简介

在前文AbstractQueuedSynchronizer使用和源码分析中讲解了AQS的原理和实现，理解了AQS的基础上，去看CountDownLatch等Synchronizer就非常简单了。
CountDownLatch从字面上理解，CountDown是倒计时的意思，Latch是锁、门栓，那么CountDownLatch就是倒计时的门栓了:)，在开发时，我们可能会有类似下面的这种场景，有三个并发任务同时去执行，然后在下一步需要等待它们都执行完成才能继续执行，实现这个现在想想大概有几种方式，Thread.join等待线程，使用wait()notify()，Executor.invokeAll、然后对各个Future调用get等，这些都可以实现，但是有没有一种专门的工具类完成这个工作呢，有的，在JDK1.5中提供了java.util.concurrent.CountDownLatch类，用于一个或多个类等待一直到其他线程完成一系列操作。
CountDownLatch创建时设置一个count值，表示倒计时的次数，然后等待状态的线程调用CountDownLatch的await()方法（注意不要和Object.wait()混淆)进行等待，倒计时的方法是countDown(), 每次countDown都会减少count的值，直到count为0，则所有的await()的线程都会从等待中返回。

使用示例

下面使用CountDownLatch实现一个并发任务执行时间统计，为了防止一部分任务先执行，要让它们都等待一个开始指令，类似起跑抢指令，然后在最后等所有线程执行结束输出整体的执行时间。

public class CountDownTest {
    private static class ProcessJob implements Runnable {
        @Override
        public void run() {
            System.out.println("Some Job");
        }
    }
    public static void main(String[] args) throws InterruptedException {
        ExecutorService executorService = Executors.newCachedThreadPool();
        int jobSize = 20;
        CountDownLatch startLatch = new CountDownLatch(1);
        CountDownLatch stopLatch = new CountDownLatch(jobSize);
        for (int i = 0; i < jobSize; i++) {
            executorService.submit(() -> {
                try {
                    // 线程等待开始的Latch
                    startLatch.await();
                } catch (InterruptedException e) {
                    e.printStackTrace();
                }
                try {
                    new ProcessJob().run();
                } finally {
                    // 调用结束的Latch的countDown
                    stopLatch.countDown();
                }
            });
        }
        long start = System.currentTimeMillis();
        startLatch.countDown();
        // 等待所有线程执行完任务
        stopLatch.await();
        long end = System.currentTimeMillis();
        System.out.println("Total cost time: " + (end - start));
        executorService.shutdown();
        executorService.awaitTermination(1, TimeUnit.MINUTES);
    }
}

CountDownLatch源码分析

像AbstractQueuedSynchronizer使用和源码分析中提到，CountDownLatch是基于AQS实现的，CountDownLatch由于可以多个线程同时通过，所以是共享模式，那么就可以考虑用state表示count，count方法则调用compareAndSet通过CAS进行减1操作，如果到0则调用releaseShared唤醒等待线程, 通过覆盖tryAcquireShared方法，只需判断当前state是否等于0，如果不为0则等待，然后await()方法就可以调用AQS的acquireShared方法了，并且可以根据是否中断、有超时调用不同的方法。CountDownLatch同样按照标准的AQS使用方式，创建一个静态内部类实现AQS相关的acquire和release方法

