service mesh istio安装测试

223 阅读1分钟
原文链接: www.maogx.win

简介

istio是一个service mesh开源实现,由Google/IBM/Lyft共同开发。与之类似的还有conduit,但是功能不如istio丰富稳定。架构图如下:

istio-arch

安装

# 去下面的地址下载压缩包
# https://github.com/istio/istio/releases
wget https://github.com/istio/istio/releases/download/0.7.1/istio-0.7.1-linux.tar.gz
tar xf istio-0.7.1-linux.tar.gz

# 使用官方的安装脚本安装
curl -L https://git.io/getLatestIstio | sh -

# 安装配置环境变量
mv istio-0.7.1 /usr/local/
ln -sv /usr/local/istio-0.7.1 /usr/local/istio
echo 'export PATH=/usr/local/istio/bin:$PATH' > /etc/profile.d/istio.sh
source /etc/profile.d/istio.sh
istioctl version

# 如果环境不是云环境,不支持LoadBalancer
# 作如下修改,使得 ingress 监听在80和443端口
# 修改 Istio ingress 使用 NodePort
# 修改使用主机端口映射
# 使用此修改版本之后,每台机器只能运行单个实例
# 大概在1548-1590行左右
cp install/kubernetes/istio.yaml install/kubernetes/istio.yaml.ori
vim install/kubernetes/istio.yaml
...
################################
# Istio ingress
################################
apiVersion: v1
kind: Service
metadata:
name: istio-ingress
namespace: istio-system
labels:
istio: ingress
spec:
#type: LoadBalancer
# 使用NodePort方式
type: NodePort
ports:
- port: 80
# nodePort: 32000
name: http
- port: 443
name: https
selector:
istio: ingress
---
apiVersion: extensions/v1beta1
#kind: Deployment
# 使用DaemonSet部署方式
kind: DaemonSet
metadata:
name: istio-ingress
namespace: istio-system
spec:
#DaemonSet不支持replicas
#replicas: 1
template:
...
imagePullPolicy: IfNotPresent
ports:
- containerPort: 80
#主机80端口映射
hostPort: 80
- containerPort: 443
#主机443端口映射
hostPort: 443
...

# 以下两种选择一种安装方式
# 安装不使用认证(不使用tls)
kubectl apply -f install/kubernetes/istio.yaml

# 安装使用认证(使用tls)
kubectl apply -f install/kubernetes/istio-auth.yaml

# 查看状态
kubectl get svc -n istio-system
kubectl get pods -n istio-system

启用自动注入 sidecar

  • 不开启自动注入部署应用需要使用如下方式的命令

    kubectl apply -f <(istioctl kube-inject -f samples/bookinfo/kube/bookinfo.yaml)

  • 开启自动注入后,使用正常命令即可部署应用

    kubectl apply -f samples/bookinfo/kube/bookinfo.yaml

# k8s 1.9 版本以后才能使用
# 查看是否支持
kubectl api-versions | grep admissionregistration

# 生成所需要的证书
./install/kubernetes/webhook-create-signed-cert.sh \
--service istio-sidecar-injector \
--namespace istio-system \
--secret sidecar-injector-certs

# 创建配置configmap
kubectl apply -f install/kubernetes/istio-sidecar-injector-configmap-release.yaml

# 生成相关yaml
cat install/kubernetes/istio-sidecar-injector.yaml | \
./install/kubernetes/webhook-patch-ca-bundle.sh > \
install/kubernetes/istio-sidecar-injector-with-ca-bundle.yaml

# 安装webhook
kubectl apply -f install/kubernetes/istio-sidecar-injector-with-ca-bundle.yaml

# 查看
kubectl -n istio-system get deployment -listio=sidecar-injector
kubectl get namespace -L istio-injection

# 测试自动注入
# 创建
kubectl apply -f samples/sleep/sleep.yaml
kubectl get deployment -o wide
kubectl get pod

# 设置 default namespace 开启自动注入
kubectl label namespace default istio-injection=enabled
kubectl get namespace -L istio-injection

# 删除创建的pod,等待重建
kubectl delete pod $(kubectl get pod | grep sleep | cut -d ' ' -f 1)

# 查看重建后的pod
# 查看是否有istio-proxy容器
kubectl get pod
kubectl describe pod $(kubectl get pod | grep sleep | cut -d ' ' -f 1)

# 清理
kubectl delete -f samples/sleep/sleep.yaml

# 关闭自动注入
kubectl label namespace default istio-injection-

# 关闭部分pod的自动注入功能
...
template:
metadata:
annotations:
sidecar.istio.io/inject: "false"
...

部署官方测试用例

# 启动(未开启自动注入)
kubectl apply -f <(istioctl kube-inject -f samples/bookinfo/kube/bookinfo.yaml)

# 启动(已开启自动注入)
kubectl apply -f samples/bookinfo/kube/bookinfo.yaml

# 查看状态
kubectl get services
kubectl get pods
kubectl get ingress -o wide

访问测试

# 命令行访问测试
GATEWAY_URL=$(kubectl get po -l istio=ingress -n istio-system -o 'jsonpath={.items[0].status.hostIP}'):$(kubectl get svc istio-ingress -n istio-system -o 'jsonpath={.spec.ports[0].nodePort}')

curl -o /dev/null -s -w "%{http_code}\n" http://${GATEWAY_URL}/productpage

# 浏览器访问测试
NODE_PORT=$(kubectl get svc istio-ingress -n istio-system -o jsonpath='{.spec.ports[0].nodePort}')
NODE_IP='11.11.11.112'
echo http://${NODE_IP}:${NODE_PORT}/productpage

# 使用daemonset方式部署可以使用如下方式访问
# 11.11.11.112为其中一个node节点的ip
curl http://11.11.11.112/productpage

清理

# 清理官方用例
samples/bookinfo/kube/cleanup.sh

# 清理istio
kubectl delete -f install/kubernetes/istio.yaml
# kubectl delete -f install/kubernetes/istio-auth.yaml
