Dom应用(八)——放大镜需求：鼠标划入时，显示白色滑块和bigdrag在small中移动，那么对应big也会展示出相应

需求：

鼠标划入时，显示白色滑块和big
drag在small中移动，那么对应big也会展示出相应部分
鼠标划出，big和drag隐藏

步骤：

small容器包含drag和img，big容器包含img
注意samll和drag的比例和big与bigimg的比例
drag有设置left和top注意定位
bigimg也要注意定位
left的设置会用到offestleft注意要拼上"px"
滑块drag会有最大移动边界，注意临界点的取值
因为两个部分是成比例的，所以可以移动的最大距离也是成比例的，计算perx，pery
perx = maxBigwidth/maxSmallwidth,pery同理
鼠标移出，drag和big隐藏
注意鼠标移动是在鼠标划入的情况下进行的

代码

<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <meta http-equiv="X-UA-Compatible" content="ie=edge">
    <title>Document</title>
    <style>
        *{
            margin: 0px;
            padding: 0px;
        }
        #small{
            height: 400px;
            width: 400px;
            position: relative;;
            float: left;

        }
        #small img{
            height: 400px;
            width: 400px;

        }
        #drag{
            height: 200px;
            width: 200px;
            background: rgba(255,255,255, 0.6);
            position: absolute;
            left: 0px;
            top: 0px;
            display: none;

        }
        #big{
            height: 400px;
            width: 400px;
            position: relative;
            float: left;
            overflow: hidden;
            display: none;


        }
        #big>img{
            height: 800px;
            width: 800px;
            position: absolute;
            left: 0px;
            top: 0px;
        }

    </style>
</head>
<body>

    <div id="small">
        <img src="./img/dog.jpg" alt="">
        <div id="drag"></div>
    </div>
    <div id="big">
        <img src="./img/dog.jpg" alt="">
    </div>
    <script>
    var oSmall = document.getElementById("small");
    var oDrag = document.getElementById("drag");
    var oBig = document.getElementById('big');
    var oImg = oBig.getElementsByTagName('img')[0];



    // 鼠标划入时darg和big都展示出来
     oSmall.onmouseover = function(){
         oDrag.style.display = "block";
         oBig.style.display = "block";

        //  鼠标移动实在鼠标划入的前提下
        oSmall.onmousemove = function(e){
            // 注意这里的offsetwidth 和 clientX都是number类型的，记得拼上px
            oDrag.style.left = e.clientX - oDrag.offsetWidth / 2 + "px";
            oDrag.style.top = e.clientY - oDrag.offsetWidth / 2 + "px";

            var maxSmallwidth = oSmall.offsetWidth - oDrag.offsetWidth
            var maxSmallheight = oSmall.offsetHeight - oDrag.offsetHeight


            // 为drag设置滑动临界点
            if (oDrag.offsetLeft < 0){
                oDrag.style.left = 0
            }
            if(oDrag.offsetLeft > maxSmallwidth){
                oDrag.style.left = maxSmallwidth + "px";
                // 记得拼上px

            }
            if(oDrag.offsetTop < 0){
                oDrag.style.top = 0;

            }
            if(oDrag.offsetTop > maxSmallheight){
                oDrag.style.top  = maxSmallheight + 'px';
                // 记得拼上px
            }

            // 对big进行比例变换
            // drag在small里面如果左移，下移，那么img在big里面就右移上移，他们两个保持一个相反的状态

            // 计算img在big中移动的最大距离
            var maxBigwidth = oImg.offsetWidth - oBig.offsetWidth;
            var maxBigheight = oImg.offsetHeight - oBig.offsetHeight;

            // 计算移动比例
            var perx = maxBigwidth / maxSmallwidth;
            var pery = maxBigheight / maxSmallheight;

            //计算oImg的真实位置
            oImg.style.left = -oDrag.offsetLeft * perx +"px";
            oImg.style.top = -oDrag.offsetTop * pery + 'px';

        }

     }
    // 鼠标划出时，展示取消
    oSmall.onmouseout = function(){
        oDrag.style.display = "none";
        oBig.style.display = "none";

    }

    </script>

</body>
</html>
