前言

有关通讯录的框架有好几种，包括AddressBook、AddressBookUI、Contacts和ContactsUI，这里，iOS9 以后AddressBook、AddressBookUI就不推荐使用了，但是如果要支持ios8以及以前的系统还是要用它们两个框架的。ios9以后系统推荐使用Contacts和ContactsUI，接下来的几篇我们就详细的解析一下这几个框架。感兴趣的可以看我写的上面几篇。
1. 通讯录相关框架详细解析（一）—— AddressBook框架基本概览
2. 通讯录相关框架详细解析（二）—— AddressBookUI框架基本概览
3. 通讯录相关框架详细解析（三）—— Contacts框架基本概览（一）
4. 通讯录相关框架详细解析（四）—— ContactsUI框架基本概览（一）
5. 通讯录相关框架详细解析（五）—— Contacts和ContactsUI框架的基本使用示例（一）

源码

1. Swift

首先看下代码组织结构

下面就是sb中的内容

接着就是源码了

1. AppDelegate.swift

import UIKit
import Contacts

extension UIColor {
  static let appBlue = UIColor(red: 0, green: 155.0 / 255.0, blue: 255.0 / 255.0, alpha: 1)
}

@UIApplicationMain
class AppDelegate: UIResponder, UIApplicationDelegate {
    var window: UIWindow?

    func application(_ application: UIApplication, didFinishLaunchingWithOptions launchOptions: [UIApplication.LaunchOptionsKey: Any]?) -> Bool {
        window?.backgroundColor = .white

        UINavigationBar.appearance().barStyle = .default
        UINavigationBar.appearance().barTintColor = .appBlue
        UINavigationBar.appearance().tintColor = .white
    UINavigationBar.appearance().isOpaque = true
    UINavigationBar.appearance().titleTextAttributes = [.foregroundColor: UIColor.white]
        UITabBar.appearance().tintColor = .appBlue

    CNContactStore().requestAccess(for: .contacts) { (access, error) in
      print("Access: \(access)")
    }

        return true
    }
}

2. FriendsViewController.swift

import UIKit
import ContactsUI

class FriendsViewController: UITableViewController {
  var friendsList = Friend.defaultContacts()

  override func viewDidLoad() {
    super.viewDidLoad()
    navigationItem.titleView = UIImageView(image: UIImage(named: "RWConnectTitle")!)
  }

  override func viewWillAppear(_ animated: Bool) {
    super.viewWillAppear(animated)
    navigationController?.navigationBar.tintColor = .white
  }

  override func prepare(for segue: UIStoryboardSegue, sender: Any?) {
    if
      segue.identifier == "EditFriendSegue",
      // 1
      let cell = sender as? FriendCell,
      let indexPath = tableView.indexPath(for: cell),
      let editViewController = segue.destination as? EditFriendTableViewController {
        let friend = friendsList[indexPath.row]
        // 2
        let store = CNContactStore()
        // 3
        let predicate = CNContact.predicateForContacts(matchingEmailAddress: friend.workEmail)
        // 4
        let keys = [CNContactPhoneNumbersKey as CNKeyDescriptor]
        // 5
        if
          let contacts = try? store.unifiedContacts(matching: predicate, keysToFetch: keys),
          let contact = contacts.first,
          let contactPhone = contact.phoneNumbers.first {
          // 6
            friend.storedContact = contact.mutableCopy() as? CNMutableContact
            friend.phoneNumberField = contactPhone
            friend.identifier = contact.identifier
        }
        editViewController.friend = friend
    }
  }

  @IBAction private func addFriends(sender: UIBarButtonItem) {
    // 1
    let contactPicker = CNContactPickerViewController()
    contactPicker.delegate = self
    // 2
    contactPicker.predicateForEnablingContact = NSPredicate(format: "emailAddresses.@count > 0")
    present(contactPicker, animated: true)
  }

