Skywalking(9.7.0) 告警配置

hongweihao
99 阅读8分钟

过年前一天发版，大家高高兴兴准备回家过年去了。这时候老板说了一句，记得带上电脑，关注用户反馈。有紧急问题在高速上都得给我找个服务区改好。

但是机智如我，怎么能让老板知道服务出问题了呢？毕竟我还奢望过完年有年终奖。那正确的方式当然服务出问题了，我们开发瞒着老板偷偷给他改了，当做什么都没发生过。

平时当然Bug多点无所谓，毕竟软件嘛，有点bug也正常。但现在是决定年终的重要时刻，我们要让老板相信我们的服务是稳定的。

1. 首先你要有个Skywalking

有条件玩K8S的同学看这个：在K8S集群中部署SkyWalking-CSDN博客

没条件就本地玩玩吧：SkyWalking 本地启动以及闪退问题-CSDN博客

告警相关配置文件路径：

打开后有一些默认的规则，这些规则的作用看这个：Alerting | Apache SkyWalking

rules:
  service_resp_time_rule:
    expression: sum(service_resp_time > 1000) >= 3
    period: 10
    silence-period: 5
    message: Response time of service {name} is more than 1000ms in 3 minutes of last 10 minutes.
  service_sla_rule:
    expression: sum(service_sla < 8000) >= 2
    period: 10
    silence-period: 3
    message: Successful rate of service {name} is lower than 80% in 2 minutes of last 10 minutes
  service_resp_time_percentile_rule:
    expression: sum(service_percentile{_='0,1,2,3,4'} > 1000) >= 3
    period: 10
    silence-period: 5
    message: Percentile response time of service {name} alarm in 3 minutes of last 10 minutes, due to more than one condition of p50 > 1000, p75 > 1000, p90 > 1000, p95 > 1000, p99 > 1000
  service_instance_resp_time_rule:
    expression: sum(service_instance_resp_time > 1000) >= 2
    period: 10
    silence-period: 5
    message: Response time of service instance {name} is more than 1000ms in 2 minutes of last 10 minutes
  database_access_resp_time_rule:
    expression: sum(database_access_resp_time > 1000) >= 2
    period: 10
    message: Response time of database access {name} is more than 1000ms in 2 minutes of last 10 minutes
  endpoint_relation_resp_time_rule:
    expression: sum(endpoint_relation_resp_time > 1000) >= 2
    period: 10
    message: Response time of endpoint relation {name} is more than 1000ms in 2 minutes of last 10 minutes

2. 告警规则参数

Alerting | Apache SkyWalking

Rule name：规则名称。需要保证唯一，必须以 _rule 结尾

Expression：告警表达式。

Include names：告警规则生效包含的实体名列表。在 Skywalking中，实例有多种类型 Alerting | Apache SkyWalking

实体名称这里要注意一下，我们在集成 Agent 的时候，一般都会设置 Namespace 和 Service group。举个栗子： SW_AGENT_NAMESPACE："dev" SW_AGENT_NAME："dev::example-name" 当我这样定义时，service name 应该写成 dev::example-name|dev|，参考：Table of Agent Configuration Properties | Apache SkyWalking

Exclude names：告警规则不生效包含的实体名列表

Include names regex：和 Include names 一样。只不过是正则表达式字符串

Exclude names regex：和 Exclude names 一样。只不过是正则表达式字符串

Tags：自定义的 k-v 对

Period：表达式计算结果的缓存时间

Silence Period：推送最低间隔时间。例如我有一个规则，1分钟会触发一次，当我把Silence Period配置为 3 时。那就是每3分钟发送一次请求到 hook

Hooks：向外界发送通知的方式 ，本质上都是 WebHook。

3. 表达式解析

service_sla_custom_rule:
    # service_sla 是一个在 `alarm-config.yaml` 中默认定义的指标，当然可以覆盖它。
    # sum((service_sla / 100) < 90) 就是字面意思，服务SLA低于90% 的次数
    # >= 4 是关键，表达式每分钟算一次（这是我看了文档后猜的，应该没问题）, 那这里就表示最近4分钟服务SLA都低于90%
    expression: sum((service_sla / 100) < 90) >= 4

