1.CATransition

CATransition是CAAnimation的子类,用于过渡动画或转场动画。为视图层移入移除屏幕提供转场动画。首先来看一下简单的Demo:

 CATransition *animation = [CATransition animation];    animation.type = kCATransitionFade;    animation.subtype = kCATransitionFromRight;    animation.duration = 1.0;    // 在window上执行CATransition, 即可在ViewController转场时执行动画    [self.view.window.layer addAnimation:animation forKey:@"kTransitionAnimation"];    AViewController *vc = [[AViewController alloc] init];    [self presentViewController:vc animated:NO completion:nil];

将该动画添加到window.layer上,则会present或push时使用指定的转场动画。

其中最主要的两个属性就是type和subtype。

type:转场动画的类型。

官方SDK只提供了四种转场动画的类型,即:

CA_EXTERN NSString * const kCATransitionFade;CA_EXTERN NSString * const kCATransitionMoveIn;CA_EXTERN NSString * const kCATransitionPush;CA_EXTERN NSString * const kCATransitionReveal;

私有的type:

NSString *const kCATransitionCube = @"cube"; NSString *const kCATransitionSuckEffect = @"suckEffect"; NSString *const kCATransitionOglFlip = @"oglFlip"; NSString *const kCATransitionRippleEffect = @"rippleEffect"; NSString *const kCATransitionPageCurl = @"pageCurl"; NSString *const kCATransitionPageUnCurl = @"pageUnCurl"; NSString *const kCATransitionCameraIrisHollowOpen = @"cameraIrisHollowOpen";NSString *const kCATransitionCameraIrisHollowClose = @"cameraIrisHollowClose";

subtype:动画类型的方向

CA_EXTERN NSString * const kCATransitionFromRight;CA_EXTERN NSString * const kCATransitionFromLeft;CA_EXTERN NSString * const kCATransitionFromTop;CA_EXTERN NSString * const kCATransitionFromBottom;

上面讲的是给window.layer添加transition,这样使得在present或push时使用指定的转场动画。

既然讲到这里了,就看一下把transition加在layer上。

看一下示例代码:

- (void)viewDidLoad {    [super viewDidLoad];    UIButton *button = [[UIButton alloc] initWithFrame:CGRectMake(100, 100, 100, 50)];    [button setTitle:@"进入" forState:UIControlStateNormal];    button.backgroundColor = [UIColor redColor];    [button addTarget:self action:@selector(buttonClicked) forControlEvents:UIControlEventTouchUpInside];    [self.view addSubview:button];    _imageView = [[UIImageView alloc] initWithFrame:CGRectMake(100, 300, 150, 150)];    [self.view addSubview:_imageView];    _imageView.backgroundColor = [UIColor redColor];    _imageArray = @[[UIImage imageNamed:@"成果秀1"],[UIImage imageNamed:@"点赞他人1"],[UIImage imageNamed:@"偷师学艺1"],[UIImage imageNamed:@"学会欣赏3"]];    _imageView.image = [UIImage imageNamed:@"成果秀1"];}- (void)buttonClicked{    CATransition *animation = [CATransition animation];    animation.type = @"cube";    animation.subtype = kCATransitionFromRight;    animation.duration = 1.0;    //换图片的时候使用转场动画    [self.imageView.layer addAnimation:animation forKey:nil];    //cycle to next image    UIImage *currentImage = self.imageView.image;    NSUInteger index = [self.imageArray indexOfObject:currentImage];    index = (index + 1) % [self.imageArray count];    self.imageView.image = self.imageArray[index];}

2.transitionFromViewController

UIViewController自带的方法:

transitionFromViewController:toViewController:duration:options:animations:completion:这个转场动画是用在当一个父视图控制器中有几个childViewController,当要在这几个子视图控制器之间切换时就可以用这个方法。

AViewController *a = self.childViewControllers[0];BViewController *b = self.childViewControllers[1];CViewController *c = self.childViewControllers[2];// Curl 翻页效果// UIViewAnimationOptionTransitionCurlUp, UIViewAnimationOptionTransitionCurlDown// Flip 翻转效果// UIViewAnimationOptionTransitionFlipFromLeft, UIViewAnimationOptionTransitionFlipFromRight// UIViewAnimationOptionTransitionFlipFromTop, UIViewAnimationOptionTransitionFlipFromDown[self transitionFromViewController:_currentViewController                  toViewController:b                          duration:0.5                           options:UIViewAnimationOptionTransitionFlipFromRight                        animations:^{} completion:^(BOOL finished) {}];