}

//MARK: - UITableViewDataSource
extension FriendsViewController {
  override func tableView(_ tableView: UITableView, numberOfRowsInSection section: Int) -> Int {
    return friendsList.count
  }

  override func tableView(_ tableView: UITableView, cellForRowAt indexPath: IndexPath) -> UITableViewCell {
    let cell = tableView.dequeueReusableCell(withIdentifier: "FriendCell", for: indexPath)

    if let cell = cell as? FriendCell {
      let friend = friendsList[indexPath.row]
      cell.friend = friend
    }

    return cell
  }
}

//MARK: - UITableViewDelegate
extension FriendsViewController {
  override func tableView(_ tableView: UITableView, didSelectRowAt indexPath: IndexPath) {
    tableView.deselectRow(at: indexPath, animated: true)
    // 1
    let friend = friendsList[indexPath.row]
    let contact = friend.contactValue
    // 2
    let contactViewController = CNContactViewController(forUnknownContact: contact)
    contactViewController.hidesBottomBarWhenPushed = true
    contactViewController.allowsEditing = false
    contactViewController.allowsActions = false
    // 3
    navigationController?.navigationBar.tintColor = .appBlue
    navigationController?.pushViewController(contactViewController, animated: true)
  }
}

//MARK: - CNContactPickerDelegate
extension FriendsViewController: CNContactPickerDelegate {
  func contactPicker(_ picker: CNContactPickerViewController,
                     didSelect contacts: [CNContact]) {
    let newFriends = contacts.compactMap { Friend(contact: $0) }
    for friend in newFriends {
      if !friendsList.contains(friend) {
        friendsList.append(friend)
      }
    }
    tableView.reloadData()
  }
}

3. EditFriendTableViewController.swift

import UIKit
import Contacts

class EditFriendTableViewController: UITableViewController {
  @IBOutlet private weak var nameLabel: UILabel!
  @IBOutlet private weak var emailLabel: UILabel!
  @IBOutlet private weak var phoneTypeLabel: UILabel!
  @IBOutlet private weak var phoneTextField: UITextField!
  @IBOutlet private weak var saveButton: UIButton!

  var friend: Friend?

  override func viewDidLoad() {
    super.viewDidLoad()
    setup()
  }

  private func setup() {
    guard let friend = friend else {
      nameLabel.text = ""
      emailLabel.text = ""
      phoneTextField.text = ""
      phoneTextField.isEnabled = false
      return
    }
    let formatter = CNContactFormatter()
    formatter.style = .fullName
    if let name = formatter.string(from: friend.contactValue) {
      nameLabel.text = name
    } else {
      nameLabel.text = "Name Not Available"
    }
    emailLabel.text = friend.workEmail
    if let phoneNumberField = friend.phoneNumberField,
      let label = phoneNumberField.label {
      phoneTypeLabel.text = CNLabeledValue<CNPhoneNumber>.localizedString(forLabel: label)
      phoneTextField.text = phoneNumberField.value.stringValue
    }
  }

  @IBAction private func save(_ sender: Any) {
    phoneTextField.resignFirstResponder()
    let store = CNContactStore()
    guard let friend = friend,
      let phoneNumberText = phoneTextField.text else { return }
    let phoneNumberValue = CNPhoneNumber(stringValue: phoneNumberText)
    let saveRequest = CNSaveRequest()

    if let storedContact = friend.storedContact,
      let phoneNumberToEdit = storedContact.phoneNumbers.first(
        where: { $0 == friend.phoneNumberField }
      ),
      let index = storedContact.phoneNumbers.firstIndex(of: phoneNumberToEdit) {

      // 1
      let newPhoneNumberField = phoneNumberToEdit.settingValue(phoneNumberValue)
      storedContact.phoneNumbers.remove(at: index)
      storedContact.phoneNumbers.insert(newPhoneNumberField, at: index)
      friend.phoneNumberField = newPhoneNumberField
      // 2
      saveRequest.update(storedContact)
      friend.storedContact = nil
    } else if let unsavedContact = friend.contactValue.mutableCopy() as? CNMutableContact {
      // 3
      let phoneNumberField = CNLabeledValue(label: CNLabelPhoneNumberMain,
                                            value: phoneNumberValue)
      unsavedContact.phoneNumbers = [phoneNumberField]
      friend.phoneNumberField = phoneNumberField
      // 4
      saveRequest.add(unsavedContact, toContainerWithIdentifier: nil)
    }

    do {
      try store.execute(saveRequest)
      let controller = UIAlertController(title: "Success",
                                         message: nil,
                                         preferredStyle: .alert)
      controller.addAction(UIAlertAction(title: "OK", style: .default))
      present(controller, animated: true)
      setup()
    } catch {
      print(error)
    }
  }
}