    # 字符串匹配写法
    include-names:
      - 'dev::example|dev|'

    # 正则写法：所有dev组的
    include-names-regex: '^dev::.*'

    # 表达式计算结果缓存时长，表达式每一分钟计算一次，我表达式中设置了>=4
    # 所以period 应该设置一个大于4的值，这样能避免重复计算
    period: 10

    # 通知静默时长，如果服务有10分钟SLA是低于90的，那么m4的时候会提醒。
    # 下一次本来是m5提醒的，我设置了2，所以等到m6再次计算表达式的时候才会在提醒
    silence-period: 2

    # 自定义 tags,key-value形式
    tags:
      level: ERROR

    # 提醒文本，可以通过格式化插入参数
    message: '服务 SLA 低于 90%'

    # 使用的通知方式，如果不填则选择默认hooks
    hooks:
      - '{hookType}.{hookName}'

4. 表达式定义实例

4.1 所有服务SLA在最近3分钟内小于100

service_success_rule:
  expression: sum((service_success / 100) < 100) >= 3
  period: 5
  silence-period: 5
  message: '服务 SLA 低于 100%'

4.2 单接口SLA在最近3分钟内小于100

endpoint_sla_rule:
  expression: sum((endpoint_sla / 100) < 100) >= 3
  include-names:
      - 'GET:/test/custom1 in dev::example|dev|'
  period: 5
  message: '此接口 SLA 低于 100%'

4.3 所有DB SLA 最近1分钟内小于100

database_access_sla_rule:
  expression: sum((database_access_sla / 100) < 100) >= 1
  period: 3
  message: 'DB SLA 低于 100%'

5. 定义配置 Hooks

实际测试下来，直接配置飞书会出现只有首次才会通知的情况。自己提供个Webhook在透传到飞书正常。猜测是Skywalking中集成飞书通知的模块有问题，这个待验证。

5.1 Webhook

Alerting | Apache SkyWalking

自定义的接口

@RestController
@RequestMapping("/alerting")
public class AlertingController {
    // 我用的是lark，用飞书得改下host
    private final static String WEBHOOK_URL = "https://open.larksuite.com/open-apis/bot/v2/hook/<token>";
    @Resource
    private RestTemplate restTemplate;
    @PostMapping("skywalking")
    public void alert(@RequestBody List<AlarmMessage> alarmMessageList) {
        alarmMessageList.parallelStream().forEach(alarmMessage -> {
            String text = "Apache SkyWalking Alarm:\n\n" +
                    alarmMessage.getScope() + ": " + alarmMessage.getName() + "\n\n" +
                    alarmMessage.getAlarmMessage();

            ImmutableMap<String, Object> body = ImmutableMap.of(
                    "msg_type", "text",
                    "content", ImmutableMap.of("text", text)
            );

            restTemplate.postForEntity(WEBHOOK_URL, body, String.class);
        });
    }
    // https://github.com/apache/skywalking/blob/master/oap-server/server-core/src/main/java/org/apache/skywalking/oap/server/core/alarm/AlarmMessage.java
    @Getter
    @Setter
    @JsonNaming(PropertyNamingStrategy.LowerCaseStrategy.class)
    public static class AlarmMessage {
        private int scopeId;
        private String scope;
        private String name;
        private String id0;
        private String id1;
        @JsonAlias("ruleName")
        private String ruleName;
        @JsonAlias("alarmMessage")
        private String alarmMessage;
        private List<Tag> tags;
        @JsonAlias("startTime")
        private long startTime;
        private transient int period;
    }
    @Getter
    @Setter
    public static class Tag {
        private String key;
        private String value;
    }
}

在 alarm-config.yaml 中配置

hooks:
  webhook:
    default:
      # 定义这是默认的hook
      is-default: true
      urls:
        - http://localhost:8080/alerting/skywalking

5.2 飞书

创建机器人很简单的，基本上有手就行。

Alerting | Apache SkyWalking

自定义机器人使用指南 - 开发指南 - 开发文档 - Lark 开放平台 (larksuite.com)