3.Transition Animation

1 UINavigationControllerDelegate + UIViewControllerAnimatedTransitioning

在UINavigationController的转场动画中,要指定UINavigationControllerDelegate对象:

self.navigationController.delegate = self;[self.navigationController pushViewController:itemVC animated:YES];

UINavigationControllerDelegate主要有以下两个协议方法:

//pop- (nullable id <UIViewControllerInteractiveTransitioning>)navigationController:(UINavigationController *)navigationController                          interactionControllerForAnimationController:(id <UIViewControllerAnimatedTransitioning>) animationController NS_AVAILABLE_IOS(7_0);//push- (nullable id <UIViewControllerAnimatedTransitioning>)navigationController:(UINavigationController *)navigationController                                   animationControllerForOperation:(UINavigationControllerOperation)operation                                                fromViewController:(UIViewController *)fromVC                                                  toViewController:(UIViewController *)toVC  NS_AVAILABLE_IOS(7_0);

首先创建一个基类PDAnimatorBaseTransition实现UIViewControllerAnimatedTransitioning协议的方法。

UIViewControllerAnimatedTransitioning协议的方法有:

//动画持续时间- (NSTimeInterval)transitionDuration:(nullable id <UIViewControllerContextTransitioning>)transitionContext;//转场动画实现细节- (void)animateTransition:(id <UIViewControllerContextTransitioning>)transitionContext;动画结束时调用- (void)animationEnded:(BOOL) transitionCompleted;

PDAnimatorBaseTransition.h

#import <Foundation/Foundation.h>#import <UIKit/UIKit.h>typedef NS_ENUM(NSInteger, PDAnimationType){    animationTypePresent = 0,    animationTypeDismiss ,    animationTypePush ,    animationTypePop,};@interface PDAnimatorBaseTransition : NSObject <UIViewControllerAnimatedTransitioning>@property (nonatomic, assign)PDAnimationType animationType;@property (nonatomic, strong)UIView *containerView;@property (nonatomic, strong)UIViewController *from;@property (nonatomic, strong)UIViewController *to;@property (nonatomic, strong)UIView *fromView;@property (nonatomic, strong)UIView *toView;@property (nonatomic, weak)id <UIViewControllerContextTransitioning> transitionContext;@end

PDAnimatorBaseTransition.m

#import "PDAnimatorBaseTransition.h"@interface PDAnimatorBaseTransition() @end@implementation PDAnimatorBaseTransition#pragma mark -required- (NSTimeInterval)transitionDuration:(nullable id <UIViewControllerContextTransitioning>)transitionContext{    return 1.f;}- (void)animateTransition:(id <UIViewControllerContextTransitioning>)transitionContext{    _transitionContext = transitionContext;    _containerView = [transitionContext containerView];    _from = [transitionContext viewControllerForKey:UITransitionContextFromViewControllerKey];    _to = [transitionContext viewControllerForKey:UITransitionContextToViewControllerKey];    if([transitionContext respondsToSelector:@selector(viewForKey:)]){        _fromView = [transitionContext viewForKey:UITransitionContextFromViewKey];        _toView = [transitionContext viewForKey:UITransitionContextToViewKey];    }else{        _fromView = _from.view;        _toView = _to.view;    }    if(self.animationType == animationTypePresent){        [self animationPresent];    }else if (self.animationType == animationTypeDismiss){        [self animationDismiss];    }else if (self.animationType == animationTypePop){        [self animationPop];    }else{        [self animationPush];    }}#pragma mark -optional//动画结束时回调- (void)animationEnded:(BOOL) transitionCompleted{   }- (void)animationPresent{  }- (void)animationDismiss{}- (void)animationPop{ }- (void)animationPush{}

然后创建子类PDAnimatorPUshPopTransition继承自PDAnimatorBaseTransition,实现- (void)animationPush,- (void)animationPop方法。

