id) {
      this.selectId = (this.selectId === id ? -1 : id)
      this.$nextTick(() => {
        const el = document.getElementsByClassName('leaflet-popup-close-button')[0]
        if (el) {
          el.addEventListener('click', () => {
            this.selectId = -1
          })
        }
      })
    },
    markPoint(point) {
      this.markers.find((item) => { return item.id === point.id }).isMark = !point.isMark
    },
    setText(item) {
      let str = ''
      str = (item.isMark ? '取消' : '')
      let classStr = ''
      classStr = (item.isMark ? 'map-popup__switch--marked' : 'map-popup__switch--unmarked')
      // return `marker<div class="map-popup__switch ${classStr}" onclick=bbb(\'${str}\')>${str}标记</div>`
      const htmlStr =
          `<div class="map-popup">
            <span class="map-popup__name-link"><label>名称：</label>${item.name}</span>
            <span class="map-popup__type"><label>类型：</label>${item.type}</span>
            <div class="map-popup__switch ${classStr}" onclick=markPoint(` + JSON.stringify(item) + `)>${str}标记</div>
          </div>`

      return htmlStr
    }
  }

<style lang="scss">
.map-popup {
  width: 280px;
  font-size: 14px;
  position: relative;
  label {
    color: #333;
  }
  span{
    color: #4a5366;
  }
}
.map-popup__type{
  font-size: 14px;
  border-bottom: 1px solid hsla(39,34%,89%,.32);
  padding-bottom: 10px;
}
.map-popup__name-link {
  line-height: 30px;
  display: block;
  cursor: pointer;
  text-decoration: none;
  color: #4a5366;
}
.map-popup__switch {
  position:absolute;
  bottom:100%;
  left:-19px;
  transform:translateY(-23px);
  font-size:14px;
  line-height:34px;
  background-color:#fff;
  width:72px;
  text-align:center;
  border-radius:3px;
  cursor:pointer
}
.map-popup__switch--marked {
  background-color:#ebebeb;
  color:#a6a6a6
}
.map-popup__switch--unmarked:before {
  content:"";
  display:inline-block;
  width:16px;
  height:16px;
  background-size:contain;
  vertical-align:sub;
  margin-right:4px
}
.leaflet-popup-content-wrapper {
  border-radius: 4px;
}
.mhy-game-gis-marker {
  border: none;
  background: transparent;
}
.mhy-game-gis-icon{
  padding: 3.125% 3.125% 34.3%;
  background-size: contain;
  background-position: top;
  background-repeat: no-repeat;
  .gis-icon {
    display: block;
    padding-top: 100%;
    border-radius: 50%;
    background-position: 50%;
    background-size: 100% 100%;
    background-repeat: no-repeat;
    background-image: url("https://uploadstatic.mihoyo.com/ys-obc/2020/09/08/75276545/c59585d1fabc9c22ad3fcf94e1622aa8_357413506633071859.png");
  }
}
</style>

左侧菜单的展开与隐藏

左侧菜单（及图标）的展开与隐藏：由这两个样式控制.map-layer-control--visible .map-layer-control--hidden，hidden时多一句css：transform: translate3d(-340px,0,0);

