Android LovelyView一个组合图片和文本的view

A view that combines images and texts, allowing you to save time by developing a list item like 'images + text' follow the display order of left, center, and right.

中文

Use

Add it in your root build.gradle at the end of repositories：

allprojects {
    repositories {
        //...
        maven { url 'https://jitpack.io' }
    }
}

Add it in your app build.gradle at the end of repositories:

dependencies {
    implementation 'com.github.samlss:LovelyView:1.0'
}

View diagram

• Left：includes one ImageView and three TextViews
• center：includes one TextView
• Right：includes one ImageView and three TextViews
• Top and bottom both contain a split line (View)

Attributes description：

ImageView

attr	description
leftImage/rightImage	ImageView resources, for example: @mipmap/ic_launcher
leftImageWidth/rightImageWidth	ImageView width
leftImageHeight/rightImageHeight	ImageView's height
leftImageScaleType/rightImageScaleType	ImageView's ScaleType
leftImageMarginLeft/rightImageMarginLeft	ImageView's marginLeft distance
leftImageMarginRight/rightImageMarginRight	ImageView's marginRight distance
leftImageMarginTop/rightImageMarginTop	ImageView's marginTop distance
leftImageMarginBottom/rightImageMarginBottom	ImageView's marginBottom distance

TextView

attr	description
leftText/rightText/centerText	TextView stringId or string
leftTextSize/rightTextSize/centerTextSize	TextView's size
leftTextColor/rightTextColor/centerTextColor	TextView's color
leftTextMarginLeft/rightTextMarginLeft	TextView's marginLeft distance
leftTextMarginRight/rightTextMarginRight	TextView's marginRight distance
leftTextMarginTop/rightTextMarginTop	TextView's marginTop distance
leftTextMarginBottom/rightTextMarginBottom	TextView's marginBottom distance

More attrs

View(split line)

attr	description
topLineDisplay/bottomLineDisplay	Whether to display the line, false will be set to invisible
topLineColor/bottomLineColor	the color of split line
topLineHeight/bottomLineHeight	the height of split line
topLineMarginLeft/bottomLineMarginLeft	marginLeft distance
topLineMarginRight/bottomLineMarginRight	marginRight distance
topLineMarginTop/bottomLineMarginTop	marginTop distance
topLineMarginBottom/bottomLineMarginBottom	marginBottom distance

in layout.xml：

      <com.iigo.library.LovelyView
                android:background="@android:color/white"
                app:leftImage="@mipmap/ic_launcher"
                app:leftImageWidth="50dp"
                app:leftImageHeight="50dp"
                app:leftImageMarginLeft="10dp"
                app:leftText="Left"
                app:leftTextSize="16sp"
                app:leftTextMarginLeft="10dp"
                app:leftTextColor="@android:color/holo_orange_light"
                app:leftTopText="Left Top"
                app:leftTopTextSize="16sp"
                app:leftTopTextMarginLeft="10dp"
                app:leftTopTextColor="@android:color/holo_orange_light"
                app:leftBottomText="Left Bottom"
                app:leftBottomTextSize="16sp"
                app:leftBottomTextMarginLeft="10dp"
                app:leftBottomTextColor="@android:color/holo_orange_light"
                app:centerText="All Attr"
                app:centerTextSize="16sp"
                app:centerTextColor="@android:color/black"
                app:rightText="Right"
                app:rightTextSize="16sp"
                app:rightTextColor="@android:color/holo_blue_dark"
                app:rightTextMarginRight="10dp"
                app:rightTopText="Right Top"
                app:rightTopTextSize="16sp"
                app:rightTopTextColor="@android:color/holo_blue_dark"
                app:rightTopTextMarginRight="10dp"
                app:rightBottomText="Right Top"
                app:rightBottomTextSize="16sp"
                app:rightBottomTextColor="@android:color/holo_blue_dark"
                app:rightBottomTextMarginRight="10dp"
                app:rightImage="@mipmap/ic_launcher"
                app:rightImageWidth="50dp"
                app:rightImageHeight="50dp"
                app:rightImageMarginRight="10dp"
                android:layout_width="match_parent"
                android:layout_height="100dp"/>

in code：

        lovelyView.getRightTextView().setText("right");
        lovelyView.getRightTextView().setTextSize(20);

        lovelyView.getRightTopTextView().setText("right");
        lovelyView.getRightTopTextView().setTextSize(20);

        lovelyView.getRightBottomTextView().setText("right");
        lovelyView.getRightBottomTextView().setTextSize(20);

        lovelyView.getLeftTopTextView().setText("left top");
        lovelyView.getLeftTextView().setText("left");
        lovelyView.getLeftBottomTextView().setText("left bottom");

        lovelyView.getLeftImageView().setImageResource(R.mipmap.icon_cab);
        lovelyView.getRightImageView().setImageResource(R.mipmap.icon_cab);

        lovelyView.getCenterTextView().setText("center");
    }

• If the attribute specified in the layout.xml does not meet your requirements, you can directly using get...View() to do more.