PDAnimatorPUshPopTransition.h

#import "PDAnimatorBaseTransition.h"#import <UIKit/UIKit.h>@interface PDAnimatorPUshPopTransition : PDAnimatorBaseTransition@property (nonatomic, assign)CGPoint itemCenter;@property (nonatomic, assign)CGSize itemSize;@property (nonatomic, strong)NSString *imageName;@end

PDAnimatorPUshPopTransition.m

#import "PDAnimatorPUshPopTransition.h"@implementation PDAnimatorPUshPopTransition- (instancetype)init{    self = [super init];    if(self){    }    return self;}- (NSTimeInterval)transitionDuration:(nullable id <UIViewControllerContextTransitioning>)transitionContext{    return 5.f;}- (void)animateTransition:(id <UIViewControllerContextTransitioning>)transitionContext{    [super animateTransition:transitionContext];}- (void)animationPush{    NSTimeInterval duration = [self transitionDuration:self.transitionContext];    __weak typeof(self) weakSelf = self;    self.containerView.backgroundColor = [UIColor lightGrayColor];    UIImageView *imageView = [[UIImageView alloc] initWithFrame:CGRectMake(0, 0, 100, 160)];    imageView.image = [UIImage imageNamed:self.imageName];    imageView.center = _itemCenter;    CGFloat initialScale = _itemSize.width / CGRectGetWidth(imageView.frame);    CGAffineTransform transform = CGAffineTransformIdentity;    transform = CGAffineTransformScale(transform, initialScale, initialScale);    transform = CGAffineTransformRotate(transform, M_PI);    imageView.layer.affineTransform = transform; //   imageView.transform = CGAffineTransformMakeScale(initialScale, initialScale);    [self.containerView addSubview:imageView];    self.toView.frame = [self.transitionContext finalFrameForViewController:self.to];    CGPoint finalCenter = self.toView.center;    self.toView.center = finalCenter;    self.toView.alpha = 0.0;    //这一句一定要    [self.containerView addSubview:self.toView];    [UIView animateWithDuration:duration delay:0 usingSpringWithDamping:0.5 initialSpringVelocity:0 options:UIViewAnimationOptionCurveLinear animations:^{        imageView.layer.affineTransform = CGAffineTransformIdentity;        imageView.center = finalCenter;        self.fromView.alpha = 0.0;        self.containerView.backgroundColor = [UIColor redColor];    } completion:^(BOOL finished){        [imageView removeFromSuperview];        weakSelf.toView.alpha = 1.0f;        weakSelf.fromView.alpha = 1.0f;        [weakSelf.transitionContext completeTransition:![weakSelf.transitionContext transitionWasCancelled]];    }];}- (void)animationPop{    NSTimeInterval duration = [self transitionDuration:self.transitionContext];    __weak typeof(self) weakSelf = self;    self.toView.frame = [self.transitionContext finalFrameForViewController:self.to];    [self.containerView insertSubview:self.toView belowSubview:self.fromView];    self.fromView.alpha = 0.0;    self.fromView.backgroundColor = [UIColor clearColor];    [UIView animateWithDuration:duration delay:0 usingSpringWithDamping:0.5 initialSpringVelocity:0 options:UIViewAnimationOptionCurveLinear animations:^{        CGFloat initialScale = _itemSize.width / 200;        weakSelf.fromView.transform = CGAffineTransformMakeScale(initialScale, initialScale);        weakSelf.fromView.center = weakSelf.itemCenter;        weakSelf.toView.alpha = 1.0f;    } completion:^(BOOL finished){        weakSelf.fromView.alpha = 0.0f;        [weakSelf.transitionContext completeTransition:![weakSelf.transitionContext transitionWasCancelled]];    }];}@end

然后我们在需要push的地方实现UINavigationControllerDelegate的协议方法:

- (nullable id <UIViewControllerAnimatedTransitioning>)navigationController:(UINavigationController *)navigationController                                            animationControllerForOperation:(UINavigationControllerOperation)operation                                                         fromViewController:(UIViewController *)fromVC                                                           toViewController:(UIViewController *)toVC  NS_AVAILABLE_IOS(7_0){    PDAnimatorPUshPopTransition *animationTransition = [[PDAnimatorPUshPopTransition alloc] init];    if(operation == UINavigationControllerOperationPush){        animationTransition.animationType = animationTypePush;    }else if (operation == UINavigationControllerOperationPop){        animationTransition.animationType = animationTypePop;    }    NSArray *indexPaths = [self.collectionView indexPathsForSelectedItems];    if (indexPaths.count == 0) {        return nil;    }    NSIndexPath *selectedIndexPath = indexPaths[0];    UICollectionViewCell *cell = [self.collectionView cellForItemAtIndexPath:selectedIndexPath];    // 一定要加上convertPoint:toView:操作    animationTransition.itemCenter = [self.collectionView convertPoint:cell.center toView:self.view];    animationTransition.itemSize = cell.frame.size;    animationTransition.imageName = [NSString stringWithFormat:@"%ld", (long)selectedIndexPath.item];    return animationTransition;}

2UIViewControllerTransitioningDelegate+UIViewControllerAnimatedTransitioning

首先需要设置被present的Controller的transitionDelegate

DemoViewControllerTransitionPresentedViewController *presentedVC = [[DemoViewControllerTransitionPresentedViewController alloc] init];presentedVC.transitionDelegate = self;[self presentViewController:presentedVC animated:YES completion:nil];UIViewControllerTransitioningDelegate的代理的协议方法有://       prenent       - (id )animationControllerForPresentedController:(UIViewController *)presented presentingController:(UIViewController *)presenting sourceController:(UIViewController *)source;//       pop       - (id )animationControllerForDismissedController:(UIViewController *)dismissed;//       prenent       - (id )interactionControllerForPresentation:(id )animator;//       pop       - (nullable id )interactionControllerForDismissal:(id )animator;

创建子类PDAnimationPresentTransitio继承自基类PDAnimatorBaseTransition,实现- (void)animationPresent,- (void)animationDismiss方法。

PDAnimationPresentTransition.h

#import "PDAnimatorBaseTransition.h"@interface PDAnimationPresentTransition : PDAnimatorBaseTransition@end

PDAnimationPresentTransition.m

#import "PDAnimationPresentTransition.h"@implementation PDAnimationPresentTransition- (NSTimeInterval)transitionDuration:(nullable id <UIViewControllerContextTransitioning>)transitionContext{    return 1.f;}- (void)animateTransition:(id <UIViewControllerContextTransitioning>)transitionContext{    [super animateTransition:transitionContext];}- (void)animationPresent{    NSTimeInterval duration = [self transitionDuration:self.transitionContext];    __weak typeof(self) weakSelf = self;    self.toView.frame = [self.transitionContext initialFrameForViewController:self.to];    self.fromView.frame = [self.transitionContext initialFrameForViewController:self.from];    CGAffineTransform transform = CGAffineTransformIdentity;    transform = CGAffineTransformScale(transform, 0.001, 0.001);    self.toView.layer.affineTransform = transform;    [self.containerView addSubview:self.toView];    self.toView.alpha = 0.0;    [UIView animateWithDuration:duration delay:0 usingSpringWithDamping:0.6 initialSpringVelocity:0 options:UIViewAnimationOptionCurveEaseInOut animations:^{        self.toView.layer.affineTransform = CGAffineTransformIdentity;        self.toView.frame = [self.transitionContext finalFrameForViewController:self.to];        self.toView.alpha = 1.0;    } completion:^(BOOL finished){        BOOL wasCancelled = [weakSelf.transitionContext transitionWasCancelled];        [weakSelf.transitionContext completeTransition:!wasCancelled];    }];}

然后我们在需要present的地方实现UIViewControllerTransitioningDelegate的代理方法。

- (nullable id <UIViewControllerAnimatedTransitioning>)animationControllerForPresentedController:(UIViewController *)presented presentingController:(UIViewController *)presenting sourceController:(UIViewController *)source{    PDAnimationPresentTransition *animationTransition = [[PDAnimationPresentTransition alloc] init];    animationTransition.animationType = animationTypePresent;    return animationTransition;}- (nullable id <UIViewControllerAnimatedTransitioning>)animationControllerForDismissedController:(UIViewController *)dismissed{    PDAnimationPresentTransition *animationTransition = [[PDAnimationPresentTransition alloc] init];    animationTransition.animationType = animationTypePresent;    return animationTransition;}