leaflet的学习(L-control-zoom)和优化（marker,popup）

leaflet比例尺组件：l-control-zoom，属性position="bottomright"，啊，感觉学习怎么改这个比例尺的样式要很久

修改了marker的icon（图标真的茫茫多，就写几个意思意思吧）

setIcon(item) {
      const versionArray = [
        '2020/09/08/75276545/',
        '2020/11/10/75276545/',
        '2020/12/08/75276545/',
        '2020/12/21/75276545/',
        '2020/12/22/9918847/'
      ]
      const iconArray = {
        '七天神像': { id: 'c59585d1fabc9c22ad3fcf94e1622aa8_357413506633071859', version: versionArray[0] },
        '传送锚点': { id: '0cc42d15134cbb724304050fd0bbcaac_8799482478853097434', version: versionArray[0] },
        '秘境': { id: '186a776c87addad503af2d730230e333_5715047075425774284', version: versionArray[3] },
        '忍冬之树': { id: 'b1d8af1877bb2a97f7890985cc5a26a6_7290602061532571860', version: versionArray[4] },
        '风神瞳': { id: '9d3ded0ae2ac20aab3758cc475f9f65b_6769403721373052094', version: versionArray[1] },
        '岩神瞳': { id: '2868bba96b4e4fccab2667b65676cc26_3366803659083755673', version: versionArray[1] },
        '粉红玉髓': { id: 'd564ff58c9b0cabb7ca22c3dd54b7458_2879418302062023946', version: versionArray[2] }
      }
      const iconUrl = this.baseUrl + iconArray[item.name].version + iconArray[item.name].id + '.png'
      const oneIcon = L.divIcon({
        html: `<div class="mhy-game-gis-icon">
                <div class="gis-icon" style="background-image: url(` + iconUrl + `)"></div>
              <div/>`,
        iconSize: this.selectId === item.id ? [48, 48] : [32, 32],
        className: 'mhy-game-gis-marker'
      })
      return oneIcon
    },

修改了popup里的内容，感觉已经把es6的模版字符串用的炉火纯青有没有，里面遇到了一个如何在拼接html的函数里传字符串，传对象的问题（应该有更好的办法拿html而不是手动拼接吧。希望以后能优化出来 ）

setText(item) {
      let str = ''
      str = (item.isMark ? '取消' : '')
      let classStr = ''
      classStr = (item.isMark ? 'map-popup__switch--marked' : 'map-popup__switch--unmarked')
      const expStr = item.exp ? `<div class="map-popup__exp"><label>获取：</label><div><p>` + item.exp + `</p></div></div>` : ''
      const descStr = item.desc ? `<div class="map-popup__desc"><p><img src="` + this.baseUrl + item.desc + `"></p></div>` : ''
      const contentStr = (item.desc || item.exp) ? `<div class="map-popup__content">${expStr}${descStr}</div>` : ''
      const htmlStr =
          `<div class="map-popup">
            <span class="map-popup__name-link"><label>名称：</label>${item.name}</span>
            <div class="map-popup__type"><label>类型：</label>${item.type}</div>
            ${contentStr}
            <div class="map-popup__switch ${classStr}" onclick=markPoint(` + JSON.stringify(item) + `)>${str}标记</div>
          </div>`
      return htmlStr
    }

左侧菜单关闭时发现参考地图左下角有个毫无修饰的 新建标点

左侧菜单中panel和tab的切换

细化左侧菜单

主要是panel（观测者标点、我的标点）和tab（海灯节、全地图...）的联动与切换，源代码里应该是通过css样式来实现的（visible和active）

• panel的切换

      <div class="layer-control__panel-list">
        <ul>
          <li :class="selectPanel===1?'active':''" @click="selectPanel=1">观测者标点</li>
          <li :class="selectPanel===2?'active':''" @click="selectPanel=2">我的标点</li>
        </ul>
      </div>

      li {
        flex-shrink: 1;
        flex-grow: 1;
        line-height: 26px;
        cursor: pointer;
        width: 0;
      }
      li.active{
        background: #f9f7ef;
        border-radius: 2px;
        color: #333;
      }

• tab的切换

      <ul class="layer-control__tabs" :class="selectPanel===1?'visible':''">
        <li :class="selectTab===1?'active':''" @click="selectTab=1">
          <img class="tab__img--pc" src="https://uploadstatic.mihoyo.com/ys-obc/2021/02/10/75276545/2c16f8ac82e9d03d64b7d992cc57d1ed_4840089266454406085.png" alt="">
          <img class="tab__img--pc tab__img--active" src="https://uploadstatic.mihoyo.com/ys-obc/2021/02/10/75276545/4c43710ddb977ee09abf383e50cd3712_3919397148410738998.png" alt="">
        </li>
        <li :class="selectTab===2?'active':''" @click="selectTab=2">
        </li>
        <li :class="selectTab===3?'active':''" @click="selectTab=3">
          <img class="tab__img--pc" alt="" src="https://uploadstatic.mihoyo.com/ys-obc/2021/02/02/75276545/c567b06b45731f7b717489d84e42d5a8_1481937890353876637.png">
          <img class="tab__img--pc tab__img--active" alt="" src="https://uploadstatic.mihoyo.com/ys-obc/2021/02/02/75276545/b3a0a7def938d3f808d8b643dbb6a0ab_1442014105576212461.png">
        </li>
        <li :class="selectTab===4?'active':''" @click="selectTab=4">
          <img class="tab__img--pc" alt="" src="https://uploadstatic.mihoyo.com/ys-obc/2020/12/21/75276545/5be221faea5c6a1dc438e99560fd4728_4477393884157974390.png">
          <img class="tab__img--pc tab__img--active" alt="" src="https://uploadstatic.mihoyo.com/ys-obc/2020/12/21/75276545/5ea73b7be08f0f9b6059d308ce94f185_2984733876175625841.png">
        </li>
        <li :class="selectTab===5?'active':''" @click="selectTab=5">
          <img class="tab__img--pc" alt="" src="https://uploadstatic.mihoyo.com/ys-obc/2020/12/21/75276545/76f527395d27cd478ce57cd64f7e0f46_5127368496664517484.png">
          <img class="tab__img--pc tab__img--active" alt="" src="https://uploadstatic.mihoyo.com/ys-obc/2020/12/21/75276545/a8735d936127a2405530a2adec019fc3_7158521410518821527.png">
        </li>
      </ul>