public class CountDownLatch {

    private static final class Sync extends AbstractQueuedSynchronizer {
        private static final long serialVersionUID = 4982264981922014374L;
        Sync(int count) {
            setState(count);
        }
        int getCount() {
            return getState();
        }
        protected int tryAcquireShared(int acquires) {
            // 只有当当前state为0即count为0的时候能够返回
            return (getState() == 0) ? 1 : -1;
        }
        protected boolean tryReleaseShared(int releases) {
            // Decrement count; signal when transition to zero
            for (;;) {
                int c = getState();
                if (c == 0)
                    return false;
                int nextc = c-1;
                if (compareAndSetState(c, nextc))
                    // 成功CAS将count变为0的线程负责唤醒等待线程
                    return nextc == 0;
            }
        }
    }
    private final Sync sync;
    /**
     * Constructs a {@code CountDownLatch} initialized with the given count.
     *
     * @param count the number of times {@link #countDown} must be invoked
     *        before threads can pass through {@link #await}
     * @throws IllegalArgumentException if {@code count} is negative
     */
    public CountDownLatch(int count) {
        if (count < 0) throw new IllegalArgumentException("count < 0");
        this.sync = new Sync(count);
    }
    /**
     * await()调用acquireShared的不可中断的方法acquireSharedInterruptibly，acquireSharedInterruptibly又会调用到上面Sync实现的tryAcquire方法判断是否能够返回还是继续等待。
     * Causes the current thread to wait until the latch has counted down to
     * zero, unless the thread is {@linkplain Thread#interrupt interrupted}.
     *
     * If the current count is zero then this method returns immediately.
     *
     *
If the current count is greater than zero then the current
     * thread becomes disabled for thread scheduling purposes and lies
     * dormant until one of two things happen:
     *

     * The count reaches zero due to invocations of the
     * {@link #countDown} method; or
     *
Some other thread {@linkplain Thread#interrupt interrupts}
     * the current thread.
     *
     *
     * If the current thread:
     *

     * has its interrupted status set on entry to this method; or
     *
is {@linkplain Thread#interrupt interrupted} while waiting,
     *
     * then {@link InterruptedException} is thrown and the current thread's
     * interrupted status is cleared.
     *
     * @throws InterruptedException if the current thread is interrupted
     *         while waiting
     */
    public void await() throws InterruptedException {
        sync.acquireSharedInterruptibly(1);
    }
    /**
     * 这是acquire的具有超时、中断的版本
     * Causes the current thread to wait until the latch has counted down to
     * zero, unless the thread is {@linkplain Thread#interrupt interrupted},
     * or the specified waiting time elapses.
     *
     * If the current count is zero then this method returns immediately
     * with the value {@code true}.
     *
     *
If the current count is greater than zero then the current
     * thread becomes disabled for thread scheduling purposes and lies
     * dormant until one of three things happen:
     *

     * The count reaches zero due to invocations of the
     * {@link #countDown} method; or
     *
Some other thread {@linkplain Thread#interrupt interrupts}
     * the current thread; or
     *
The specified waiting time elapses.
     *
     *
     * If the count reaches zero then the method returns with the
     * value {@code true}.
     *
     *
If the current thread:
     *

     * has its interrupted status set on entry to this method; or
     *
is {@linkplain Thread#interrupt interrupted} while waiting,
     *
     * then {@link InterruptedException} is thrown and the current thread's
     * interrupted status is cleared.
     *
     * If the specified waiting time elapses then the value {@code false}
     * is returned.  If the time is less than or equal to zero, the method
     * will not wait at all.
     *
     * @param timeout the maximum time to wait
     * @param unit the time unit of the {@code timeout} argument
     * @return {@code true} if the count reached zero and {@code false}
     *         if the waiting time elapsed before the count reached zero
     * @throws InterruptedException if the current thread is interrupted
     *         while waiting
     */
    public boolean await(long timeout, TimeUnit unit)
        throws InterruptedException {
        return sync.tryAcquireSharedNanos(1, unit.toNanos(timeout));
    }
    /**
     * countDown调用sync的releaseShared方法，releaseShared方法又会调用上面Sync实现的tryReleaseShared方法根据返回结果判定是否唤醒线程
     * Decrements the count of the latch, releasing all waiting threads if
     * the count reaches zero.
     *
     *
If the current count is greater than zero then it is decremented.
     * If the new count is zero then all waiting threads are re-enabled for
     * thread scheduling purposes.
     *
     * If the current count equals zero then nothing happens.
     */
    public void countDown() {
        sync.releaseShared(1);
    }
   ...
}