飞书群机器人通知配置

hooks:
  feishu:
    default:
      text-template: |-
        {
        "msg_type": "text",
        "content": {
          "text": "Apache SkyWalking Alarm: \n\n%s"
          }
        }
      webhooks:
        - url: https://open.larksuite.com/open-apis/bot/v2/hook/<token>
        - secret: <secret>

6. 测试告警

  1. 启动 SkyWalkingAPM


  1. 项目接入SkyWalking Agent

VM 参数加入 skywalking-agent 配置

-javaagent:E:\apache-skywalking-apm-bin\skywalking-agent\skywalking-agent.jar -Dskywalking.agent.service_name=dev::user-api -Dskywalking.agent.namespace=dev
  1. 提供接口

接口的内容是一样的，只是接口名不一样。接口根据请求的 code 参数，返回对应的 Http status。

@RestController
@Api(tags = "测试")
@RequestMapping("/test")
@Slf4j
public class TestController {
    @ApiOperation(value = "自定义")
    @GetMapping("custom")
    public ResponseEntity<Object> custom(@RequestParam Integer code) {
        return ResponseEntity.status(code).build();
    }

    @ApiOperation(value = "自定义")
    @GetMapping("custom1")
    public ResponseEntity<Object> custom1(@RequestParam Integer code) {
        return ResponseEntity.status(code).build();
    }
}
  1. 弄个Python脚本来请求接口
import requests
import time


def call_api():
    try:
        print("Calling API at:", time.strftime("%Y-%m-%d %H:%M:%S", time.localtime()))
        requests.get("http://127.0.0.1:10001/test/custom?code=500")
        requests.get("http://127.0.0.1:10001/test/custom?code=200")
        requests.get("http://127.0.0.1:10001/test/custom?code=400")
        requests.get("http://127.0.0.1:10001/test/custom1?code=500")
        requests.get("http://127.0.0.1:10001/test/custom1?code=200")
        requests.get("http://127.0.0.1:10001/test/custom1?code=400")
    except Exception:
        # 如果发生异常，你也可以在这里进行处理
        print("Error")


def main():
    while True:
        call_api()
        time.sleep(10)  # 每10s调用一次接口


if __name__ == "__main__":
    main()


  1. 整理一下告警规则，更容易触发
rules:
  endpoint_sla2_rule:
    expression: sum((endpoint_sla / 100) < 99) >= 1
    period: 1
    silence-period: 1
    message: '{name} \n\n单接口异常'
  endpoint_sla3_rule:
    expression: sum((endpoint_sla / 100) < 99) >= 1
    include-names:
      - 'GET:/test/custom in dev::user-api|dev|'
    period: 1
    silence-period: 1
    message: '{name} \n\n单接口异常include-names custom'
  endpoint_regex_rule:
    expression: sum((endpoint_sla / 100) < 99) >= 1
    include-names-regex: '.*custom.*'
    period: 1
    silence-period: 1
    message: '{name} \n\n正则匹配报警'

  endpoint_sla4_rule:
    expression: sum((endpoint_sla / 100) < 99) >= 1
    include-names:
      - 'GET:/test/custom1 in dev::user-api|dev|'
    period: 1
    silence-period: 1
    message: '{name} \n\n单接口异常include-names custom1'
  service_success_rule:
      expression: sum((service_success / 100) < 99) >= 1
      # [Optional] Default, match all services in this metrics
      include-names:
        - 'dev::user-api|dev|'
      period: 1
      message: '{name}\n\n服务 SLA 低于 99%'