.layer-control__tabs {
    position: absolute;
    left: 100%;
    top: 180px;
    pointer-events: none;
    overflow: hidden;
    li{
      white-space: nowrap;
      pointer-events: all;
      cursor: pointer;
      margin-bottom: 10px;
      transform: translate3d(-100%,0,0);
      transition: transform .2s;
      .tab__img--pc {
        display: block;
        height: 50px;
        width: auto;
      }
      .tab__img--pc.tab__img--active {
        display: none;
      }
    }
    li.active{
      .tab__img--pc{
        display: none;
      }
      .tab__img--pc.tab__img--active {
        display: block;
      }
    }
  }
  //动画效果：tab从左侧滑出
    .layer-control__tabs.visible li {
    transform: translateZ(0);
  }

这块代码我写的挺冗余的，有很多优化的地方，这种简单的切换应该抽成组件。另外还有一种方式，不通过改变css样式也能达到预期效果，代码如下：

①        <li @click="selectTab=5">
          <img alt="" :src="selectTab===5?
              'https://uploadstatic.mihoyo.com/ys-obc/2020/12/21/75276545/a8735d936127a2405530a2adec019fc3_7158521410518821527.png':
              'https://uploadstatic.mihoyo.com/ys-obc/2020/12/21/75276545/76f527395d27cd478ce57cd64f7e0f46_5127368496664517484.png'"
          >
        </li>
②        <li @click="selectTab=5">
          <img v-if="selectTab===5" alt="" src="https://uploadstatic.mihoyo.com/ys-obc/2020/12/21/75276545/a8735d936127a2405530a2adec019fc3_7158521410518821527.png">
          <img v-else alt="" src="https://uploadstatic.mihoyo.com/ys-obc/2020/12/21/75276545/76f527395d27cd478ce57cd64f7e0f46_5127368496664517484.png">
        </li>
③        <li @click="selectTab=5">
          <img v-show="selectTab===5" alt="" src="https://uploadstatic.mihoyo.com/ys-obc/2020/12/21/75276545/a8735d936127a2405530a2adec019fc3_7158521410518821527.png">
          <img v-show="selectTab!==5" alt="" src="https://uploadstatic.mihoyo.com/ys-obc/2020/12/21/75276545/76f527395d27cd478ce57cd64f7e0f46_5127368496664517484.png">
        </li>

.layer-control__tabs {
    position: absolute;
    left: 100%;
    top: 180px;
    pointer-events: none;
    overflow: hidden;
    li{
      white-space: nowrap;
      pointer-events: all;
      cursor: pointer;
      margin-bottom: 10px;
      transform: translate3d(-100%,0,0);
      transition: transform .2s;
      img{
        height: 50px;
        width: auto;
      }
    }

这两种使用方式的差异体现在是最终生成的html上，对于响应时间的优劣没展开测试（自我感觉切换的都挺快的）

css代码优化

关于地图底图的替换，放几个参考地址备忘，有时间再实现吧。

暂列关键词，瓦片地图，瓦片切割工具等等
leaflet加载离线瓦片地图
HTML超大图片加载显示解决方案--图片切割转换成瓦片地图（BaiduMapTileCutter）
实现地图加载自定义图片（含图片切割）
瓦片地图原理
