最近跟进的需求中，页面有一系列复杂视觉效果的按钮（大致效果如下所示）。
对于单一复杂的视觉效果按钮，完全可以切图来完成（雪碧图等等，放过自己为好，阿门～）。
但是鉴于这个页面这类按钮较多（宽高有细微差距）且追求较少的性能消耗，此处使用了css的方案进行实现。
主要是通过点九图的思维、叠加了遮罩和背景融合进行实现～
具体的实现思路，可以详细查看下方的描述过程:
实现带有特殊形状的轮廓
主要是通过-webkit-mask-box-image实现带有拉伸的特殊形状。
代码及效果图如下所示。
<div class="demo"></div>
.demo {
height: 104px;
background-color: #61A1AD;
webkit-mask-box-image: url("形状.svg") 30 40 fill / 30px 40px;
}
PS：此处的素材建议使用svg，图片边缘容易有锯齿形状。
实现带噪点及渐变色效果的背景填充
主要是通过background的叠加，再添加背景的混合（background-blend-mode）
/* 燥点渐变背景 */
background: url("噪点素材图.png") repeat, linear-gradient(278deg, rgba(209, 174, 113, 0.00) 16.44%, rgba(209, 174, 113, 0.25) 102.55%), linear-gradient(142deg, rgba(0, 0, 0, 0) 22%, rgba(0, 0, 0, 0.60) 77%), #61A1AD;
/* 背景混合 */
background-blend-mode: soft-light, overlay, soft-light, normal;
纹理实现
一个祥云纹理（png素材）直接用background即可；一个边框方形纹理（svg素材，避免边缘锯齿），需要做延伸用mask-box-image做。
关键代码如下:
<div class="demo">
<i class="demo-icon"></i>
</div>
.demo-icon::before {
content: "";
position: absolute;
position: absolute;
top: 0; left: -4px; bottom: 0; right: -4px;
background-color: #61A1AD;
-webkit-mask-box-image: url("形状.svg") 30 40 fill / 30px 40px;
background: linear-gradient(278deg, rgba(209, 174, 113, 0.00) 16.44%, rgba(209, 174, 113, 0.25) 102.55%), linear-gradient(142deg, rgba(0, 0, 0, 1) 22%, rgba(0, 0, 0, 1) 77%), #61A1AD;
background-blend-mode: overlay, soft-light, normal;
z-index: -1;
}
.demo-icon::after {
content: "";
position: absolute;
top: 0; left: 0; bottom: 0; right: 0;
background-image: url('祥云.png');
background-size: auto 100%;
background-position: center right;
/* 层级需要低一些 */ z-index: -2;
}
完整代码示意
1️⃣支持通过mainColor变色；
2️⃣支持通过-webkit-mask-box-image-slice调整适配不同的高度
3️⃣注意z-index
<!-- html -->
<div class="demo">
<i class="demo-icon"></i>
<p>其他按钮内容</p>
</div>
<!-- css -->
.demo {
position: relative;
height: 104px;
z-index: 4;
display: flex;
justify-content: center;
align-items: center;
}
.demo::before {
content: "";
position: absolute;
top: 0; left: 0; bottom: 0; right: 0;
margin: auto;
background-color: var(--mainColor, #61A1AD);
z-index: -4;
}
.demo::after {
content: "";
position: absolute;
top: 2px; left: 2px; bottom: 2px; right: 2px;
background: url("噪点素材图.png") repeat, linear-gradient(278deg, rgba(209, 174, 113, 0.00) 16.44%, rgba(209, 174, 113, 0.25) 102.55%), linear-gradient(142deg, rgba(0, 0, 0, 0) 22%, rgba(0, 0, 0, 0.60) 77%), var(--mainColor, #61A1AD);
background-blend-mode: soft-light, overlay, soft-light, normal;
z-index: -3;
}
.demo-icon::before {
content: "";
position: absolute;
position: absolute;
top: 0; left: -4px; bottom: 0; right: -4px;
background-color: var(--mainColor, #61A1AD);
background: linear-gradient(278deg, rgba(209, 174, 113, 0.00) 16.44%, rgba(209, 174, 113, 0.25) 102.55%), linear-gradient(142deg, rgba(0, 0, 0, 1) 22%, rgba(0, 0, 0, 1) 77%), var(--mainColor, #61A1AD);
background-blend-mode: overlay, soft-light, normal;
z-index: -1;
}
.demo-icon::after {
content: "";
position: absolute;
top: 0; left: 0; bottom: 0; right: 0;
background-image: url('祥云素材图.png');
background-size: auto 100%;
background-position: center right;
z-index: -2;
}