4. Friend.swift

import UIKit
import Contacts

class Friend {
  let firstName: String
  let lastName: String
  let workEmail: String
  var identifier: String?
  let profilePicture: UIImage?
  var storedContact: CNMutableContact?
  var phoneNumberField: (CNLabeledValue<CNPhoneNumber>)?

  init(firstName: String, lastName: String, workEmail: String, profilePicture: UIImage?){
    self.firstName = firstName
    self.lastName = lastName
    self.workEmail = workEmail
    self.profilePicture = profilePicture
  }

  static func defaultContacts() -> [Friend] {
    return [
      Friend(firstName: "Mic", lastName: "Pringle", workEmail: "mic@example.com", profilePicture: UIImage(named: "MicProfilePicture")),
      Friend(firstName: "Ray", lastName: "Wenderlich", workEmail: "ray@example.com", profilePicture: UIImage(named: "RayProfilePicture")),
      Friend(firstName: "Sam", lastName: "Davies", workEmail: "sam@example.com", profilePicture: UIImage(named: "SamProfilePicture")),
      Friend(firstName: "Greg", lastName: "Heo", workEmail: "greg@example.com", profilePicture: UIImage(named: "GregProfilePicture"))]
  }
}

extension Friend: Equatable {
  static func ==(lhs: Friend, rhs: Friend) -> Bool{
    return lhs.firstName == rhs.firstName &&
      lhs.lastName == rhs.lastName &&
      lhs.workEmail == rhs.workEmail &&
      lhs.profilePicture == rhs.profilePicture
  }
}

extension Friend {
  var contactValue: CNContact {
    let contact = CNMutableContact()
    contact.givenName = firstName
    contact.familyName = lastName
    contact.emailAddresses = [CNLabeledValue(label: CNLabelWork, value: workEmail as NSString)]
    if let profilePicture = profilePicture {
      let imageData = profilePicture.jpegData(compressionQuality: 1)
      contact.imageData = imageData
    }
    if let phoneNumberField = phoneNumberField {
      contact.phoneNumbers.append(phoneNumberField)
    }
    return contact.copy() as! CNContact
  }

  convenience init?(contact: CNContact) {
    guard let email = contact.emailAddresses.first else { return nil }
    let firstName = contact.givenName
    let lastName = contact.familyName
    let workEmail = email.value as String
    var profilePicture: UIImage?
    if let imageData = contact.imageData {
      profilePicture = UIImage(data: imageData)
    }
    self.init(firstName: firstName, lastName: lastName, workEmail: workEmail, profilePicture: profilePicture)
    if let contactPhone = contact.phoneNumbers.first {
      phoneNumberField = contactPhone
    }
  }
}

5. FriendCell.swift

import UIKit
import Contacts

class FriendCell: UITableViewCell {
  @IBOutlet private weak var contactNameLabel: UILabel!
  @IBOutlet private weak var contactEmailLabel: UILabel!
  @IBOutlet private weak var contactImageView: UIImageView! {
    didSet {
      contactImageView.layer.masksToBounds = true
      contactImageView.layer.cornerRadius = 22.0
    }
  }

  var friend : Friend? {
    didSet {
      configureCell()
    }
  }

  private func configureCell() {
    let formatter = CNContactFormatter()
    formatter.style = .fullName
    guard let friend = friend,
      let name = formatter.string(from: friend.contactValue) else { return }
    contactNameLabel.text = name
    contactEmailLabel.text = friend.workEmail
    contactImageView.image = friend.profilePicture ?? UIImage(named: "PlaceholderProfilePic")
  }
}

后记

本篇主要讲述了Contacts和ContactsUI框架的一个简单示例，感兴趣的给个赞或者关注~~~