hooks:
  webhook:
    default:
      is-default: true
      urls:
        - http://localhost:11005/alerting/skywalking
  1. 获取到接口参数
[
    {
        "scopeId": 3,
        "scope": "ENDPOINT",
        "name": "GET:/test/custom in dev::user-api|dev|",
        "id0": "ZGV2Ojp1c2VyLWFwaXxkZXZ8.1_R0VUOi90ZXN0L2N1c3RvbQ\u003d\u003d",
        "id1": "",
        "ruleName": "endpoint_sla2_rule",
        "alarmMessage": "GET:/test/custom in dev::user-api|dev| \\n\\n单接口异常",
        "tags": [],
        "startTime": 1709716162892,
        "hooks": [
            "webhook.default"
        ]
    },
    {
        "scopeId": 3,
        "scope": "ENDPOINT",
        "name": "GET:/test/custom1 in dev::user-api|dev|",
        "id0": "ZGV2Ojp1c2VyLWFwaXxkZXZ8.1_R0VUOi90ZXN0L2N1c3RvbTE\u003d",
        "id1": "",
        "ruleName": "endpoint_sla2_rule",
        "alarmMessage": "GET:/test/custom1 in dev::user-api|dev| \\n\\n单接口异常",
        "tags": [],
        "startTime": 1709716162892,
        "hooks": [
            "webhook.default"
        ]
    },
    {
        "scopeId": 3,
        "scope": "ENDPOINT",
        "name": "GET:/test/custom in dev::user-api|dev|",
        "id0": "ZGV2Ojp1c2VyLWFwaXxkZXZ8.1_R0VUOi90ZXN0L2N1c3RvbQ\u003d\u003d",
        "id1": "",
        "ruleName": "endpoint_sla3_rule",
        "alarmMessage": "GET:/test/custom in dev::user-api|dev| \\n\\n单接口异常include-names custom",
        "tags": [],
        "startTime": 1709716162893,
        "hooks": [
            "webhook.default"
        ]
    },
    {
        "scopeId": 3,
        "scope": "ENDPOINT",
        "name": "GET:/test/custom in dev::user-api|dev|",
        "id0": "ZGV2Ojp1c2VyLWFwaXxkZXZ8.1_R0VUOi90ZXN0L2N1c3RvbQ\u003d\u003d",
        "id1": "",
        "ruleName": "endpoint_regex_rule",
        "alarmMessage": "GET:/test/custom in dev::user-api|dev| \\n\\n正则匹配报警",
        "tags": [],
        "startTime": 1709716162893,
        "hooks": [
            "webhook.default"
        ]
    },
    {
        "scopeId": 3,
        "scope": "ENDPOINT",
        "name": "GET:/test/custom1 in dev::user-api|dev|",
        "id0": "ZGV2Ojp1c2VyLWFwaXxkZXZ8.1_R0VUOi90ZXN0L2N1c3RvbTE\u003d",
        "id1": "",
        "ruleName": "endpoint_regex_rule",
        "alarmMessage": "GET:/test/custom1 in dev::user-api|dev| \\n\\n正则匹配报警",
        "tags": [],
        "startTime": 1709716162893,
        "hooks": [
            "webhook.default"
        ]
    },
    {
        "scopeId": 3,
        "scope": "ENDPOINT",
        "name": "GET:/test/custom1 in dev::user-api|dev|",
        "id0": "ZGV2Ojp1c2VyLWFwaXxkZXZ8.1_R0VUOi90ZXN0L2N1c3RvbTE\u003d",
        "id1": "",
        "ruleName": "endpoint_sla4_rule",
        "alarmMessage": "GET:/test/custom1 in dev::user-api|dev| \\n\\n单接口异常include-names custom1",
        "tags": [],
        "startTime": 1709716162893,
        "hooks": [
            "webhook.default"
        ]
    },
    {
        "scopeId": 1,
        "scope": "SERVICE",
        "name": "dev::user-api|dev|",
        "id0": "ZGV2Ojp1c2VyLWFwaXxkZXZ8.1",
        "id1": "",
        "ruleName": "service_success_rule",
        "alarmMessage": "dev::user-api|dev|\\n\\n服务 SLA 低于 99%",
        "tags": [],
        "startTime": 1709716162893,
        "hooks": [
            "webhook.default"
        ]
    }
]


Ref

Alerting | Apache SkyWalking

skywalking.apache.org/docs/main/v…

Analysis Native Streaming Traces and Service Mesh Traffic | Apache SkyWalking

skywalking/docs/en/setup/backend/backend-alarm.md at master · apache/skywalking (github.com)

skywalking/docs/en/api/metrics-query-expression.md at master · apache/skywalking (github.com)

自定义机器人使用指南 - 开发指南 - 开发文档 - Lark 开放平台 (larksuite.com)

Table of Agent Configuration Properties | Apache SkyWalking
