组动画

#import "ViewController.h"

@interface ViewController ()

/*动画路径*/
@property (nonatomic,strong) UIBezierPath *animationPath;
/*第一个按钮*/
@property (nonatomic,strong) UIButton *startBtn;
/*第二个按钮*/
@property (nonatomic,strong) UIButton *endBtn;
/*展示层*/
@property (nonatomic,strong) CAShapeLayer *shapeLayer;

@end

@implementation ViewController

- (void)viewDidLoad {
    [super viewDidLoad];

    [self startBtn];
    [self endBtn];
}

/*左边按钮*/
- (UIButton *)startBtn {
    if(!_startBtn) {
        _startBtn = [UIButton buttonWithType:UIButtonTypeCustom];
        _startBtn.bounds = CGRectMake(0, 0, 30, 30);
        _startBtn.center = CGPointMake(100, 150);
        _startBtn.layer.cornerRadius = 15;
        _startBtn.layer.masksToBounds = YES;
        _startBtn.layer.borderColor = [UIColor orangeColor].CGColor;
        _startBtn.layer.borderWidth = 1;
        [_startBtn setTitle:@"点我" forState:UIControlStateNormal];
        [_startBtn setTitleColor:[UIColor grayColor] forState:UIControlStateNormal];
        _startBtn.titleLabel.font = [UIFont systemFontOfSize:12];
        [_startBtn addTarget:self action:@selector(clickMe:) forControlEvents:UIControlEventTouchUpInside];
        [self.view addSubview:_startBtn];
    }
    return _startBtn;
}

/*右边按钮*/
- (UIButton *)endBtn {
    if(!_endBtn) {
        _endBtn = [UIButton buttonWithType:UIButtonTypeCustom];
        _endBtn.bounds = CGRectMake(0, 0, 30, 30);
        _endBtn.center = CGPointMake(300, 150);
        _endBtn.layer.cornerRadius = 15;
        _endBtn.layer.masksToBounds = YES;
        _endBtn.layer.borderColor = [UIColor orangeColor].CGColor;
        _endBtn.layer.borderWidth = 1;
        [_endBtn setTitle:@"点我" forState:UIControlStateNormal];
        [_endBtn setTitleColor:[UIColor grayColor] forState:UIControlStateNormal];
        _endBtn.titleLabel.font = [UIFont systemFontOfSize:12];
        [_endBtn addTarget:self action:@selector(clickMe:) forControlEvents:UIControlEventTouchUpInside];
        [self.view addSubview:_endBtn];
    }
    return _endBtn;
}

/*显示层shapeLayer*/
- (CAShapeLayer *)shapeLayer {
    if(!_shapeLayer) {
        _shapeLayer = [CAShapeLayer layer];
        _shapeLayer.strokeColor = [UIColor orangeColor].CGColor;
        _shapeLayer.lineWidth = 1;
        _shapeLayer.fillColor = [UIColor clearColor].CGColor;
        _shapeLayer.lineCap = kCALineCapRound;
        [self.view.layer addSublayer:_shapeLayer];
    }
    return _shapeLayer;
}

//按钮点击方法
- (void)clickMe:(UIButton *)sender {
    if (sender == self.startBtn) {
        BOOL clockwise = YES;
        //点击左边按钮的时候，起始点为右边按钮的中心点；结束点为左边按钮的中心点，动画方向为顺时针
        [self cicle:CGPointMake(100, 150) ToCicle:CGPointMake(300, 150) clockwise:clockwise];
    } else {
        //点击右边按钮的时候，起始点为左边按钮的中心点；结束点为右边按钮的中心点，动画方向为逆时针
        [self cicle:CGPointMake(300, 150) ToCicle:CGPointMake(100, 150) clockwise:NO];
    }
}

/**
 * 实现动画
 * @param fromPoint 开始点
 * @param toPoint 结束点
 * @param clockwise 动画顺序
 */
- (void)cicle:(CGPoint)fromPoint ToCicle:(CGPoint)toPoint clockwise:(BOOL)clockwise {
    //创建第一个中心点
    CGPoint point1 = fromPoint;
    //创建第二个中心点
    CGPoint point2 = toPoint;
    //计算路径长度
    CGFloat length = 4*M_PI*20 + 200;
    //计算一个圆的长度,用来计算后续动画的结束点
    CGFloat cicleLength = 2 * M_PI * 20;

    //创建路径
    if (!self.animationPath) {
        self.animationPath = [UIBezierPath bezierPath];
    }
    //删除动画路径上的所有点
    [self.animationPath removeAllPoints];
    [self.animationPath addArcWithCenter:point1 radius:20 startAngle:M_PI_2-0.0001 endAngle:2*M_PI + M_PI_2 clockwise:clockwise];
    [self.animationPath addArcWithCenter:point2 radius:20 startAngle:M_PI_2-0.0001 endAngle:2*M_PI + M_PI_2 clockwise:clockwise];
    self.shapeLayer.path = self.animationPath.CGPath;

    //创建strkeEnd动画
    CABasicAnimation *strokeEndAnimation = [CABasicAnimation animationWithKeyPath:@"strokeEnd"];
    strokeEndAnimation.duration = 3;
    strokeEndAnimation.fromValue = @0;
    strokeEndAnimation.toValue = @1;
    strokeEndAnimation.removedOnCompletion = clockwise;
    strokeEndAnimation.fillMode = kCAFillModeForwards;
    //    kCAMediaTimingFunctionEaseOut 是让动画全速开始然后慢慢减速停止
    strokeEndAnimation.timingFunction = [CAMediaTimingFunction functionWithName:kCAMediaTimingFunctionEaseOut];

    //创建strokeStart动画
    CABasicAnimation *strokeStartAnimation = [CABasicAnimation animationWithKeyPath:@"strokeStart"];
    strokeStartAnimation.duration = strokeEndAnimation.duration - 0.15;
    strokeStartAnimation.fromValue = @0;
    strokeStartAnimation.toValue = @(1-(cicleLength/length));
    strokeStartAnimation.removedOnCompletion = clockwise;
    strokeStartAnimation.fillMode = kCAFillModeForwards;
    //kCAMediaTimingFunctionEaseIn是动画缓慢开始，突然停止
    strokeStartAnimation.timingFunction = [CAMediaTimingFunction functionWithName:kCAMediaTimingFunctionEaseIn];
    /*通过设置timingFunction来是的动画组开起来更加美观流畅*/

    //创建动画组
    CAAnimationGroup *group = [CAAnimationGroup animation];
    group.duration = strokeEndAnimation.duration;
    group.removedOnCompletion = NO;
    group.fillMode = kCAFillModeForwards;
    group.repeatCount = 1;
    group.animations = @[strokeEndAnimation,strokeStartAnimation];

    [self.shapeLayer addAnimation:group forKey:@"stroke"];
}

@end
