antv-f2自己研究的一些图例

4,761 阅读8分钟

一、前言

最近在开发钉钉小程序,然后有很多图表需求,研究了 echarts,发现现有的小程序 echarts 库钉钉不支持,ucharts 使用简单,但是自定义功能少,满足不了需求,最后把注意力放到了 antv-f2。

antv-f2 的优势是自定义功能多,基本上和 antv-g2 没啥区别,强大的 api 基本可以满足你的需求。缺点就是官方的图例实在太少,相比于 echarts 和 ucharts 本身已经集成好多种类型,antv-f2 似乎是只提供了我们作画的工具,想画什么图还要自己去设计,这点对于新手来说的话不是那么的友好。当然写这篇文章的我也只是个新手,记录一下自己的研究,也希望可以让别人更容易上手这个工具。

二、个人环境

开发平台:uniapp+antv 小程序插件(基于 f2: 3.6.3 f2-context: 0.0.2)
测试环境:钉钉小程序

由于是使用 uniapp,且插件已经将 antv-f2 封装了起来,因此以下所有示例的模板都如下:

<template>
  <f2 :init="initChart" />
</template>

<script>
import f2 from '@/components/i-uni-f2';
export default {
  methods: {
    initChart(F2, config) {
      // 在这里配置参数,下面的图例皆是这个函数
    }
  }
};
</script>

三、图例

1.仪表盘

代码

// 仪表盘配置
const initChart = (F2, config) => {
   const Shape = F2.Shape
   Shape.registerShape('point''pointer', {
    draw(cfg, container) {
     const group = container.addGroup({});
     // 获取极坐标系下画布中心点
     const center = this.parsePoint({
      x0,
      y0
     });
          // 指针的结束位置
     const a = this.parsePoint({
      x: cfg.origin._origin.value/9,
      y2
     })
     // 绘制指针
     group.addShape('line', {
      attrs: {
       x1: center.x,
       y1: center.y,
       x2: a.x,
       y2: a.y,
       strokeStyle: cfg.color,
       lineWidth3,
       lineCap'round',
      },
     });
     group.addShape('circle', {
      attrs: {
       x: center.x,
       y: center.y,
       r5,
       stroke: cfg.color,
       lineWidth4.5,
       fill'#fff',
      },
     });

     return group;
    },
   })
   const data = [{
    value: 6
   }]
      // 初始化实例
   const chart new F2.Chart(config)
      // 读取数据
   chart.source(data)
      // 设置极坐标
   chart.coord('polar', {
    startAngle: (-10 / 8) * Math.PI,
    endAngle: (2 / 8) * Math.PI,
    radius: 1
   });
   chart.scale('value', {
    min0,
    max9,
    ticks: [2.253.755.256.75],
   });
      // 设置坐标轴
   chart.axis('1'false);
   chart.axis('value', {
    linenull,
    tickLinenull,
    gridnull,
    label: (text, index, total) => {
     const cfg = {
      fontSize: 10,
      textAlign: 'center',
     }
     if(text==='2.25'){
      cfg.text = '差'
     }else if(text==='3.75'){
      cfg.text = '中'
     }else if(text==='5.25'){
      cfg.text = '良'
     }else{
      cfg.text = '优'
     }
     return cfg
    },
   });
   chart.legend(false);
   chart
    .point()
    .position('value*1')
    .shape('pointer')
    .color('#1890FF');

   // 绘制仪表盘刻度线
   chart.guide().line({
    start: [32.7],
    end: [3.00352.5],
    style: {
     stroke'#19AFFA', // 线的颜色
     lineDashnull, // 虚线的设置
     lineWidth3,
    },
   });
   chart.guide().line({
    start: [4.52.7],
    end: [4.52.5],
    style: {
     stroke'#19AFFA', // 线的颜色
     lineDashnull, // 虚线的设置
     lineWidth3,
    },
   });

   chart.guide().line({
    start: [62.7],
    end: [6.00352.5],
    style: {
     stroke'#19AFFA', // 线的颜色
     lineDashnull, // 虚线的设置
     lineWidth3,
    },
   });

   // 绘制仪表盘背景
   chart.guide().arc({
    topfalse,
    start: [03],
    end: [93],
    style: {
     stroke'#CBCBCB',
     lineWidth8,
     lineDashnull,
    },
   });

   // 绘制指标
   chart.guide().arc({
    start: [03],
    end: [data[0].value, 3],
    style: {
     stroke'#1890FF',
     lineWidth8,
     lineDashnull,
    },
   });
   // 绘制指标数字
   chart.guide().text({
    position: ['50%''85%'],
    content'合格率',
    style: {
     fontSize11,
     fill'#545454',
     textAlign'center',
    },
    offsetY10
   });
   chart.guide().text({
    position: ['50%''90%'],
    content: `${data[0].value * 10} %`,
    style: {
     fontSize11,
     fill'#545454',
     textAlign'center',
    },
    offsetY20,
   });
   // 渲染,然后返回chart
   chart.render()
   return chart
  }

踩坑点

1.由于最开始是直接从antv-g2的图例直接复制代码过来的,g2和f2的用法其实差不多,但是有部分api名字不一样,如g2的chart.data和f2的chart.source,这里踩坑了就这能根据错误信息去对文档了。
2.g2中的draw方法的cfg参数是会自动处理data的数值映射的,而f2中的不会,所以在draw方法中手动处理了指针的结束位置(x代表弧度,y代表半径,极坐标中都是这样表示的)

2.子弹图

代码

initChart(F2, config) {
 const data = [{
   月份: '1月',
   height: 5,
   width: 1
  },
  {
   月份: '2月',
   height: 5,
   width: 1
  },
  {
   月份: '3月',
   height: 5,
   width: 1
  },
  {
   月份: '4月',
   height: 5,
   width: 1
  },
  {
   月份: '5月',
   height: 5,
   width: 1
  },
 ];
 const chart = new F2.Chart(config)
 chart.legend(false// 不显示图例
  // 坐标反转
 chart.coord({
  transposed: true
 });
 chart.axis(false)
 chart.source(data, {
    // 制定纵坐标范围
  width: {
   min: 0,
   max: 2
  }
 });
 data.forEach((item, index) => {
    // 生成注释
  chart.guide().text({
   content: index * '2',
   position: [(index + 1) * 20 - 10 + '%''30%']
  })
  chart.guide().text({
   content: index,
   position: [(index + 1) * 20 - 10 + '%''50%'],
   offsetY: 10
  })
  chart.guide().text({
   content: index + 1 + '月',
   position: [(index + 1) * 20 - 10 + '%''80%'],
   offsetY: 5
  })
 })
 chart.interval().position('width*height').color('月份''#D9F2FD-#385074').size(10).adjust('stack')
 chart.render()
 return chart
}

踩坑点

1.这里需要制定纵坐标的范围,原因是如果不这样做图的位置永远会在最上方,把纵坐标的位置限制在坐标轴的中间就能够使图纵向居中,方便进行上下的文字布局。
2.最好不要用默认的坐标轴,通过guide方法来配置文字注释会更加灵活。

四、结语

研究这个antv-f2可谓是费心费力了,如果觉得对你有帮助的话就点个赞吧。
